OVERVIEW OF CLIMATE SCIENCE

1
OVERVIEW OF CLIMATE SCIENCE
2
What is the difference between climate and
weather?
3
Climate A composite of a regions average
conditions
4
Climate

• Applies to long-term changes
• Measured in terms of
• Temperature
• Precipitation
• Snow and ice cover
• Winds
• Can refer to
• The entire planet
• Specific regions (continents or oceans)

5
Weather
6
Weather

• Shorter fluctuations lasting
• Hours
• Days
• Weeks
• Can refer to very short changes

7
Climates on Earth are Favorable to Life

• Surface Temperature
• Averages 15oC (59oF)
• Much of the Surface Ranges from 0o C to 30oC

8
Temperature Scales

• Kelvin Scale
• Divided into units of Kelvin instead of degrees
• Absolute scale
• Converting values between the Fahrenheit and
  Celsius Scales
• Tc (Tf 32)
• Tf (Tc 32)

5
9
9
5
9
Geologic Time
10

• 1 km 1 million years
• LA to NY 4,500 million yrs
• Precambrian LA to Pittsburgh, PA
• Paleozoic entirely in PA
• Mesozoic 179 km drive to NJ, 65 from NYC
• End of ice age 10 m from destination
• 2,000 AD years is 2 meters
• Human life spanlt10 cm

11
Another Geologic Time Analogy . . .

• If all Earth history had been recorded from its
  origin to the present as a motion picture
• Each frame would flash on the screen for 1/32 of
  a second which would equal 100 years
• To show all Earth history would take 16 days.
• The last 2,000 years would take ¾ of a second
• The present to the last ice age would be less
  than 7 seconds.
• The last 65 million years would take almost six
  hours
• The Paleozoic Era would last two days

12

• We will focus on the last several million years
  of Earths history (about 10 of its total age)
• This can only be represented by
• A series of magnifications
• Using a log scale that increases by factors of 10

13
Time Scales of Climate Change
Longest
Shortest
14
Tectonic Change The Longest Time Scale

• Shows a slow warming
• Between 300 Myr and 100 Myr
• Last 100 million years
• Gradual Cooling
• Led to ice ages during the last 3 million years
• Note shorter oscillations

15
Time Scales of Climate Change

• As the time scales become shorter
• Progressively smaller time scales are magnified
  out from the larger changes at longer time scales.

16
Degree of Resolution

• Amount of detail retrieved from records
• Older records have less resolution
• Long term averages over millions of years
• Younger records have progressively greater
  resolution
• Shorter term averages
• Occur within intervals of
• Thousands
• Hundreds
• Even tens of years

17
Development of Climate Science
National Center for Atmospheric Research Boulder,
CO

• Modern climatology is an interdisciplinary
  endeavor throughout the world
• Universities
• National Laboratories
• Research Centers

18
Diversity of Studies

• Meteorology
• Oceanography
• Chemistry
• Glaciology
• Ecology
• Geology
• Includes geophysics, geochemistry, paleontology
• Climate Modelers
• Historians

19
Studying Climate Change The Scientific Method

• Hypothesis
• An informal idea that has not been widely tested
  by the scientific community
• Most are discarded.
• Theory
• When a hypothesis is capable of explaining a wide
  array of observations.
• Additional observations support the theory
• New techniques for data analysis
• Devise models

20
Theories can be discarded

• Ongoing work may disprove the predictions of a
  current theory

21
An Historical Example . . .The Geocentric Model
of the Solar System

• Devised by Ptolemy (Claudius Ptolemaeus) in the
  second century AD
• Accepted until 1543

22
The Heliocentric Model replaced the Geocentric
Model
Pluto is no longer considered a planet!
23
Plutos Been Demoted!

• On August 24, 2006 the International Astronomical
  Union redefined the definition of a planet as
• a celestial body that is in orbit around the sun
• has sufficient mass for its self-gravity to
  overcome rigid body forces so that it assumes a
  nearly round shape,
• and has cleared the neighborhood around its
  orbit.

24
Pluto is now considered a Dwarf Planet

• Pluto lost its status as a planet because its
  highly eccentric orbit crosses over the orbit of
  Neptune.
• As such it hasnt cleared the neighborhood
  around its orbit.
• A dwarf planet like Pluto is
• Any other round object that
• Has not cleared the neighborhood around its
  orbit
• Is not a satellite

25
(No Transcript)
26
(No Transcript)
27
A Law or Unifying Theory

• If a theory has survived the test of time
• Years or decades
• Its the closest approximation to the truth as
  possible.
• Its impossible to prove a theory as being true.
• We can only prove its untrue.

28
Revolutions in Climate Change

• A scientific revolution that endeavors to
  understand climate change has accelerated.
• The mystery of climate change yields its secrets
  slowly.
• This revolution has achieved the status so that
  it has begun to take its place alongside two
  great earlier revolution in knowledge of Earth
  history.

29
Evolution
30
Evolution of the Jaw in Fish
31
Who is the Descendent of this Mammal?
32
(No Transcript)
33
(No Transcript)
34
Plate Tectonics
The unifying theory of geology
35
Tectonic Plate Boundaries
36
Earths Climate System

• Small number of external factors
• Force or drive changes in the climate system

37
Earths Climate System

• Internal components respond to external factors
• They change and interact in many ways

38
Earths Climate System

• End Result of interactions
• A number of observed variations in climate
• Can be measured
• Analogous to a machines output after input
  (factors)

39
Climate Forcing

• Three fundamental kinds of climate forcing

40
1. Tectonic Processes

• Part of Plate Tectonic Theory
• Alter the geography of Earths surface
• Changes in distribution of land and sea
• Changes in surface topography
• Formation of mountain ranges
• Erosion of the land surface
• Slow processes
• Occur on a scale of millions of years

41
2. Variations in Earths Orbit

• Alter the amount of solar radiation received on
  Earth
• By season
• As a function of latitude
• Occur over tens to hundred of thousands of years.

42
3. Changes in the Suns Intensity

• Affects the amount of solar radiation arriving on
  Earth
• Long-term increase since Earths origin
• Shorter-term variations may be partially the
  cause for changes on shorter time scales of
• Decades
• Centuries
• Millenia

43
A Fourth Factor to be Considered

• Anthropogenic Forcing
• In a strict sense, not part of the natural system
• The effect of humans on climate
• Unintended byproduct of agricultural, industrial,
  and other human activities
• Results from additions of materials to the
  atmosphere

44
Climate System Responses

• Changes in global and regional temperatures
• Extent of ice
• Amounts of rainfall and snowfall
• Wind strength and direction
• Ocean circulation
• At Depth
• At the surface
• Vegetation
• Types
• Amount

45
Response TimeAn Example . . .

• The rate at which water in the beaker warms
• Rate slows with time

46
Response TimeAn Example . . .

• Equilibrium is reached
• Rate slows as response nears this state

47
Variation in the Response Times of Climate System
Components
48
Time Scales ofForcing Vs. Response

• Forcing is Slow in Comparison to Response
• Forcing is Fast in Comparison to Response
• Forcing and Response Time Scales are Similar

49
Slow Forcing in Comparison to Response
Earlier Time
Later

• Response keeps pace with gradual forcing (i.e.,
  Equivalent to slowly increasing the bunsen burner
  flame.)
• Typical of tectonic scales of climate change
• Climate changes in response to movement of
  landmasses
• 1 degree of latitude per million years (100
  km/million years)
• Slow changes in solar heating
• Average temperature over the continent keeps pace
  with average changes in solar radiation because
  of the short response time of land and water

50
Fast Forcing in Comparison to Response
Earlier Time
Later

• Response time of the climate system is much
  slower than the time scale of the change in
  forcing
• Little or no response
• Analogous to turning the Bunsen burner on and off
  so quickly that temperature doesnt respond

51
Fast Forcing in Comparison to ResponseThe
Eruption of Mt. Pinatubo - 1991

• Earths average temperature decreased by 0.5o C
  in less than a year
• Most of the fine dust remained aloft for only a
  few years
• No long-term climate change

52
Similar Forcing and Response Time Scales

• Bunsen Burner Analogy
• Abruptly turned on
• Left on for awhile
• Turned off
• Turned on again
• And so on . . .
• Varying degrees of response
• In the natural world climate forcing rarely acts
  in an on-or-of way

Earlier Time
Later
53
Similar Forcing and Response Time Scales

• Climate forcing (Bunsen Burner)
• Behaves as a moving target
• Climate system response (temperature) never
  catches up
• lags behind
• Continuously changing series of equilibrium
  values
• Created by the moving target of climate forcing
• Rate of response is always fastest when the
  system is farthest from equilibrium

Earlier Time
Later
54
Cycles of Forcing and Response

• Response to a moving target forcing is usually
  cyclic
• Fundamentally the same as the physical response
  of the beaker of water.

55
Cycles of Forcing and Response

• Larger climate change
• The climate system has ample time to respond
• The same amplitude of forcing produces
• Smaller climate changes if the climate system has
  less time to respond.

56
Cycles of Forcing and Response

• Results from changes in Earths orbit
• Over tens of thousands of years
• The climate response time characteristic of large
  ice sheets that advance and retreat
• Characteristic of Seasonal time lags between
• Highest solar intensity and hottest temperatures
• Lowest solar intensity and lowest temperatures

57
Response Times Can Vary with an Abrupt Change in
Climate Forcing

• Climate responses can range from slow to fast
  within different components of the climate
  system.
• Depends on their inherent response times.

58
Variations in Cycles of Response

• Some fast-response parts track right along with
  the climate forcing.
• Other slow-response parts lag behind the forcing.

59
Variations in Cycles of Response

• Fast response
• Seasonal changes in tropical monsoons
• Slow response
• Ice sheets

60
Variations in Cycles of Response
Single point of time - A huge ice sheet in
Canada and northern U.S.

• Low position of asterisk on the cold
  slow-response curve
• Ice sheet is at its maximum size
• Heating from the Sun has begun a slow, long-term
  increase
• Has not yet begun to melt any of the ice

61
This Has Happened in the Past
Pleistocene Ice Age 20,000 years ago to 11,000
years ago
62
Two Possible Responses of Air Temperatures Over
Land South of the Ice Sheet
Single point of time - A huge ice sheet in
Canada and northern U.S.

• Would air warm with slow increase of solar
  radiation?
• Climate response would track right along with the
  initial forcing curve
• Would air temperature still be affected by the
  ice sheet?
• If so, the response might follow a slower,
  delayed response pattern of the ice.
• The ice would also be exerting and influence of
  its own

63
Both Explanations are Sound and Plausible

• The response of air temperatures could be
  influenced by both the Sun and the ice.
• Then, the air temperature response would fall
  between the fast and slow responses.
• Faster than the response of the ice
• Lagging behind the forcing of the Sun

64
Climate Feedbacks

• Processes that Alter Climate Changes Already
  Underway

65
Positive Feedback

• Produces additional climate beyond that caused by
  the original factor
• Amplifies change underway
• Not to be interpreted as a good change.
• Example
• Decrease in solar energy could result in glaciers
  at high latitudes
• Increase in ice and snow cover could further
  result in lower temperatures.

66
Negative Feedback

• Climate change is muted.
• Not to be considered a bad change.
• After initial climate change is triggered, some
  components of the climate system reduce it.
• Example
• Effect of clouds on warming effects of increasing
  CO2 in the atmosphere.
