Title: Functional Programming


1
Functional Programming Standard ML
  • Hossein Hojjat et al.

2
By doing it mathematically, you provide a firm
foundation which will enable people to go
further. Robin Milner, Turing Award
Lecturer(1991) and the ML designer
3
Outline
  • Introduction
  • Why functional programming?
  • Some History
  • Standard ML
  • ML Syntax
  • Programming in Standard ML
  • Some Good References

4
Introduction
5
Introduction
  • We use a zillion different programming languages
  • general purpose programming  Fortran, Lisp,
    Basic, C, Pascal, C, Java, etc.
  • scripting  Visual Basic, awk, sed, perl, tcl,
    sh, csh, bash, REXX, Scheme, etc.
  • search regular expressions, browser queries,
    SQL, etc.

6
Introduction
  • display and rendering  PostScript, HTML, XML,
    VRML, etc.
  • hardware  SystemC, VHDL, Esterelle
  • theorem proving and mathematics  Mathematica,
    Maple, Matlab, NuPRL, Coq
  • others?

7
Introduction
  • ML is very different from what most of us have
    seen it is functional
  • Before considering ML, we will summarize the
    imperative languages properties

8
Introduction
9
Introduction
  • Design of imperative languages is based directly
    on the von Neumann architecture

10
Introduction
  • Programs in imperative languages rely heavily on
    modifying the values of a collection of
    variables, called the state
  • Before execution, the state has some initial
    value s
  • During execution, each command changes the state

11
Introduction
  • Example
  • In a sorting program, the state initially
    includes an array of values
  • When the program has finished, the state has been
    modified in such a way that these values are
    sorted
  • Intermediate states represent progress towards
    this goal

12
Introduction
  • The state is typically modified by assignment
    commands
  • By using control structures, one can execute
    these commands conditionally, or repeatedly,
    depending on other properties of the current state

13
Introduction
  • But

14
Introduction
  • Functional programs dont use variables - there
    is no state
  • Therefore they cannot use assignments there is
    nothing to assign to

15
Introduction
  • The idea of executing commands in sequence is
    meaningless
  • The first command can make no difference to the
    second there are not any state between them
  • They are based on Mathematical functions

16
Introduction
  • Functions can be treated in exactly the same way
    as simpler objects like integers
  • They can be passed to other functions as
    arguments and returned as results
  • Most traditional languages provide poor
    facilities in these areas

17
Introduction
  • Instead of sequencing and looping, functional
    languages use recursive functions

18
Introduction
  • Example
  • f(n)
  • 1 if n1
  • f(5n-1) if n is odd, n?1
  • f(n/4-3) if n is even
  • Question You said there are not any variables,
    but what about n?

19
Introduction
  • n is an identifier
  • In a Functional Language, the identifier bind to
    values
  • Variable is something that can be assigned a
    value
  • Functions have no side effect
  • They do not update any variables
  • It is easy to define the semantics

20
Introduction
  • Haskell is an example of a pure functional
    language.
  • Haskell is, as of 2002, the functional language
    on which the most research is being performed.
  • ML is not a pure functional language in that it
    is possible to write procedural programs (with
    assignments and side-effects)

21
Why Functional Programming?
22
Why Functional Programming?
The von Neumann bottleneck
  • Backus' famous paper encouraged much interest in
    functional languages as a means of breaking the
    von-Neumann bottleneck

23
Why Functional Programming?
  • Von Neumann bottleneck pumping single words back
    and forth between CPU and store
  • Task of a program change store in some major
    way.
  • It has kept us tied to word-at-a-time thinking
    instead of of encouraging us to think in terms of
    the larger conceptual units of the task at hand.

24
Why Functional Programming?
  • The assignment statement is the von Neumann
    bottleneck of programming languages
  • Pure functional programming languages remove
    state and assignments
  • Concurrency possible order of evaluation doesnt
    matter

25
Why Functional Programming?
26
Why Functional Programming?
  • System is referentially transparent if, in a
    fixed context, the meaning of the whole can be
    determined solely by the meaning of its parts.
  • Independent of the surrounding expression.

27
Why Functional Programming?
  • Do we have such property in imperative languages?
  • If the function has side-effects (updating a
    global variable, doing input or output), then
    f(3) f(3) may not be the same as 2 f(3).
  • The second f(3) has a different meaning than the
    rst

28
Why Functional Programming?
  • Purely declarative languages guarantee
    referential transparency
  • It makes it easier to understand how a program
    works

29
Why Functional Programming?
  • Many features of imperative languages have arisen
    by a process of abstraction from typical computer
    hardware
  • Perhaps the right approach is not to start from
    the hardware and work upwards

30
Why Functional Programming?
  • Start with programming languages as an abstract
    notation for specifying algorithms and then work
    down to the hardware. (Dijkstra 1976)

31
Why Functional Programming?
  • Makes programming into an engineering discipline
    rather than a trial-and-error process
  • The Formalism Principle Correctness should be
    confirmed by reasoning and not by experiment-
    Marjan Sirjani

32
Why Functional Programming?
  • As a matter of fact, it is unlikely that
    programmers will have the patience to perform
    such proofs the proofs are usually long and
    boring

33
  • Beware of bugs in the above code I have only
    proved it correct, not tried it. ,Donald Knuth

34
Why Functional Programming?
  • Functional Programming is an area of current
    research
  • ACM Conference on LISP and Functional Programming

35
Some History
36
Some History
  • 1940s
  • Alonzo Church and Haskell Curry developed the
    lambda calculus, a simple but powerful
    mathematical theory of functions.

37
Some History
  • Alonzo Church is a famous computer scientist
  • He had many doctoral students , such as Stephen
    C. Kleene or Alan Turing

38
Some History
  • 1960s
  • John McCarthy developed Lisp, the first
    functional language. Some influences from the
    lambda calculus, but still retained variable
    assignments.

39
Some History
  • 1978
  • John Backus publishes award winning article on
    FP, a functional language that emphasizes
    higher-order functions and calculating with
    programs.

40
Some History
  • Mid 1970s
  • Robin Milner develops ML, the first of the modern
    functional languages, which introduced type
    inference and polymorphic types.

41
Some History
  • Late 1970s - 1980s
  • David Turner develops a number of lazy functional
    languages leading up to Miranda, a commercial
    product.
  • 1988
  • A committee of prominent researchers publishes
    the first definition of Haskell, a standard lazy
    functional language.

42
Some History
  • 1999
  • The committee publishes the definition of Haskell
    98, providing a long-awaited stable version of
    the language.

43
Standard ML
44
Standard ML
  • Historically, ML stands for metalanguage
  • General-purpose functional programming language
  • Developed by Robin Milner and others in the late
    1970s at Edinburgh University

45
Standard ML
  • In 1969 Dana Scott introduced LCF, his Logic for
    Computable Functions
  • It was a core higher-order call-by-name
    functional programming language with arithmetic,
    booleans and recursion at all types
  • That lead to Milner et al's LCF system and then
    the programming language ML

46
ML Syntax
  • A program in ML, like any other language, is made
    up of various kinds of expressions.

47
ML Syntax
syntactic class syntactic variable(s) and grammar rule(s) examples
identifiers x, y a, x, y, x_y, ...
constants c ...2, 1, 0, 1, 2 (integers) 1.0, 0.001, 3.141 (reals)true, false (booleans)"hello", "", "!" (strings)"A", " " (characters)
unary operator u , not, size, ...
binary operators b , , -, gt, lt, gt, lt, , ...
expressions (terms) e x    c    u e    e1 b e2   if e then e else e     let d1...dn in e end    e (e1, ..., en) foo, 0.001, not b, 2 2,
declarations d val x e    fun y (x1t1, ..., xntn) t  e val one 1fun square(x int) int
types t int    real    bool    string    char    t1...tn-gtt int, string, int-gtint, boolint-gtbool
Adapted from Cornell lectures
48
Programming in Standard ML
  • Example A simple function declaration that
    computes the absolute value of a real number

49
Programming in Standard ML
  • The SML prompt lets you type either a term or a
    declaration that binds a variable to a term
  • Running an ML program is just evaluating a term
  • The ML evaluator takes the left-most expression
    that is not a value and reduces it to some
    simpler expression. Eventually the whole
    expression is a value and then evaluation stops
    the program is done

50
Programming in Standard ML
  • For example consider evaluating abs(2.01.0)
  • abs(2.01.0) ?
  • abs(3.0) ?
  • if 3.0 lt 0.0 then 3.0 else 3.0 ?
  • if false then 3.0 else 3.0 ?
  • 3.0

51
Programming in Standard ML
  • The let expression works by
  • Evaluating all of its bindings.
  • Those bindings are substituted into the body of
    the let  expression (the expression in between
    in...end)
  • Example
  • let val x 14 in x3 ?
  • let val x 5 in x3 ?
  • 53 ? 15

52
Programming in Standard ML
  • Rather big example

53
Programming in Standard ML
54
Some Good References
  • Functional Programming Using Standard ML Ake
    Wikstrom
  • Introduction to Functional Programming John
    Harrison
  • Introduction to Standard ML,Robert Harper
  • Cornell CS312 lectures
  • And lots more

55
Any Questions ?!
