Broadband Wireless World Forum San Francisco

1
Broadband Wireless World Forum San Francisco
February 2001
www.airspan.com
Unlocking the Broadband Residential Market
Advances in Low-Cost CPE and Installation Eric
Stonestrom CEO
2
Outline

• Main themes
• Broadband wireless Residential market
  characteristics and trends
• Technology trends to address market needs
• Airspans response
• Conclusion

3
Main themes

• Broadband wireless is happening now
• Combining voice AND data is the key to a
  successful business model
• The introduction of residential broadband
  wireless will drive volumes up and costs down
• Many systems deployed already especially in
  3.5GHz, PCS and MMDS bands

4
Residential market characteristics and trends

• Data speeds comparable to DSL
• 512k today 2Mbit/s by end 2001
• 4X year-on-year speed increases!
• Distance independence from exchange
• A uniform service must be delivered by the
  operator significant numbers of residential
  subscribers live out of reach of DSL
• Combined delivery of high quality voice AND
  high-speed data are key to success
• Voice alone is not enough operators need to
  offer high speed data in order to remain
  competitive
• Data alone can rarely generate sufficient
  revenues to justify the business case for ANY
  technology
• High Churn rates
• Some markets churn at 2 percent per month

5
Technology trends to address market needs

• Data speeds
• Wireless DSL systems available today to meet data
  speed requirements
• Many technical developments underway to achieve
  future data needs
• 64QAM MIMO OFDM multi-carrier CDMA etc
• Distance independence from exchange
• Frequency band is critical to achieving good
  range LMDS is not appropriate for residential
  market
• Below 5GHz is best compromise
• Wireless DSL systems deliver!
• Combined delivery of high quality voice AND
  high-speed data
• VoIP to end customer is not the best solution for
  residential
• But integration with VoIP networks is a clear
  industry trend
• High churn rates
• Need to be able to recover large proportion of
  installed equipment when subscriber churns away
  Integrated external subscriber equipment
• Very short installation/recovery time auto
  configuration of subs equipment, subscriber
  installs

6
Technical and Technology Aspects
7
Technology Evolution for low-cost BWA
Flexible, scaleable Base Station (CT) architecture
Modular CTs for Microcell applications and
small-scale deployments
Infrastructure
Wide range of voice and data terminals

• Expanded range of terminals
• Lower cost
• Multi-Megabit Speeds

CPE
ASIC technology

• Soft-configuration
• Higher integration
• Smaller footprint
• Higher Bandwidth
• Higher spectral efficiency

Underlying Technology
TIME
Speed
Cost
8
CPE - Airspans approach

• Internal Service Dependent unit
• Upgradeable / replaceable if service mix changes
• Low power
• Unobtrusive

• External Frequency dependent antenna
• Small, lightweight, easy to deploy
• Single co-ax connection

This approach maximizes flexibility whilst
minimizing product cost
9
Lower costs through standardization

• Agreement on standards can make a significant
  impact on technology costs - viz the
  (GSM/cdmaOne) mobile markets.
• However in the broadband wireless access market,
  the needs are different
• Non-uniform regulation and allocation of spectrum
• Customers are not mobile
• Much proprietary development has been undertaken
  already
• Some fora are active
• IEEE 802.16 (WirelessMAN) - Widest industry
  support today
• WDSL Consortium
• ETSI BRAN/HyperAccess
• . Others
• Standards may evolve - but not before many
  systems have been deployed!

10
System range and performance

• This is key to the ultimate economics of a given
  system
• 5 x range will typically need 25 x fewer base
  stations to cover given area
• There are also 25 fewer backhaul links to be
  installed
• HOWEVER this depends on having sufficient system
  capacity for large range systems
• AND sufficient spectrum
• Where many small sites are deployed,
  INTERFERENCE is often the limiting factor
• In comparing the economics of various systems, it
  is essential to examine the detailed tradeoffs
  between
• Capacity
• Deployed spectral efficiency
• Associated costs of (e.g. backhaul, site
  acquisition, power)

11
Quality and DFM (Design For Manufacture)

• Operational costs are in many cases highly
  dependent on the maturity of the product, the
  quality of the build and the experience of the
  manufacturer concerned
• Operating BWA equipment requires
• Extremely rugged tried-and-tested designs capable
  of withstanding a wide range of climatic
  conditions
• A product that can be easily maintained or
  upgraded, with minimal downtime while upgrades
  are undertaken
• Comprehensive OM facilities
• To manufacture such high performance equipment
  requires excellent DFM techniques, and access to
  high-volume production lines in order to achieve
  lowest-cost product.

12
System Architecture

• Frequency
• Many different frequency bands and allocations in
  many different global markets
• No world-wide frequency standards
• Inevitable consequence an architecture that
  restricts frequency flexibility will not achieve
  ultimate low-cost - insufficient manufacturing
  volumes
• Services
• Wide variations in service requirements and mix
• Mixtures of 10bT, n x POTS, leased lines, ISDN
• Combinations of service delivery to customers
  such as voice and data
• Dictates need for flexible subscriber service
  delivery unit
• HOWEVER - more modularity generally leads to
  higher costs therefore careful design that
  achieves both flexibility and low-cost needs to
  be thought through from the outset.

13
Spectrum Aspects
1 GHz
2 GHz
4 GHz
10 GHz
40 GHz

• BWA
• ISM
• MMDS

• Microwave pt-pt
• LMDS (28)
• MVDS (40)

• Rural Radio
• Mobile

• Satellites
• Fixed links
• Cordless
• Mobile

• Microwave pt-pt

CARRIER CAPACITY
LOW
HIGH
SPECTRUM CONGESTION
HIGH ----------
LOW

• CELL SIZE
• LOS
• Atmospheric Attenuation

LARGE
SMALL

• Optimum balance between
• Performance
• Ease of Deployment
• Economics

INTRINSIC COST
LOW
HIGH
PCS
MMDS
3.8 GHz
900 MHz
14
HomeRF and HomePNA
Integrated Subscriber Terminal
Phone1
RJ11
Home Wiring
Phone2
ST-P1V2
Connect Box
Power Supply

• Home PNA and HomeRF allow simple and fast
  installation of CPE
• Customers may extend home networks more easily
• More equipment can be recovered when subscribers
  churn

15
OM - key requirements

• Fault detection and repair
• Presentation of events
• Redundancy - automatic/manual switching
• Routine/background testing
• Over the air customer activation
• Minimal turn-up cost
• Links into other management systems
• Service management
• Performance analysis
• Quality of service
• Minimize cost and frequency of customer call out
• Evolve with the operator

16
AS8100 Network Management System
SUPPORTS ALL AS4000 Releases
Comprehensive graphical-based network management
system
17
Typical residential installation

• Simple, fast install typically 10 STs per 2-man
  team per day
• Low installation costs

18
Radio survey

• Note trees all around! Systems need to work
  reliably in this environment!
• Results used to predict which subscribers can be
  reached targeted deployment at lowest
  operational cost

19
Infrastructure

• Modularity to achieve scalability and
  customisation
• Re-use of hardware as multi-function boards
  soft-configured for different functions
• Reduces costs
• Simplifies spares
• Simplifies maintenance
• Minimal requirement for site visits
• Full configuration and upgrade via OM

20
Airspans Response AS4000 Wireless DSL
AS8100 Sitespan
AS4000 CT and AC
AS9000 Airplan
AS4000 Subscriber Terminals
AS4000
21
Conclusion

• Broadband Wireless is here today and being
  deployed worldwide!
• Low-cost solutions are available for residential
  markets especially SoHo applications
• Application of new technology is driving costs
  down
• Quicker install, HomeRF/PNA, and self-install
• Product costs
• Delivery of bundled services (voice and data)
  produces a compelling business case for ILECs,
  CLECs and ISPs

22
Thank you for listening..
www.airspan.com
Leaders in the Wireless DSL market
23
Company Overview
www.airspan.com
24
Company Profile

• A global supplier of Wireless DSL systems and
  solutions
• Dedicated solely to wireless fixed access
  telecommunications
• Established technology with a proven track record

• Committed to the evolving business
  technological needs of our customers

25
Experience - 1992 to Today

• Formed in 1992 to focus on RD of wireless
  communications within DSC Communications
• A pioneering product range launched in 1996
• One of the first to deploy point-to-multipoint
  radio systems
• Became an independent US corporation in February,
  1998. Investors included Sevin Rosen, Oak, and
  Deutsche Bank
• IPO in July 2000

26
Resources

• Headquartered in Florida, with primary operations
  in London
• More than 100 engineers involved directly with
  RD
• Self-contained facilities from lab testing to
  system assembly delivery
• A "greenfield" live air site for testing
  monitoring long term system performance
• Comprehensive service portfolio from initial
  consulting to full system support
• On-site in-house customer training programs

27
Our Experience

• Installed capacity exceeds 170,000 lines
  worldwide
• More than 50 customers in over 40 countries
• Urban to rural deployments
• Approvals in more than 25 countries

28
Global Customer Base
Datel
29
Some of Airspans partners
Technology Manufacturing
OEMs
30
Market Overview

• Internet growth is driving global demand for
  reliable access increased bandwidth
• World-wide telecom deregulation is creating new
  opportunities to provide local access
• Service providers are
• Differentiating their services by offering a
  greater range of services
• Expanding their focus beyond large business
  customers
• Needing more cost-effective solutions
• Airspan has products that meet todays
  requirements and that evolve with the
  ever-changing market

31
Airspans Response AS4000 Wireless DSL
AS8100 Sitespan
AS4000 CT and AC
AS9000 Airplan
AS4000 Subscriber Terminals
AS4000
32
AS4000 Wireless DSL Platform Architecture
The CO Site
Subscriber Sites
The Radio Site
Small Business
Ethernet (10baseT)
AC
PSTN interconnect
Voice
CT
Backhaul
Switch
Residential or SOHO
TCP/IP
Router
Router
SS
Ethernet
Voice
V.90 modem
SC
Residential
Voice
V.90 modem
The Management Site

• AS4000 - an Integrated Services Platform
• DSL rate data and toll quality voice
• Internet traffic groomed for ISP presentation

33
PacketDrive - High Speed Wireless DSL

• 1.6 Mbit/s Packet Delivery per RF channel today
  20Mbit/s per channel by end 2001
• Up to 24 RF channels per Base Station - 480
  Mbit/s total Packet throughput

High speed Packet pipe
Multi-subscriber Internet Access
RF Channel
34
Airspan Total Solution Provider

• Having a working product is not enough
• Customers increasingly require complete solutions
• Network Management
• Network/radio planning
• Surveys, Installation turn-up ongoing
  technical support
• Airspan provides additional product and support
  services
• Airspan AS8100 - Sitespan element manager
• Customer Support Services
• Training Services
• Radio Planning Services
• AS9000 - AirPlan radio planning software
• Industry experts

35
Airspan - the leader in the W-DSL market
Airspan has unrivalled experience - derived from
many years of deployment and development of
Wireless Access systems

• Airspan has solutions for
• Internet access
• Data
• Voice
• TODAY!

Airspan has the technology roadmap to support
even higher speeds and capacities in the future
36
www.airspan.com
