Title: Trees


1
Chapter 5
  • Trees

2
Binary trees
  • A binary tree is a finite set of elements that is
    either empty or is partitioned into 3 disjoint
    subsets

root left subtree right subtree
3
An example of binary tree (1)
  • root A
  • node A, B, C, , H, I
  • father of B A
  • sons of B D, E
  • left son of B D
  • right son of B E
  • depth 3
  • ancestors of E A, B
  • descendants of B D, E, G

level
0
A
1
C
B
2
F
E
D
3
G
H
I
4
An example of binary tree (2)
  • left descendant of B D
  • right descendant of B E, G
  • brother B and C are brothers
  • D and E are brothers
  • leaf a node that has no sons e.g. D, G, H, I

right subtree of A
left subtree of A
B
C
D
E
F
G
H
I
5
Not binary trees
A
A
B
C
B
C
E
D
F
E
D
F
A
G
H
I
G
B
C
(a)
(b)
E
D
F
G
H
I
(c)
6
Strictly binary tree
  • Each nonleaf node has nonempty left and right
    subtrees.

A
C
B
E
D
F
G
7
Complete binary tree of depth 3
  • of nodes in a complete binary tree of depth d

A
B
C
E
D
G
F
J
I
H
K
N
M
L
O
8
Implementation of a binary tree
  • Each node has 3 fields.
  • ??? doubly linked list, ???? link,
  • ??? "father" ??? 4 ? field.

left son
information
right son
A
null C null
B
null E null
null D null
9
Linked array representation
  • define NUMNODES 500
  • struct nodetype
  • int info
  • int left
  • int right
  • int father
  • struct nodetype nodeNUMNODES

10
Dynamic node representation
  • struct nodetype
  • int info
  • struct nodetype left
  • struct nodetype right
  • struct nodetype father
  • typedef struct nodetype NODEPTR

11
Creation of a new tree
  • maketree(x) Create a new tree consisting of a
  • single node
  • NODEPTR maketree(int x)
  • NODEPTR p
  • p getnode()
  • p-gtinfo x
  • p-gtleft NULL
  • p-gtright NULL
  • return(p)
  • / end maketree /

X
12
Creation of a new son
  • setleft(p, x) create a new left son of node p
  • with information field x.
  • void setleft(NODEPTR p, int x)
  • if (p NULL)
  • printf("void insertion\n")
  • else if (p-gtleft ! NULL)
  • printf("invalid insertion\n")

p
p
x
13
An application of binary trees
  • Finding all duplicate numbers in a number series.
  • 14, 15, 4, 9, 7, 18, 3, 5, 16, 4, 20, 17, 9, 14,
    5
  • build a binary search tree
  • smaller numbers stored in the left subtree.
  • larger numbers stored in the right subtree.
  • Duplicate numbers

14
Implementation with C
  • struct nodetype
  • int info
  • struct nodetype left
  • struct nodetype right
  • typedef struct nodetype NODEPTR
  • main()
  • NODEPTR ptree
  • NODEPTR p, q
  • int number
  • scanf("d", number)
  • ptree maketree(number)

15
  • while (scanf("d", number) ! EOF)
  • p q ptree
  • while (number ! p-gtinfo q ! NULL)
  • p q
  • if (number lt p-gtinfo)
  • q p-gtleft
  • else
  • q p-gtright
  • / end while /
  • if (number p-gtinfo)
  • printf("d is a duplicate\n", number)
  • else if (number lt p-gtinfo)
  • setleft(p, number)
  • else
  • setright(p, number)
  • / end while /
  • / end main /

16
Traversals in a binary tree (1)
  • (1) preorder (depth-first order)
  • root
  • left subtree
  • right subtree
  • (2) inorder (symmetric order)
  • left subtree
  • root
  • right subtree
  • (3) postorder
  • left subtree
  • right subtree
  • root

17
Traversals in a binary tree (2)
  • preorder
  • inorder
  • postorder

18
Preorder traversal
  • void pretrav(NODEPTR tree)
  • if (tree ! NULL)
  • printf("d\n", tree-gtinfo) // visit the
    root
  • pretrav(tree-gtleft) // traverse left
    subtree
  • pretrav(tree-gtright)// traverse right
    subtree
  • / end if /
  • / end pretrav /

19
Inorder traversal
  • void intrav(NODEPTR tree)
  • if (tree ! NULL)
  • intrav(tree-gtleft) // traverse left
    subtree
  • printf("d\n", tree-gtinfo) // visit the
    root
  • intrav(tree-gtright) // traverse right
    subtree
  • / end if /
  • / end intrav /

20
Postorder traversal
  • void posttrav(NODEPTR tree)
  • if (tree ! NULL)
  • posttrav(tree-gtleft) //traverse left
    subtree
  • posttrav(tree-gtright)//traverse right
    subtree
  • printf("d\n", tree-gtinfo) // visit the
    root
  • / end if /
  • / end posttrav /

21
Binary search tree
  • 14, 15, 4, 9, 7, 18, 3, 5, 16, 4, 20, 17, 9, 14, 5

14
15
4
3
9
18
14
7
9
16
20
17
5
  • inorder traversal
  • sorted 3,4,4,5,5,7,9,9,14,14,15,16,17,18,20

4
5
22
Expressions in binary trees
  • prefix A B C
  • ( preorder traversal )
  • infix A B C
  • ( inorder traversal )
  • postfix A B C
  • ( postorder traversal )


A

C
B
23
Implicit array for an almost- complete binary
tree (1)
  • (1) Each leaf is either at level d or at level
    d-1.
  • (2) For any node n with a right descendant at
    level d, all the left descendants of node n that
    are leaves are also at level d.

A
0
2
C
B
1
3
G
F
E
D
6
5
4
J
H
I
8
9
7
0 1 2 3 4 5 6 7 8 9
A B C D E F G H I J
24
Implicit array for an almost- complete binary
tree (2)
  • An almost complete binary tree can be implemented
    by an array.
  • sons of node p
  • father of node p
  • not an almost complete binary tree

25
Extension to not almost complete binary trees
A
B
C
E
D
G
F
0 1 2 3 4 5 6 7 8 9 10 11 12
A B C D E F G
26
Nonrecursive inorder traversal
  • define MAXSTACK 100
  • void intrav2(NODEPTR tree)
  • struct stack
  • int top
  • NODEPTR itemMAXSTACK
  • s
  • NODEPTR p
  • s.top -1
  • p tree
  • do
  • /travel down left branches as far as
    possible /
  • / saving pointers to nodes passed /
  • while (p ! NULL)
  • push(s, p)
  • p p-gtleft
  • / end while /

27
  • / check if finished /
  • if (!empty(s))
  • / at this point the left subtree is empty
    /
  • p pop(s)
  • printf("d\n", p-gtinfo) / visit the root
    /
  • p p-gtright / traverse right subtree
    /
  • / end if /
  • while (!empty(s) p ! NULL)
  • / end intrav2 /
  • The recursion stack cannot be eliminated.

28
Right in-threaded binary tree
  • A node with an empty right subtree points to its
    inorder successor. It can be traversed in inorder
    without a stack.

setleft(p, x)
A
C
B

F
E
D
setright(p, x)

I
H
G
29
Implementation of a right in-threaded binary tree
  • If the array implementation is used,
  • positive pointer normal right son
  • negative pointer inorder successor
  • dynamic implementation
  • struct nodetype
  • int info
  • struct nodetype left // pointer to left son
  • struct nodetype right // pointer to right son
  • int rthread // rthread is TRUE if
  • // right is NULL or
  • // a non-NULL thread
  • typedef struct nodetype NODEPTR

30
Implementation with C (1)
  • void intrav3(NODEPTR tree) // No stack is used
  • NODEPTR p, q
  • p tree
  • do
  • q NULL
  • while (p ! NULL)
  • / traverse left branch /
  • q p
  • p p-gtleft
  • / end while /

31
Implementation with C (2)
  • if (q ! NULL)
  • printf("d\n", q-gtinfo)
  • p q-gtright
  • while (q-gtrthread p ! NULL)
  • printf("d\n", p-gtinfo)
  • q p
  • p p-gtright
  • / end while /
  • / end if /
  • while (q ! NULL)
  • / end intrav3 /

32
Heterogeneous binary trees
''
  • The binary tree represents 3 4(6-7)/5 3.

3
''
'/'
3
5
''
4
'-'
7
6
33
Evaluation of an expression represented by a
binary tree (1)
  • define OPERATOR 0
  • define OPERAND 1
  • struct nodetype
  • short int utype / OPERATOR or OPERAND /
  • union
  • char chinfo
  • float numinfo
  • info
  • struct nodetype left
  • struct nodetype right
  • typedef struct nodetype NODEPTR
  • float evalbintree(NODEPTR tree)
  • float opnd1, opnd2
  • char symb

34
Evaluation of an expression represented by a
binary tree(2)
  • if (tree-gtutype OPERAND) / expression is a
    single /
  • return (tree-gtnuminfo) / operand /
  • / tree-gtutype OPERATOR /
  • / evaluate the left subtree /
  • opnd1 evalbintree(tree-gtleft)
  • / evaluate the right subtree /
  • opnd2 evalbintree(tree-gtright)
  • symb tree-gtchinfo / extract the
    operator /
  • / apply the operator and return the result /
  • return(oper(symb, opnd1, opnd2))
  • / end evalbintree /

35
The Huffman code (1)
  • Suppose we have a set of symbols A, B, C, D
  • 1) Each symbol is encoded by 3 bits (inefficient)
  • Message A B A C C D A would be encoded by 21 bits

symbol code A 0 1 0
B 1 0 0 C 0 0 0
D 1 1 1
010 100 010 000 000 111 010
36
The Huffman code (2)
  • 2) Each symbol is encoded by 2 bits
  • Message A B A C C D A would be encoded by 14 bits

symbol code A 00
B 01 C
10 D 11
00 01 00 10 10 11 00
37
The Huffman code (3)
  • 3) Huffman codes (variable-length codes)
  • symbol code
  • A 0
  • B 110
  • C 10
  • D 111
  • Message A B A C C D A would be encoded by 13
    bits
  • 0 110 0 10 10 111 0
  • A frequently used symbol is encoded by a short
    bit string.

38
Huffman tree
39
Construction of a Huffman tree
symbol
E I A D C G B F H 25 15 15 12 7 6 6
4 1 25 15 15 12 7 6 6 5 25 15 15 12 11 7
6 25 15 15 13 12 11 25 23 15 15 13 28 25 23
15 38 28 25 53 38 91
frequency
40
Sym Freq Code Sym Freq Code Sym Freq
Code
A 15 111 D 12 011 G 6
1100 B 6 0101 E 25 10 H
1 01000 C 7 1101 F 4 01001
I 15 00
41
The result of Huffman coding
decode
  • A Huffman tree is a strictly binary tree. The
    Huffman algorithm is an optimal encoding scheme.

111 01000 10 111 011 A H E A D
encode
42
Representing lists as binary trees (1)
  • n of elements

array linked list binary tree
(balanced)
insertion or deletion (kth element)
O(1) (inserting an element following a
given element)
O(n-k)
O(log2n)
finding the kth element
O(1)
O(k)
O(log2n)
43
Representing lists as binary trees (2)
  • nonleaf node of leaves in the left subtree
  • leaf node contents of a list element

A
F
null
B
C
D
E
4
k3
Finding the kth element k3
1
2
k1
1
1
F
E
A
B
C
D
44
Representing lists as binary trees (3)
  • A complete binary tree of depth d has 2d1-1
    nodes or 2d leaf nodes.
  • If an almost complete binary tree is used to
    represent a list, the kth element can be found by
    accessing O(log2n) nodes.

45
Deleting elements in the list (1)
4
3
tree
1
1
2
2
F
E
F
E
1
1
1
D
X
A
B
C
D
A
B
X
p
(a)
(b)
46
Deleting elements in the list (2)
  • Time O(log2n)

2
1
2
F
E
1
A
B
(d)
X
(c)
47
Trees
  • root of the tree A
  • B, C, D are brothers.
  • degree of a node of sons
  • degree of A 3
  • degree of B 2
  • degree of C 0
  • degree of D 1

Fig.1
48
Ordered trees
  • ordered tree the subtrees of each node form an
    ordered set
  • Fig.1 and Fig.2 are different ordered trees.
  • In Fig.1,
  • oldest son of A B
  • youngest son of A D

Fig.1
Fig.2
49
Representation of trees
oldest son
information
next brother
A
null
B
C
D
null
null
null
E
F
null
G
null
null
null
50
Ordered tree and binary tree
  • An ordered tree can be represented as a binary
    tree.

Binary tree
ordered tree
51
Forest
  • an ordered set of ordered trees

52
Representing a forest by a binary tree
  • corresponding binary tree
  • preorder traversal
  • A B C D E F G H I J M K L
  • inorder traversal
  • B D E F C A H G M J K L I
  • postorder traversal
  • F E D C B H M L K J I G A

53



Preorder A B C D E Inorder A B C
D E PostorderA B C D E
A
B

E
C
D
(a)

why same?

A

Preorder A B C D E Inorder A B C D
E PostorderB A D C E
B

C
E
D
(b)
54
An example game trees
  • tic-tac-toe ????
  • evaluation function
  • ?????????(??) ? ?????????(??)

X O
X
O
?? X ?? O
X O
X X
O
X O
X
X O
X O
X
X O
X O
X X
O
X O X
X
O
2 3-1
2 3-1
2
2
1 3-2
55
The minimax method
  • look ahead
About PowerShow.com
