Title: Chapter 21 The Genetic Control of Animal Development


1
(No Transcript)
2
The Differentiation of Vertebrate Immune Cells
  • In the immune system, two types of cells
    participate directly in defense against
    pathogens.
  • Plasma B cells produce and secrete
    immunoglobulins (antibodies), and killer T cell
    produce membrane-bound proteins that act as
    receptors for various substances.
  • B cell antibodies and T cell receptors bind to
    specific antigens. A cell must make many
    varieties of these proteins because there are
    many potential pathogens.

3
An Antigen-Antibody Complex
4
Structure of an Antibody Molecule
5
Human Antibody Genes
  • Two light chain loci the ? on chromosome 2 and
    ? on chromosome 22
  • One heavy chain locus on chromosome 14.
  • Each locus consists of a long array of gene
    segments.

6
Gene Segments for a Kappa Polypeptide
  1. An L?V? gene segment, encoding a leader peptide,
    which is removed later, and the N-terminal 95
    amino acids of the variable region of the kappa
    light chain. (76 gene segments in humans 40 of
    these are functional)
  2. A J? gene segment, encoding the last 13 amino
    acids of the variable region of the kappa light
    chain. (5 gene segments in humans)
  3. A C? gene segment, encoding the constant region
    of the kappa light chain. (1 gene segment in
    humans)

7
The Kappa Locus
  • During B cell development, the kappa light chain
    gene that will be expressed is assembled from one
    L?V? segment, one J? segment, and the C? segment
    by somatic recombination.
  • Segment joining is mediated by recombination
    signal sequences adjacent to each gene segment by
    a protein complex including RAG1 and RAG2
    (recombination activating gene proteins 1 and 2).

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Many Different Antibodies Can Be Produced
  • 40 L?V? segments ? 5 J? segments ? 1 C? segment
    200 kappa light chains.
  • Recombination of gene segments can create 120
    lambda light chains and 6600 different heavy
    chains.
  • Combinatorial assembly of these allows production
    of 2,112,000 different antibodies.
  • Even more antibodies are possible due to
    variation in recombination sites and
    hypermutability of the variable regions.

12
Evidence for DNA Rearrangement During Immune Cell
Differentiation
13
http//www.youtube.com/watch?vAxIMmNByqtM
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Conserved sequences in Bold
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
CsCl centrifugation of DNA over time developed by
Meselson and Stahl
27
(No Transcript)
28
We will talk about this again in a later
lecture But CsCl gradients are not the same
thing as Sucrose Gradients or Agarose Gel
Electrophoresis.
29
(No Transcript)
30
CsCl centrifugation of DNA over time
31
N15 is heavier than N14-Can be resolved in CsCl
32
pulse-chase Experiment Incubator with N15
containing medium for time,
then chase with N14 medium
Expt 1 grows Slowly Expt 2 Bacteria Grow
Faster Why?
33
Why would they do 2 different growth rates?
Experiment 1
Experiment 2
34
Fuse Results from Expt 1 and 2
Cell Divisions
35
Experiment 1 observations
Watson-Crick Model
Does Expt 1 prove hybrid formation?
36
N15 dsDNA
N15 ssDNA
Critical Experiment Hybrid Strand Separation And
CsCl centrifugation
Looks like control below
N15 ssDNA
N14 ssDNA
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Evolution?
43
(No Transcript)
44
Movie time
45
In class question (extra credit) for Quiz 4
Question 1 (0.5pts) Why does one add EtBr to
CsCl gradients for the isolation of plasmid DNA?
Question 2 (0.5pts-All or None credit) Is an 8kb
supercoiled plasmid more dense than a 3kb
supercoiled plasmid. Yes/No (circle one) Will an
8kb supercoiled plasmid have more EtBr bound to
it? Yes/No (circle one)
