Logic Programming March 27, 2012Tom Lever

1
Logic ProgrammingMarch 27, 2012 Tom Lever
2
What is Logic Programming?

• Roots in automatic theorem proving
• Describe the problem, not the solution
• Let the computer decide how to solve it
• Describe problem in language native to the field
• Write declarative sentences in a dialect of FOL
• Computer follows simple rules to analyze
• Correct description ? correct solution (?!)

3
What is PROLOG?

• PROgramming en LOGique
• Early 1970s work on natural language processing
• Alain Colmerauer Montreal and Marseille
• Robert Kowalski Imperial College, London
• David H D Warren University of Edinburgh
• Warren Abstract Machine (WAM) interpreted code
• Declarations are in the form of Horn clauses (see
  section 17.3 of our textbook - clauses in CNF
  with at most one positive literal in each
  disjunction)

4
What do declarations look like?

• Material conditionals (implications) facing left
  (?)
• Literal - Literal Literal Literal
• Each literal takes the form of Predicate(arguments
  )
• Each declaration has the form Head - Body.
• A declaration with only a Head is a Fact
• owns(max,pris).
• A declaration without a head is a Query
• ? owns(max,Who).
• A complete declaration is a Rule
• ownsCat(Who, Pet) - owns(Who, Pet), animal(Pet,
  cat).

5
Basic Housekeeping

• Predicates and constants begin with lower-case
• Variables begin with upper-case
• A comma between predicates means AND
• Variables are instantiated with values when a
  predicate is examined (executes)
• Predicates in the same declaration are examined
  left to right.
• Facts and rules are preloaded from files.

6
Fact an assertion or premise

• owns(max, carl).
• owns(max, pris).
• owns(claire, scruffy).
• owns(claire, folly).
• animal(carl, dog).
• animal(scruffy, cat).
• animal(folly, dog).
• animal(pris, cat).

7
Query interactive way to access data

• Queries continue executing until the entire
  database has been examined. Continue after
  pauses with Tab or terminate with Enter.
• ? owns(max, folly).
• ? owns(Who, folly).
• ? owns(Who, Pet).
• ? animal(Pet, dog).
• ? ownsCat(Person, Pet).
• ? owns(Person, Pet), animal(Pet, What).

8
Definite Programs and Goals

• Definite program a set of definite clauses
  (facts rules)
• Definite goal a query consisting of atomic
  formulas as subgoals which must each be satisfied
• Query analogous to relational database query,
  posing an existential question whether all
  subgoals can be satisfied
• Rules containing variables imply universal
  quantification
• Rules defined recursively can give a model
  infinite depth
• PROLOG code specifies what exists but not how
  to find the solution

9
Backtracking? animal(Pet, _), owns(Person,
Pet).

• When a predicate succeeds, it instantiates its
  variables and control passes to the right
• The rightmost predicate pauses after it succeeds,
  then continues where it left off
• When the rightmost predicate fails, control
  passes back to its predecessor
• If it succeeds again, it re-instantiates its
  variables and control passes to the right again
• The rightmost predicate starts from the top

10
Unification

• The process of matching up references and
  definitions of predicates (argument passing)
• Sophisticated pattern matching to instantiate
  variables in two directions. For example
• T p( X, f(a,b), g(Z,F))
• U p(t(e), W, g(3,C))
• Combining these changes both to this
• T U p(t(e), f(a,b), g(3,C)
• where only variable C (or F) remains
  uninstantiated

11
Recursion

• Used in list processing (similar to LISP)
• Defining something in terms of itself
• Must define a stop condition
• append(, List, List).
• append(HeadTail, List, HeadNewTail) -
  append(Tail, List, NewTail).
• Sample uses
• ? append(a,b,c, d,e,f, What).
• ? append(First, Second, mary, anne, john).

12
Quicksort Pseudocode

• function quicksort('array')
• if length('array') 1
• return 'array' // 0 or 1 elements
  already sorted
• select and remove a pivot value 'pivot'
  from 'array'
• create empty lists 'less' and 'greater'
• for each 'x' in 'array'
• if 'x' 'pivot' then append 'x' to
  'less'
• else append 'x' to 'greater'
• return concatenate(quicksort('less'),
  'pivot',
• quicksort('greater')) //
  two recursive calls

13
Quicksort in PROLOG

• partition(, _, , ).
• partition(XXs, Pivot, Smalls, Bigs) -
• ( X _at_lt Pivot -gt
• Smalls XRest,
• partition(Xs, Pivot, Rest, Bigs)
• Bigs XRest,
• partition(Xs, Pivot, Smalls, Rest)
• ).
• quicksort() --gt .
• quicksort(XXs) --gt
• partition(Xs, X, Smaller, Bigger) ,
• quicksort(Smaller), X, quicksort(Bigger).

14
Applications

• Natural language processing
• Artificial intelligence
• Theorem proving
• Ontologies (information frameworks)
• Expert systems
• Automated answering systems
• Control systems
• Games

15
References

• Bharath, R. An Introduction to PROLOG, Tab Books
  1986
• Saint-Dizier, P. An Introduction to Programming
  in PROLOG, Springer-Verlag, 1990
• http//www.learnprolognow.org/ - a free online
  introductory course to PROLOG, with links to free
  downloadable implementations
• http//en.wikipedia.org/wiki/Prolog - overview
  with abundant links leading in many directions
• http//www.cs.bham.ac.uk/pjh/prolog_course/sem223
  _se.html - Logic Programming with Prolog An
  Introduction for Software Engineers - course
  overview
