Feature Oriented Regional Modeling System (FORMS)

1
Feature Oriented Regional Modeling System (FORMS)
as a synthesis component of the Global and
Coastal IOOS

• Avijit Gangopadhyay
• University of Massachusetts Dartmouth
• Email avijit_at_umassd.edu
• Seed funded by NASA

2
OUTLINE

• Feature Oriented Regional Modeling
• Concept -- Initialization/Synthesis Methodology
• Example of Strategy in Sicily Strait
• Shallow water applications CCS
• Global Applications
• Feature oriented synthesis..

3
Gulf Stream Front and Ring Analysis
2/11/02
4
(No Transcript)
5
(No Transcript)
6
Features in Western North Atlantic
Deep Sea region (GSMR)
Coastal region (GOMGB)

• Gulf Stream
• Warm Core Rings
• Cold Core Rings
• Southern Recirculation Gyre
• Northern Recirculation Gyre
• Deep Western Boundary Current
• Gangopadhyay et al., 3-part series in 1997
  Journal of Atmospheric and Oceanic Tech. (14)
  13141365

• Maine Coastal Current
• NEC Inflow
• GSC Outflow
• Jordan Basin Gyre
• Wilkinson Basin Gyre
• Georges Basin Gyre
• Georges Bank Gyre
• Tidal Mixing Front
• Gangopadhyay et al. 2003 Continental Shelf Res.
  23(3-4), 317-353
• Gangopadhyay and Robinson, 2002 DAO 36(2002)
  201-232

7
(No Transcript)
8
U(x,y,z)?(y)UT(x)-UB(x)?(x,z) UB(x)
T(x,y,z)Ta(x,z)?(x,z)?(y) where, Ta(x,z)T0(x)
-Tb(x)?(x,z) Tb
9
In general, a coastal current (CC), a front (SSF)
and an eddy/gyre (E/G) are represented
by CC TM(x, ?, z) TMa(x, z) aM(x, z) ?M(?)
  SSF Tss(x, y, z) Tsh (x, z) (Tsl (x,
z) Tsh(x, z)) ?(?, z)   E/G T(r, z) Tc
(z) - Tc (z) - Tk (z) 1-exp(-r/R)   where,
TMa(x, z), Tsh (x, z) and Tc (z) are axis,
shelf and core ?(?) ?? (0 ? ? ? W) ?(?,
z) ½ ½ tanh(?-?.Z)/?
10
Strategy for GOMGB
Feature Models at feature locations Regional
Climatology FORMS
MCC, WBG, JBG, GBG, GBAG, TMF, SSF, Inflow/Outflow
11
FORMS Protocol

• Identify Circulation and Water mass features
• Regional Synthesis -- Processes from a modeling
  perspective
• Synoptic Data sets -- in-situ and satellite
• Regional Climatology (Background Circulation)
• Objective Analysis (Climatology Feature Models)
• Simulation -- Nowcasting/Forecasting

12
Feature oriented methodology is applicable to ALL
different Numerical Models

• MOM (Modular Ocean Model)
• ROMS (Regional Ocean Model System)
• POM (Princeton Ocean Model)
• HYCOM
• MIT GCM
• HOPS (Harvard Ocean Prediction System)
• Finite Element / Finite Volume models

It is an Initialization and Assimilation
Methodology
13
(No Transcript)
14
(No Transcript)
15
Strait of Sicily Feature Oriented Regional
Modeling Set Up
16
(No Transcript)
17
FORMS Applications in Different Oceans
Ocean Application
Western North Atlantic Operational Modeling, e.g. AFMIS-RFAC
Strait of Sicily Dynamical Analysis
Monterey Bay Real-time forecasting w/ ROMS AOSN-II in summer 2003 upwelling
Brazil Current Meander-eddy-Upwelling Interaction
Persian Gulf, Arabian Sea, Red Sea Monsoonal FORMS
Chilean Waters - Northern Humboldt Currents Nested Biophysical Modeling
18

19
Shallow water feature models

• Use of intelligent observations that are
  important to resolve the scales and represent the
  underlying dynamical processes
• Not only temperature-salinity structure, but
  include first-order dynamics
• Process-oriented feature models

20
Arabian Sea - Persian Gulf Red Sea
21
(No Transcript)
22
Meander-eddy-Upwelling System
23
Elements of Synthesis

• Synthesis of Multi-sensor observational system
  Satellite (SST, SSH, SSC), in-situ, CODAR --
  using feature-oriented approach
• Process-oriented shallow water feature models
• Feature Tracking -- High resolution data fusion
• EOF analysis for Vertical Structure determination
  (Warn-Varnas et al., 2004)
• High-resolution regional climatology
• Dynamical Adjustment via Models -- FORMS

24
Some more thoughts

• Feature-oriented method allows for strategic
  deployment of available resources
• It optimizes (possibly maximizes) return on
  investments (ROIs)
• The returns are not only in but in science,
  too
• Minimizes human involvement (loss) because its
  a knowledge-based system

25
Thank You!!www.smast.umassd.edu/modeling/
