Title: 3D Game Programming


1
3D Game Programming
  • ???
  • kevin.cwang_at_msa.hinet.net
  • 2005

2
????
  • Introduction to Game Development (3hr)
  • Game System Analysis (3hr)
  • The Game Main Loop (3hr)
  • 3D Game Engine Training (Using TheFly3D) (6hr)
  • Game Mathematics Geometry (3hr)
  • Terrain (3hr)
  • Characters (3hr)
  • Game Control System (3hr)
  • Advanced Scene Management System (3hr)
  • Game AI (6hr)
  • Game Physics (3hr)
  • Game FX (3hr)
  • Network Gaming (3hr)
  • MMOG (3hr)
  • Summary
  • Wangs Method for Real-time 3D Game Development

3
????
  • One term project
  • The students are in teams.
  • Use TheFly3D 3D engine to code a Real-time 3D
    Game.
  • Action RPG
  • The teacher will provide graphics materials and
    setup the game design.
  • Final examination
  • Homework will be closely coupled with the term
    project.

4
??? (1/3)
  • ??
  • ?????? ???? / ??
  • ???? ??
  • ???? 3D????
  • ??
  • ????????????
  • ??
  • 04-04 ??????????? ????
  • 97-04 ?????????? ???
  • 96-96 ?????????????? ????
  • 93-96 ???????????? ????
  • 90-93 ???????? ?????
  • 89-90 ?????????? CAE Lab ????

5
??? (2/3)
  • Game??
  • Current
  • TheFly3D 3D Engine
  • ????
  • DragonFly 3D Game Engine
  • M2????, VRLobby, ???
  • Lizard 3D Game Engine
  • ????????? I II????? I II??????????????????????
    ??????????
  • ??????
  • Ultimate Fighter
  • 1st real-time 3D fighting game in Taiwan

6
??? (3/3)
  • ?? (Expertise)
  • 3D Computer Graphics
  • Geometric Modeling
  • Numerical Methods
  • Character Animation
  • Photo-realistic Rendering
  • Real-time Shading
  • Volume Rendering
  • ???? (Applications)
  • ??3D???? (Real-time 3D Game Development)
  • ???? (Computer Animation)
  • ???? (Virtual Reality)
  • ?????? (Computer-aided Design, CAD)
  • ???? (Scientific Visualization)

7
1st Introduction to Game Development
8
Introduction to Game Development
  • Game platform
  • Game types
  • Game team
  • Game development pipeline
  • Game software system
  • Tools

9
Game Platform
  • PC
  • Single player
  • Match Makings
  • MMOG (Massive Multi-player Online Game)
  • Web-based Games
  • Console
  • Sony PS2
  • MS Xbox
  • Nintendo GameCube
  • Arcade
  • Mobile
  • Nintendo GBA
  • Nintendo DS
  • Sony PSP
  • Hand-held

10
Game Development on PC
  • PC is designed for general office application.
  • Not for entertainment purpose
  • A virtual memory system
  • Unlimited system memory
  • But video memory is limited.
  • For frame buffers, z buffers, textures, vertices,
  • PCI / AGP might be a problem for performance.
  • Open architecture
  • Hardware driver version issue
  • Different capabilities
  • Different performance
  • Compatibility test is very important.
  • Development is easy to setup.
  • Visual C/C with DirectX

11
Game Development for Consoles
  • Specific hardware designed for games
  • Single user OS
  • Single process OS
  • No hard disk drive (?)
  • Closed system
  • Native coding environment
  • Proprietary SDK
  • Hardware related features
  • C language with assembly
  • Limited resources
  • Memory for everything
  • 32M for PS2
  • 64M for Xbox
  • One console runs, the others do !
  • Use gamepad and no keyboard

12
Game Types
  • RPG (Role playing games)
  • AVG (Adventure games)
  • RTS (Real-time strategy games)
  • FPS (First-person shooting games)
  • RSLG (??)
  • STG
  • Sports
  • Action
  • Puzzle games
  • Table games
  • MMORPG
  • Massive Multiple Player Online Role Playing Games

13
Game Team Members
  • ????
  • ???
  • ?????
  • ????
  • ????
  • ????
  • ??????
  • ????(PM)
  • ????
  • ???????
  • Game project approval
  • ??????
  • ???? game master (GM)
  • Customer services
  • MIS

14
Game Producer ?????
  • Team leader (usually)
  • ???? (Resource management)
  • ???? (Administration)
  • ???? (Project management)
  • ???? (Upward management)
  • ?????
  • ????

15
???????
  • ??????
  • Daily ??
  • House keeping
  • Meeting coordinator
  • Schedule checking
  • Cross-domain communication
  • Usually not a full-time job position
  • A position for training and becoming a producer

16
???? (1/2)
  • ???? (Story telling)
  • ???? (Scripting)
  • ???? (Game play design)
  • ????(Character design)
  • ????(Animation design)
  • ???? (Level design)
  • ????(Effect design)
  • ????
  • ????(User Interface design)
  • ???? (Game tuning)
  • ???? (Numerical setup)
  • AI ?? (Game AI design)
  • ???? (Sound FX setup)

17
???? (2/2)
  • ???? (Scene setup)
  • Game document writing
  • Game quality checking

18
????
  • Visual setup for game design
  • 2D setup
  • 3D setup
  • Graphics design and production
  • ?? (Terrain)
  • ?? (Character)
  • ?? (Models)
  • ?? (Textures)
  • ?? (Motion / Animation)
  • ?? (FX)
  • User Interface
  • ???? (??.??..?)

19
????
  • ???? (Game Program) ??
  • ?????? (Game Tools) ??
  • Level editor
  • Scene editor
  • FX editor
  • Script editor
  • Game editor
  • ??Data exporters from 3D animation Software
  • 3dsMax / Maya / Softimage
  • Game engine development
  • Game technique research
  • Online game server development

20
??????
Basic Procedures for Game Development
Idea
Proposal
Production
Integration
Testing
Debug
Tuning
Concept Approval
Prototype
Pre-alpha
Alpha
Beta
Final
  • ?? (Idea)
  • ?? (Proposal)
  • ?? (Production)
  • ?? (Integration)
  • ?? (Testing)
  • ?? (Debug)
  • ?? (Tuning)

gt Concept approval
gt ?? (prototype)
gt Pre-alpha
gt Alpha
gt Beta
21
????(Concept Design)
  • ???? (Game types)
  • ????? (Game world)
  • ?? (Story)
  • ???? (Features)
  • ???? (Game play)
  • ???? (Game product positioning)
  • Target player
  • Marketing segmentation / positioning
  • ??????
  • ???? (Risk)
  • SWOT (Strength/Weakness/Opportunity/Threat) ??
  • ???
  • Concept Design Document (CDD)

22
????(Proposal)
  • ???? (System analysis)
  • GDD ?? (Game design document)
  • MDD ?? (Media design document)
  • TDD ?? (Technical design document)
  • ?????? (Game project)
  • Schedule
  • Milestones / Check points
  • Risk management
  • ?????
  • ???? (Team building)
  • ???
  • GDD
  • MDD
  • TDD
  • The Team

23
????(Production)
  • ??????
  • Modeling
  • Textures
  • Animation
  • Motion
  • FX
  • ???? (Coding)
  • ??????

?? !
24
????(Integration)
  • ???? (Level integration)
  • ???? (Number tuning)
  • ???? (Audio)
  • ??????
  • ???????
  • Testing within the game team
  • Focus group (User study)
  • Release some playable levels for focus group.
  • Get the feedback from focus group to adjust the
    game play.
  • Invited outside game players but evaluation
    in-house

25
????(Test)
  • Alpha ??
  • ?? (Debug)
  • Make the game stable
  • Beta ??
  • ????
  • Game play ??
  • ??????? (MMOG)
  • ???? (Closed beta)
  • Invited game players
  • ???? (Open beta)
  • Free for public players
  • ???? (Critical testing)
  • Only for MMOG
  • Continuously implementing
  • For servers

26
Bugs
  • Bug ?? (Bug Classification)
  • A Bug
  • B Bug
  • C Bug
  • S Bug
  • Principles
  • Bug ????
  • Tester vs Debugger

27
Game Software System
Game
Game Play Layer
Engine Layer
System Layer
Hardware
28
System Layer APIs (1/2)
  • 3D Graphics API
  • DirectX 9.0 SDK Direct3D
  • Newest update DirectX 9.0c SDK Update (June,
    2005)
  • OpenGL
  • 2.0
  • 2D API
  • DirectX 9.0 SDK - DirectMedia
  • Win32 GDI
  • Input device
  • DirectX 9.0 SDK DirectInput
  • Audio
  • DirectX 9.0 SDK DirectSound / Direct3DSound /
    DirectMedia
  • OpenAL

29
System Layer APIs (2/2)
  • OS API
  • Win32 SDK
  • MFC
  • Network
  • DirectX 9.0 SDK DirectPlay
  • Socket library

30
Engine Layer (1/2)
  • 3D scene management system
  • Scene graph
  • Shaders
  • 2D sprite system
  • Audio system
  • Gamepad
  • Hotkeys
  • Mouse
  • Timers
  • Network
  • DDK interface

31
Engine Layer (2/2)
  • Terrain system
  • Advanced scene management system
  • Space partition technique
  • BSP Tree
  • Octree
  • Character system
  • Bone-skin
  • Motion Blending
  • Dynamics
  • Particle system
  • Rigid-body dynamics
  • Collision detection
  • Sound FX
  • User interface

32
Game Play Layer
  • NPC (Non-playable characters) management
  • Game AI
  • Path finding
  • Finite state machine (FSM)
  • Steering behavior
  • Avatar
  • Combat system
  • FX system
  • Script system
  • Trading system
  • Number system

33
Game Development Tools for Programming (1/2)
  • System Tools
  • Visual C/C
  • .Net 2003
  • VC/C 7.1
  • Visual C/C 6.0 SP5
  • NuMega BoundsChecker
  • Finding memory leaking
  • Intel vTune
  • Finding computation performance bottlenecks
  • for CPU
  • PIX
  • Finding graphics performance bottlenecks
  • For GPU

34
Game Development Tools for Programming (2/2)
  • SDKs
  • System API
  • Win32 SDK or MFC
  • DirectX SDK or OpenGL
  • Socket library
  • Middleware (Game engine)
  • Renderware
  • Unreal
  • Physics
  • ODE

35
Game Development Tools for Artists
  • 3D tools
  • Discrete 3dsMax
  • Maya
  • Softimage XSI
  • 2D tools
  • Photoshop
  • Illustrator
  • Motion tools
  • Motion capture devices
  • Motion Builder
  • FiLMBOX

36
2nd Game System Analysis
37
What Will We Talk
  • The idea about system analysis (SA)
  • Mind mapping
  • Case study - Term project

38
Why System Analysis (1/2)
  • For ???? analysis
  • The main program
  • Game development tools
  • To identify ???
  • New game engine ?
  • Re-used code ?
  • Tools needed to be developed ?
  • For ?? management
  • Total man month
  • How many programmers ?
  • How good the programmers ?
  • For job dependency analysis

39
Why System Analysis (2/2)
  • To do technical possibility analysis
  • ???????
  • RD ?
  • Where is the technical bottleneck ?
  • Pre-processor for
  • Technical design document
  • Project management
  • Bridge from game design to programming

40
Something about System Analysis
  • No standard procedures or approaches
  • Its not a theory.
  • Experience
  • You can use your own method/tool
  • UML
  • Mind mapping
  • ????
  • This is the one we will use in this course

41
Wangs System Analysis Steps
  • Brainstorming
  • Integration
  • Dependency analysis
  • Create the project
  • Technical design document (TDD) writing

42
Brainstorming
  • Based on the game design to put everything as
    many as you could
  • Use mind mapping
  • Including
  • Game system
  • Combat / Village / Puzzle /
  • Program modulus
  • Camera / PC control / NPC AI / UI / FX /
  • Tools
  • Level editor / Scene editor /
  • Entities in games
  • Characters / vehicle / terrain / audio /

43
Integration
  • Confirm the resource limitation
  • Technical implement possibility
  • Put all related items together
  • Man month analysis
  • How many ?
  • Who ?
  • Jobs / System identification

44
Dependency Analysis
  • Sort the Jobs
  • By job dependency
  • By programmers schedule
  • Prototype for scheduling

45
System Analysis Create the Project
  • Scheduling
  • Job assignment
  • Resource allocation
  • Check points
  • Milestones
  • Major check points
  • Output
  • Risk management
  • Alternatives
  • Risk management policy

46
Technical Design Document
  • Specification
  • Resources
  • Design in details
  • Implement methods (??)
  • Algorithms
  • Project
  • Output in each milestone
  • SOP (optional)
  • TDD Template

47
Mind Map
  • ????
  • A radiant thinking tool
  • Applications
  • ????
  • Proposal
  • ????
  • ??
  • System Analysis
  • Reference
  • Programs
  • Visio
  • MindManager
  • Books
  • Tony Buzan, Barry Buzan
  • The Mind Map Book How to Use Radiant Thinking
    to Maximize Your Brain's Untapped Potential

48
(No Transcript)
49
(No Transcript)
50
Mind Map Demo Using MindManager
  • Use MindManager X5 pro
  • Developed by MindJet

51
3rd The Game Main Loop
52
Win32 Application (1/3)
int APIENTRY WinMain(HINSTANCE hInst, HINSTANCE
hPrevInst, LPSTR lpCmdLine, int nCmdShow)
WNDCLASSEX wc ... // register window
class ZeroMemory(wc, sizeof(WNDCLASSEX))
wc.style CS_OWNDC CS_HREDRAW
CS_VREDRAW CS_DBLCLKS wc.lpfnWndProc
KKMainProc ... RegisterClassEx(wc)
... // the main loop KKMainLoop() //
unregister the window class UnregisterClass(wc.
lpszClassName, hInst) return id
53
Win32 Application (2/3)
LRESULT CALLBACK KKMainProc(HWND hWnd, UINT uMsg,
WPARAM wParam, LPARAM lParam) LRESULT l
FALSE ... // switch for all incoming
messages from WindowsXX switch (uMsg)
case WM_KEYDOWN ... l TRUE
break ... // echo the result if
(l) return l else
return DefWindowProc(hWnd, uMsg, wParam,
lParam)
54
Win32 Application (3/3)
void KKMainLoop() MSG msg BOOL kkBeQuit
FALSE // the main loop while
(!kkBeQuit) // check window's messages
while (PeekMessage(msg, NULL, 0, 0,
PM_REMOVE)) if (msg.message
WM_QUIT) kkBeQuit TRUE
// invoke the WindowsX to handle the
incoming messages TranslateMessage(msg)
DispatchMessage(msg)
// do your jobs here, for example, check the
timing and do something in regular ...

55
Event-driven Programming
  • Win32 programs are event-driven
  • Messages events
  • So as all windows system (for example X window)
  • We need an infinitive loop to check all incoming
    events.
  • In the loop
  • Check if there are incoming events (messages)
  • Handle the events
  • Check the time and do something in regular
  • Incoming events
  • Interrupts
  • System requests

56
Timers Events (1/2)
  • Timers (do something in regular timing)
  • The sub-system to handle timing
  • Must be precise to at least 1 ms or less
  • 30fps 1/30 second 33.333 ms
  • On win32 platform, you can use performance
    counter instead of the win32s WM_TIMER
    message
  • For windows9x, WM_TIMER 18.2 fps (maximum)
  • Events
  • Input devices
  • Mouse
  • Keyboard
  • Something coming from network
  • System requests
  • Re-draw
  • Losing/getting the input focus

57
Timers Events (2/2)
  • Two types of jobs (Callbacks) to do (Call)
  • In regular
  • Timers callbacks
  • By requests
  • Input device callbacks
  • So as the game main program
  • A game is an interactive application.
  • Mouse
  • Hotkeys
  • Gamepads
  • A game is time-bound.
  • Rendering locked in 30fps or 60fps
  • Motion data produced in 30fps
  • Game running in 30fps

58
Implement the Timer (1/6)
  • On PC platform use Performance Counter
  • QueryPerformanceFrequency()
  • QueryPerformanceCounter()

// timers data structure typedef struct BOOL
beAble // is the timer is
enabled/disabled ? BOOL be1st // is
this the 1st time for the timer to be checked
// after last
initialization ? BOOL beLockFps // is
locked on FPS ? double initTime // initial
time double timeInv // system ticks for
one frame double nxtTime // next checking
time void (timer)(int) // timer's callback
double resetTime // reset time TIMERs,
TIMERptr
59
Implement the Timer (2/6)
/------------------------------------------------
---------------------- initialize a timer and
bind a user-defined timer callback
--------------------------------------------------
----------------------/ void FyBindTimer(DWORD
id, float fps, void (fun)(int), BOOL beLock)
if (id lt 0 id gt MAXTIMERS) return /
assign the timer's callback /
fyTimerid.timer fun / set lock-to-fps
flag / fyTimerid.beLockFps beLock /
calculate the ticks for one frame /
fyTimerid.timeInv (double) (fyFreq) /
(double) fps fyTimerid.be1st TRUE
fyTimerid.beAble TRUE
60
Implement the Timer (3/6)
/------------------------------------ get
current system clock tick -----------------------
---------------/ double FYGetCurrentSystemTick()
LARGE_INTEGER timeCount / get current
tick / QueryPerformanceCounter(timeCount)
return (double) timeCount.QuadPart / //
get the system ticks for one second
QueryPerformanceFrequency(timeFreq) fyFreq
timeFreq.LowPart /
61
Implement the Timer (4/6)
/------------------------------------------------
------------ invoke the TheFly3D system to
handle the timers -------------------------------
-------------------------------/ void
FyInvokeTheFly(BOOL beTimer) MSG msg if
(fyBeQuit) return while (!fyBeQuit)
// check window's messages while
(PeekMessage(msg, NULL, 0, 0, PM_REMOVE))
if (msg.message WM_QUIT) fyBeQuit TRUE
TranslateMessage(msg)
DispatchMessage(msg) // check
the timer if (beTimer fyBeTimer)
FYInvokeTimer()
62
Implement the Timer (5/6)
/--------------------- check all timers
----------------------/ void FYInvokeTimer()
int i, skipS double dTime // get
current time dTime FYGetCurrentSystemTick()
for (i 0 i lt MAXTIMERS i) if
(fyTimeri.beAble fyTimeri.timer ! NULL)
// for the first time .....
if (fyTimeri.be1st) // initialize
the timer fyTimeri.be1st FALSE
fyTimeri.initTime dTime
fyTimeri.nxtTime dTime fyTimeri.timeInv
((fyTimeri.timer))(1)

63
Implement the Timer (6/6)
else if
(fyTimeri.beLockFps) if (dTime
gt fyTimeri.nxtTime) //
calculate skip frames skipS
(int)((dTime - fyTimeri.nxtTime) /
(double)fyTimeri.timeInv) 1
// get next checking time
fyTimeri.nxtTime (double) (skipS
fyTimeri.timeInv) // check
some abnormal conditions ...
// invoke the timer callback
((fyTimeri.timer))(skipS)
else
((fyTimeri.timer))(1)

64
Game Loop (1/2)
  • Single player

65
Game Loop (2/2)
  • Network client

Loop
y
Check game over
Exit
n
Peek user input
Receive messages
From network
Timer callbacks
To network
Send messages
Rendering
66
Jobs in Regular (In Timers)
  • Check Win/Lose
  • Check Quit
  • Make objects moving
  • Play characters motion to the next frame
  • Play animation to the next frame
  • Models
  • Textures
  • Perform game logic calculation
  • Perform geometry associated calculation
  • i.e. LOD
  • Perform AI Thinking
  • Perform collision detection
  • Perform the 3D rendering
  • Play FX

67
Jobs By Request
  • Mouse Input
  • Press/release the mouse button
  • Drag
  • Double-click
  • Move
  • Keyboard Input
  • Hotkey
  • Typing
  • Gamepad
  • Same behavior as the hotkey
  • Except looking not like the keyboard
  • Network
  • System

68
4th TheFly3D Game Engine
69
The Main Program
void main(int argc, char argv) // create
the game world 3D scene ... // set
Hotkeys FyDefineHotKey(FY_ESCAPE, QuitGame,
FALSE) ... // define some mouse
functions FyBindMouseFunction(LEFT_MOUSE,
InitPivot, PivotCam, EndPivot, NULL) ...
// bind a timer for rendering, frame rate 60
fps FyBindTimer(0, 60.0f, RenderIt, TRUE)
// bind a timer for game AI, frame rate 30 fps
FyBindTimer(1, 30.0f, GameAI, TRUE) //
invoke the system FyInvokeTheFly(TRUE)
70
Hotkey Callback
//------------------- // quit the
game //------------------- void QuitGame(WORLDid
gID, BYTE code, BOOL value) if (code
FY_ESCAPE) if (value)
FyWin32EndWorld(gID)
71
Mouse Callback
/-----------------------------------------
initialize the pivot of the camera
------------------------------------------/ void
InitPivot(WORLDid g, int x, int y) oldX
x oldY y
/------------------ pivot the camera
-------------------/ void PivotCam(WORLDid g,
int x, int y) FnModel model if (x !
oldX) model.Object(cID)
model.Rotate(Z_AXIS, (float) (x - oldX),
GLOBAL) oldX x if (y ! oldY)
model.Object(cID)
model.Rotate(X_AXIS, (float) (y - oldY),
GLOBAL) oldY y
72
The Timer Callback
//------------------------------------------------
---------------------------------------- //
Render callback which will be invoked by TheFly3D
every 1/60 second //------------------------------
--------------------------------------------------
-------- void RenderIt(int skip) FnViewport
vp FnWorld gw // render the scene
vp.Object(vID) vp.Render(cID, TRUE, TRUE)
// perform double-buffering gw.Object(gID)
gw.SwapBuffers()
73
Introduction to TheFly3D
  • A real-time 3D graphics programming library
  • Using C
  • Cross-platform
  • DirectX9.0c
  • OpenGL 1.5
  • An API for 3D graphics developers
  • Provide a fundamental scene management system
  • Scene tree
  • Built-in visibility culling
  • According to the experiences from the author,
    some game development features are added.
  • Characters
  • Terrain system
  • Current version 0.8a1 (0920, 2005)
  • Shader has been added in D3D version

74
TheFly3D in A Chart
Game
Game Play Layer
Terrain
Collision
Character
UI
Dynamics
Sound FX
Engine Layer
3D Scene Mngmt
2D Sprite
Gamepad
Network
Audio
3D Graphics API
2D API
Input Device
OS API
System Layer
Hardware
Developing
Developed
75
Development Environment
  • .NET2003 Visual C 7.1
  • DirectX9.0c SDK (Dec, 2004)
  • Two include files (must!)
  • TheFly.h
  • TheFlyWin32.h (Win32 version D3D)
  • Linked libraries (API version)
  • TheFlyLibD_08_01.lib
  • d3d9.lib d3dx9.lib dsound.lib dxguid.lib
    winmm.lib

76
Create the Visual C Project for TheFly3D
  • Create folders for TheFly3D API
  • \include
  • \lib
  • New a Win32 application project
  • Set the additional include/library directories to
    TheFly3D API
  • Add DirectX 9.0 SDKs include/lib to additional
    search directories
  • Add d3d9.lib d3dx9.lib dsound.lib dxguid.lib
    winmm.lib to additional dependencies
  • Add TheFly.h, TheFlyWin32.h, TheFly3DLibD_xxxx.lib
    into the project

77
The 1st TheFly3D Program hello.cpp
  • Create a 3D world
  • Create a viewport
  • Create a scene
  • Create 3D entities
  • A camera
  • A teapot model
  • A light source
  • Translate the camera to show the model
  • Bind callbacks to make the program interactive

78
Demo - Hello
Do it!
79
The Basics to Write TheFly3D Program
  • All Win32 code is transparent.
  • void main(int argc, char argv)
  • All Win32 DirectX code are hidden within the
    engine.
  • ID Function class
  • TheFly3D creates the objects for you.
  • Return the object ID
  • TheFly3D owns the objects.
  • You have the right to handle the objects.
  • Use function classes
  • No internal data structure functions revealed

// create a viewport vID
gw.CreateViewport(ox, oy, ww, hh) FnViewport
vp vp.Object(vID) vp.SetBackgroundColor(0.
3f, 0.3f, 0.0f)
80
Initialize TheFly3D
  • In general the 1st function to use TheFly3D is
  • FyWin32CreateWorld()
  • After the calling successfully, you can get the
    non-zero ID (WORLDid) of a world object.
  • Assign the ID to a world function class object
    for manipulating the world.

// create a new world WORLDid gID
FyWin32CreateWorld(Tester", 0, 0, 800, 600, 16,
FALSE) FnWorld gw gw.Object(gID)
gw.SetTexturePath("Data\\textures")
81
The World in TheFly3D
  • A world is a set of graphics layers where the 3D
    objects acts on.

82
The 3D Graphics Layer
  • A 3D graphics layer is a projection of the
    rendering of a 3D view.
  • The set of the 3D objects in the view
  • We call it the Scene.
  • The projection we call the Viewport

83
The Viewports Scenes
  • TheFly3D supports the multiple viewports.
  • A scene can be rendered on different viewports.
  • Viewports scenes are created by the world
    object.

// create a new world WORLDid gID gID
FyWin32CreateWorld(Tester", 0, 0, 800, 600, 16,
FALSE) FnWorld world world.Object(gID)
SCENEid sID world.CreateScene()
VIEWPORTid vID world.CreateViewport(0, 0, 400,
300) world.DeleteScene(sID)
world.DeleteViewport(vID)
84
The Scene
  • A scene is not a real 3D object, just a set
    of 3D objects.
  • A scene provides multiple rendering groups to
    handle the priority sorting for the rendering of
    3D objects.
  • There are three object lists within a rendering
    group.
  • Invisible list
  • Opacity list
  • Semi-transparent list
  • The objects are rendered by the order of
    rendering groups.
  • In the same rendering group, the opaque objects
    are rendered first.
  • And the semi-transparent objects are sorted and
    rendered from far to near

85
The 3D Entities Objects
  • A 3D scene is constructed by a set of objects
    which are the basic entities in a scene.
  • An object is a carrier to carry real 3D data
    including
  • Model geometry
  • Camera data
  • Lighting data
  • Terrain data
  • Particle emitters
  • Forces
  • Audio
  • Objects are created/deleted by its host scene.
  • Objects can be switched between scenes.
  • Objects should be assigned to a rendering group.

86
The Objects Can
  • Can have shapes (geometric data)
  • Can be grouped (hierarchy)
  • Can move (transformation)
  • Can look alike (clone or data sharing)
  • Can perform (animation or deformation)
  • Can be affected (lighted, listened)
  • Can be changed dynamically (modification)

87
A Scene Object
88
A Model Object
  • An object to carry a set of geometry data is a
    model object
  • You can load the model data from files.
  • TheFly3D loads .cw3 model files in default.

// create 3D entities nID
scene.CreateObject(ROOT) FnObject model
model.Object(nID) // load a teapot
model.Load("Teapot.cw3")
89
TheFly3D Scene Tree
  • A tree-based representation
  • Simplified scene graph

Root
90
TheFly3D Scene Tree Is Simplified Scene Graph
  • A tree-based representation
  • Simplified scene graph

Root
91
Object Hierarchy
nID scene.CreateObject(ROOT) cID
scene.CreateCamera(ROOT) FnObject
model model.Object(nID) model.SetParent(cID)
cID
nID
92
Clone a Model Object
OBJECTid nID scene.CreateObject(ROOT) FnObject
model model.Object(nID) OBJECTid nID1
model.Instance()
nID
nID1
Data
instance
93
TheFly3D Major Model Object Functions (1/2)
  • void model.SetParent(parent_object_ID)
  • void model.Show(be_show)
  • void model.SetOpacity(opacity)
  • opacity 0.0 1.0
  • void model.SetRenderMode(mode)
  • mode WIREFRAME or TEXTURE
  • OBJECTid clonedID model.Instance()
  • void model.ChangeScene(sID)
  • BOOL model.Load(char file)
  • Load a .cw3 model file to a model object
  • void model.ShowBoundingBox(beShow)
  • void model.Translate(x, y, z, op)

94
TheFly3D Major Model Object Functions (2/2)
  • model.SetRenderOption(item, value)
  • (item, value)
  • (Z_BUFFER, TRUE/FALSE)
  • (Z_BUFFER_WRITE, TRUE/FALSE)
  • (ALPHA, TRUE/FALSE)
  • Add/remove the model to/from alpha sorting list
  • (FOG, TRUE/FALSE)
  • (SPECULAR, TRUE/FALSE)
  • (LIGHTING, TRUE/FALSE)
  • (ANTIALIASING, TRUE, FALSE)
  • (SOURCE_BLEND_MODE BLEND_ZERO / BLEND_ONE /
    BLEND_SRC_COLOR / BLEND_INV_SRC_COLOR /
    BLEND_SRC_ALPHA /
    BLEND_INV_SRC_ALPHA / BLEND_DEST_ALPHA /
    BLEND_INV_DEST_ALPHA /
    BLEND_DEST_COLOR / BLEND_INV_DEST_COLOR /
    BLEND_SRC_ALPHA_SAT / BLEND_BOTH_SRC_ALPHA /
    BLEND_BOTH_INV_SRC_ALPHA)
  • (DESTINATION_BLEND_MODE values are same as the
    SOURCE_BLEND_MODE)

95
Coordinate System
  • Every model should have its own local coordinate
    system.
  • Local space
  • Model space
  • The space when its modeled
  • To its parent model, it is in the global space.
  • Global space
  • The space for reference
  • World space
  • The global space of the Root

96
Transformation
  • Three basic linear transformations used in
    TheFly3D.
  • Translate
  • Rotate
  • Scale
  • Principles
  • Right-handed rule
  • v v M0 M1
  • Matrix in 12-element (I call the M12)

97
Translation
model.Translate(dx, dy, dz, op)
x x dx y y dy z z dz
(dx dy dz)
1 0 0 0 1 0 0 0 1 dx dy dz
T
98
Rotation
i.e. rotate with z axis
model.Rotate(Z_AXIS, 30.0f, op)
z
x x cosq y sinq y x sinq y cosq z z
y
cosq sinq 0 -sinq cosq 0 0 0 1 0
0 0
x
Rz
99
Scaling
model.Scale(sx, sy, sz, op)
x x sx y y sy z z sz
sx 0 0 0 sy 0 0 0 sz 0 0 0
T
100
Matrix Operations
  • Matrix operation
  • REPLACE, LOCAL, GLOBAL

Z
Y
X
op LOCAL
z
op REPLACE
x
y
M
ML
MG
op GLOBAL
Object Transformation Matrix
101
TheFly3D Model Transformation Functions
  • model.Translate(x, y, z, op)
  • op LOCAL, GLOBAL, or REPLACE
  • model.Rotate(axis, angle, op)
  • op LOCAL, GLOBAL, or REPLACE
  • axis X_AXIS, Y_AXIS, Z_AXIS
  • model.Scale(sx, sy, sz, op)
  • op LOCAL, GLOBAL, or REPLACE
  • model.Quaternion(w, x, y, z, op)
  • w the scalar part of the quaternion
  • x, y, z the vector part of the quaternion
  • The quaternion should be a unit quaternion
  • op LOCAL, GLOBAL, or REPLACE
  • model.SetMatrix(M12, op)
  • M12 an M12 matrix
  • op LOCAL, GLOBAL, or REPLACE
  • float model.GetMatrix()
  • Get the pointer of the model objects matrix

102
Transformations vs Movements
  • Transformation is the term used in computer
    graphics but not friendly for games.
  • We use movements to control the 3D objects moving
    around in the scene.
  • Move forward
  • Move right
  • Move up
  • Turn right
  • Turn left

103
Facing Direction and Up Direction
  • Each object is modeled with a facing direction
    and up direction visually
  • In TheFly3D, we use y axis as the default facing
    direction for a model, z axis as the default up
    direction
  • But for a camera
  • -z axis is the facing direction
  • y axis is the up direction

104
Move Forward (1/2)
new position old position
distance (facing direction in unit)
105
Move Forward (2/2)
  • The object has a local coordinate system.
  • Align a local axis of the object with the facing
    direction
  • Make a translation to move the object align the
    local axis
  • Apply the matrix first before to apply the
    existing transformations (op LOCAL)
  • Then the object is moving forward!

FnObject model model.Object(nID) model.Translat
e(0.0f, -dist, 0.0f, LOCAL) // facing to -y
106
Turn Right/Left (1/2)
  • An example (rotate with an arbitrary axis)

-1 -1
-1 M T1 R1 R2 Rx(angle) R2 R1
T1 T1 / 1 0 0 0 R1 / cs2 -sn2 0
0 0 1 0 0 -z sn2 cs2 0 0
0 0 1 0 0 0 1 0
-x -y -z 1 / 0 0 0 1 / R2
/ cs1 0 -sn1 0 Rx / 1 0 0 0 y
0 1 0 0 0 cs sn 0 sn1
0 cs1 0 0 -sn cs 0 0 0
0 1 / 0 0 0 1 /
107
Turn Right/Left (2/2)
  • The object has a local coordinate system
  • Align a local axis of the object with the up
    direction
  • Make a rotation matrix to turn the object along
    the local axis
  • Apply the matrix first before to apply the
    existing transformations
  • Then the object is turning !

FnObject model model.Object(nID) model.Rotate(Z
_AXIS, -angle, LOCAL) // turn right
108
Terrain
  • A terrain is a place for 3D objects to walk on
  • A terrain can be generated from a model file
  • Neighboring triangles are the next searching
    target for current triangle for terrain following
  • A terrain for terrain following is not the same
    as the terrain in visual

109
Generate Terrain in TheFly3D
// create a terrain object tID
scene.CreateTerrain() FnTerrain
t t.Object(tID) // load a terrain model (just
like a regular object) // but a terrain is
invisible in default t.Load("test_terrain_followin
g.cw3") // generate the neighboring data for
terrain following // otherwise, the terrain model
is for visual only t.GenerateTerrainData()
110
Put a Model on Terrain Using TheFly3D
// if tID is the terrain object (OBJECTid) //
load a model OBJECTid nID scene.CreateObject(RO
OT) FnObject obj obj.Object(nID) // put the
model on terrain float pos3 pos0 x pos1
y pos2 10000.0f // should be higher
than the terrain! obj.SetPosition(pos) obj.PutOnT
errain(tID, be3D, offset, rangeF, rangeB, angle)
111
Terrain Following
Terrain Following (3D)
offset
Terrain Following (2D)
offset
112
Probe for a Model on Terrain
probeBack
probeFront
terrain following check point
113
TheFly3D Model Movement Functions (1/3)
  • void model.GetPosition(pos)
  • pos is a 3D vector to get the position of the
    model object
  • void model.GetDirection(faceDir, upDir)
  • If you just want to get one of the directions,
    just send NULL pointer to the one that you do not
    want to query
  • void model.SetPosition(pos)
  • The position is related to its parent object
  • void model.SetDirection(faceDIr, upDir)
  • If you just want to set one of the directions,
    just send NULL pointer to the one that you do not
    want to set
  • Void model.SetDirectionAlignment(fDAxis, uDAxis)
  • You can change the local axes for facing and up
    directions

114
TheFly3D Model Movement Functions (2/3)
  • BOOL model.PutOnTerrain(tID, be3D, offset,
    probeFront, probeBack, probeAngle, hightLimit)
  • tID is a terrain object
  • be3D TRUE for 3D terrain following
  • Offset is the height above the terrain
  • hightLimit is the terrain following height limit
  • Return TURE if you successfully put the model on
    a terrain
  • int model.MoveForward(dist, beTerrainFollow,
    be3D, offset)
  • If you just want to move the model forward but
    not on terrain, set beTerrainFollow to FALSE
  • You should put a model on terrain first. Then you
    can move it forward on terrain.
  • Return value
  • WALK (ok for moving)
  • BOUNDARY (hit the terrain boundary)
  • BLOCK (not implemented yet, for collision)
  • DO_NOTHING (something wrong )

115
TheFly3D Model Movement Functions (3/3)
  • int MoveRight(dist, beTerrainFollow, be3D,
    offset)
  • Same as the MoveForward except moving in
    right-hand direction
  • void model.TurnRight(float angle)
  • Angle is in degree format
  • int model.GetCurrentTerrainTriangle()
  • Get current triangle ID in terrain, where the
    model is standing

116
A Character
117
Character with motion
118
Introduction to Characters
  • The characters are the actors of the games.
  • Three types of characters implemented in games
  • Segmented
  • Mesh
  • Bone-skin
  • Root-base concept
  • Production
  • 3D animation tools
  • Motion capture (MoCap)
  • For motion data

119
A Segmented Character
  • A character is composed by a set of models with
    motion data to simulate a live creature in real
    world
  • Benefits
  • Hierarchical structure
  • Easy to implement in a scene tree
  • Drawbacks
  • Segment-like

120
  • The scene tree of a segmented character

head
up arm
hand
body
groin
fore arm
Base
thigh
groin
foot
shin
body
thigh_r
thigh_l
head
up_arm_r
shin_r
up_arm_l
shin_l
fore_arm_l
fore_arm_r
foot_r
hand_l
foot_l
hand_r
121
A Mesh Character
  • Vertex animation on skins
  • Animated positional data on skins
  • 3D warping
  • Benefits
  • Easy to implement
  • Flexible mesh in animation
  • Drawbacks
  • No hierarchy
  • Each frame is independent.
  • Massive dataset

122
A Bone-skin Character
  • Bone-skin skeleton
  • Hierarchical bones
  • Skin deformation run-timely
  • Benefits
  • Hierarchical structure
  • Not segmented look
  • Drawbacks
  • More complicated than the other solutions
  • Skin deformation need more CPU cost than
    transformation only

123
Motion Production by 3D Animation Tools (1/2)
  • Keyframe system
  • 3ds MAX
  • Softimage
  • Maya

124
Motion Production by 3D Animation Tools (2/2)
  • Low cost (relatively)
  • Easy to combine animations
  • Hand-made animations
  • Hard to make good motions
  • Long production time

125
Motion Production by Motion Capture (1/2)
  • Motion Capture
  • MoCap in short
  • Types
  • Optical
  • Magnetic
  • ...

126
Motion Production by Motion Capture (2/2)
  • Expensive solution
  • Hardware and software
  • Every frame is a keyframe
  • Very live motion
  • Noise !
  • Need post-processing for games
  • Patching the data
  • Re-keyframing
  • Cleaning noise
  • Re-targeting
  • Hard to combine motions

127
The Root-Base Concept (1/2)
  • Use root-base structure to construct the character

Base
Root (groin)
Base
128
The Root-Base Concept (2/2)
  • A character has some models to be the geometry
    roots of the character system.
  • The root plays as the gravity center of the
    character.
  • The root can be translated and rotated.
  • The others are joints.
  • The joints can rotate only.
  • A ghost object is added to be the parent of the
    root, which is the base of the character.
  • The base is the center for the characters
    movement.
  • We move the base to perform characters moves.

129
Motion Data - Pose
  • A set of frames to describe a characters motion
  • For examples Walk, run, attack,
  • Keyframed or non-keyframed
  • Motion data in
  • Position (pivot) quaternion
  • Position (pivot) Euler angles
  • Position (pivot) (q, n)
  • Matrix

130
Load a Character
FnScene scene CHARACTERid actorID scene.Object(
sceneID) actorID scene.LoadCharacter(fm.cwc
")
.cwc is a character description file.
131
Play a Pose
BLENDTREEid btID actor.GetBlendTree()
FnBlendTree bt bt.Object(btID) // the
2nd motion definition BLENDNODEid aaaID
aaaID bt.CreateAnimationNode(2) // start
to play a pose (1st time) actor.PlayBlendNode(a
aaID, (float) 0, START, TRUE) // continue to
play a pose actor.PlayBlendNode(CURRENT,
(float) skip, LOOP, TRUE)
132
Make a Character to Move Forward
FnCharacter actor // play walking
pose actor.Object(actorID) actor.PlayBlendNode(CU
RRENT, (float) skip, LOOP, TRUE) // move it
forward actor.MoveForward(dist, beTF, be3D,
offset)
133
TheFly3D Character Movement Functions (1/2)
  • void actor.GetPosition(pos)
  • pos is a 3D vector to get the position of the
    character
  • void actor.GetDirection(faceDir, upDir)
  • If you just want to get one of the directions,
    just send NULL pointer to the one that you do not
    want to query
  • void actor.SetPosition(pos)
  • The position is related to its parent object
  • void actor.SetDirection(faceDIr, upDir)
  • If you just want to set one of the directions,
    just send NULL pointer to the one that you do not
    want to set
  • BOOL actor.PutOnTerrain(tID, be3D, offset,
    probeFront, probeBack, probeAngle, hightLimit)
  • tID is a terrain object
  • be3D TRUE for 3D terrain following
  • Offset is the height above the terrain
  • hightLimit is the terrain following height limit
  • Return TURE if you successfully put the character
    on a terrain

134
TheFly3D Character Movement Functions (2/2)
  • void actor.MoveForward(dist, beTF, be3D, offset)
  • If you just want to move the character forward
    but not on terrain, set beTF to FALSE
  • You should put a character on terrain first. Then
    you can move it forward on terrain.
  • A character is always using his local -y-axis as
    facing direction
  • void actor.TurnRight(float angle)
  • Angle is in degree
  • A character is always using his local z-axis as
    up direction

135
TheFly3D Character Functions
  • OBJECTid actor.GetBaseObject()
  • You can get the base object of the character
  • OBJECTid actor.GetObjectByName(name)
  • You can get the each model part of the character
    by its name in character file
  • For a bone-skin character, this function can get
    the bones in the skeleton
  • BOOL actor.PlayFrame(frame, beIncludeBase)
  • The function is to play the motion for a specific
    frame
  • Set beIncludeBase TRUE to play the base
    objects motion
  • BLENDTREEid actor.GetBlendTree()
  • Get the characters blend tree data
  • You can define all poses in a blend tree (blend
    nodes)
  • float actor.PlayBlendNode(btNodeID, skipFrame,
    mode, beIncludeBase)
  • All poses for a character is defined as a blend
    node
  • Skip frames can be floating-point
  • Mode can be ONCE or LOOP!

136
5th Game Mathematics
137
Essential Mathematics for Game Development
  • Matrices
  • Vectors
  • Fixed-point Real Numbers
  • Triangle Mathematics
  • Intersection Issues
  • Euler Angles
  • Angular Displacement
  • Quaternion
  • Differential Equation Basics

138
Matrices (1/7)
  • Matrix basics
  • Definition
  • Transpose
  • Addition

a11 .. a1n . . . . am1 .. amn
A (aij)
C A T cij aji
C A B cij aij bij
139
Matrices (2/7)
  • Scalar-matrix multiplication
  • Matrix-matrix multiplication

C aA cij aaij
r
C A B cij Saikbkj
k 1
140
Matrices (3/7)
  • Transformations in Matrix form
  • A point or a vector is a row matrix (de facto
    convention)

V x y z
  • Using matrix notation, a point V is transformed
    under translation, scaling and rotation as

V V D V VS V VR
where D is a translation vector and S and R are
scaling and rotation matrices
141
Matrices (4/7)
  • To make translation be a linear transformation,
    we introduce the homogeneous coordinate system

V (x, y, z, w)
, where w is always 1
  • Translation Transformation

x x Tx y y Ty z z Tz
V VT
1 0 0 0 0 1 0 0 0 0 1 0 Tx Ty
Tz 1
x y z 1 x y z 1 x y z
1 T
142
Matrices (5/7)
  • Scaling Transformation

x xSx y ySy z zSz
V VS
Sx 0 0 0 0 Sy 0 0 0 0 Sz 0 0
0 0 1
x y z 1 x y z 1 x y z
1 S
Here Sx, Sy and Sz are scaling factors.
143
Matrices (6/7)
  • Rotation Transformations

1 0 0 0 0 cosq sinq 0 0 -sinq cosq 0 0
0 0 1
Rx Ry Rz
cosq 0 -sinq 0 0 1 0 0 sinq 0 cosq 0 0
0 0 1
cosq sinq 0 0 -sinq cosq 0 0 0 0 1 0
0 0 0 1
144
Matrices (7/7)
  • Net Transformation matrix

x y z 1 x y z 1 M1 and x y z
1 x y z 1 M2 then the transformation
matrices can be concatenated M3 M1
M2 and x y z 1 x y z 1 M3
  • Matrix multiplication are not commutative

M1 M2 M2 M1
145
Vectors (1/5)
  • A vector is an entity that possesses magnitude
    and direction.
  • A 3D vector is a triple
  • V (v1, v2, v3), where each component vi is a
    scalar.
  • A ray (directed line segment), that possesses
    position, magnitude and direction.

V (x2-x1, y2-y1, z2-z1)
(x1,y1,z1)
(x2,y2,z2)
146
Vectors (2/5)
  • Addition of vectors

X V W (x1, y1, z1) (v1 w1, v2 w2,
v3 w3)
W
V W
W
V W
V
V
  • Length of vectors

V (v12 v22 v32)1/2 U V / V
147
Vectors (3/5)
  • Cross product of vectors
  • Definition

X V X W (v2w3-v3w2)i (v3w1-v1w3)j
(v1w2-v2w1)k where i, j and k are standard
unit vectors i (1, 0, 0), j (0, 1, 0), k
(0, 0, 1)
  • Application
  • A normal vector to a polygon is calculated from 3
    (non-collinear) vertices of the polygon.

Np
polygon defined by 4 points
V2
Np V1 X V2
V1
148
Vectors (4/5)
  • Transformation of the normal vectors

N(X) detJ J-1T N(x) where X F(x) J the
Jacobian matrix, Ji(x)
dF(x)
dxi
"Global and Local Deformations of Solid
Primitives" Alan H.
Barr Computer Graphics Volume 18, Number 3 July
1984
149
Vectors (5/5)
  • Dot product of vectors
  • Definition

X V . W v1w1 v2w2 v3w3
  • Application

V
q
W
V . W
cosq
VW
150
Fixed Point Arithmetics (1/2)
  • Fixed point arithmetics n bits (signed) integer
  • Example N 16 gives range 32768 ? a ? 32767
  • We can use fixed scale to get the decimals.

a a / 28
8 integer bits
1
1
1
8 fractional bits
a 315, a 1.2305
151
Fixed Point Arithmetics (2/2)
  • Multiplication then requires rescaling

e a.c a / 28 . c / 28 ? e (a . c) / 28
  • Addition just like normal

e ac a / 28 c / 28 ? e a c
152
Fixed Point Arithmetics - Application
  • Compression for floating-point real numbers
  • 4 bytes reduced to 2 bytes
  • Lost some accuracy but affordable
  • Network data transfer
  • Software 3D rendering (without hardware-assistant)

153
Triangular Coordinate System
ha
(xa,ya,za)
Ac
p
Ab
hb
h
(xb,yb,zb)
Aa
hc
(xc,yc,zc)
Aa
Ab
Ac
h ha hb hc
where A Aa Ab Ac If (Aa lt 0 Ab lt 0
Ac lt 0) than the point is outside the
triangle Triangular Coordinate System
A
A
A
154
Triangle Area 2D
Area of a triangle in 2D xa ya
A ½ xb yb xc yc
xa ya ½ (xayb xbyc xcya
xbya xcyb xayc)
(xa,ya,za)
(xb,yb,zb)
(xc,yc,zc)
155
Triangle Area 3D
Area of a triangle in 3D A ½ (N.
Sum(Pi1 cross Pi2))
where (i1, i2) (a,b), (b,c),
(c,a)
float GmArea3(float x0, float x1, float x2,
float n) float area, len, sum1, sum2,
sum0 len (float) sqrt(n0 n0 n1
n1 n2 n2) 2.0f / find sum of
cross products / sum0 x11 (-x02
x22) x21 (-x12 x02)
x01 (-x22 x12) sum1 x12
(-x00 x20) x22 (-x10 x00)
x02 (-x20 x10) sum2
x10 (-x01 x21) x20 (-x11
x01) x00 (-x21
x11) / find the area / return (sum0
n0 sum1 n1 sum2 n2) / len
156
Triangular Coordinate System - Application
  • Terrain following
  • Interpolating the height of arbitrary point
    within the triangle
  • Hit test
About PowerShow.com
