Title: Software analysis and design tools T120B029 2012 pavasario sem.


1
Software analysis and design tools T120B029 2012
pavasario sem.
2
Instructor Eduardas Bareiša, Professor
Department of Software Engineering Studentu
50-406 Office Hours Monday 800 - 1000, Friday
800 - 1000 Lectures Hours Thursday 1000 -
1145 Labs Hours Thursday 1415 - 1915
phone 370 37 300361 email
edas_at_soften.ktu.lt www. soften.ktu.lt/edas/t120b0
29
T120B029
3
Textbooks
  • Craig Larman, Applying UML and Patterns An
    Introduction to Object-Oriented Analysis and
    Design and the Unified Process ,2/e (ISBN
    0130925691)
  • Ian Sommerville, Software Engineering 6th Edition

T120B029
4
LINKS
  • http//www.dotnetcoders.com/web/learning/uml/defau
    lt.aspx
  • http//www.johndeacon.net/UML/UML_Appendix/Generat
    ed/UML_Appendix.asp
  • http//www.cs.queensu.ca/Software-Engineering/tool
    cat.html

T120B029
5
Software Lifecycle Activities
T120B029
6
Products of Requirements Process
T120B029
7
Modeling with UML
T120B029
8
Why model software?
  • Software is already an abstraction why model
    software?
  • Software is getting larger, not smaller
  • NT 5.0 40 million lines of code
  • A single programmer cannot manage this amount of
    code in its entirety.
  • Code is often not directly understandable by
    developers who did not participate in the
    development
  • We need simpler representations for complex
    systems
  • Modeling is a mean for dealing with complexity

T120B029
9
Application and Solution Domain
  • Application Domain (Requirements Analysis)
  • The environment in which the system is operating
  • Solution Domain (System Design, Object Design)
  • The available technologies to build the system

T120B029
10
What is UML?
  • UML (Unified Modeling Language)
  • An emerging standard for modeling object-oriented
    software.
  • Resulted from the convergence of notations from
    three leading object-oriented methods
  • OMT (James Rumbaugh)
  • OOSE (Ivar Jacobson)
  • Booch (Grady Booch)
  • Supported by several CASE tools
  • Rational ROSE
  • Microsoft Visio
  • ...

T120B029
11
UML and This Course
  • You can model 80 of most problems by using about
    20 UML
  • In this course, we teach you those 20

T120B029
12
UML First Pass
  • Use case diagrams
  • Describe the functional behavior of the system as
    seen by the user.
  • Class diagrams
  • Describe the static structure of the system
    Objects, Attributes, and Associations.
  • Sequence diagrams
  • Describe the dynamic behavior between actors and
    the system and between objects of the system.
  • Statechart diagrams
  • Describe the dynamic behavior of an individual
    object as a finite state machine.
  • Activity diagrams
  • Model the dynamic behavior of a system, in
    particular the workflow, i.e. a flowchart.

T120B029
13
UML First Pass Class Diagrams
Class
Multiplicity
Association
SimpleWatch
1
1
1
1
1
1
2
2
Battery load()
Time now()
PushButton state push() release()
LCDDisplay
blinkIdx blinkSeconds() blinkMinutes() blinkHours(
) stopBlinking() referesh()
Attributes
Operations
Class diagrams represent the structure of the
system
T120B029
14
Concepts In Software Type and Instance
  • Type
  • An abstraction in the context of programming
    languages
  • Name int, Purpose integral number, Members 0,
    -1, 1, 2, -2, . . .
  • Instance
  • Member of a specific type
  • The type of a variable represents all possible
    instances the variable can take.
  • Abstract data type
  • Special type whose implementation is hidden from
    the rest of the system.

T120B029
15
Classes
Name
Signature
Attributes
Operations
  • A class represent a concept.
  • A class encapsulates state (attributes) and
    behavior (operations).
  • Each attribute has a type.
  • Each operation has a signature.
  • The class name is the only mandatory information.

T120B029
16
Instances
tariff_1974TarifSchedule
zone2price 1, .20, 2, .40, 3, .60
  • An instance represents a phenomenon.
  • The name of an instance is underlined and can
    contain the class of the instance.
  • The attributes are represented with their values.

T120B029
17
Associations
TarifSchedule
Enumeration getZones() Price getPrice(Zone)

  • Associations denote relationships between
    classes.
  • The multiplicity of an association end denotes
    how many objects the source object can
    legitimately reference.
  • Associations should be named (added by Hartrum)

T120B029
18
1-to-1 and 1-to-Many Associations
1-to-1 association
1-to-many association
T120B029
19
Qualification
  • The qualifier improves the information about the
    multiplicity of the association between the
    classes.
  • It is used for reducing 1-to-many multiplicity to
    1-1 multiplicity

Without qualification A directory has many
files. A file belongs only to one directory.
With qualification A directory has many files,
each with a unique name
T120B029
20
Aggregation
  • An aggregation is a special case of association
    denoting a consists of hierarchy.
  • The aggregate is the parent class, the components
    are the children class.

1
0..2
T120B029
21
Composition
  • A solid diamond denote composition, a strong form
    of aggregation where components cannot exist
    without the aggregate.

T120B029
22
Generalization
  • Generalization relationships denote inheritance
    between classes.
  • The children classes inherit the attributes and
    operations of the parent class.
  • Generalization simplifies the model by
    eliminating redundancy.

T120B029
23
Object Types
  • Entity Objects
  • Represent the persistent information tracked by
    the system (Application domain objects, Business
    objects)
  • Boundary Objects
  • Represent the interaction between the user and
    the system
  • Control Objects
  • Represent the control tasks performed by the
    system
  • Having three types of objects leads to models
    that are more resilient to change.
  • The boundary of a system changes more likely than
    the control
  • The control of the system change more likely than
    the application domain
  • Object types originated in Smalltalk
  • Model, View, Controller (MV)

T120B029
24
Example 2BWatch Objects
  • UML provides several mechanisms to extend the
    language
  • UML provides the stereotype mechanism to present
    new modeling elements

T120B029
25
Finding Participating Objects in Use Cases
  • For any use case do the following
  • Find terms that developers or users need to
    clarify in order to understand the flow of events
  • Always start with the users terms, then
    negotiate
  • FieldOfficerStationBoundary or FieldOfficerStation
    ?
  • IncidentBoundary or IncidentForm?
  • EOPControl or EOP?
  • Identify real world entities that the system
    needs to keep track of. Examples FieldOfficer,
    Dispatcher, Resource
  • Identify real world procedures that the system
    needs to keep track of. Example
    EmergencyOperationsPlan
  • Identify data sources or sinks. Example Printer
  • Identify interface artifacts. Example
    PoliceStation
  • Do textual analysis to find additional objects
    (Use Abotts technique)
  • Model the flow of events with a sequence diagram

T120B029
26
UML First Pass Sequence Diagram
Object
Message
Activation
Sequence diagrams represent the behavior as
interactions
T120B029
27
Sequence Diagram Observations
  • UML sequence diagrams represent behavior in terms
    of interactions.
  • Complement the class diagrams which represent
    structure.
  • Useful to find participating objects.
  • Time consuming to build but worth the investment.

T120B029
28
UML First Pass Statechart Diagrams
State
Initial state
Event
Transition
button12Pressed
Final state
T120B029
29
Activity Diagrams
  • An activity diagram shows flow control within a
    system
  • An activity diagram is a special case of a state
    chart diagram in which states are activities
    (functions)
  • Two types of states
  • Action state
  • Cannot be decomposed any further
  • Happens instantaneously with respect to the
    level of abstraction used in the model
  • Activity state
  • Can be decomposed further
  • The activity is modeled by another activity
    diagram

T120B029
30
Activity Diagram Modeling Decisions
T120B029
31
Activity Diagrams Modeling Concurrency
  • Synchronization of multiple activities
  • Splitting the flow of control into multiple
    threads

Synchronization
Splitting
T120B029
32
Activity Diagrams Swimlanes
  • Actions may be grouped into swimlanes to denote
    the object or subsystem that implements the
    actions.

T120B029
33
Other UML Notations
  • UML provide other notations that we will be
    introduced in subsequent lectures, as needed.
  • Implementation diagrams
  • Component diagrams
  • Deployment diagrams
  • Introduced in lecture on System Design
  • Object Constraint Language (OCL)
  • Introduced in lecture on Object Design

T120B029
34
Summary
  • UML provides a wide variety of notations for
    representing many aspects of software development
  • Powerful, but complex language
  • Can be misused to generate unreadable models
  • Can be misunderstood when using too many exotic
    features
  • We concentrate only on a few notations
  • Functional model use case diagram
  • Object model class diagram
  • Dynamic model sequence diagrams, statechart and
    activity diagrams

T120B029
35
Analysis UML Activity Diagram
T120B029
36
Requirements Analysis Document Template
  • 1. Introduction
  • 2. Current system
  • 3. Proposed system
  • 3.1 Overview
  • 3.2 Functional requirements
  • 3.3 Nonfunctional requirements
  • 3.4 Constraints (Pseudo requirements)
  • 3.5 System models
  • 3.5.1 Scenarios
  • 3.5.2 Use case model
  • 3.5.3 Object model
  • 3.5.3.1 Data dictionary
  • 3.5.3.2 Class diagrams
  • 3.5.4 Dynamic models
  • 3.5.5 User interface
  • 4. Glossary

T120B029
