Zero Knowledge Proofs

Interactive proof

- An Interactive Proof System for a language L is

a two-party game between a verifier and a prover

that interact on a common input in a way

satisfying the following properties

Interactive proof

- The verifiers strategy is a probabilistic

polynomial-time procedure. - Correctness requirements
- Completeness There exists a prover strategy P,

such that for every x?L, when interacting on a

common input x, the prover P convinces the

verifier with probability at least 2/3. - Soundness For every x?L, when interacting on the

common input x, any prover strategy P convinces

the verifier with probability at most 1/3.

Zero Knowledge Proof

- Let (P,V) be an interactive proof system for some

language L. We say that (P,V), actually P, is

zero-knowledge if for every probabilistic

polynomial-time ITM V there exists a

probabilistic polynomial-time machine M s.t. for

every x?L holds - ltP,Vgt(x)x?L ? M(x)x?L
- Machine M is called the simulator for the

interaction of V with P.

Perfect Zero Knowledge

- Definition
- Let (P,V) be an interactive proof system for

some language L. We say that (P,V), actually P,

is perfect zero-knowledge (PZK) if for every

probabilistic polynomial time ITM V there exists

a probabilistic polynomial-time machine M s.t.

for every x?L the distributions ltP,Vgt(x)x?L

and M(x)x?L are identical, i.e.,

ltP,Vgt(x)x?L ? M(x)x?L

Statistical Zero Knowledge

- Definition
- Let (P,V) be an interactive proof system for some

language L. We say that (P,V), actually P, is

statistical zero knowledge (SZK) if for every

probabilistic polynomial time verifier V there

exists a probabilistic polynomial-time machine M

s.t. the ensembles ltP,Vgt(x)x?L and M(x)x?L

are statistically close.

Statistical Zero Knowledge

- Definition-cont.
- The distribution ensembles Axx?L and Bxx?L

are statistically close or have negligible

variation distance if for every polynomial p()

there exits integer N such that for every x?L

with x ? N holds ?? Pr Ax ? Pr Bx

? ? p(x)-1

Computational Zero Knowledge

- Definition
- Let (P,V) be an interactive proof system for some

language L. (P,V), actually P, is computational

zero knowledge (CZK) if for every probabilistic

polynomial-time verifier V there exists a

probabilistic polynomial-time machine M s.t. the

ensembles ltP,Vgt(x)x?L and M(x)x?L are

computationally indistinguishable.

Computational Zero Knowledge

- Definition
- Two ensembles Axx?L and Bxx?L are
- computationally indistinguishable if for
- every probabilistic polynomial time
- distinguisher D and for every polynomial p()
- there exists an integer N such that for every
- x?L with x ? N holds
- Pr D(x,Ax) 1 Pr D(x,Bx) 1 ? p(x)-1

Graph Isomorphism problem

- Definition
- Graph Isomorphism two graphs G0 (V0,E0) and G1

(V1, G1) are isomorphic ? ? permutation ? - s.t
- ? (u,v) ? E0 ?(? (u), ?(v)) ? E1
- if G0 and G1 are isomorphic and ? is an

isomorphism between G0 to G1 we write G1 ?(G0)

.

Graph Isomorphism problem

- Graph Isomorphism problem Given Two Graphs G1

and G2 Are They Isomorphic ? - Lemma GI ?ZK
- Proof Zero Knowledge Interactive Proof for GI.

Zero Knowledge Interactive proof for Graph

Isomorphism

- 1. Repeat the following n times
- 2. The Prover chooses a random permutation ? of

(1n) and computes H ?(G1) and send it to the

verifier. - 3. The verifier chooses randomly i1 or 2 and

sends it to the prover.

Zero Knowledge Interactive proof for Graph

Isomorphism-cont.

- 4. The prover chooses permutation ? s.t H

?(Gi). - If i1 the prover sends ? to the verifier

otherwise the prover will send ? ?-1 .(? is the

isomorphism between G1 and G2. - 5. The verifier checks if H is the image of Gi

under ?. - 6. The verifier accepts if H is the image of Gi

in all n rounds.

Zero Knowledge Interactive proof for Graph

Isomorphism-cont.

Prover

Verifier

? H ?(G1)

i1,2

R

? or ? ?-1

Checks if H is the image of Gi

Building simulator M for graph isomorphism

problem

- We will define simulator M as follows
- Input(G0, G1) ? ISO
- 1.Randomly chooses a random string RANDOM and

puts it on the Random tape of Verifier V. - 2. Randomly chooses a ?0,1 and permutation ?

and construct H ?(Ga) send H to V .

Building simulator M for graph isomorphism

problem

- 3. Receive b from V .
- If b ?0,1 then outputs RANDOM,H,b and

STOP. - If a b then outputs RANDOM,H,b, ? and

STOPelse GOTO 1 .

Zero-Knowledge Password Proofs

- 1. The prover finds two large primal numbers - p

and q and sends npq to the verifier - 2. r is a random number belongs to n, n4. The

prover sends x2 modn and r2 modn to the verifier. - 3. The verifier then randomly asks for r or xr

and checks the prover.

Zero-Knowledge Password Proofs

Prover

Verifier

npq x2 modn r2 modn

Asks for xr or r

xr or r

Checks the Prover

NP and Zero Knowledge proofs

- Lemma NP?ZK
- Proof 3col?ZK .

Zero Knowledge proof for 3col problem

- 1. The prover randomly chooses a permutation ?.

Computes ?(c(v)), puts in envelopes and sends to

the verifier. - 2. The verifier chooses randomly
- (u,v) ?E and opens the envelope.
- If the colors are different and legal he answers

yes.

Zero Knowledge proof for 3col problem

Prover

Verifier

permutation ?. ?(c(v))

Chooses (u,v) ?E

envelope

Checks that colors are different

ZK protocol for Co-SAT

- Transform the CNF to a polynom by these

transformation rules - 1. T ? positive value
- 2. F ? 0
- 3. Xi ? Xi
- 3. ? Xi ? (1-Xi)
- 4. OR ?
- 5. AND ?

ZK protocol for Co-SAT

- The protocol
- 1. The prover selects a prime number q gt 2n 3m

and sends to the verifier. - 2. The verifier checks that q is prime. If q

isnt prime halts and rejects.

ZK protocol for Co-SAT

- 3. V0 is at the initialized at value zero. The

prover does the following for i1n. The prover

computes polynom Pi that its rank is at most m .

- The construction of Pi
- P1(x) ? xn 0,1. ? xn0,1 p(x1 xn)
- P2(x) ? xn 0,1. ? xn0,1 p(r1,x, x3 xn)
- Pn(x) p(r1,... Rn-1, xn ) the prover puts

polynom Pi in envelopes and send to the verifier.

ZK protocol for Co-SAT

- 4. The prover moves to the next stage(ii1).
- 5. We know that the verifier will accept
- if ? r1 ri rn s.t Pi(0) Pi(1) vi -1modq.

- Since checking each assignment is polynomial this

problem is in NP . - We can now do a reduction from any NP problem to

3col ? ZK .

ZK protocol for Graph non isomorphism

- Definition
- Graph non Isomorphism given two graphs G0

(V0,E0) and G1 (V1, G1) . - (G0, G1 )?GNI ?
- there is no permutation ?
- s.t
- ? (u,v) ? E0 ?(? (u), ?(v)) ? E1

ZK protocol for Graph non isomorphism

- 1. The verifier chooses randomly a number i

?(0,1) . The verifier chooses a random

permutation ? and computes H ? (Gi). Then the

verifier chooses randomly j ?(0,1) . The verifier

creates the pair of graphs (H0, H1) such that - if j0
- H0 is a permutation of G0
- H1 is a permutation of G1

ZK protocol for Graph non isomorphism

- if j1
- H0 is a permutation of G1
- H1 is apermutation of G0
- the verifier sends H and the pair (H0, H1).

ZK protocol for Graph non isomorphism

- 2. The prover chooses randomly
- b ?(0,1) . The prover sends b to the verifier .

- If b0 then the verifier sends the prover the

isomorphism between (G0, G1) and (H0, H1). - If b1 the verifier sends the prover the

isomorphism between H and (H0, H1) .

ZK protocol for Graph non isomorphism

- 3. The prover checks that the right isomorphism

is sent otherwise it stops. the prover computes b

such that Gb is isomorphic to H and sends b to V

. If there is no such b , the prover sends a

random b. - 4. The verifier accepts if jb.

ZK protocol for Graph non isomorphism

Prover

Verifier

1. i ?(0,1) 2.H ? (Gi) 3. H and the pair (H0,

H1)

1.Isomorphism between (G0, G1) and (H0, H1).

OR 2.Isomorphism between (H0, H1) and H.

Check isomorphism computes b

checks that jb

ZK protocol for Graph non isomorphism

- Lemma GNI ? PZK
- Proof building M
- s.t ltP,Vgt(x)x?L ? M(x)x?L
- 1. The machine M takes random string of bits and

puts ot on a Random tape.

ZK protocol for Graph non isomorphism

- Mv does the following n times
- 2. Mv waits to get H and the pair (H0, H1) from

V . - 3. Mv chooses a random b .
- 4. Mv gets from V the isomorphism between H

and (H0, H1) and (G0, G1). Mv checks if it is

not the right isomorphism it stops.

ZK protocol for Graph non isomorphism

- Otherwise1. Returns V to the point after H and
- (H0, H1) were received.
- 2. choose b again and sends to V
- 3. Waits to get I from V
- I- isomorphism received from V.

ZK protocol for Graph non isomorphism

- If b?b then the Mv finds isomorphism from I and

I, from G0,G1 to (H0, H1) and from (H0, H1) to

H. The machine uses this information to find

Isomorphism from H to G0 , G1. - 4. The machine Mv uses this information to

compute V and sends it to V.
