Title: Chapter 27 Planets of the solar System


1
Chapter 27Planets of the solar System
2
The Nebular Hypothesis
  • In 1796 Laplaces hypothesis states that the sun
    and the planets condensed about the same time out
    of a rotating cloud of gas and dust.

3
The Origin of the Solar SystemFour Challenges
  • 1. Patterns of Motion
  • Planets orbit in the same direction...
  • ...in nearly the same plane...
  • ...in nearly circular orbits.
  • Most planets rotate in the same direction.
  • Most moons orbit in the same direction.
  • 2. Categorizing Planets
  • Planets are either rocky or gas-rich.

4
The Origin of the Solar SystemFour Challenges
  • 3. Asteroids and Comets
  • Most asteroids are found between Mars and
    Jupiter.
  • Most comets have highly elliptical orbits.
  • 4. Exceptions to the Rules
  • What about Plutos elliptical orbit and
    composition?
  • What about the odd rotation of Venus and Uranus?

5
Formation of the Solar System
  • The solar system is thought to have formed from a
    cloud of gas and dust in a process know as
    accretion.
  • Our Sun is thought to be a second generation
    star.
  • What does that mean?

6
Formation
  • http//observe.phy.sfasu.edu/courses/ast105/lectur
    es105/chapter06/formation_protoplanet_disk.htm
  • http//observe.phy.sfasu.edu/courses/ast105/lectur
    es105/chapter06/accretion_and_planets.htm

7
(No Transcript)
8
Interstellar Gas/Dust Cloud
9
(No Transcript)
10
(No Transcript)
11
  • During the first few million years, matter in the
    accretion disk of our protosun coalesced (joined
    into a single mass)
  • ...in the larger objects called planetesimals,
    with diameters of about 100 km.

12
(No Transcript)
13
  • We see evidence of accretion disk around other
    stars.
  • For example, b Pictoris.

14
  • Collisions of planetesimals dominated the early
    solar system
  • ...and these objects combined to form our
    planets.
  • We see evidence of early collisions in our solar
    system in the form of impact craters on the
    planets and their moons.

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Uh oh
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
  • In addition to the 8 major planets, there are at
    least 100 moons in our solar system.
  • While some of these moons are spherical, most
    look roughly like potatoes.
  • There is still minor debris left over from the
    formation of the solar system
  • asteroids and comets.

26
Section 2 Models of the Solar System
27
Early Models of the Solar System
  • 2000 years ago Aristotle suggested an
    Earth-centered or geocentric solar system.
  • Around 130 AD Ptolemy proposed changes to the
    model to account for problems with Aristotles
    model.
  • In 1543 Copernicus proposed a sun-centered or
    heliocentric model.

28
Giants of Science Tycho Brahe Johannes Kepler
  • These two scientists showed that the Universe was
    not some ideal perfection as Ptolemy proposed and
    worked towards acceptance of Copernicus
    heliocentric model
  • Tycho Brahe
  • made the most accurate observations of stars and
    planets up to that time.
  • was a flamboyant Danish nobleman who wore a
    silver nose when part of his nose was cut off in
    a duel!

Tycho Brahe (1546-1601)
29
Tycho Brahe and Uraniborg
  • He lived in a mansion/observatory on an island
    off the coast of Denmark.
  • The mansion had very sophisticated equipment (but
    no telescopes!) to help him and his assistants to
    measure the positions of stars and planets.
  • He named the mansion Uraniborg (Sky Castle).

Some of the equipment used at Uraniborg
30
Tycho Brahes Discoveries
  • As a young man he proved that comets had to be
    farther from Earth than the Moon.
  • He also proved that a star which appeared to
    brighten dramatically over a few weeks was also
    beyond the Moon.
  • Both observations showed that the heavens could
    change like the Earth.
  • He also came up with his own compromise model of
    the Universe.

Brahes compromise All the planets went around
the Sun while the Sun moved around a fixed Earth
31
Tycho Brahe Johannes Kepler
  • A few years before he died, Brahe hired Johannes
    Kepler to help in analyzing the data he had
    collected.
  • Brahe started him out on his hardest problem
    determine the orbit of Mars.
  • Mars has the largest observed retrograde motion
    and no circular orbit could be found to match
    Brahes observations.

Brahe and assistants making observations
32
Keplers Models
  • After years of work, the most accurate circle he
    could find for Mars orbit still left an error of
    8 arcminutes (about 1/4 the angular size of the
    full Moon).
  • If I had believed that we could ignore these
    eight minutes of arc, I would have patched up
    my hypothesis accordingly. But since it was not
    permissible to ignore, those eight minutes
    pointed the road to a complete reformation in
    astronomy
  •      - Kepler

Johannes Kepler (1571-1630)
33
Keplers Breakthrough
  • Keplers key discovery
  • planets do not orbit in circles but rather in
    ellipses.
  • the Sun was not at the center of the ellipse but
    rather at one focus.
  • With this breakthrough he obtained excellent
    agreement between his model and observations.

34
Properties of Ellipses
  • Each point marked by a tack is called a focus.
  • The farther apart one focus is from another the
    more eccentric the ellipse.
  • The line cutting the ellipse in half that passes
    through each focus is called a major axis. Half
    the major axis is called a semimajor axis.
  • The semimiajor axis is the average distance of
    the planet from the Sun

35
Keplers 3 Laws of Planetary Motion
  • These laws describe the observed planetary
    motions but do not describe why these motions
    occur as they do.

36
Keplers First Law of Planetary Motion
  • The orbit of each planet around the Sun is an
    ellipse with the Sun at one focus.
  • There is nothing at the other focus.
  • The average distance of the planet from the Sun
    is the semimajor axis.
  • Throws out Ptolemys perfect circular orbits.

37
Keplers Second Law of Planetary Motion
  • As a planet moves around its orbit, it sweeps out
    equal areas in equal times.
  • A planet travels faster when it is nearer the Sun
    and slower farther away
  • Throws out Ptolemys uniform motion

38
Keplers Third Law of Planetary Motion
  • The amount of time it takes a planet to orbit the
    Sun is related to the size of its orbit by
    P2(years) a3(AU)
  • 1 AU (astronomical unit) is the semimajor axis of
    the Earths orbit. Earths average distance from
    the Sun.
  • It doesnt matter how elliptical the orbit as
    long as the average distance is the same

39
Touring Our Solar System
  • A Trip Through the Solar System

40
The Inner or Terrestrial Planets
  • Mercury, Venus, Earth and Mars share certain
    characteristics
  • All are rocky bodies.
  • All have solid surfaces.
  • Except for Mercury all have at least a thin
    atmosphere
  • They are called Terrestrial planets because of
    their resemblance to Earth.

41
The Inner or Terrestrial Planets
42
Mercury - named after the speedy messenger of the
Roman gods
  • Closest planet to the sun
  • Revolution around the sun 88 Earth days
  • Rotation on its axis 59 Earth days
  • Crater-covered surface with steep cliffs
  • Almost no atmosphere
  • Temperature range
  • as high as 427 degrees C
  • as low as -170 degrees C

43
Venus - named after the Roman goddess of beauty
and love
  • Venus is the second planet from the sun and has
    an orbital period of 225 days.
  • Venus rotates very slowly, only once every 243
    days.
  • Venus and Earth are of almost the same size,
    mass, and density, but differ greatly in other
    areas.

44
Venus - named after the Roman goddess of beauty
and love
  • Second planet from the sun
  • About the same size as Earth
  • Thick, cloudy atmosphere
  • sulfuric acid
  • carbon dioxide
  • Highest temperature range of inner planets
  • as high as 480 degrees C

45
Venus - named after the Roman goddess of beauty
and love
  • Surface pressure 91 times more than Earths
  • Surface has
  • deep canyons and tall mountains
  • craters
  • vast plains
  • Revolution around the sun 224 Earth days
  • Rotation on its axis 243 Earth days

46
Venus - named after the Roman goddess of beauty
and love
  • Greenhouse effect
  • Venus atmosphere is 95 CO2.

47
Earth
  • Earth is the third planet from the sun.
  • The orbital period of Earth is 365 1/4 days.
    Earth completes one rotation on its axis every
    day.
  • Earth has one large moon.
  • Geologic records indicate that over the last 250
    million years, Earths surface has undergone many
    changes.

48
Earth
  • Third planet from the sun
  • Revolution around the sun 365 days
  • Rotation on its axis 24 hours
  • Because the axis of the Earth is tilted, this
    creates distinct seasons throughout the year

49
Earth
  • Temperature range depends on the location,
    altitude and season
  • Gravitation pull of the moon creates tide changes
    (rise and fall of the ocean levels)
  • Surface -
  • Mountains
  • Plains
  • Deserts
  • Heavy vegetation

50
Mars - named after the Roman god of war
  • Mars is the fourth planet from the sun.
  • Mars is about 50 farther from the sun than Earth
    is.
  • Its orbital period is 687 days
  • it rotates on its axis every 24 hours and 37
    minutes.
  • Marss seasons are like Earths seasons because
    the same axis.

51
Mars - named after the Roman god of war
  • Fourth planet from the sun
  • Surface
  • rocky
  • large craters
  • soil is similar to Earths soil in many ways
  • Has the largest volcano in the solar system,
    Olympus Mons.

52
Mars - named after the Roman god of war
  • Very thin CO2 atmosphere, polar caps of mostly
    frozen CO2. Since its atmosphere is thin and cold
    there is very little greenhouse effect.
  • High winds often create dust storms
  • Temperate falls well below 0 degrees C all the
    time

53
Mars - named after the Roman god of war
  • About half the size of Earth. No geological
    activity likely now. No magnetic field.
  • Evidence of massive water erosion some time in
    the past. Scientists are searching for liquid
    water now.
  • Two satellites, Phobos and Deimos
  • (possibly captured asteroids)

54
Mars - named after the Roman god of war
55
The Outer or Jovian Planets
  • Jupiter, Saturn, Uranus and Neptune share certain
    characteristics
  • All are large, gaseous bodies.
  • All have very thick atmospheres, with possibly
    liquid interiors and solid cores
  • All have rings
  • They are called Jovian planets because of their
    resemblance to Jupiter.

56
The Outer or Jovian Planets
57
Jupiter - named after the king of the Roman gods
  • Fifth planet from the sun
  • Made of mainly
  • hydrogen
  • helium
  • Temperature range -
  • very cold at the cloud tops
  • as high as 30,000 degree C at the core

58
Jupiter - named after the king of the Roman gods
  • Jupiter is the largest planet in the solar system
    and has a mass more than 300 times that of Earth.
  • The orbital period of Jupiter is almost 12 years.
    Jupiter rotates on its axis faster than any other
    planetonce every 9 h and 50 min.
  • Jupiter has at least 60 moons.
  • It also has several thin rings that are made up
    of millions of particles.

59
Jupiter - named after the king of the Roman gods
  • Atmosphere
  • hydrogen
  • helium
  • ammonia
  • methane
  • Great Red Spot
  • hurricane-like storm
  • (as much as 20,000 years old)

60
Jupiter - named after the king of the Roman gods
  • Very high atmospheric pressure
  • Giant magnetic field
  • created by the liquid metallic layer
  • called magnetosphere

61
Saturn - named after the Roman god
  • Sixth planet from the sun
  • Surrounded by rings
  • made of icy particles
  • has at least seven major rings
  • Made of mainly
  • hydrogen
  • helium

62
Saturn - named after the Roman god
  • The orbital period of Saturn is 29.5 years.
  • Saturn rotates on its axis every 10 h and 30 min.
  • Saturn is very cold and has an average cloud-top
    temperature of 176C.
  • Saturn has at least 60 moons.

63
Saturn - named after the Roman god
  • Violent atmospheric storms
  • Very cold
  • Has a large magnetic field
  • Lowest density of all the planets

64
Uranus - named after the father of Saturn in
Roman mythology
  • Seventh planet from the sun
  • Atmosphere
  • hydrogen
  • helium
  • methane
  • Temperature range
  • as low as -220 degree C at the cloud tops

65
Uranus - named after the father of Saturn in
Roman mythology
  • Extreme atmospheric pressure
  • atmosphere is 11,000 kilometers thick
  • Rotates on its axis at a 90 degree angle
  • appears laying on its side
  • Rings of methane ice surround it

66
Neptune - named after the Roman god of the sea
  • Eighth planet from the sun
  • Atmosphere
  • hydrogen
  • helium
  • methane
  • Temperature
  • as low as -220 degrees C

67
Neptune - named after the Roman god of the sea
  • Surface
  • ocean of water and liquid methane
  • rocky core
  • Five rings surround Neptune
  • made of dust particles formed from meteorites

68
Pluto - named after the Roman god of the
underworld
  • Ninth planet from the sun
  • Smallest planet
  • Least dense planet
  • Seems to be made primarily of methane ice
  • Thin atmosphere (only on the sunny side)
  • methane ice evaporated to form this

69
Pluto - named after the Roman god of the
underworld
  • Pluto may have been a satellite of Neptune that
    was displaced from its original orbit and split
    into two pieces.

Charon
Pluto
About PowerShow.com
