Chapter 3 CNS Gross Anatomy

1
Chapter 3 CNS Gross Anatomy

• Chris Rorden
• University of South Carolina
• Norman J. Arnold School of Public Health
• Department of Communication Sciences and
  Disorders
• University of South Carolina

2
Key Objective

• To be able to identify the level of the CNS by
  recognizing the landmarks in transverse,
  horizontal, and coronal sections
• Brain, brainstem, spinal cord
• Requires practice and drill
• Use book, atlases and software
• Look for shape, size, location and proximity to
  other features.

3
Easy to spot changes

• Pyramidal Tract Changes
• Cortical Subcortical
• Ventricular Changes
• All levels including fourth ventricle and
  brainstem
• Changes in shape of brainstem and spinal cord

4
Crucial anatomy

• Horizontal and Coronal Views
• Pyramidal Tracts
• Cerebellum
• Thalamus
• Internal Capsule
• Basal Ganglia
• Putamen
• Globus Pallidus
• Caudate Nucleus

• Hippocampus
• Fornix
• Ventricles
• Corpus Callosum
• Optic tract
• Insula

5
Pyramidal tract
Corona Radiata

• Aka Corticospinal tract.
• Massive bundle of axons that contect cortex to
  spinal cord.
• Mostly voluntary motor control.
• http//library.med.utah.edu/kw/hyperbrain/syllabus
  /syllabus10.html

6
Primary Motor Cortex

• M1 is principle origin for pyramidal tract.
• Spatial organization (homunculus)

M1 movement
S1 sensation
7
Pyramidal Cells

• Neurons in layers V and VI send axons long
  distances.
• Layer V of M1 the pyramidal cells are extremely
  large. (Betz cells).
• Dendrites go into superficial layers.
• Axon travels down pyramidal tract.

8
Corona Radiata

• Near the motor cortex, we refer to the fibers of
  the pyramidal tract as being in the corona
  radiata.

9
Internal Capsule

• Near the basal ganglia, the pyramidal tract forms
  the central body (genu) of the internal capsule.

Internal capsule and neighboring basal ganglia
often injured by small strokes.
10
Peduncles
Pes Pedunculi (part of Cerebral peduncle)
A
A
P
P
11
Motor Fibers in the Pons
A
Corticospinal Tract
A
P
12
Motor Fibers in the Medulla
A
Pyramidal Tract
P
A
13
Motor Fibers in the Spinal Cord
P
Lateral Corticospinal Tract
Pyramidal Tract
A
14
CSF
Lateral Ventricles
Cerebral Aqueduct
Third Ventricle
Fourth Ventricle
15
Ventricles
16
Sections of the Brain

• Note whether views are
• Axial (Horizontal) Views
• Coronal Views
• Less need for familiarity with sagittal view
• Look for relationships and shapes of structures

17
Cerebellum

• Heavily folded appearance huge number of
  neurons.

18
Thalamus

• Difficult to see on MRI scan similar contrast
  to nearby white matter
• Major portion of diencephalon

19
Thalamus

• Sensory information is relayed to the cortex via
  the thalamus.
• Auditory, somatic, visceral, gustatory and vision
  (but not smell) each have dedicated nuclei in
  thalamus.
• Not just relaying information thalamic nuclei
  have reciprocal connections with cortex.
  Regulates level of awareness - damaged can lead
  to coma.

20
Thalamus medial, posterior to basal ganglia
Cleft for Internal Capsule
Head of Caudate Nucleus
Thalmus
Putamen
Amygdaloid Nucleus
Tail of Caudate Nucleus
Lateral View
21
Thalamus

• Not seen on the more anterior coronal slices.

22
Basal Ganglia

• Basal Ganglia (CNPutamen referred to as
  striatum)
• Caudate nucleus near lateral ventricle
• Putamen (yellow) superficial
• Globus pallidus (green) deep
• Nucleus accumbens (not shown junction of CN
  and Putamen)

Function initiating action. Involved with
parkinson disease. Also involved with motivation,
addiction.
23
Basal Ganglia

• Coronal slices

24
Papez Circuit
A

• Hippocampus, fornix and mammillary body crucial
  for long term memory.
• A difficult structure to visualize.

P
25
Hippocampus

• Hippocampus coronal view reveals folded shape.
• Fornix also visible in this view.

26
Corpus Callosum

• Massive white matter bundle that connects the two
  hemispheres

27
Corpus Callosum

• Sometimes surgically severed to treat epilepsy
• Split brain patients
• Connections mostly homotopic

28
The optic tract

• Lesions at different locations lead to different
  forms of visual field cuts.
• Important diagnostic tool to infer brain injury.

Lateral Geniculate Nucleus (Thalamus)
V1 Primary Visual Cortex
29
Visual Defects

• Field defects reveal anatomical injury
• Monocular blindness
• Monocular quadrantanopia
• Bitemporal hemianopia
• Homonymous hemianopia
• Upper quadrantanopia
• Lower quadrantanopia
• Homonymous hemianopia

30
V1

• Primary visual cortex (V1) lies in calcarine
  fissure.
• Complete damage leads to Homonymous hemianopia.
• Partial damage leads to scotomas

31
V1 retinotopic mapping

• V1 is retinotopic distorted spatial map of
  visual scene
• Fovea has massively over represented.

32
Insular Cortex

• Insula below the portions of the frontal,
  temporal, and parietal lobes

33
Insular Cortex

• Sometimes referred to as Insular Lobe
• Operculum (lids) separate the insula and the
  superficial cortex.
• Temporal Operculum(inferior bank)
• Parietal Operculum(posteriorsuperior)
• Frontal Operculum(anteriorsuperior)
