A Framework for Empirical Evaluation of Model Comprehensibility

1
AFrameworkforEmpirical EvaluationofModel
Comprehensibility

• Jorge Aranda, Neil Ernst, Jennifer Horkoff,
  Steve Easterbrook
• University of Toronto
• MiSE 2007, Minneapolis, MN

2
IMAGINE DILBERT STRIP HERE
3
If there are so manymodeling languages...

• Static modeling languages
• Dynamic modeling languages
• Intentional modeling languages
• Argumentation modeling languages
• Belief modeling languages
• Meta-modeling languages
• Unified modeling languages
• ...

4
...why does nobody use them?

• OK, nobody is too strong
• But from what I see, when faced with real
  projects...
• my colleagues do not use them
• my professors do not use them
• my tutored students do not use them
• unless I force them to
• most small software houses I know of do not use
  them
• 86 in a soon-to-appear field study of small
  software companies
• most big software corporations I know of do not
  use them
• Figure appears to range from 10-25 depending on
  the survey
• Highest usage number (50) of use case and class
  diagrams by companies contacted through the OMG
• Dilbert does not seem to use them either
• There is a community that, though they may not
  use them, they certainly talk about them

5
Why does nobody use my modeling language?
stuff?
6
Possibility 1Kial neniu uzi Esperanto?

• Esperanto for why does nobody use Esperanto?
• I think...
• Reason Unnecessary invention
• English is universal enough
• Klingon is geekier
• Only useful in Esperanto conventions!
• Remedy?
• Mostly hopeless

7
Possibility 2Why does nobody use my typewriter?

• Looks complicated
• Not intuitive
• Im used to handwriting
• Reason Complexity and unfamiliarity
• At first sight it doesnt seem to be worth the
  effort
• But all it takes is to see an expert doing
  wonders with it for us to want to learn as well
• Remedy?
• Training and publicity

8
Possibility 3Why does nobody use my bicycle?

• Very uncomfortable!
• Nicknamed bone breaker
• Painful landings
• Inappropriate roads
• Reason Needs refinement
• Evolution
• Trial and error
• Context (roads) evolves along with artifact
  (bike)
• Remedy?
• Evaluation and refinement

9
So which is it?

• Why does nobody use my modeling language?
• Useless proposal?
• Certainly true in some cases
• (but not for any of the members of this
  distinguished audience!)
• Lack of training?
• Less true than wed like it to be
• Our favourite excuse
• Software developers dont know what theyre
  doing
• This is why were going through a software
  crisis
• Adapt the user approach
• Or often blame the user...
• Needs refinement?
• Adapt the tool approach
• Evaluate, identify, eliminate weaknesses
• True of almost every proposal

10
Why would we use models?

• Exploration and reflection
• Model-driven development
• Model checking
• RUP asked me to do it
• Explaining a domain to developers
• Explaining a system to clients
• Documenting for future maintainers
• Memory aids
• Minimizing ambiguity
• Simplified, abstracted terms
• Models are primarily communication artifacts!

11
Communication Artifacts

• Models are communication artifacts...
• ...so lets study them as such!
• Some qualities of communication artifacts
• Codification effort
• Learning curve
• Obsolescence
• Comprehensibility
• We decided (for now) to focus on
  comprehensibility
• Why?
• It has bitten us in the past
• It is not enough to preach ---one must be heard

12
Challenges of Evaluating Comprehensibility

• Tricky construct
• Affected variables
• Correctness of understanding
• Time
• Confidence
• Perceived difficulty
• Affecting variables
• Type of task
• Language expertise
• Domain expertise
• Problem size
• Unfeasible to evaluate them all in a single
  empirical study

13
Challenges of Evaluating Comprehensibility

• Accessibility of participants
• Its hard enough to find participants for
  standard software engineering studies
• Requiring language/domain expertise makes the
  task much harder
• Ensuring fair comparisons
• It is practically impossible to guarantee that
  two different representations transmit the same
  meaning to a human reader
• Informal semantics play a large role in human
  comprehension

14
A Framework forEmpirical Evaluation...

• Most modeling languages are never evaluated
• And third-party evaluation is almost non-existent
• Popular languages do get their share of studies
  (ER, DFDs, some UML)
• But for most proposals were stuck with version
  1.0
• We designed a framework to run empirical studies
  of model comprehensibility
• Based on our survey of (scarce) past
  comprehensibility papers...
• ...and on our struggle to design appropriate
  evaluations
• I am not going to explain it in full here
• No time!
• I will only cover it superficially and refer you
  to our paper
• Warning The framework itself has not been
  evaluated!

15
The Framework

• Step 1 Select the modeling notation
• Which version will be studied?
• Are we including language extensions?
• Can we tweak the rules of the notation (as often
  happens in practice), or are we implementing the
  rules strictly?

16
(No Transcript)
17
The Framework (cont)

• Step 2 Articulate the underlying theory of the
  language
• What is the language useful for?
• Who should be writing in it?
• Who should be reading it?
• When in the software process should the language
  be used?
• Step 3 Formulate the claims of the notation
• Re-express the underlying theory as a set of
  claims regarding comprehension

18
(No Transcript)
19
The Framework (cont)

• Step 4 Choose a control
• It should be a sensible alternative to the
  notation
• It does not need to be diagrammatic
• Risky to compare a language extension vs. the
  bare language
• Step 5 Turn the claims into hypotheses
• Consider the affected/affecting comprehensibility
  variables
• From a language evolution perspective it is more
  important to discover which elements and concepts
  work well, and which do not, rather than to make
  general claims of the language

20
The Framework (cont)

• Step 6 Inform the hypotheses
• Bring insights from other areas that study
  comprehension
• External cognition
• Cognitive dimensions framework
• ...
• Step 7 Design and execute the study
• Suggestions
• Natural domains
• Explicit participant roles
• Expert modelers
• Two or more domains
• Collect data on all affected variables
• Step 8 Improve these guidelines

21
The Framework (summary)

• Step 1 Select the modeling notation
• Step 2 Articulate the underlying theory
• Step 3 Formulate the claims of the notation
• Step 4 Choose a control
• Step 5 Turn the claims into hypotheses
• Step 6 Inform the hypotheses
• Step 7 Design and execute the study
• Step 8 Improve these guidelines

22
Questions?
