Systems and models

1
Systems and models

• A way of systematically figuring out how things
  interact.

2
3rd rock from the sun.

• The Earth from space

3
The Earth is the only Biosphere so far

• What is a biosphere?
• The thin bit of the whole planet earth where life
  can be found
• The Atmosphere the air
• The Lithosphere the rocks
• The Hydrosphere the lakes, seas
  and oceans
• The Ecosphere the
  living bits

4
The Layers of Earth
5
Outline the concept and characteristics of
ecosystems.

• An ecosystem consists of the interactions between
  the living and non living.
• The living is called biotic.
• The non-living interactions are called A-biotic.
• Put the following in the correct column

Biotic Abiotic





Plants, humidity, predation, temperature,
parasitism, competition, light intensity, season,
soil pH, mutualism, animals
Biotic Abiotic





6
What is a system?

• A system is an assemblage of parts and their
  relationship forming a functioning unit
• A system can be made up of living things,
  non-living things or mixes of both.
• It can be a whole variety of sizes, from cells to
  cities to biospheres.
• Big systems can be made up of many little
  systems.
• eg. organisms, organ systems, organs, tissues,
  cells, organelles

IBO Environmental Systems and Societies subject
guide. (Page 75.)
7
Some examples of systems
Sydney Cityscape
A Eukaryote cell
A motorbike
Human anatomy
8
To make a system diagram there are some
conventions
All systems have They are represented as
Storages (of matter or energy) Boxes
Flows (in, thru and out) Arrows
- Inputs - Arrow in to the system
- Outputs - Arrow out of the system
Boundaries --------------------------
Processes (transfers or transformations) Label on the arrows eg - Respiration
9
Using the model below, draw your own systems
diagram for some of the following

• You
• A lake
• A mobile phone
• A scooter
• A cell
• A city

Inputs
flows
Storages
flows
Outputs
Taken from page 72, Environmental Systems and
Societies Course Companion Jill Rutherford -
2009 - Oxford
10
Types of System

• An open system exchanges energy and matter with
  what is around it. e.g human, pond
• 2. A closed system exchanges energy but not
  matter with its surroundings e.g. Earth
• 3. A isolated system exchanges neither energy
  nor matter with its surroundings.

11
(No Transcript)
12
Biosphere 2

• Was Biosphere 2 open, closed or isolated? Explain
  why?
• Why was NASA so interested in what went on at
  Biosphere 2?
• Have a look for Biosphere 2 what went wrong what
  do you think?

13
If youre interested - Lake Vostok

• http//en.wikipedia.org/wiki/Lake_Vostok
• Is this an isolated system?
• If not why not?
• If not isolated is it closed?

Lake Vostok.
http//www.ldeo.columbia.edu/mstuding/new_vostok_
14
The Laws of Thermodynamics

• Thermodynamics is about the flow of energy
  (Thermo heat Dynamics - movement.)
• The 1st law states
• Energy cannot be created or destroyed it can
  however change from one form to another.
• So, the total energy in a system is constant.
• Ecosystem sunlight (photosynthesis) biomass
  eaten heat

15

• The 2nd law states
• Energy goes from a concentrated form to a
  dispersed form e.g. from the sun to dispersed
  heat
• Amount of energy doesnt change but the amount
  available does
• Energy holds molecules together so as there is
  less energy, there is more disorder
• This is called entropy

16
A Food Chain
The arrows represent the flow of energy from
eaten to eater!
Tertiary consumer
Producer
Secondary consumer
Primary consumer
All images from clip art except Apple tree.
17
Energy losses

• The apple is only able to absorb some of the
  light. (It reflects the green)
• The worm must find the apple this takes
  wiggling and changes chemical to movement energy
  and heat.
• The little bird must fly to catch the worm and
  escape the big bird ..as above.
• The big bird

(Normally 2 efficiency)
(Normally less than 10 efficiency)
(Normally more 10 efficiency)
(Normally 10 efficiency)
The total efficiency of the big bird 0.02
x0.1x0.1x0.1 0.00002
18
Sooo.

• When energy passes through living things it is
  used by the organism and eventually lost to the
  environment as heat.

19
The flows can be

• A Transfer is a change in position of the
  matter or energy but not a change in form (eg
  water droplets in cloud becoming rain)
• A Transformation a change in the form or state
  of the energy (eg water from the sea evaporating
  to the atmosphere change from liquid to gas)

20
Transfer or transformation?

• Predator eating prey
• Rain falling and becoming a river
• Suns heat warming up a person
• In a plant sunlight joining with CO2 and water to
  become glucose

21
Equilibria - balances

• Equilibrium is the tendency of a system to return
  to an original state after it gets disturbed.
• 1. Steady state
• Your body temperature get ill, recover

22
Equilibria - balances

• 2. Static nothing goes in nothing comes out
  the amount of stuff in the system stays the same.
• e.g. a chair
• NB No ecosystem or living thing.

23
Stable and unstable equilibria

• Stable even quite a large disturbance will
  return to the status quo.

• Unstable even a small disturbance will upset the
  balance.

24

• Some stable systems resist change

• Sometimes the change is so great it moves to a
  NEW stable position

25
Feedback

• Feedback is often responsible for keeping or
  upsetting balances
• There are 2 types of feedback
• Positive (ve) feedback
• Tends to destabilize equilibrium pushing a
  system to a new state.
• Negative (-ve) feedback
• Tends to stabilize systems and resist change. It
  allows self regulation.

26
Cold day. You get cold

• How does your body react?
• Hairs?
• Blood vessels?

ve feedback or ve feedback?
27
Hot day?
28
You get hungry. Eat lots.
ve feedback or ve feedback?

• Every day. Stomach expands.needs more to fill
  it.get hungry.

29
(No Transcript)
30
(No Transcript)
31
Same system 2 ideas
-ve
ve
Climate temperature remains constant
Climate temperature increases
Which is stable? What type of feedback is
this? Which is unstable? What type of feedback is
this?
32
Learn these definitions!

• Negative feedback is a self regulating method of
  control leading to the maintenance of a steady
  state equilibrium it counteracts deviation.
• Eg. Predator prey relationships.
• Positive feedback leads to increasing change in a
  system it accelerates deviation.
• Eg. Population growth.

IBO Environmental Systems and Societies subject
guide (2007) Page 15
33
Models

• Simplified description to show how something works

34
(No Transcript)
35
Evaluation of models

• An aquarium
• Computer model
• Diagram
• Advantages
  Disadvantages

36
or - ?

• Allow you to predict
• May not be accurate
• Politicians may hijack them
• Can change inputs and see outcome dont have
  to wait
• May be too simple
• Can be interpreted in different ways
• Results can be shown to public

37
