Title: THE NERVOUS SYSTEM


1
THE NERVOUS SYSTEM
  • Chapter 7

2
  • Monitors changes-__________________________--insid
    e and outside the body
  • Processes and interprets input-___________________
    _____________
  • Effects a response by activating muscles or
    glands(effector)via_______________________________
    ______

Stimuli and gathered info is sensory input
integration
Motor output
3
Organization of the Nervous System
4
  • Divided by structure and activities
  • Structural classification
  • _____________________________________-consists of
    brain and spinal cord and is integrating command
    center
  • __________________________________-part of system
    outside CNS-nerves extending beyond the brain and
    SC
  • _______________________________-carry messages to
    and from SC and
  • ______________________________-carry impulses to
    and from brain

CNS
Spinal nerves
Cranial nerves
Peripheral nervous system
5
Functional classification
  • Divides peripheral nervous sytem into 2 divisions
  • __________________or afferent division consists
    of nerves conveying info to CNS via sensory
    receptors in the body
  • __________________________-bring in impulses from
    skin,skeletal muscles and joints
  • ________________________________bring in messages
    from inside and outside the body

Visceral or sensory fibers or afferents
sensory
Somatic sensory fibers
6
effect
Somatic nervous system
Voluntary nervous sysyem
  • Motor or efferent division carry impulses from
    CNS to effector organs-muscles and glands-They
    _________a motor response
  • a)______________________allows us to
    consciously,or voluntarily control skeletal
    musces-so this sytem is also called
    ______________________________/some skeletal
    responses are initially involuntary
  • b) __________________ regulates autonomic or
    involuntary-like smooth muscle ,cardiac muscle
    and glands..commonly called _____________________
    _,which has 2 parts 1)sympathetic-opposes
    parasympathetic-associated w/ flight or fight
    2)parasympathetic division-opposes sympathetic
    and craniosacral division

Involuntary NS
Autonomic nervous system
7
Nervous TissueStructure and Function
  • Either supporting cells or neurons
  • Supporting Cells-limped together as neuroglia and
    includes cells that generally support,insulate
    and protect delicate neurons---glial cells have
    special functions

8
  • ______________________________-abundant star
    shaped cells-swollen ends that cling to
    neurons,bracing them and anchoring to nutrient
    supply________________________/They form a
    living barrier between capillaries and neurons
    and help make exchange between the 2-help protect
    neurons from harmful substances in the blood and
    also help control brain chemical environment by
    moppingup leaked K ions and recapturing
    released neurotransmitters
  • _____________________________-spider like
    phagocytes to dispose of debris-like dead brain
    cells and bacteria

astrocytes
microglia
capillaries
9
ependymal
oligiodendrocytes
  • _____________________________-glial cells that
    line the central cavities of the brain and SC
    ..beating of cilia to distribute cerebrospinal
    fluid for those cavities and provide a cushion
  • _________________________________-glia that wrap
    flat extensions tightly around nerve
    fibers-producing fatty myelin sheath(an
    insulation)
  • 2 major varieties in PNS______________________for
    m myelin sheath and ______________________________
    -positive cushioning cells

Schwann cells
Satellite cells
10
(No Transcript)
11
(No Transcript)
12
Neurons-- anatomy-all have cell body,which
contains nucleus and is metabolic center and one
or slender extending processes
  • Neurons-- anatomy-all have cell body,which
    contains nucleus and is metabolic center and one
    or slender extending processes
  • Cell Body-metabolic center
  • Transparent ________________ w/ a conspicuous
    nucleolus
  • Cytoplasm has usual organelles except centrioles
  • Rough ER is called______________________________an
    d _____________________________(intermediate
    filaments used in maintaining cell shape)

Nissal substance
nucleus
neurofibrils
13
  • Processes-or fibers- vary greatly in length from
    microscopic - 3-4 ft.Our longest reach from
    lumbar to large toe
  • ________________________-convey incoming
    messages(electrical signals) towards cell
    body-may be many of these for one nerve cell
  • _____________________- carry messages AWAY from
    cell body-only 1 axon,but branch much 2 end
    w/hundreds of axon _____________________________.-
    they contain 100s of tiny vesicles,or
    membranous sacs w/___________________________chemi
    cals-released into extracellular space

Axon terminals
axons
dendrites
neurotransmitters
14
  • _____________________________tiny gap that
    separates axon terminal from next neuron(synapse)
  • _____________________________-whitish ,fatty
    material w/waxy appearance.It functions by
    insulating or protecting fibers and Increases
    transmission rate

Myelin sheath
Synaptic cleft
15
  • Axons outside CNS are myelinated by
    ____________________________,which is gradually
    squeezed tightly enclosing axon
  • External to Schwann cell is neurilemma-

Schwann cells
16
(No Transcript)
17
  • Gaps between Schwann cells are called
    __________________________
  • Myelinated fibers also in CNS as
    ___________________________-around small segment
    of 1 nerve fiber-coiling around as many as 60
    fibers at one timeSince they lack neurilemma
    that contributes to non regeneration property

Nodes of Ranvier
oligodendrites
18
  • __________________________________is a
    neurological disorder causing visual or speech
    problems as wel as increasingle degenerating
    muscle This is all due to an autoimmune response
    that destroys a protein in the myelin and cause
    nerves to short ciruit----Interferon is used

Multiple sclerosis
19
Terminology-
nuclei
ganglia
  • -
  • cell bodies in CNS are usually called
    ______________--carrying out metabolic
    functions/not regenerated
  • __________________small collections of cell
    bodies outside CNS-in PNS
  • ________________________ are bundles of nerve
    fibers running through CNS
  • _____________________________________ are bundles
    of nerve fibers running through PNS
  • _________________________-collections of
    myelinated fibers in CNS
  • ________________________CNS unmyelinated fibers

nerves
tracts
Gray matter
White matter
20
Classification
Sensory or afferent
  • Functionally groups neurons according to
    direction of nerve transmission relative to
    CNSif carrying impulse from receptor to
    CNS-____________________________neurons-found in
    a ganglion outside CNSdendrite endings of
    sensory neurons are usually associated with
    specialized recptors activated by specific nearby
    changes-cutaneous sense organs and________________
    _____________in muscle and tendons

proprioreceptors
21
  • _________________(efferent)neurons carry
    impulses from CNS to visceraan/or muscles or
    glands-cell bodies in CNS
  • ________________________or association neurons
    connect motor and sensory neurons in neural
    pathways-cell bodies always in CNS
  • Structurally based on of processes extending
    from cell body---if several______________________
    ______-inc. all motor and association
    neurons/__________________neurons have 2
    processes-rare in adults/_____________________neur
    ons have single process sensory neurons in PNS

motor
interneurons
multipolarneuron
bipolar
Unipolar neurons
22
6-Physiology
23
  • NERVE INPULSESNeurons have 2 major
    properties-_______________________________________
    ____
  • __________________________refers to inactive or
    resting plasma membrane(fewer ions on inner
    face(Kions)-outside are Na ions if the inside
    is more - ,it is inactive

Irritability and conductivity
polarized
24
depolarization
Action potential
repolarization
  • Action Potential and generationmany different
    stimuli excite neuronseg.light,sound,pressure-mos
    t excited by neurotransmitters released by other
    neurons.changes permeability of membrane changes
    briefly-gates of Na channels open---changing
    polarity-_________________________-inside now
    more --graded potential
  • If this strong enough it initiates
    an_________________________(nerve impulse)-all-or
    none response
  • An outflow now of K ions will restore resting
    state-__________________________________

25
  • UNTIL REPOLARIZATION HAPPENSltA NEURON CANNOT
    CARRY ANOTHER IMPULSE !
  • NA-K pump uses ATP
  • The above describes unmyelinated impulses
    Myeinated sheaths conducts impulses
    faster-__________________________________-leaps
    from node to node
  • Conductivity can be impaired by sedatives and
    anesthetics by altering permeability

Salatory conduction
26
  • Synapse Transmission-impulse does not traverse-
    synapse neurotransmitter do and they cause Na
    entry ,depolarization,etc.-brief
    transmission-electrochemical

27
  • Reflexes-rapid and predictable and involuntary
    response to stimuli
  • Somatic reflexes-stimulate skeletal muscles
  • _____________________regulate smooth
    muscles,heart and glands

Autonomic reflexes
28
  • _____________________________is a neural pathway
    and has at least 5 elements______________________
    __________________________________________________
    ____________________________

Sensory receptor,effector organ,sensory or motor
neurons and synapse-CNS integration center
Relex arcs
29
(No Transcript)
30
III. CNS
gyri
sulci
  • Functional Anatomy of the Brain
  • Brain is 3 lbs.
  • 4 regions-cerebral,diencephalons,brain
    stem,cerebellum
  • Cerebral hemispheres
  • Paired
  • Largest and most superior
  • ____________-elevated regions of tissue separated
    by shallow _______
  • ______________________are less numerous grooves
    and separate larger regions of brain

fissures
31
Longitudinal fissure
  • ______________-separates 2 hemispheres by deep
    fissure
  • Other fissures or sulci divide into lobes,named
    for corresponding cranial bone
  • 3 basic regions to ea hemisphere_________________
    ______

Superficial cortex of gray matter,internal white
matter,and basal ganglia(Gray)
32
Cerebral Cortex-includes speech,memory,logical
and emotional response, consciousness ,
interpretation of sensation,and voluntary movement
  • ________________________-posterior to central
    sulcus-primary somatic sensory area-interprets
    impulses traveling from body sensory
    receptors(except for special senses)/allows you
    to perceive pain,coldness or light touch.as
    shown in 7-14,p.245body is represented in an
    upside down manner in sensory area-such a spatial
    map is a ___________________-crossed
    pathways-left primary somatic sensory area
    receives impulse from right and vice verse

Primary somatic sensory area in parietal lobe
Sensory homunculus
33
(No Transcript)
34
(No Transcript)
35
  • __________________________visual area in
    posterior
  • ___________________________has auditory area and
    has olafactory area
  • _________________________is primary motor
    area/the axons of these motor neurons make
    ________-major voluntary motor tract and it
    descends to cord-pathways again crossed
  • _________is map on motor cortex

Temporal lobe
Occipital lobe
Corticospinal or pyramidal tract
Motor homunculus
Frontal lobe
36
  • ______________________at base of precentral
    gyrus-involved in speech-usually only in left
    hemisphere-damage here can cause inability to say
    words properly
  • In anterior frontal lobes is believed to be
    intellectual reasoning and socially acceptable
    behavior region
  • The main _____________________is located at
    junction of temporal,parietal,and occipital
    lobes-usually only in 1 hemisphere also
  • __________________is involved w/word meanings
  • Cell bodies of neurons involved in cerebral
    hemisphere are in outermost gray matter

Speech area
Brocas area
Frontal lobes
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
Cerebral White Matter-deeper,remaining
cerebrum-composed of fiber tracts carrying
impulses to and from or within cortex
  • __________________________________-large fiber
    tract that connects cerebral hemispheres(an
    example of a commisure)-allows hemispheres to
    communicate with each other.Association fiber
    tracts connects areas w/in hemisphere and
    projection fiber tract connects cerebrum

Corpus callosum
41
(No Transcript)
42
(No Transcript)
43
  • _______________________________-islands of gray
    matter buried in white matter of cerebral
    hemispheres-help regulate voluntary motor
    activities by modifying instructions-esp.
    starting or stopping
  • basal ganglia

Basal nuclei
44
(No Transcript)
45
  • ______________________________- genetic disease,
    middle-age and leads to massive degeneration of
    basal nuclei and then cerebral cortex-includes
    jerky movements and an eventual vegetative state
    w/in 15 years fatal-overdrive in motor
    stimulation
  • ______________-has basal nuclei problems-strikes
    in 50s-60s and comes from a degeneration of
    dopamine releasing neurons-dopamine deprived
    basal nuclei become overactive-tremors,head
    nodding etc.

Huntingtons disease or Chorea
Parkinsons disease
46
Diencephalon-interbrain-atop brain stem and
enclosed by cerebral hemispheres
  • ____________________________-encloses shallow 3rd
    ventricle of brain and is relay station for
    sensory impulses passing upward to sensory
    cortex-interpret sensation
  • ____________________________________-is under the
    thalamus makes up floor of diencephalons-helps
    regulate body temp.,water balance
    and,metabolism-also centers for many drives and
    emotions-part of ___________________________-emot
    ional visceral brain-thirst,appetite and sex
    drive

Thalamus
hypothalamus
Limbic System
47
  • Contains pituitary gland and mammillary bodies
    that is involved in olafaction

48
  • ___________________-roof of 3rd
    ventricle/contains ____________________-an
    endocrine organ,choroid plexus-form cerebrospinal
    fluid

Pineal body
epithalamus
49
(No Transcript)
50
____________________________________-about the
size of a thumb in diameter and about 3
longincludes midbrain,pons and medulla
oblongata/provides a pathway for ascending and
descending tracts and has small gray matter areas
  • 1)____________________________-small/_____________
    _______________________ travels through midbrain
    and anteriorly midbrain has cerebral peduncles
    that convey ascending and descending
    impulses/dorsally are 4 rounded corpora
    quadrigemina-reflex centers for vision and hearing

midbrain
Brain stem
Cerebral aqueduct
51
  • 2)___________________----rounded just below
    midbrain and has bridge of fiber tracts and
    involves in control of breathing
  • 3)___________________________-most inferior part
    and merges into SCfiber tract area and helps
    regulate visceral activity

pons
Medulla oblongata
52
(No Transcript)
53
Cerebellum-dorsally under occipital lobe and
has 2 hemispheres-has outer cortex of gray matter
and inner cortex of white matter
  • Provides timing factor for skeletal and controls
    muscle activity
  • ________________________-cerebellum damage
    causing clumsiness and disorganization

ataxia
54
(No Transcript)
55
(No Transcript)
56
Protection of CNS
  • A.__________-3 connective tissue membranes
    protecting CNS
  • 1)______________________-outermost layer and
    leathery(tough or hard mother),double layered
    where surrounds brain

Dura mater
meninges
57
(No Transcript)
58
  • _____________________-attached to inner surface
    of skull
  • ___________________-Outermost covering of brain
    and continues as dura mater of spinal cord
  • Dural layers fused except in 3 areas where they
    separate to enclose dural venous sinuses that
    collect _________________________.

Periosteal layer
Meningeal layer
Venous blood
59
Inner dural membrane extends inward to form a
fold that attaches brain to cranial cavity
60
______________________________-middle meningeal
layer,weblikespans subarachnoid space to attach
TO innermost membrane.
Arachnoid mater
61
  • 3)_____________________________-innermost
    membrane(gentle mother)-clings tightly to
    surface of brain and spinal cord,following every
    fold
  • Subarachnoid space is filled w/ cerebrospinal
    fluid and ______________________________protrude
    through dura mater
  • Cerebrospinal fluid is absorbed into venous blood
    in dural sinuses through arachnoid villi

Projections of arachnoid membrane called
arachnoid villi
Pia mater
62
(No Transcript)
63
encephalitis
  • ______________________________-inflammation of
    meninges,serious threat to brain(bacterial or
    viral) because may spread to the nervous tissue
    of the CNS/spinal diagnostic taps derived from
    subarachnoid space
  • ___________________________-brain inflammation

meningitis
64
Cerebrospinal Fluid(CSF)-somewhat watery and
similar to blood plasma,but contains less protein
and more vitamin C and a different ion
composition
  • CSF continually formed from blood by choroids
    plexus(clusters of capillaries hanging from roof
    of each of brains ventricles)
  • Forms a watery cushion to protect fragile nervous
    tissue
  • Continually moves in brain,circulating from 2
    _________________________into 3rd ventricle and
    then through cerebral aquaduct of midbrain into
    4th ventricle.some of this continues down SC,but
    most circulates into subarachnoid space

Lateral ventricles
65
(No Transcript)
66
  • CSF returns to blood in dural venous sinuses
    through _____________________________
  • Normal means CSF forms and drains at a constant
    rate maintaining about ½ cup fluid.Any
    significant changes-like blood cells or general
    composition may mean ____________________
  • Test w/ lumbar puncture
  • ________________________________--if drainage of
    CSF is obstructed-maybe by tumor or born that way

Sign of miningitisor certain brain pathologies
such as tumor or MS
Arachnoid villi
hydrocephalis
67
(No Transcript)
68
Blood-Brain Barrier
  • Brain is very sensitive to pressure and chemical
    changes
  • Thus,the least permeable capillaries in
    bodyalmost seamlessly bound by tight junctions
    all around-passing only water ,glucose and amino
    acids pass easily throughpreventing
    _________________________
  • Barrier useless against __________________________
    __(thus explains entrance of alcohol,nicotine and
    anesthetics

Preventing urea, toxins,proteins and many drugs
from entering
Fats,respiratory gases and other fat-soluble
molecules
69
(No Transcript)
70
Brain Dysfunctions
  • _______________________________-progressive
    degenerative disease of brain resulting,eventually
    , in dementiaassociated w/shortage of Ach and
    structural changes in braingyri shrink and brain
    atrophies
  • _______________________-minor and not permanent
    brain damage
  • __________________________-marked tissue
    destruction-severe forms always result in comas

concussion
Alzheimers disorder
contusion
71
  • ____________________________-after a blow to the
    head-bleed from ruptured vessels
  • ________________________-swelling of brain from
    inflammatory response to injury
  • ______________________________-3rd leading cause
    of death in US-when blood circulation is blocked
    and vital tissue dies
  • ____________________one sided paralysis
  • _________________damage to left cerebrum and
    affects speech
  • __________________-temporary restriction of blood
    flow

Cerebral edema
Cerebrovascular accidents-CVA-ie.stroke
Intracranial hemorrhage
hemiplegia
aphasias
Transient ischemic attack -TIA
72
SPINAL CORD-cylindrical and appx.17
long,glistening white2 way conduction pathway to
and from brain and reflex center
  • Extends from foramen magnum to ___________________
    ______________,ending below the ribs(thus L3 good
    for spinal tap)
  • Protected by CSF and meningeal coverings
  • 31 prs spinal nerves-arise from cord and exit
    from vertebral column to serve nearby area of
    body
  • ____________________collection of spinal nerves
    at end of vertebral canal

Cauda equina
1st or 2nd lumbar vertebra
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
A)Gray matter of SC and spinal roots
  • Looks like butterfly in crosssection
  • Contains dorsal horns(has interneurons) ,ventral
    horns(contain cell bodies of motor
    somaticvoluntary nervous sytem and surrounds
    central canal of SC ,containing CSF)
  • Cell bodies of sensory neurons enter cord by
    dorsal root and are called _______________________
    ____________-If severed ,sensation at that point
    is lost
  • Ventral horn sends its axons out
    ______________________
  • Dorsal and ventral roots fuse to form
    ________________________________
  • ____________________________-damage to ventral
    root/affecting muscles servedmuscles will
    atrophy

Flaccid paralysis
Spinal nerves
Dorsal root ganglion
Ventral root of cord
77
(No Transcript)
78
B-White matter of SC
  • Myelinated fiber tracts-serving higher
    centers,some travel brain to SC and some
    innervate one or the other side of the SC
  • Dorsal,lateral and ventral columns-3 regions of
    white matter
  • Tracts conducting Sensory impulse to brain by
    _________________or afferent tracts
  • Motor(efferent tracts) carry from
    __________________________________
  • __________________________________-if SC is cut
    crosswise or crushed-afferent stay intact and
    involuntary movement of those muscles results and
    sensation loss below cut-compare quadriplegic to
    paraplegic

Marieb, E. N. (2009). Essentials of Human Anatomy
and Physiology (9th ed.). San Francisco,
California Pearsonincludes images
Brain to skeletal muscles
sensory
About PowerShow.com
