Conceptpower Modular 80 and 100kVA
THE BEST WAY TO PREDICT THE FUTURE IS TO INVENT IT
2
Unique Power Protection Concept (PPC)
6 Key-Features at a Glance

• Modularity
• Redundancy
• Scalability
• Environmentally Friendly
• Serviceability
• Manageability

3
ConceptpowerTM Modular
Modularity

• First and unique hot swappable 3phase double
  conversion (VFI) UPS modular design
• 2 possible power ranges80 and 100kVA

Welcome to the future of power protection
4
ConceptpowerTM Module
Front view 80-100kVA

• Active module includes
• Rectifier Booster
• Battery charger
• Inverter
• µProcessor control board

• Passive module includes
• Input filter
• Output filter
• Booster coils
• Static By-pass

5
ConceptpowerTM Module
Dry contacts NC/NO, D25P/Fconnection
Smart port RS232
Front view 80-100kVA
By-pass line fuses
EPO, Gen-on, Batt.temp.connector
LCD Display Panelconnector
Module Interfaceconnector
ComBus Module to Module
6
ConceptpowerTM Module
Rear view 80-100kVA
Weight of the passive module 80-100 kVA 55-60
Kg Size of the UPS module667x412x834mm (WxHxD)
Weight of the active module 80-100 kVA 55-60
Kg Size of the UPS module667x412x834mm (WxHxD)
7
ConceptpowerTM Module
Inside view 80-100kVA
µ Control board
Batt. Charger
Input LC FIlter
By-pass
Inverter
Booster
DC Cap.
Output LC Filter
8
ConceptpowerTM Modular
Power modules 80-100 kVA
Upgrade frame 300 kVA
Welcome to the future of power protection
9
ConceptpowerTM Modular
UPGRADE FRAME
Power modules 80-100kVA

• Limited up to 10 modules in parallel (gt 10
  modules on request)

• Distribution section for the max. capacity
  (300kVA)

• No single point of failure

• Space saving, 300kVA in 1.22 sqm.

10
ConceptpowerTM Modular
UPGRADE FRAME DISTRIBUTION 300KVA
Modules output disconnects
Centralized SNMP Slot (Multidrop).
RS232, PFC, EPO
DPA extension bus
Centralized MaintenanceBy-pass
11
ConceptpowerTM Modular - Scalability

• Optimized capital investment by extending your
  power protection capacity at a pace that fits
  your business on demand
• Scalable performance of the power capacity and
  runtime by simply adding independent UPS or
  battery increments

Upgrade Frame (Vertical Scalability) (floor-saving
-frame)
12
ConceptpowerTM Modular Environmentally Friendly

• Sinewave input current (THD7-9)
• Input PF0.98 in a standard versionThis
  means
• Smaller cables size and lower losses
• Smaller fuses or Circuit Breakers (no
  malfunction and false tripping)
• No separate phase compensation required
• No extra heating of transformer and generators
  oversized

No additional hardware for harmonic reduction is
required
13
ConceptpowerTM Modular Environmentally Friendly

• Highest double-conversion efficiency ESIS (Energy
  Saving Inverter Switching) up to 95 in on- line,
  double conversion mode
• Load dependent audible noise
• Wide input frequency windows (35-70Hz)
• Low weight (3x100kVA 700kg)
• Compact size (3x100kVA 1.22 sqm)

The total annual operating costs for a Newave
UPS can be gt40 less compared to those for a
previous generation
14
ConceptpowerTM Modular Environmentally Friendly
Product positioning Case 1 configuration
required 2x200kVA redundant
15
ConceptpowerTM Modular Environmentally Friendly
Product positioning Case 2 configuration
required 2x500kVA redundant
16
Battery cost saving

• Flexible Battery Management (FBM)
• Variable DC-voltage enabling the use of battery
  blocks (40-50 blocks of 12VDC)
• Wide input voltage windows (-23/15 _at_100
  load) (-30/15 _at_lt80 load)
  (-40/15 _at_lt60 load) Less need for battery
  operation
• Automatic battery test with algorithm CPU
  controlled Early warning in case of battery
  fault
• Temperature compensation Increases battery
  lifetime
• Ripple free through battery charger Longer
  battery life time

17
ConceptpowerTM Modular Serviceability

• Modular and hot-swappable design means minimizing
  service and maintenance cost and
• Reduction of MTTR, maximize your power
  protectionavailability
• Front access only
• No needs for skilled personnel on site
• No need of spares, just modules

18
ConceptpowerTM Modular Manageability

• Redundant Power Management Display advances the
  Power Protection Manageability
• Common data execution functions for parallel
  systems on redundant parallel PMDs.
• The complete parallel system may be managed by
  any one of the parallel PMDs.
• PMD consists of mimic diagram for system status,
  push buttons for single module and parallel
  system control and LCD for monitoring, event logs
  and diagnosis.

19
ConceptpowerTM Module Display
Most important information available at first
glance
20
ConceptpowerTM Modular Remote Control and
Shutdown

• Remote Signalling Panel (RSP)For Status and
  Alarm Remote Indications
• Wavemon (CD)For Automatic Server shutdownand
  Monitoring. Cross Platform shutdown available
• SNMP-card or Box for connection of UPS in Network
  Management systems

21
10 reasons for buying ConceptpowerTM Modular
1. Optimize capital investment and available
space Pay-as-you-grow solution lowers your
capital costs and increases utilization rates,
while innovative rack-based technology frees up
space previously needed for infrastructure
support. 2. Adapt to ever-changing power
requirements No need to abandon previous
investment when power density needs increase or
if physically moving your data centre. Adapt to
changing wattage requirements in your racks with
single- or multi-branch rack-mount power
distribution units. 3. Accelerate speed of
deployment Electrical and physical modularity
allows for rapid installation with minimal
engineering. 4. Lower the cost of service
contracts Simplicity of system design and
intelligent modular parts lessen the dependency
on expensive service contracts. 5. Increase
availability Specifically engineered to deliver
higher availability through proactively designed,
building block architecture and reduced MTTR
22
10 reasons for buying ConceptpowerTM Modular
6. Decrease mean-time-to-recovery (MTTR)
Compartmentalize potential failures with system
components consisting of intelligent,
maintainable modules for quick fault
recovery. 7. Plan for a power density that is
increasing and unpredictable Eliminate hot spots
in your data centre caused by higher power
densities by targeting availability where you
need it most. 8. Minimize points of failure
between the UPS and the critical load Move
redundancy closer to the load and prevent the
majority of failures that cause critical load
downtime. 9. Minimize human error Simplicity of
design and intelligent modules increase system
availability by mitigating human error the
number one cause of critical load downtime. 10.
Decrease the operating costs With efficiency up
to 95 (double conversion mode), the operating
costs for a Conceptpower modular UPS can be gt40
less compared to those for a previous generation
23
Power Protection Leader Through Innovation

• INNOVATION
• SUPPORT
• QUALITY

TO PROTECT YOUR MISSION CRITICAL APPLICATIONS
