Title: Approximation algorithms for geometric intersection graphs

1
Approximation algorithms for geometric
intersection graphs
2
Outline
• Definitions
• Problem description
• Techniques
• Shifting strategy

3
Definitions
• Intersection graph
• Given a set of objects on the plane
• Each object is represented by a vertex
• There is an edge between two vertices if the
corresponding objects intersect
• It can be extended to n-dimensional space
• Applications 4
• Wireless networks (frequency assignment problems)
• Map labeling

4
Map labeling
5
Definitions
• Intersection graphs (cont.)
• Examples

Geometric representation
Intersection graph
6
Definitions
• ?-approximation algorithm for optimization
problems
• Runs in polynomial time
• Approximation ratio ?
• Min Approx/OPT ?
• Max OPT/Approx ?
• PTAS Polynomial Time Approximation Scheme
• Is a class of approximation algorithms
• ? 1 e for every constant e gt 0

7
Problem description
• A unit disk graph is the intersection graph of a
set of unit disks in the plane.
• We present polynomial-time approximation schemes
(PTAS) for the maximum independent set problem
(selecting disjoint disks).
• The idea is based on a recursive subdivision of
the plane. They can be extended to intersection
graphs of other disk-like geometric objects
(such as squares or regular polygons), also in
higher dimensions.

8
Independent Set
• Maximum Independent Set for disk graphs
• Given a set S of disks on the plane, find a
subset IS of S such that for any two disks
D1,D2?IS, are disjoint
• IS is maximized.
• We are given a set of unit disks and want to
compute a maximum independent set, i.e., a subset
of the given disks such that the disks in the
subset are pairwise disjoint and their
cardinality is maximized.

9
Independent Set
10
Independent set

0 1 2 3 4
5 6 7 8
11
Independent set

0 1 2 3 4
5 6 7 8
12
Independent set

0 1 2 3 4
5 6 7 8
13
Independent set
• Can we improve the greedy algorithm?

0 1 2 3 4
5 6 7 8
14
Do we need the representation
15
What known? (Using shifting strategy)
?
• Max-Independent Set
• Unit disk graph (UDG) nO(k)
1/(1-2/k)
• Weighted disk graph (WDG) nO(k2)
1/(1-1/k)2
• Min-Vertex Cover
• UDG
nO(k2) (11/k)2
• WDG
nO(k2) 16/k
• Min-Dominating Set
• UDG
nO(k3) (11/k)2
• WDG ??
??

16
Independent set
• We start by simple intuition

0 1 2 3 4
5 6 7 8
17
Independent set
• We start by simple intuition

0 1 2 3 4
5 6 7 8
18
Independent set
• We start by simple intuition

0 1 2 3 4
5 6 7 8
K1 the squares of OPT on even lines. K2 the
squares of OPT on odd lines. OPT k1k2
19
Shifting strategy
• Ideas
• Partition the plane using vertical and horizontal
equally separated lines
• Number vertical lines from bottom to top with 0,
1,
• Given a constant k, there is a group of vertical
(horizontal) lines whose line numbers r (mod k)
and the number of disks that intersect those
lines is not larger than 1/k of total number of
disks.

20
Shifting strategy
• Example for unit disk graph k 3

0 1 2 3 4
5 6 7 8
21
Shifting strategy
• Example

22
Shifting strategy
• We can solve each strip independently.
• Let assume we can solve each strip.
• Let Ai be the value of the solution of shift i.
• Let OPT denote the optimal solution.
• Let OPTi be the disks of OPT intersecting active
lines in shift i.
• OPT OPT1 OPT2 OPTk

23
Shifting strategy
• Example

24
Shifting strategy
• For each pair of integers ( i , j ) such that
• 0 i, j lt k
• Let Di,j be the subset of disks obtained by
removing all disks that intersects a vertical
line at x i kp (p is integer)
• and horizontal line at x j kp (p is
integer)
• We left with disjoint squares of side length k
• One square can contain at most O(k2) disks.

25
Shifting strategy
• The Cardinality of the solution output is at
least
• (1 2 / k ) OPT
• Each disk intersects only one horizontal line and
• one vertical line.
• There exists a value of i such that at most OPT/k
• disks in OPT intersects vertical lines x i
kp Similarly, there is a value of j such that
at most OPT/k disks in OPT intersects horizontal
lines
• x j kp
• The set Di,j still contains an independent set of
size at most (1 2 / k ) OPT.

26
Shifting strategy
• Our algorithm computes a maximum independent set
in each Di,j the largest such set must have
cardinality at least
• (1 2 / k ) OPT
• For given e gt 0 we choose k 2/ e to obtain
• (1 e ) OPT
• The running time is DO(k2)

27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Problem description
• Min-Dominating Set for disk graphs
• Given a set S of disks on the plane, find a
subset DS of S such that for any disk D?S,
• D is either in DS, or
• D is adjacent to some disk in DS.
• DS is minimized.
• Whether MDS for disk graph has a PTAS or not is
still an open question. In my project, I first
assume it exists, and then try to find a PTAS
using existing techniques.

37
(No Transcript)
38
References
• 1 B. S. Baker, Approximation algorithms for
NP-complete Problems on Planar Graphs, J. ACM,
Vol. 41, No. 1, 1994, pp. 153-180
• 2 T. Erlebach, K. Jansen, and E. Seidel,
Polynomial-time approximation schemes for
geometric intersection graphs, Siam J. Comput.
Vol. 34, No. 6, pp. 1302-1323
• 3 Harry B. Hunt III, M. V. Marathe, V.
Radhakrishnan, S. S. Ravi, D. J. Rosenkrantz, R.
E. Stearns, NC-approximation schemes for NP- and
PSPACE-hard problems for geometric graphs, J.
Algorithms, 26 (1998), pp. 238274.
• 4 http//www.tik.ee.ethz.ch/erlebach/chorin02sl
ides.pdf
