Chapter 21 Implementing lists : Linked implementations

1
Chapter 21 Implementing lists Linked
implementations
2
Linked implementations

• Structure built from collection of nodes that
  reference each other.
• A node
• contains reference to a list element,
• one or more variables referencing other structure
  nodes.

3
First linked implementation

• LinkedList Each node references node containing
  next list element.

4
Class Node

• Class Node, local to LinkedList, models nodes.
• Node structure
• must know an element of the List,
• must know the next Node in sequence.
• As local class of LinkedList has no methods.

5
Class Node implementation
public class LinkedListltElementgt extends
AbstractListltElementgt private class Node
private Element element private Node
next // Create a Node containing specified
element. public Node (Element element)
this.element element this.next null
// end of class Node // end of class
LinkedList
6
LinkedList implementation
public class LinkedListltElementgt extends
AbstractListltElementgt private int
size private Node first // Create an empty
LinkedListltElementgt. public LinkedList ()
size 0 first null
7
An empty linked list
8
Linked list with three entries
9
Method to get the i-th node
/ The i-th node of this LinkedList. The
LinkedList must be non-empty. require 0 lt i
i lt this.size() / private Node getNode (int
i) Node p first int pos 0 // p is
pos-th Node while (pos ! i) p
p.next pos pos 1 return p
10
Method to get the i-th node i 2
LinkedList
size
4
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
11
Method to get the i-th node i 2
LinkedList
size
4
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
12
Method to get the i-th node i 2
LinkedList
size
4
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
13
Implementing LinkedList methods
public Element get (int index) Node p
getNode(index) return p.element

• Note method get
• uses getNode
• get(i) will take i1 steps to get the element.

14
Method remove(int)

• Given an index referencing a node to be removed
• Find previous node referencing it.
• Update that nodes next.

15
Method remove(int)

• Find previous node.

LinkedList
Element to be removed
size
4
first
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
16
Method remove(int)
LinkedList
Element to be removed
size
4
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
17
Method remove(int)
18
Method remove(int)
19
Method remove(int)
LinkedList
Element to be removed
size
4
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
20
Method remove(int)
LinkedList
Element to be removed
size
3
first
p
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
21
Method remove(int), special case

• Recall getNode requires argument gt 0.
• If index is 0, its not legal to write
• Node p getNode(index-1)
• Special case index 0 removes first linked
  element.
• instance variable first of LinkedList must be
  modified.

22
Method remove(int)
LinkedList
size
4
node to be removed
first
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
23
Method remove(int)
LinkedList
size
4
node to be removed
first
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
copy
24
Method remove(int)
node to be removed
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
25
Method remove(int)
node to be removed
Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
26
Implementation of remove(int)
public void remove (int index) if (index
0) first first.next else Node p
getNode(index-1) p.next p.next.next size
size - 1
27
Method add (int, Element)

• To add an element at the i-th position
• must find the element with index i-1
• special case to consider when i is 0.

28
Method add(int, Element)

• Add an element at index 2.
• Must find previous node.

29
Method add(int, Element)
30
Method add(int, Element)

• New node next is ps next

31
Method add(int, Element)

• p node next is new node

Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
32
Method add(int, Element)

• LinkedList size is incremented.

Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
33
Method add(int, Element)

• add at index 0

Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
34
Method add(int, Element)

• add at index 0

Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
35
Method add(int, Element)

• add at index 0

Node
Node
Node
Node
next
next
next
next
element
element
element
element
É
É
É
É
36
Method add (int, Element)

• public void add (int index, Element element)
• Node newNode new Node(element)
• if (index 0)
• newNode.next first
• first newNode
• else
• Node p getNode(index-1)
• newNode.next p.next
• p.next newNode
• size size 1

37
Linked list variations

• Adding a reference to last node makes adding to
  end of list constant.

38
LinkedList adding a last reference

• Creates special cases in other methods. For
  instance, remove

public void remove (int index) if (size 1)
// remove only element first null last
null else if (index 0) //remove first
element first first.next else Node p
getNode(index-1) p.next p.next.next
if (index size-1) //last element removed
last p size size - 1
39
Header nodes

• dummy node
• Always present at front of list,
• contains no element,
• first always references header node,
• first is never null.
• Reduces special cases in the implementation of
  some methods.

40
Header nodes
41
Circular lists

• Last node references the first.

42
Doubly-linked lists
43
Doubly-linked list constructor

• Assuming Header extends Node DoublyLinkedList
  constructor creates header Node, and links it to
  itself.

public DoublyLinkedList () size 0 header
new Header() header.next header header.previ
ous header
44
Doubly-linked list constructor
45
Doubly-linked lists add(Element)
Header
A
B
C
New
46
Doubly-linked lists add(Element)

• new node previous is node C

Header
A
B
C
New
47
Doubly-linked lists add(Element)

• new node next is header

Header
A
B
C
New
48
Doubly-linked lists add(Element)

• Header previous is new node

Header
A
B
C
New
49
Doubly-linked lists add(Element)

• C node next is new node

Header
A
B
C
New
50
Doubly-linked lists remove(1)
51
Doubly-linked lists remove(1)
Header
A
B
C
52
Doubly-linked lists remove(1)
Header
A
B
C
53
Linked Lists limitations

• Element access by index is linear.
• Would not use a linked implementation if primary
  operation is to access randomly by index.
• Method get uses getNode requires i steps to get
  Node with index i.

54
Linked Lists limitations indexOf(Element)

• indexOf uses method get.
• If element not found, get executes n times, with
  index values 0 through n-1
• value of i 0 1 2 n-1
• steps of get(i) 0 1 2 n-1
• Steps require 0 1 2 (n-1) (n2-n)/2.
• Method is quadratic.

55
Re-implementation of indexOf
public int indexOf (Element element) Node p
first int pos 0 while (p ! null
!element.equals(p.element)) p p.next pos
pos1 if (p null) return
-1 else return pos

• Method is linear.
• But uses private members of the class LinkedList.

56
Dynamic memory allocation

• Recall memory space for method variables
  parameters and local variables is allocated
  when the method is invoked, and reclaimed
  (deallocated) when the method completes.
• This is called automatic allocation and
  deallocation.
• Space for an objects instance variables is
  allocated when the object is created. This is
  sometimes called dynamic allocation.

57
Dynamic memory allocation

• In an array-based list implementation, memory
  space for the array elements is allocated when
  the array is created.
• In a linked implementation, space required for a
  node is allocated when the node is created, i.e.
  when an item is added to the list.
• But when is this space deallocated?

58
Dynamic memory allocation

• The Java run-time system implements a facility
  called garbage collection.
• Dynamically allocated space that can no longer be
  accessed is termed garbage.
• If we create an object and then lose all
  references to the object, the memory space
  occupied by the object becomes garbage.
• The run-time system continuously looks for
  garbage and reclaims the space collects the
  garbage.

59
Dynamic memory allocation

• Many programming languages do not include garbage
  collection as part of their run-time systems.
• These languages require programs to explicitly
  deallocate dynamically allocated space.
• Problem difficult to know when an object is no
  longer accessible and can be safely deallocated.
• Subtle errors
• Memory leaks garbage not being recognized and
  reclaimed
• Dangling reference space still accessible being
  mistakenly reclaimed as garbage.
