TRAUMA OF SPINE

1
TRAUMA OF SPINE SPINAL CORD

• Dr K. Bougoulias
• Orthopaedic Trauma surgeon
• MSc Sports Exercise Medicine
• Diploma Orth and Trauma

2
Objectives

• Incidence
• Anatomy
• Pathophysiology
• Classification
• Accident scene management
• Resuscitation
• Assessment
• Intervention

3
Incidence

• 4.0 to 5.3 per 100.000 population 12000 new
  spinal cord inj per year
• ( Thurman et al, paraplegia 1994)
• Neurological deficits 10 to 25 with 40 in
  cervical spine and 20 thoracolumbar spine

4
Incidence

• Motor vehicle accidents 45
• Falls 20
• Sports 15
• Acts of violence 15
• Other 5

5
(No Transcript)
6
Anatomy

• 33 vertebrae 7 cervical, 12 thoracic, 5 lumbar,
  5 sacral,4 coccygeal
• Ligaments
• Intervertebral disc-nerve roots
• Lordosis- cyphosis
• 50 flexion extension C1 occiput
• 50 rotation C1-C2

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Topographic Landmarks

• Mandible
• Hyoid cartilage
• Thyroid cartilage
• Cricoid cartilage
• Vertebra prominence
• Scapular spine
• Distal tip of scapula
• Iliac crest

• C2-3
• C3
• C4-5
• C6
• C7
• T3
• T7
• L4-5

13
(No Transcript)
14
Spinal cord

• Extends from brain stem to inferior border L1-
  Conus Medullaris-Cauda Equina
• Dorsal columns deep touch, proprioception,
  vibration
• Lateral spinothalamic tract pain, temperature
• Lateral corticospinal tract voluntary
  contraction
• Anterior spinothalamic tract light touch
• Anterior corticospinal tract voluntary
  contraction.

15
(No Transcript)
16
(No Transcript)
17
Pathophysiology

• Kinetic injury is transferred by one of two
  mechanisms
• Direct flexion , extension, rotation
• Indirect impaction of bone or disc fragments

18
Pathophysiology

• Contusion and compression rather complete
  transection
• Cord injury leads to petechial haemorrhages,
  myelin sheath and axoplasm disruption, edema
  within 6 hours, tissue hypoxia, cystic
  degeneration
• (Ducker et al, J neurosurgery, 1971)

19
Classification

• Definitions by ASIA
• Complete injury No motor and/or sensory function
  exists more than three segments below the level
  of injury
• Incomplete injury some neurological function
  exists
• Level of injury The most caudal segment that
  tests intact (motor and sensory)

20
Simplicity(Waters et al, 1991, Paraplegia)

• Sacral nerve root sparing indicates at least
  partial structural continuity
• Sacral sparing is diagnosed by Periannal
  sensation, rectal tone function, great toe flexion

21
Complete injury

• Spinal shock for 24 hours, if more ,no functional
  recovery in 99 of patients
• (Stauffer 1975, Clin Orthopaedics)
• Exception injury to conus medullaris

22
Incomplete Spinal cord Injury Syndromes

• Central cord Syndrome most common, quadriplegic
  with periannal sensation, early return of bladder
  bowel function, 75 recovery
• Anterior Cord Syndrome Complete motor and
  sensory loss- retained trunk and lower extremity
  deep pressure and proprioception- worst prognosis
  ( 10)

23
Incomplete Spinal cord injury syndromes

• Posterior cord syndrome Rare, loss of deep
  pressure, deep pain, proprioception normal cord
  function otherwise
• Brown- Sequard unilateral cord injury,
  ipsilateral motor deficit, contralateral pain and
  temperature hypesthesia best prognosis gt90

24
(No Transcript)
25
Accident Scene Management

• ATLS
• ABCD (Airway- Breathing- Circulation, C
  spine- Disability, neurological status)
• High level of suspicion
• Trauma patient is considered that has spine
  injury until prove otherwise

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
Basic rules

• C spine secured before move from accident scene
• Sandbags on either side of head which is taped to
  backboard
• Full length backboard
• Repeat ABCD
• Transport

31
High level of suspicion

• Frequently poly-trauma patients
• Facial injury C spine ?
• Thoracic abdominal Thoracolumbar Spine

32
Neurogenic shock

• Hypotension with bradycardia due to disruption of
  sympathetic outflow and unopposed vagal tone
• ( Grundy et al, 1986)
• Zipnic et al ( J. Trauma 1993) showed that
  penetrating trauma differs from blunt trauma
• Out of 75 patients only 7 developed neurogenic
  shock

33
Resuscitation

• No matter cause of hypotension, support of blood
  loss needs aggressive treatment by blood volume
  replacement.
• Vasopressors if hypotension without tachycardia
  persists
• Leg elevation to counteract venous pooling in
  extremities
• Atropine? maintain heart rate
• ? Gentle sympathomimetic agent ( e.g phenylephrine

34
Assesment

• Secondary survay
• ABCDE
• Xrays
• Intubation always with a jaw thrust manuever
• Responsive patient Past history, location pain,
  sensation (marked on skin), motor function,
  Reflexes

35
Unconscious patient

• Observation of spontaneous extremity motion
• Spontaneous respiration indicate normal thoracic
  innervation
• Log roll ecchymosis, abrasions (location), step
  off, interspinus widening

36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Reflexes

• Spinal shock absent reflexes for 24h replaced by
  hyper-reflexia, muscle spasticity, clonus
• Spinal injury- concomitant head injury
• Extremity reflexes without spontaneous motion
  cranial upper motor neuron lesion
• Absence of reflexes lower motor neuron lesion

44
Reflexes

• Babinski sign Oppenheims sign upper motor
  neuron lesion
• Cremasteric reflex T12-L1
• Annal wink S2, S3, S4
• Bulbocavernosus reflex S3, S4

45
(No Transcript)
46
(No Transcript)
47
INTERVANTION

• Pharmacological
• High doses of intravenous methylprednisolone?
• Bracken et al (1990, 1991), controlled,
  randomized study MPS within first 8 hours
  improved neurologic recovery at 1 year
• Naloxone no better than control
• MPS after 8h, patient less function than placebo

48
Intervention

• 30mg/ Kg body weight bolus
• Continuous infusion 5,4 mg/Kg/hr for 23h
• The earlier the administration the better the
  outcome
• More literature Kwon BK et al, 2004
• Wellman et al, 2003
• Bledsoe BE et al, 2004

49
Physical Intervention

• Immobilization
• Reduction
• Stabilization

50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
THANK YOU
