ABCS

1
Acquire the Target
Track the Target
Warn the Force
ABCS with BlackWatch
Quick Reaction Force
Patent Pending
Respond to the Attack
Respond to the Attack
Respond to the Attack
ABCS by AVKM LLC
2
ABCS with BlackWatch
Developed by AVKM LLC
PREVIOUS THIRD GENERATION FRAMES WITH CENTRAL
CHASSIS
OLD ANALOG SYSTEM WITH CENTRAL CHASSIS
ABCS by AVKM LLC
3
ABCS features

• No heavy cumbersome analog central chassis
  required

My Old Analog System, Front and Rear view NO
LONGER REQUIRED
ABCS by AVKM LLC
4
ABCS features

• No heavy cumbersome analog central chassis
• Easy to train and operate digital operation
  Cat6 Cable

Internal View of My Old Analog Central Chassis,
NONE OF THESE COMPONENTS AND WIRING ARE REQUIRED
ABCS by AVKM LLC
5
ABCS features

• No heavy cumbersome analog central chassis
• Easy to train and operate digital operation
  Cat6 Cable
• Easy to maintain and transport minimize
  components

Internal View of My Old Analog Central Chassis,
NONE OF THESE COMPONENTS AND WIRING ARE REQUIRED
ABCS by AVKM LLC
6
ABCS features

• No heavy cumbersome analog central chassis
• Easy to train and operate digital operation
  Cat6 Cable
• Easy to maintain and transport minimize
  components
• BlackWatch frames can be connected together to
  create a virtual display wall KnowledgeWall

ABCS by AVKM LLC
7
ABCS features

• No heavy cumbersome analog central chassis
• Easy to train and operate digital operation
  Cat6 Cable
• Easy to maintain and transport minimize
  components
• BlackWatch frames can be connected together to
  create a virtual display wall KnowledgeWall
• BlackWatch frames available 60X45, 72X45,
  72X54, 80X50, 80X60 and 90X56.25 all
  sizes available in same ruggedized screen case

ABCS by AVKM LLC
8
ABCS features

• No heavy cumbersome analog central chassis
• Easy to train and operate digital operation
  Cat6 Cable
• Easy to maintain and transport minimize
  components
• BlackWatch frames can be connected together to
  create a virtual display wall KnowledgeWall
• BlackWatch frames available 60X45, 72X45,
  72X54, 80X50, 80X60 and 90X56.25 all
  sizes available in same ruggedized case
• Any input can be shown on one display or every
  display
• Any input can be shown across all displays
• Analog inputs converted to digital, internal
  digital procssing and system outputs analog or
  digital data to displays

ABCS by AVKM LLC
9
ABCS Digital System
PC or LAPTOP
PC or LAPTOP
UAV
VTC
DVD/VCR
SAT
VTC
INPUTS
VGA OR DVI
COMPOSITE VIDEO
Input Modules 1.5 X 6 X 10
HIRES IPUT MODULE
HIRES INPUT MODULE
HIRES INPUT MODULE
HIRES INPUT MODULE
VIDEO INPUT MODULE
Up to 100M with Cat 6 Cable or longer with Fiber
GIGABIT SWITCH 1.75 HIGH
Up to 100M with Cat 6 Cable or longer with Fiber
Output Modules 1.5 X 6 X 10
DISPLAY MODULE
DISPLAY MODULE
DISPLAY MODULE
CONTROL COMPUTER
VGA OR DVI
BlackWatch SCREEN
SYSTEM OPERATES AT 110 and 220 VOLTS EASILY
EXPANDED
BlackWatch SCREEN
OUTPUTS
BlackWatch SCREEN
ABCS by AVKM LLC
10
ABCS storage casesInput modules, power supplies
and cables
storage case label
eleven input modules
power supplies for in/out modules
110/220v power cables and Cat6 cables
ABCS by AVKM LLC
11
ABCS storage cases Projectors, lamps and output
modules
storage case label
projectors, projector mounts and lamps
projector remotes
three output modules
ABCS by AVKM LLC
12
ABCS storage cases Speakers, mic and cables
storage case label
speakers
speaker remotes
power cables and Cat6 cables
Mic and mic cable
ABCS by AVKM LLC
13
Why use ABCS Ultra Lite

• Shared situation awareness among TOC users
• Integration of relevant mission status
  information
• Intuitive graphical interface
• Flexible configuration that can easily be changed
  by users
• Tactical focus for the displayed information

14
ABCS Ultra Lite 110/220V System Configurations

• 3 BlackWatch Screen System
• 10 HiRes inputs, 4 CompVideo inputs and 3
  outputs
• 2 BlackWatch Screen System
• 8 HiRes inputs, 4 CompVideo inputs and 2
  outputs
• 1 BlackWatch Screen System
• 4 HiRes inputs, 4 CompVideo inputs and 1 output
• All systems include Hardigg cases, 48 Port
  Gigabit switch, sound system, cabling and Control
  Computer
• All sytems are easily expanded by adding modules
  and BlackWatch screens

ABCS by AVKM LLC
15
Single image displayed on KnowledgeWall attached
to 3 BlackWatch frames
ABCS by AVKM LLC
16
Multiple images displayed on a KnowledgeWall
covering 3 BlackWatch frames
ABCS by AVKM LLC
17
CRISES MANAGEMENT
Live video and computer graphics
ABCS by AVKM LLC
18
Portable
Set up in a tent
ABCS by AVKM LLC
19
Portable
Set up in a building
ABCS by AVKM LLC
20
Permanent
Using installed projection cubes
ABCS by AVKM LLC
21
Permanent
Using installed projection cubes
ABCS by AVKM LLC
22
ABCS BlackWatch screen system with two lcd
monitors
LCD center screen
LCD left screen
BlackWatch right screen
control computer
output modules
ABCS by AVKM LLC
23
ABCS BlackWatch screen with leg extenders on
floor
leg extenders to raise screen
ABCS by AVKM LLC
24
ABCS BlackWatch screen secured in its shipping
case
BlackWatch
TMSS
Screen frame floats in case which scratches all
components and snaps are not protected
Restraining straps secure frame to case Screen
snaps face case walls and are protected
TMSS Trailer Mounted Support System (US DoD)
ABCS by AVKM LLC
25
ABCS BlackWatch compact projector v-arm
ABCS by AVKM LLC
26
ABCS BlackWatch projector v-arm TMSS v-arm
BlackWatch
TMSS
New and improved projector v-arm is totally
compatible with and replaces the TMSS version
ABCS by AVKM LLC
27
ABCS BlackWatch side view projector v-arm
screen
old TMSS hinge
registering pin hole
one piece, folds at top
ABCS by AVKM LLC
28
ABCS BlackWatch Old TMSS projector mount
Non captive screw scratches metal, difficult to
adjust
Mount can easily slip off v-arm, lose the screw
and its unstable
Non captive screw
unstable
v-arm
v-arm
Hook on bottom
ABCS by AVKM LLC
29
ABCS BlackWatch New projector mount
Captive screw clamps v-arm, will not scratch
metal
Mount hooks on v-arm, very stable and machine
welded
heavy duty powder coated machine welded
easily adjusted
clamp
hook
v-arm
captive screw
v-arm
New and improved projector mount is totally
compatible with and replaces the TMSS version
ABCS by AVKM LLC
30
ABCS BlackWatch Old TMSS v-arm hinge
V-arm rests on rivet hinge, hinge can only be
moved between snaps
Non captive screws scratch v-arm and screen,
difficult adjustment
rivet
moves only between snaps
Non captive screews
hinge
v-arm
spot weld
screen top
fragile design
snaps on opposite side
ABCS by AVKM LLC
31
ABCS BlackWatch New v-arm hinge
V-arm rests on flat base, hinge adjustable along
screen anywhere
Captive screw clamps v-arm screen, will not
scratch metal
captive screw
smooth surface for v-arm
clamp
v-arm
heavy duty powder coated machine welded
snaps on opposite side
lubricating washer and captive screw
captive screw
clamp
New and improved v-arm hinge is totally
compatible with and replaces the TMSS version
ABCS by AVKM LLC
32
ABCS BlackWatch Old TMSS screen separator
Screen separator is fragile, screen alignment
needs improvement
Non captive screws scratch frame, inferior spot
welded assembly
spot welds
fragile design
screws scratch frame
non captive screws
ABCS by AVKM LLC
33
ABCS BlackWatch New screen separator
Separator machine welded, screen and separator
are pin registered
Captive screws clamp frames, will not scratch
metal heavy duty
heavy duty powder coated machine welded
pin registered
clamp
clamp
captive screws
New and improved screen separator is totally
compatible with and replaces the TMSS version
ABCS by AVKM LLC
34
ABCS BlackWatch
A long time TMSS user, after using the new ABCS
BlackWatch system commented The ABCS system
is truly next generation! Everything I have
ever wanted to change on the TMSS screen you have
implemented on the BlackWatch screen. The
BlackWatch projector mount should replace all
existing TMSS projector mounts in the
field. The ABCS system is more compact,
lighter, uses less power, digital, user
configurable, easy to setup and move, expandable,
easy to maintain and the investment required is
less than any system on the market.
ABCS by AVKM LLC
35
ABCS by AVKM LLC
ADVANCED BATTLE COMMAND SYSTEM
To set up a demonstration, schedule an exercise,
or for further information contact Le
Kepley Sales Engineer AVKM LLC kepleyl_at_avkmllc.com
[phone]
