Simple Linear Regression: An Introduction

1
Simple Linear RegressionAn Introduction

• Dr. Tuan V. Nguyen
• Garvan Institute of Medical Research
• Sydney

2

• Give a man three weapons correlation,
  regression and a pen and he will use all three
  (Anon, 1978)

3
An example
ID Age Chol (mg/ml) 1 46 3.5 2 20 1.9 3 52 4.0
4 30 2.6 5 57 4.5 6 25 3.0 7 28 2.9 8 36 3.8 9 22
2.1 10 43 3.8 11 57 4.1 12 33 3.0 13 22 2.5 14 63
4.6 15 40 3.2 16 48 4.2 17 28 2.3 18 49 4.0
Age and cholesterol levels in 18 individuals
4
Read data into R

• id lt- seq(118)
• age lt- c(46, 20, 52, 30, 57, 25, 28, 36, 22,
• 43, 57, 33, 22, 63, 40, 48, 28, 49)
• chol lt- c(3.5, 1.9, 4.0, 2.6, 4.5, 3.0, 2.9, 3.8,
  2.1,
• 3.8, 4.1, 3.0, 2.5, 4.6, 3.2, 4.2, 2.3,
  4.0)
• plot(chol age, pch16)

5
(No Transcript)
6
Questions of interest

• Association between age and cholesterol levels
• Strength of association
• Prediction of cholesterol for a given age

Correlation and Regression analysis
7
Variance and covariance algebra

• Let x and y be two random variables from a sample
  of n obervations.
• Measure of variability of x and y variance

• Measure of covariation between x and y ?

• Algebraically
• var(x y) var(x) var(y)
• var(x y) var(x) var(y) 2cov(x,y)
• Where

8
Variance and covariance geometry

• The independence or dependence between x and y
  can be represented geometrically

y
h
h
y
H
x
x
h2 x2 y2 2xycos(H)
h2 x2 y2
9
Meaning of variance and covariance

• Variance is always positive
• If covariance 0, x and y are independent.
• Covariance is sum of cross-products can be
  positive or negative.
• Negative covariance deviations in the two
  distributions in are opposite directions, e.g.
  genetic covariation.
• Positive covariance deviations in the two
  distributions in are in the same direction.
• Covariance a measure of strength of
  association.

10
Covariance and correlation

• Covariance is unit-depenent.
• Coefficient of correlation (r) between x and y is
  a standardized covariance.
• r is defined by

11
Positive and negative correlation
r 0.9
r -0.9
12
Test of hypothesis of correlation

• Hypothesis Ho r 0 versus Ho r not equal to
  0.
• Standard error of r is
• The t-statistic

• This statistic has a t distribution with n 2
  degrees of freedom.
• Fishers z-transformation
• Standard error of z
• Then 95 CI of z can be constructed as

13
An illustration of correlation analysis

• ID Age Cholesterol
• (x) (y mg/100ml)
• 46 3.5
• 20 1.9
• 52 4.0
• 30 2.6
• 57 4.5
• 25 3.0
• 28 2.9
• 36 3.8
• 22 2.1
• 43 3.8
• 57 4.1
• 33 3.0
• 22 2.5
• 63 4.6
• 40 3.2
• 48 4.2
• 28 2.3

Cov(x, y) 10.68
t-statistic 0.56 / 0.26 2.17 Critical t-value
with 17 df and alpha 5 is 2.11 Conclusion
There is a significant association between age
and cholesterol.
14
Simple linear regression analysis

• Only two variables are of interest one response
  variable and one predictor variable
• No adjustment is needed for confounding or
  covariate

• Assessment
• Quantify the relationship between two variables
• Prediction
• Make prediction and validate a test
• Control
• Adjusting for confounding effect (in the case of
  multiple variables)

15
Relationship between age and cholesterol
16
Linear regression model

• Y random variable representing a response
• X random variable representing a predictor
  variable (predictor, risk factor)
• Both Y and X can be a categorical variable (e.g.,
  yes / no) or a continuous variable (e.g., age).
• If Y is categorical, the model is a logistic
  regression model if Y is continuous, a simple
  linear regression model.
• Model
• Y a bX e
• a intercept
• b slope / gradient
• random error (variation between subjects in y
  even if x is constant, e.g., variation in
  cholesterol for patients of the same age.)

17
Linear regression assumptions

• The relationship is linear in terms of the
  parameter
• X is measured without error
• The values of Y are independently from each other
  (e.g., Y1 is not correlated with Y2)
• The random error term (e) is normally distributed
  with mean 0 and constant variance.

18
Expected value and variance

• If the assumptions are tenable, then
• The expected value of Y is E(Y x) a bx
• The variance of Y is var(Y) var(e) s2

19
Estimation of model parameters
Given two points A(x1, y1) and B(x2, y2) in a
two-dimensional space, we can derive an equation
connecting the points.
Gradient
y
B(x2,y2)
Equation y mx a What happen if we have
more than 2 points?
dy
A(x1,y1)
dx
a
0
x
20
Estimation of a and b

• For a series of pairs (x1, y1), (x2, y2), (x3,
  y3), , (xn, yn)
• Let a and b be sample estimates for parameters a
  and b,
• We have a sample equation Y a bx
• Aim finding the values of a and b so that (Y
  Y) is minimal.
• Let SSE sum of (Yi a bxi)2.
• Values of a and b that minimise SSE are called
  least square estimates.

21
Criteria of estimation
yi
Chol
Age
The goal of least square estimator (LSE) is to
find a and b such that the sum of d2 is minimal.
22
Estimation of a and b

• After some calculus operations, the results can
  be shown to be

Where

• When the regression assumptions are valid, the
  estimators of a and b have the following
  properties
• Unbiased
• Uniformly minimal variance (eg efficient)

23
Goodness-of-fit

• Now, we have the equation Y a bX e
• Question how well the regression equation
  describe the actual data?
• Answer coefficient of determination (R2) the
  amount of variation in Y is explained by the
  variation in X.

24
Partitioning of variations concept

• SST sum of squared difference between yi and
  the mean of y.
• SSR sum of squared difference between the
  predicted value of y and the mean of y.
• SSE sum of squared difference between the
  observed and predicted value of y.
• SST SSR SSE
• The the coefficient of determination is
• R2 SSR / SST

25
Partitioning of variations geometry
SSE
SST
Chol (Y)
SSR
mean
Age (X)
26
Partitioning of variations algebra

• Some statistics
• Total variation
• Attributed to the model
• Residual sum of square
• SST SSR SSE
• SSR SST SSE

27
Analysis of variance

• SS increases in proportion to sample size (n)
• Mean squares (MS) normalise for degrees of
  freedom (df)
• MSR SSR / p (where p number of degrees of
  freedom)
• MSE SSE / (n p 1)
• MST SST / (n 1)

• Analysis of variance (ANOVA) table

Source d.f. Sum of squares (SS) Mean squares (MS) F-test
Regression Residual Total p Np 1 n 1 SSR SSE SST MSR MSE MSR/MSE
28
Hypothesis tests in regression analysis

• Now, we have
• Sample data Y a bX e
• Population Y a bX e
• Ho b 0. There is no linear association
  between the outcome and predictor variable.
• In layman language what is the chance, given
  the sample data that we observed, of observing a
  sample of data that is less consistent with the
  null hypothesis of no association?

29
Inference about slope (parameter b)

• Recall that e is assumed to be normally
  distributed with mean 0 and variance s2.
• Estimate of s2 is MSE (or s2)
• It can be shown that
• The expected value of b is b, i.e. E(b) b,
• The standard error of b is
• Then the test whether b 0 is t b / SE(b)
  which follows a t-distribution with n-1 degrees
  of freedom.

30
Confidence interval around predicted valued

• Observed value is Yi.
• Predicted value is
• The standard error of the predicted value is

• Interval estimation for Yi values

31
Checking assumptions

• Assumption of constant variance
• Assumption of normality
• Correctness of functional form
• Model stability
• All can be conducted with graphical analysis.
  The residuals from the model or a function of the
  residuals play an important role in all of the
  model diagnostic procedures.

32
Checking assumptions

• Assumption of constant variance
• Plot the studentized residuals versus their
  predicted values. Examine whether the
  variability between residuals remains relatively
  constant across the range of fitted values.
• Assumption of normality
• Plot the residuals versus their expected values
  under normality (Normal probability plot). If
  the residuals are normally distributed, it should
  fall along a 45o line.
• Correct functional form?
• Plot the residuals versus fitted values. Examine
  whether the residual plot for evidence of a
  non-linear trend in the value of the residual
  across the range of fitted values.
• Model stability
• Check whether one or more observations are
  influential. Use Cooks distance.

33
Checking assumptions (Cont)

• Cooks distance (D) is a measure of the magnitude
  by which the fitted values of the regression
  model change if the ith observation is removed
  from the data set.
• Leverage is a measure of how extreme the value of
  xi is relative to the remaining value of x.
• The Studentized residual provides a measure of
  how extreme the value of yi is relative to the
  remaining value of y.

34
Remedial measures

• Non-constant variance
• Transform the response variable (y) to a new
  scale (e.g. logarithm) is often helpful.
• If no transformation can achieve the non-constant
  variance problem, use a more robust estimator
  such as iterative weighted least squares.
• Non-normality
• Non-normality and non-constant variance go
  hand-in-hand.
• Outliers
• Check for accuracy
• Use robust estimator

35
Regression analysis using R

• id lt- seq(118)
• age lt- c(46, 20, 52, 30, 57, 25, 28, 36, 22,
• 43, 57, 33, 22, 63, 40, 48, 28, 49)
• chol lt- c(3.5, 1.9, 4.0, 2.6, 4.5, 3.0, 2.9, 3.8,
  2.1,
• 3.8, 4.1, 3.0, 2.5, 4.6, 3.2, 4.2, 2.3,
  4.0)
• Fit linear regression model
• reg lt- lm(chol age)
• summary(reg)

36
ANOVA result

• gt anova(reg)
• Analysis of Variance Table
• Response chol
• Df Sum Sq Mean Sq F value Pr(gtF)

• age 1 10.4944 10.4944 114.57 1.058e-08

• Residuals 16 1.4656 0.0916

• ---
• Signif. codes 0 '' 0.001 '' 0.01 '' 0.05
  '.' 0.1 ' ' 1

37
Results of R analysis
gt summary(reg) Call lm(formula chol
age) Residuals Min 1Q Median
3Q Max -0.40729 -0.24133 -0.04522 0.17939
0.63040 Coefficients Estimate Std.
Error t value Pr(gtt) (Intercept) 1.089218
0.221466 4.918 0.000154 age
0.057788 0.005399 10.704 1.06e-08
--- Signif. codes 0 '' 0.001 '' 0.01
'' 0.05 '.' 0.1 ' ' 1 Residual standard error
0.3027 on 16 degrees of freedom Multiple
R-Squared 0.8775, Adjusted R-squared 0.8698
F-statistic 114.6 on 1 and 16 DF, p-value
1.058e-08
38
Diagnostics influential data
par(mfrowc(2,2)) plot(reg)
39
A non-linear illustration BMI and sexual
attractiveness

• Study on 44 university students
• Measure body mass index (BMI)
• Sexual attractiveness (SA) score

id lt- seq(144) bmi lt- c(11.00, 12.00, 12.50,
14.00, 14.00, 14.00, 14.00, 14.00,
14.00, 14.80, 15.00, 15.00, 15.50, 16.00,
16.50, 17.00, 17.00, 18.00, 18.00, 19.00,
19.00, 20.00, 20.00, 20.00, 20.50,
22.00, 23.00, 23.00, 24.00, 24.50,
25.00, 25.00, 26.00, 26.00, 26.50,
28.00, 29.00, 31.00, 32.00, 33.00, 34.00, 35.50,
36.00, 36.00) sa lt- c(2.0, 2.8, 1.8,
1.8, 2.0, 2.8, 3.2, 3.1, 4.0, 1.5, 3.2,
3.7, 5.5, 5.2, 5.1, 5.7, 5.6, 4.8, 5.4, 6.3,
6.5, 4.9, 5.0, 5.3, 5.0, 4.2, 4.1, 4.7, 3.5,
3.7, 3.5, 4.0, 3.7, 3.6, 3.4, 3.3, 2.9,
2.1, 2.0, 2.1, 2.1, 2.0, 1.8, 1.7)
40
Linear regression analysis of BMI and SA
reg lt- lm (sa bmi) summary(reg) Residuals
Min 1Q Median 3Q Max
-2.54204 -0.97584 0.05082 1.16160 2.70856
Coefficients Estimate Std. Error t
value Pr(gtt) (Intercept) 4.92512
0.64489 7.637 1.81e-09 bmi -0.05967
0.02862 -2.084 0.0432 --- Signif.
codes 0 '' 0.001 '' 0.01 '' 0.05 '.' 0.1
' ' 1 Residual standard error 1.354 on 42
degrees of freedom Multiple R-Squared 0.09376,
Adjusted R-squared 0.07218 F-statistic 4.345
on 1 and 42 DF, p-value 0.04323
41
BMI and SA analysis of residuals
plot(reg)
42
BMI and SA a simple plot
par(mfrowc(1,1)) reg lt- lm(sa bmi) plot(sa
bmi, pch16) abline(reg)
43
Re-analysis of sexual attractiveness data

• Fit 3 regression models
• linear lt- lm(sa bmi)
• quad lt- lm(sa poly(bmi, 2))
• cubic lt- lm(sa poly(bmi, 3))
• Make new BMI axis
• bmi.new lt- 1040
• Get predicted values
• quad.pred lt- predict(quad,data.frame(bmibmi.new))

• cubic.pred lt- predict(cubic,data.frame(bmibmi.new
  ))
• Plot predicted values
• abline(reg)
• lines(bmi.new, quad.pred, col"blue",lwd3)
• lines(bmi.new, cubic.pred, col"red",lwd3)

44
(No Transcript)
45
Some comments Interpretation of correlation

• Correlation lies between 1 and 1. A very small
  correlation does not mean that no linear
  association between the two variables. The
  relationship may be non-linear.
• For curlinearity, a rank correlation is better
  than the Pearsons correlation.
• A small correlation (eg 0.1) may be statistically
  significant, but clinically unimportant.
• R2 is another measure of strength of association.
  An r 0.7 may sound impressive, but R2 is 0.49!
• Correlation does not mean causation.

46
Some comments Interpretation of correlation

• Be careful with multiple correlations. For p
  variables, there are p(p 1)/2 possible pairs of
  correlation, and false positive is a problem.
• Correlation can not be inferred directly from
  association.
• r(age, weight) 0.05 r(weight, fat) 0.03 it
  does not mean that r(age, fat) is near zero.
• In fact, r(age, fat) 0.79.

47
Some comments Interpretation of regression

• The fitted line (regression) is only an estimated
  of the relation between these variables in the
  population.
• Uncertainty associated with estimated parameters.
• Regression line should not be used to make
  prediction of x values outside the range of
  values in the observed data.
• A statistical model is an approximation the
  true relation may be nonlinear, but a linear is
  a reasonable approximation.

48
Some comments Reporting results

• Results should be reported in sufficient details
  nature of response variable, predictor variable
  any transformation checking assumptions, etc.
• Regression coefficients (a, b), their associated
  standard errors, and R2 are useful summary.

49
Some final comments

• Equations are the cornerstone on which the
  edifice of science rests.
• Equations are like poems, or even an onion.
• So, be careful with your building of equations!
