Research Methods

1
Research Methods

• Collecting, Processing and Analyzing Data

2
Aims of the Session

• The purpose of this session is to
• Alert you to the different types of methodology
  available to you in your research
• Make you aware of the different techniques that
  you might use in collecting, presenting and
  analysing data
• Discuss the different kinds of problems that you
  might encounter in pursuing your research.

3
Contents

• Developing Your Research Questions
• The Different Types of Research
• Selecting Appropriate Research Methods
• Robustness of Methods
• Structuring Your Methodology
• Data Analysis
• Problems with The Research Process
• Summary

4
1. Developing your Research Questions

• This section of the presentation examines what
  you need to do in order to focus your research.

5
The Purpose of Research

• The purpose of research is to contribute to a
  current academic debate, and possibly to advance
  knowledge in some manner. This means that the
  research that you undertake has to be
• Embedded in a recognisable field of study, taking
  account of, and drawing on, past research
• Of interest to other researchers working in the
  same field, and possibly to the wider community
• Generalisable to more than one individual
  experience or circumstance.

6
Typical Research Structure
Conduct Literature Review
The process of research is well-documented. This
diagram more or less describes the activities you
need to undertake. What we will do in this
session, is to look at some of the elements, and
how they fit together.
Select Research Questions
Devise Methodology Research Instruments
Apply Methods Instruments
Perform Statistical Analysis
Test Hypotheses Draw Conclusions
7
Getting Started
The first thing that you will do is to make sure
you are well-informed, and to pose pertinent
questions which your research will answer.
Conduct Literature Review
Select Research Questions
Devise Methodology Research Instruments
Apply Methods Instruments
Perform Statistical Analysis
Test Hypotheses Draw Conclusions
8
Defining Your Field of Study (1)

• You undertake a Literature Review in a particular
  field, in order to ensure that your research is
  embedded within that field, and that you are
  taking account of the methods, issues, results,
  theories and conventions which apply.
• At the end of the literature review, you will
  have narrowed the field down to a relatively
  small topic within the field, and will have some
  unanswered questions which your research will
  try to investigate.
• These focussed questions form the basis of your
  Research.

9
Defining Your Field of Study (2)

• Your Research Questions are crucial, as they
  effectively define both the content of your
  research and the manner in which you carry it
  out.
• Your research methodology is designed
  specifically to attempt to answer these questions
• The data that you collect will be focussed on
  issues relevant to these questions
• Your analysis of the data will seek to provide
  answers to the questions
• Your conclusions will summarise the answers.

10
Research Questions

• Typical research questions might be
• To what extent is the business community in India
  aware of the potential of Bluetooth?
• Is the software currently available for teaching
  arithmetic to 5 year olds appropriate and
  effective?
• Are there differences in the way that men and
  women approach the task of writing software?
• How can historical events be modelled effectively
  using VRML?

11
Defining Your Population

• When framing your Research questions, you need to
  be clear about what set of objects, people or
  events forms the background population in your
  study.
• Are you saying, for example that the CAL software
  you produce is designed for all English-Speaking
  people, all men, all Afro-Caribbeans, all
  children under 5, all those who have been
  diagnosed as dyslexic, or simply to
  Afro-Caribbean boys under 5 with specific
  learning difficulties?
• If you are investigating whether on-line learning
  is effective, is your population students,
  University students, UK University students,
  Liverpool Hope Students, Liverpool Hope Computing
  Students or Liverpool Hope MSc. Computing
  Students?

12
Research QuestionsReferences (SW Library)

• Lewis, Ian. - So you want to do research! a
  guide for beginners on how to formulate research
  questions. - 2nd ed. - Edinburgh Scottish
  Council for Research in Education, 1997. - (SCRE
  publication 2 .. - 1860030327

13
2. The Different Types of Research

• Here we look at the different options available
  to us in carrying out the research.

14
Your Research Focus

• The main focus of your research can be
• Product-based Research, focusing on producing a
  piece of hardware or software (or the designs for
  them) which is at the cutting edge of a
  discipline, drawing on other researchers ideas,
  best practice and what is feasible. In doing
  this, you may need to explore how the product
  will enmesh with current systems, and existing
  and future technologies.
• People-based research, focusing on the people who
  interact with the hardware or software, looking
  at issues such as usability, user behaviour,
  compatibility of software with current user
  systems and other HCI issues.
• Both of these approaches are legitimate, and it
  is possible that in carrying out your research
  you might need to use elements of each one.

15
Product v. PeopleWhich focus?

• The focus of your research is decided by you.
• It will depend upon how confident you are in
  creating a product at the cutting edge, or how
  comfortable you will be as a researcher in
  dealing with people.
• When you frame your research questions, you need
  to ensure that their focus leads you into the
  kind of research that you want to do.
• There is no right answer, but you may find that
  your research will be best carried out by using a
  main focus of one element, with a subsidiary
  focus of another. For example producing a piece
  of software which securely encodes personal data
  as a self-encrypting and decrypting file stored
  on an ID card, may well need trialling with real
  people.

16
Approaches to Research

• There are two main approaches to doing research
• Quantitative Research looks for hard numerical
  data it proceeds by counting, measuring and
  summarising. The goal is to look for statistical
  significance in the results.
• Qualitative Research takes a soft approach to
  data, and has a more descriptive feel. It
  attempts to get to the heart of the matter,
  exploring individual cases in detail, and seeking
  the reasons for behaviour and explanations for
  events.
• Both of these approaches are legitimate, and it
  is
• possible to combine elements.

17
Quantitative v. QualitativeWhich approach?

• The approach you use will depend upon your topic
  and your research questions.
• It will also depend upon how comfortable you as a
  researcher feel about using these methods.
• There is no right answer here, and, as we shall
  see in the rest of this presentation, there may
  be good reasons for adopting a variety of
  methods, which encompass both quantitative and
  qualitative approaches

18
Types of Research

• There are four main types of research that you
  might consider
• Experimental Research
• Survey Research
• Evaluative Research
• Observational Research
• All four of these types can incorporate both
  quantitative and qualitative approaches

19
Experimental Research

• This is normally quantitative, but can take two
  forms
• An attempt to produce a piece of hardware,
  software or a combination of both, which is at
  the cutting edge of a discipline.
• An attempt to investigate and document the
  performance of a particular piece technology in
  specific circumstances.
• This might involve
• Creating hardware or software applications
• Devising detailed tests and evaluation procedures
• Carrying out rigorous testing
• Evaluating performance or usability

20
Survey Research

• This research can be qualitative or
  quantitative in the widest sense, you are
  interviewing people. This might involve
• An unstructured interview
• A semi-structured interview
• An structured interview based on questionnaire
  (face to face, or by telephone)
• An administered questionnaire
• A Postal Questionnaire

21
Evaluative Research

• This is primarily qualitative. Here you are
  trying to assess whether something is of value,
  whether it meets its specifications, or whether
  it is fit-for-purpose. This might involve
• Developing a list of criteria on which to make
  judgements
• Examining the object against each of the criteria
  to judge to what extent it conforms to
  expectations
• Weighing the positives and the negatives, coming
  to overall conclusions
• Matching these judgments against similar
  judgements made elsewhere in the literature or in
  real life.

22
Observational Research

• This research normally uses a qualitative
  approach in the widest sense, you are recording
  peoples behaviour. This might involve
• Participating in a task or situation
• Making field notes of experiences
• Creating and using an Observation Schedule
• Making a check-list of occurrences of particular
  events or items.

23
Research possibilities
Qualitative Quantitative
Experiment Field- testing Bench-testing and simulations
Survey Unstructured Interviews Written Questionnaires
Evaluation Using expert judges Evaluation criteria and checklists.
Observation Participant Observation Observation schedules
24
Other Forms of Research

• Historical Documentary Research proceeds by
  scrutinising existing materials, both written and
  artefacts, using them as sources of evidence.
• Action Research is normally conducted in an
  educational or political context. Action is
  taken, monitored, evaluated and then modified for
  the next cycle.
• Ethnographic Research consists of an in-depth
  study of a cultural phenomenon, in order to
  generate new theory.
• Case Study Research selects a whole range of
  research methods in scrutinising one particular
  context or situation.

25
Research methods 1References (SW Library)

• Crabtree, Benjamin F. - Doing qualitative
  research. - London Sage, 1992. - (Research
  Methods for Primary Care 3). - 0803943121
• Creswell, John W.. - Research design
  qualitative and quantitative approaches / John W.
  Creswell. - Thousand Oaks, Calif London Sage,
  1994. - 0803952554
• Creswell, John W.. - Qualitative inquiry and
  research design choosing among five traditions
  / J. - Thousand Oaks, Calif. London SAGE,
  1998. - 0761901434

26
Research methods 2References (SW Library)

• Miller, Delbert Charles. - Handbook of research
  design and social measurement. - 3rd ed. - New
  York David McKay Co . Inc, 1977. - m0859739
• Research methods in education and the social
  sciences / Research Methods in. - Block 3B
  Research design. - Milton Keynes Open
  University Press, 1983. - (DE304, Block 3B 3B).
  - 0335074235
• Yin, Robert K.. - Case study research design
  and methods. - Rev. ed. - Newbury Park London
  Sage, 1989. - (Applied social research methods
  series v.5). - 080393470x

27
3. Selecting Appropriate Research Methods

• The next few slides discuss how you might go
  about selecting your research methods from those
  available

28
Selecting Your Methodology

• Your research methodology consists of
• Research Methods (experiment, survey etc.)
• Research Instruments (questionnaire, tests etc.)
• Analytical Tools (statistics, inductive or
  deductive methods)
• When selecting the methodology, you need to be
  aware of
• The Research Questions you are trying to answer
• The Population you are trying to generalise to.

29
Factors to Consider
How has previous research in this area been done?
Undertake Literature Review
What methods have been used?
Select Research Questions
What research instruments have been devised?
Devise Methodology Research Instruments
How will the methods instruments be applied?
Apply Methods Instruments
What Statistical tests can be carried out?
Perform Statistical Analysis
What Research Hypotheses can be tested?
Test Hypotheses Draw Conclusions
30
Appropriate methodology

• Do your Research Questions involve impressions,
  attitudes, opinions, beliefs or knowledge held by
  people?
• If so, then survey research is appropriate
• Do your Research Questions involve behaviour,
  actions, reactions to events, circumstances or
  objects?
• If so, then observational research is appropriate


31
Appropriate methodology

• Do your Research Questions involve the
  reliability or robustness of hardware, software,
  systems or infrastructure?
• If so, then an evaluative study is appropriate
• Do your Research Questions involve the testing of
  hardware or software at the technical level,
  speed, accuracy, security etc?
• If so, then experimentation is appropriate

32
A Mix of Methods

• It may be that your research questions overlap
  some of these categories, or different questions
  address more than category.
• If so, you should consider a mix of methods, that
  ensure that you cover all eventualities. This may
  bring added benefits. (See Triangulation)

33
Mixed MethodsReferences (SW Library)

• Mixing methods qualitative and quantitative
  research / edited by Julia Bra. - Aldershot
  Avebury, 1995. - 1859721168
• Tashakkori, Abbas. - Mixed methodology
  combining qualitative and quantitative approaches
  / Abba. - Thousand Oaks, Calif. London Sage,
  1998. - (Applied social research methods series
  v.46). - 0761900705

34
4. Robustness of Methods

• As well as ensuring that your questions are
  well-focussed, and your methods relevant and
  appropriate, you need to ensure that your methods
  are also Reliable and Valid

35
Reliability Validity

• Research is Reliable if different methods,
  researchers and sample groups would have produced
  the same results.
• Research is Valid if the results produced by the
  research are accurate portrayals of the
  situation, explanations are effective, and
  predictions from the research are actually borne
  out by observation.

36
Reliability

• Research can have poor reliability, if it on one
  or two cases only, or if personal judgement or
  opinion is included.
• Reliability can be improved if data collection
  methods are made more precise, we have controlled
  experimentation, and we can produce statistical
  summaries.

37
Validity

• Research can have poor validity if the data
  produced is too far removed the object under
  study, or the respondent. Using detailed, highly
  structured research instruments can lead to
  distortions, by forcing observations into
  categories when they do not fit. Data summaries
  and averaging can also lead to distortions, and
  meaningless generalities. Graphical
  representations and percentages can be highly
  selective and produce biased findings.
• Validity can be improved by working directly with
  individuals or objects, focusing on specific
  cases, making detailed observations, conducting
  face to face interviews, taking detailed
  measurements in specific circumstances etc.

38
Reliability v. Validity
Valid, but not reliable
39
Reliability v. Validity
Reliable, but not Valid
40
Methodological Trade-Off

• If you improve validity, you will almost
  certainly reduce reliability.
• If you improve reliability it will be at the cost
  of reducing your validity.
• The trade-off is to balance the two so that the
  benefits of using particular methods outweigh the
  losses incurred.

41
Triangulation

• Triangulation takes its name from the
  navigational method of positioning a ship at sea
  by making two independent observations.
• The purpose here is to use two distinct
  methodologies, independent of one another to
  confirm that the effects which we are observing
  are real, and not artefacts of the research
  process.

42
Triangulation

• Triangulation attempts to counter the
  methodological trade-off by using a mix of
  methodologies.
• If you are using highly structured, statistical
  or measurement-based research, you supplement
  this with detailed observations or face to face
  interviewing.
• If your research is mainly based on individuals
  or on single items, you ensure that at least part
  of it has some statistical summaries, structured
  observations or questionnaires.

43
Validity ReliabilityReferences (SW Library)

• Kirk, Jerome. - Reliability validity in
  qualitative research. - Beverly Hills Calif
  Sage Pubns, 1986. - (Qualitative Research Methods
  Series 1). - 0803924704
• Litwin, Mark S. - How to measure survey
  reliability and validity. - London Sage, 1995.
  - (The Survey Kit 7). - 0803957041

44
5. Structuring Your Methodology

• This section looks in detail at the techniques
  that you might employ in the Research Activity
  itself.

45
Research Structure
Conduct Literature Review
After framing your Research Questions, and
selecting your methodology, you should test that
this is going to work by conducting a small-scale
Pilot Study
Select Research Questions
Devise Methodology Research Instruments
Apply Methods Instruments
Perform Statistical Analysis
Test Hypotheses Draw Conclusions
46
5a Pilot Studies

• A pilot study is a set of preliminary
  investigations procedures carried out prior to
  the main research, to ensure that the research is
  possible and can proceed without hitches.

47
Pilot Study (1)

• In almost every type of Research, you will need
  to devise or adapt some sort of Research Method
  or Instrument.
• This might be a measuring procedure, a set of
  evaluation criteria, an interview procedure or
  questionnaire, or an observational method or
  schedule.

48
Pilot Study (2)

• Your procedure or instrument should be based on
  best practice from previous research.
• It is unlikely that you will find exactly what
  you need you will be forced to adapt or amend
  it.
• This means that you will need to conduct a Pilot
  Study to test whether the new instrument is
  fit-for-purpose.

49
Pilot Study (3)

• The main purpose of a Pilot Study is to iron out
  bugs in procedures, or to check that
  instruments work.
• The size of the pilot study will depend on how
  inventive you needed to be.
• If your procedures are almost entirely of your
  own devising, then you will need a fairly
  extensive pilot study to check them.
• If you have lifted methods from the literature,
  than your pilot can be quite small.

50
Pilot Study (3)

• With questionnaires observation schedules, you
  will need to check that individual items are
  giving you expected results.
• With test procedures, you need to check that you
  can actually do what you have said that you are
  going to do.
• With evaluation criteria, you need to use these
  in a limited context, to see that they are
  workable and effective.

51
Pilot Study (4)

• As a result of the Pilot Study, you need to
  evaluate procedures and instruments, making
  amendments where necessary.
• The Pilot Study stage will be part of your
  research you will need to write this up,
  reporting on how your methods were adapted and
  improved as a result.

52
Carrying Out the Research
Undertake Literature Review
Select Research Questions
Devise Methodology Research Instruments
Here we will examine how particular methods and
instruments can be applied in the research
situation.
Apply Methods Instruments
Perform Statistical Analysis
Test Hypotheses Draw Conclusions
53
5b A detailed look at some Research methods

• Experimental Design
• Evaluative Research
• Observational Research
• Survey Research

54
5c.1 Experimental Design

• This section looks at the different ways in
  which you can conduct experiments. Note that you
  do not need to be doing pure experimental
  research to adopt these methods.

55
Experimental Designs

• You may need to think about experimental design
  even if you are doing types of research other
  than Experiments
• These designs occur where you have made some
  change, and are trying to find out its effect.
• The net result is that you are comparing one
  thing, or one group with another thing or group.

56
Experimental Designs

• The terminology for experimental designs comes
  from agricultural experiments.
• We have different treatments which we apply to
  different groups
• We control the groups for different factors

57
Experimental Designs

• Experiments normally involve independent and
  dependent variables
• Independent variables are factors that can be
  controlled for, like temperature, file sizes,
  age, gender etc.
• Dependent variables are those factors which will
  change as a result of altering the independent
  variables.
• For example, download times will increase as a
  result of increasing file sizes.
• Download time dependent variable,
• File size independent variable

58
Pre-Test/Post TestControl Group Design

• This is the classic experimental design.
• It allows you to split your sample into two
  distinct parts (A B)
• You give the same test to the two groups before
  you start
• You treat one of the groups
• You apply the same test afterwards.

Group A (treated)
Group B (untreated)
Pre-test
Pre-test
Treatment
Post-test
Post-test
59
Control Group

• The Control Group (B), is one which is the same
  in all respects, except for the fact that we make
  no changes.
• We can use the test measurements on the control
  group as a benchmark for any changes we make to
  the treatment group (A)

60
Example 1 Server Testing

• Suppose we wish to check whether a firewall is
  effective in blocking external attacks.
• Set up System A System B on two different
  servers, running near-equivalent internal
  external programs.
• Devise a test which includes a full range of
  possible attacks apply to both A B. Take
  series of measurements observations.
• Incorporate firewall into System A
• Reapply test to both systems, which are again
  running near-equivalent programs.

61
Example 2 Software Design

• Suppose we wish to find out whether
  anthropomorphic agents are useful in
  communicating with novice users of a website.
• Set up Website A Website B with
  near-equivalent structure, but different
  content.
• Devise a procedure which asks two equivalent sets
  of users to make explorations of the websites
  apply to both A B. Make a series of
  observations
• Incorporate Agents into Website A
• Re-apply procedure, asking two more equivalent
  sets of users to make the same explorations of
  both Websites. Again make observations.

62
Example 3 On-Line Learning

• Suppose we wish to find out whether training is
  effective in helping students cope with the
  demands of on-line learning.
• Set up group A group B with near-equivalent
  members.
• The two groups to undertake a short programme of
  learning on-line, which incorporates a short
  evaluation and a knowledge test.
• Give Training to Group A
• The two groups to undertake a further short
  programme of learning on-line, again
  incorporating a short evaluation and knowledge
  test.

63
Factorial Designs

• This is where we examine the effects of two or
  more independent factors simultaneously.
• For two factors, we would need 4 groups
• Group A (Control no treatment)
• Group B (Factor 1 treatment only)
• Group C (Factor 2 Treatment only)
• Group D (Factors 1 2 Treatments)
• Clearly, this is going to increase the complexity
  and size of the research, but it has the added
  benefit of producing verifiable results in cases
  where two factors interact to produce interesting
  effects.

64
Other Design Variants

• Post-Test only Control Group Design
• Here we assume that both groups are the same (but
  do not test that assumption). We simply apply the
  treatment to one group, and apply the test to
  both groups.
• Matched Pairs Design
• The individuals we use in the test groups
  (subjects) are matched for characteristics which
  are likely to affect the outcome (gender, age,
  level of education, ethnicity etc.)

65
Experimental DesignsReliability Issues

• For high reliability, we need to build in strict
  controls over each of the independent variables
  affecting the outcomes of the experiment.
• We will also need to ensure that any measurements
  taken of the dependent variables are as accurate
  as possible.
• We also need to ensure that our methodology is
  clear and replicable.

66
Experimental DesignsValidity Issues

• For high validity, we need to conduct the
  experiment in as natural a setting as possible,
  and in as near as exact a match to the
  circumstances in which the events or objects
  would normally operate.
• If a sample is being used, then the sample
  (whether time, events, people or objects) should
  be as representative of the background
  population as possible, and we should make
  detailed observations of how the events unfold as
  well as the final measurements.

67
Experimental DesignReferences (SW Library)

• Campbell, Donald T., Donald Thomas, 1916-. -
  Experimental and quasi-experimental designs for
  research / Donald T. Campbell. - Boston London
  Houghton Mifflin, 1963. 0395307872
• Field, Andy. - How to design and report
  experiments / Andy Field, Graham Hole. - London
  SAGE, 2003. - 0761973826
• Miller, Steve. - Experimental design and
  statistics. - London Methuen, 1975. -
  (Essential Psychology A8). - m0805407

68
5c.2 Evaluative Research

• This section looks at the methods and issues
  surrounding evaluation. You may need to use such
  techniques if evaluation is implicit in your
  research questions

69
Evaluative Research

• Evaluative Research covers those cases where you
  are attempting to compare whether one procedure
  or object is better or more effective than
  another procedure or object, or to determine
  whether a particular procedure or object is
  fit-for-purpose.
• Evaluation needs to be done against a set of
  criteria, which have been established as valid
  and reliable in this context. You would normally
  produce an evaluation form to be completed by
  respondents.

70
Evaluation Criteria

• To establish criteria for evaluation, we need to
  break the topic down into individual elements,
  and state the different sub-topics on which the
  item is to be evaluated.
• Alongside this, we will normally state specific
  questions which will need to be answered in order
  to judge the item against the criterion.
• The answers to the questions may involve
  measurements, counts, assessments on subjective
  scales, statements of fact or possibly even
  opinion.

71
Example Website Evaluation Criteria

• Design
• Is the use of colour acceptable?
• Are the elements in harmony?
• Navigation
• Do the links work?
• How many links per page?
• Content
• How many words graphics on page?
• Is the text interesting informative?
• Interactivity
• What interactive features are used?
• Do these improve communication with the user?
• Coding
• What scripting is used? Is it clearly annotated?

72
Example Website Evaluation Form

• 1. Design
• Colour Safe Pallet used? Yes/ No
• Harmony of elements on page good/ neutral/ poor
• 2. Navigation
• Number of links on the page ____
• Number of working links ____
• 3. Content
• Total size of graphics files on page ____ MB
• Is the text boring/ dull/ neutral/
  interesting/ fascinating
• 4. Interactivity
• Tick and/or name all interactive features used
• rollovers dynamic images image maps ______,
  ______
• 5. Coding
• What DTD has been used? _______________________

73
Evaluation CriteriaValidity Issues

• For criteria to be valid, each of the criteria
  elements need to have face or content validity
  the questions posed by the criterion needs to be
  relevant to the object, and relates to a feature
  of it
• We also need to be able to answer the questions
  in an objective manner, without recourse to
  guessing, or giving an impressionistic response.

74
Evaluation CriteriaReliability Issues

• For criteria to be reliable, each of the criteria
  elements need to be clear and unambiguous, so
  that different assessors would interpret the
  criteria in the same way.
• We also need to ensure that repetition of the
  evaluation exercise will yield results which are
  not dissimilar to one another.

75
Evaluation MethodsReferences (SW Library)

• Britain, Sandy. - A framework for pedagogical
  evaluation of virtual learning environments. -
  Manchester Joint Information Systems Committee,
  1999. - (JISC Technology Applications Programme
  r.. - M0000712EL
• Broadbent, George Ernest. - The role of
  evaluation in user interface design a practical
  implementation. - Liverpool University of
  Liverpool, 1997. - p7270369
• Redmond-Pyle, David. - Graphical user interface
  design and evaluation (GUIDE) a practical
  process. - London Prentice Hall, 1995. -
  013315193x
• Smeltzer, Nicholas. - Critical analysis of the
  design and evaluation of a computer-based
  project. - Liverpool University of Liverpool,
  2001. - M0002704LO

76
5c.3 Observational Research

• This section describes what you need to do if
  your research involves making detailed
  observations of people, events or objects.

77
Observational Research

• In this case you are trying to determine
• Either How an individual or group of individuals
  react, interact or behave in particular
  circumstances
• Or How software or hardware performs when used
  by particular groups of people

78
Participant Observation

• In this case, the researcher becomes one of the
  subjects, and works alongside the subject,
  monitoring behaviour and interacting with them.
• ProsResearcher can fully understand what the
  issues are. Can get real validity to research.
• Cons Researcher can influence the research,
  alter opinions. Highly subjective unreliable.
  Taking notes is difficult relies on good memory.

79
Non-Participant Observation

• In this case, the researcher studies the
  situation apart from subjects, taking notes,
  monitoring behaviour and observing interactions.
  The use of audio video recording is useful
  here.
• ProsResearcher can get overview of the
  situation, and achieve objectivity
• Cons Researcher can only see resulting
  behaviours, not what is causing it or why it is
  happening.

80
Observation Schedules

• An observation schedule can be a simple list of
  things to look for in a particular situation
• It can be far more complex a minute by minute
  count of events such a mouse-clicks or verbal
  interactions between subjects.

81
Observation ScheduleAn Example

• Observation of subject using Information Portal
• Subject M / F Age 18-21 / 21-30 / 31-50 / 50
• Date _________ Time _________
• Selected Navigation Tool Mouse /Keyboard/
  TouchScreen
• First 5 pages visited in order __ __ __
  __ __
• Time to obtain to obtain required information
  ___ min ___ sec
• Total Number of Pages visited __
• Feedback from subject
• very positive / positive / neutral / negative /
  very negative

82
Observation SchedulesSome Reliability Issues

• For an observation schedule to be reliable, it
  should require structured documentation of
  events.
• This will involve such things as checklists,
  minute-by-minute categorisation of activity and
  numerical data such as frequencies of occurrence
  and time intervals. Timings should have a clear
  start and end points.
• The schedule should leave little room for
  subjective judgement.

83
Observation SchedulesSome Validity Issues

• For an observation schedule to be valid, it
  should refer to events which actually happen
  each of the events on the sheet should be
  possible, and likely to occur.
• Timings should be possible to take, and not
  interfere with other observations which should be
  made.
• There should be room for observations which
  enrich the data by adding detail to the
  numbers, offering explanation and illumination.

84
Observational ResearchReferences (SW Library)

• Harding, Jacqueline. - How to make observations
  assessments / Jackie Harding and Liz
  Meldon-Smith. - 2nd ed. - London Hodder
  Stoughton, 2000. - 034078038x
• Robertson, Kevin. - Observation, analysis and
  video / editors Anne Simpkin and Penny
  Crisfield. - Leeds National Coaching
  Foundation, 1999. - 1902523164
• Simpson, Mary. - Using observations in
  small-scale research a beginner's guide / Mary
  Simpson. - Glasgow Scottish Council for
  Research in Education, 1995. - (SCREpublications
  16 130). - 1860030122

85
5c.4 Survey-Type Research

• This section describes what you need to do in
  order to use human respondents to provide you
  with information.

86
Survey methods

• There are two distinct elements here
• The interview techniques that you adopt in order
  to elicit information from people
• The sampling methods that you adopt in order to
  select respondents for interview
• You will need to make rational choices for both
  of these elements, depending upon the focus of
  your research and the population under study.

87
Interviewing

• We interview people face-to-face in order to try
  to find out exactly what they think.
• With the right questions, people respond with
  high quality information.
• The data that you get can be of high validity,
  since you have access to respondents own words.

88
Types of Interviews

• Unstructured Interview
• Structured Interview
• Semi-Structured Interview
• Administered Questionnaire

89
Open or Closed?

• When interviewing respondents, the main choice
  facing the researcher is whether to use open
  questions, which leave the respondent free to
  answer in any way they think fit, or closed
  questions which force the respondent to make
  particular choices, pre-determined by the
  researcher.
• OPEN What is your experience of chat rooms?
• CLOSED Do you think chat rooms should be
  monitored? (Yes/No/Maybe)

90
Open or Closed?Validity Reliability Issues

• In general, the data from open questions is
  richer, more illuminating, and more valid, as it
  can illustrate clearly why particular subjects
  think the way that they do, or why they behave in
  particular ways.
• Data from closed questions however, is more
  amenable to statistics. It is easier to
  summarise, spot trend and make comparisons. In
  general the data is more reliable.
• A good strategy is to use a mixture of both open
  and closed questions

91
Unstructured Interviews

• Unstructured Interview
• Interviewer has no set agenda the object is to
  get the respondent to talk freely about various
  topics.
• Pros Can be high quality data, often get real
  insights into what people really think.
• Cons Can be difficult for the novice researcher
  to carry out need to be good at steering the
  conversation without forcing it. Time consuming
  can only carry out a small number. Difficult to
  analyse

92
Semi- Structured Interview

• Interviewer has a formal list of topics, which
  sets the agenda however, the interviewer is free
  to take these in different orders, or to return
  to topics at different points.
• Here we include the idea of focus groups, where
  a facilitator encourages the discussion of a
  particular topic.
• Pros Data provided can be almost as good as
  unstructured interview, but in a more focussed
  manner.
• Cons Can miss important ideas, because agenda
  set beforehand interviews can also be time
  consuming difficult to manage analyse
  afterwards.

93
Structured Interviews

• Interviewer has a list of topics to be taken in a
  particular order questions are written, and read
  out.
• Pros You can make good comparisons between
  different respondents you also will have access
  to respondents thinking.
• Cons Unless you have done some preliminary
  investigations, and extensively piloted the
  interviews, you may miss lots of important data.
  Takes time to do properly can only carry out a
  few.

94
Administered Questionnaire

• Interviewer has devised a list of questions which
  are read out some multiple choice, some
  open-ended. Filled in either by respondent or
  interviewer.
• Pros Interview can be quite brief easy to make
  comparisons, data amenable to statistical
  analysis.
• Cons Data may be warped by the choice of
  questions. Respondent may be forced into giving
  fabricated answers.

95
Questionnaires

• There are many different types of questionnaire,
  depending upon what you are trying to find out.
• As well as gathering factual data about the
  person, you may be trying to explore their
• Knowledge
• Beliefs
• Attitudes
• Opinion
• Behaviour

If you need to design a questionnaire, see for
example http//www.leeds.ac.uk/iss/documentation/
top/top2/index.html
96
Question Types

• Factual Data
• Binary (Yes/No)
• Single Selection from Categories
• Multiple Selection from Categories
• Attitude Scale items
• Focussed items to elicit categories
• Conditional Questions for routing
• Open-ended Questions
• Self-Reporting

97
Writing Questions
See http//www.analytictech.com/mb313/principl.ht
m

• Put Factual Data (demographics) at end
• Put Explanations and Disclaimers at the start
• Keep questions as brief as possible
• Use non-technical language where possible
• Avoid leading respondents towards particular
  answers
• Use direct questions, no hypotheticals
• Use simple questions, no portmanteaus
• Use a mixture of positively and negatively worded
  questions
• Verify data by asking same question in different
  ways.

98
Questionnaire Example

• 1. Which operating system are you currently
  using
• Linux Windows Other
• 2. How would you rate the operating system?
• very poor poor good very good
• 3. Circle the tasks which you use your computer
  to do
• Word processing Internet Access Program
  Development
• 4. Estimate the number of hours you use the
  computer for each week
• ______ hours
• 5. Do you use broadband?
• Yes No

99
Protocol

• Whatever your interviewing method, as part of
  the ethical constraints on Hope Researchers, you
  are required to do the following
• Explain to the respondents what the research is
  about.
• Tell them that they will not be identified by
  name in the final report, and that any views that
  they express will be in confidence.
• Explain to them that if there are questions with
  which they feel uncomfortable, they do not have
  to answer.

100
Attitude Measurement

• You may wish to incorporate attitude
  measurement into your questionnaire as either a
  major or a minor feature.
• There are several different types of scales which
  can be used to elicit numerical measurements of
  attitude
• Likert Scaling
• Thurstone Scaling
• Guttman Scaling
• Semantic Differential Scaling
• See http//www.socialresearchmethods.net/kb/scalg
  en.htm

101
Likert Scales (1932)

• This consists of items like I would not trust a
  banks website to keep my details secure
• Respondents are asked to use a scale such as
  1Strongly disagree 2disagree 3neutral
  4agree 5strongly agree
• Scales can vary 0-4, 1-7 etc.
• Some proponents suggest removing the neutral
  category to force a choice, but this can reduce
  validity.
• Scores on individual items are totalled to obtain
  the respondents score this is often shown as an
  average.

102
Thurstone Scales (1928)

• This pre-ranks 11 statements with numerical
  values 1-11 each statement carries a numerical
  score, for example
• 1 Teleworking is an impossible concept
• 2 Teleworking may be OK in exceptional cases
• 8 If offered the opportunity, I would try
  teleworking
• 11 In 20 years time, everyone will be
  teleworking
• Clearly, lots of preparatory work needs to be
  done to generate and rank the statements.
• A respondents score, is the average numerical
  value of all the items they agree with.

103
Guttman Scales (1944)

• This pre-ranks statements in order, very similar
  to Thurstone scaling, except here we attempt to
  construct the scale so that if a person agrees
  with item 4 on the scale, they will also agree
  with items 1,2 and 3.
• When the questions are administered, the items
  are muddled, but each retains a ranking.
• The respondents score is the sum of the ranks
  associated with the items he or she agreed with.

104
Osgoods (1957)Semantic Differential Scales

• Respondents are asked to rate an idea or an
  object against a series of opposing adjectives or
  descriptions, for example
• Using Learnwise
• Exciting Dull
• Hard Easy
• Frustrating
  Stimulating
• The scale asks respondents to tick the box
  nearest the descriptor that they agree with. Each
  box has a numerical value e.g. 1,2,3 7
• The respondents score can be portrayed
  graphically, or as a total of numerical values.

105
Questionnaires InterviewsReliability Issues

• For questionnaire results to be reliable, you
  need closed questions that are precisely framed,
  unambiguous, with response categories that are
  well-defined, exhaustive and exclusive. You need
  to ask the same question in different ways, and
  you need to collate the information into
  statistical summaries and expose the data to
  rigorous statistical testing.
• You need to use as large a sample as possible,
  and even out any random fluctuations in the data
  by using summary statistics and hypothesis
  testing.

106
Questionnaires InterviewsValidity Issues

• For questionnaire results to be valid, you need
  response categories which enable the respondent
  to express their views accurately this can best
  be done with open questions. You should take time
  with the respondent and respect the data that
  they provide for you.
• You need to ensure that the sample is
  representative of the population, and large
  enough for the results to be statistically
  significant.

107
Questionnaire References On-Line

• http//www.tardis.ed.ac.uk/kate/qmcweb/qcont.htm
• http//www.leeds.ac.uk/iss/documentation/top/top2.
  pdf
• http//www.statpac.com/surveys/
• http//www.fao.org/docrep/W3241E/w3241e05.htmchap
  ter20420questionnaire20design
• http//www.surveysystem.com/sdesign.htm

108
Questionnaire References (1)(SW Library)

• Foddy, William. - Constructing questions for
  interviews and questionnaires theory and
  practice. - Cambridge Cambridge University
  Press, 1993. - 0521467330
• Fowler, Floyd J.. - Improving survey questions
  design and evaluation. - London Sage, 1995. -
  0803945833
• Frazer, Lorelle. - Questionnaire design and
  administration a practical guide / Lorelle
  Frazer. - Brisbane Wiley, 2000. - 0471342920
• Gillham, W. E. C., William Edwin Charles, 1936-.
  - Developing a questionnaire. - London
  Continuum, 2000. - (Real world research). -
  0826447953

109
Questionnaire References (2) (SW Library)

• Oppenheim, A. N., Abraham Naftali, 1924-. -
  Questionnaire design, interviewing and attitude
  measurement / A.N. Oppenheim. - New ed. - London
  Continuum, 2000. - 0826451764
• Wengraf, Tom. - Qualitative research interviewing
  biographic narrative and semi-structured
  interviews - London SAGE, 2001. - 0803975007
• Young, Pauline V. - Scientific social surveys and
  research an introduction to the background,. -
  Englewood Cliffs, N.J. Prentice-Hall, 1966. -
  (Prentice-Hall Sociology Series). - m0859969
• Youngman, Michael Brendan. - Designing and
  analysing questionnaires. - Maidenhead, Berks
  TRC Rediguide. - (Rediguide 12). - m0891542

110
Sampling

• The question of how to select the respondents for
  the sample is always tricky.
• The principle behind sampling, is that you should
  ensure that the sample is appropriate in order
  for you to generalise your results to the
  population under study.
• There are essentially three ways in which this is
  done
• Random Sampling
• Quota Sampling
• Stratified Random Sampling

111
Random Sampling

• This method requires you to get a list of all the
  population, as near complete as you can find,
  then use some random selection method (such as
  shutting your eyes and stabbing a pen at the
  list, or allocating using random numbers)
• The idea is that every person in the population
  has an equal chance of ending up in the sample.
• Most statistical methods assume that you are
  sampling randomly, and it is the only method
  which overall is guaranteed to ensure that
  samples are free from bias, and therefore provide
  validity.

112
Quota Sampling

• Here, you identify particular sectors of the
  population, such as men, women , those under 21,
  over 21, employed, unemployed etc., and put
  quotas on the number of people in each category.
• For example, in a quota sample of 12, we might
  have
• 2 males under 21 2 females under 21
• 4 males over 21 4 females over 21
• The purpose here is not to get a sample which
  represents the population in its entirety, but to
  ensure that views from important sections of the
  population are represented.

113
Stratified Random Sampling

• One of the problems with Random Sampling, is that
  if you take small samples, you can very well end
  up with a biased sample , by chance.
• In Stratified Random sampling, you would measure
  what proportions of the population lie in each
  category or strata, and select your sample so
  that you get precisely those proportions in those
  strata
• For example in your population you might have
• 15 males under 21 10 females under 21
• 30 males over 21 45 females over 21
• If you select a sample of 200 you would need
  stratified samples
• 30 males under 21 20 females under 21
• 60 males over 21 90 females over 21
• The allocation of subjects to samples should be
  done randomly.
• The purpose here is to get a valid sample which
  which represents the population in its entirety.

114
Other Sampling Methods

• Snowball Sampling This method is used whenever
  you are dealing with a tricky subject, where
  people may be doing devious or illegal activities
  (for example hacking, virus creation etc.). In
  this case, you would use one respondent to
  suggest the name of another who might be willing
  to be interviewed that one would lead to several
  others and so on.
• Cluster Sampling This method might be used if
  you have a diverse population (such as those
  living in African urban communities). Here you
  would randomly select particular cities, and
  sample within neighbourhoods within those cities.

• Convenience Sampling This is used mainly for
  investigative research. It relies on the fact
  that people appearing at a particular location or
  time will do so, at random (may not be true).
  We use this fact to stand in one place and
  interview them.

115
Sampling On-Line References

• This is an easy introduction
• http//www.csm.uwe.ac.uk/pwhite/SURVEY1/node26.ht
  ml
• This is more complex and technical
• http//www.socialresearchmethods.net/kb/external.h
  tm

116
6. Data Analysis

• This section of the presentation looks at the
  different types of data available, and how this
  can be analysed

117
Analysis of Research Data
Undertake Literature Review
Select Research Questions
Devise Methodology Research Instruments
Here we examine how the data produced by the
research can be presented effectively and
statistically analysed.
Apply Methods Instruments
Perform Statistical Analysis
Test Hypotheses Draw Conclusions
118
Data Analysis

• 6a Types Of Data
• 6b Extracting Data for Analysis
• 6c Presentation of Data
• 6c Principles of Statistical Testing
• 6d Selected Tests
• 6e Analytical Tools

119
6a Types of Data

• In this section we describe the different types
  of data that you might encounter, and what you
  might do with it in your study.

120
Types of Data

• Measurement-type data, given in units measured
  on a decimal scale. e.g. MB/sec, times, averages
  and other statistical summary values.
• Counted data number of occurrences of events
  or objects e.g. number of pages visited
• Ranking data subjective impressions, such as
  marks out of 10, rankings etc. e.g. Interface
  rated as very poor (1), poor (2), good (3) or
  very good (4).
• Categorical data Names of different things or
  categories, such as those named by an interviewee
  (NB these may be counted) e.g. Manager A
  discussed 3 concerns security, access and
  reliability
• Descriptive data, such as that produced by
  interviews or observational field-notes e.g.
  Subject A tried to click on all the blue text,
  even though it was not underlined.

121
Measured Data

• Such data is called continuous, ratio scale,
  or real number data
• This type of data is easiest to use it can be
  arithmetically manipulated (added, subtracted,
  multiplied, divided, summarised)
• it is also likely to have good, predictable
  statistical features.
• There are lots of methods to pick from.
• The inclusion of valid measured data will add
  reliability to your study.

122
Counted Data

• Such data is normally called discrete,
  interval scale, or integer data
• It can be added, subtracted and averaged.
• Counted data, has almost all the features of
  measured data, especially if the numbers of the
  count are large (above 30 or so).
• For small numbers (e.g. less than 30 observations
  in total), methods are limited.
• The inclusion of valid counted data will almost
  certainly improve the reliability of your study.

123
Ranking Data

• Such data is normally called interval scale
  data data.
• In order to use it effectively, there are several
  techniques the usual one is to convert the data
  into numerical values (e.g. Yes 1, No 0)
• When this has been done, it can be added,
  subtracted and averaged.
• Interval data needs care the data looks like
  counts where the numbers are small, but are
  simply subjective impressions. To deal with such
  data we need to summarise large volumes of it
  data.
• The inclusion of valid counted data, suitably
  summarised can add reliability to your study.

124
Categorical Data

• Such data is normally called nominal data.
• In order to use such data effectively, the
  objects, classes or ideas that these categories
  represent should have the items within them
  counted, evaluated on an interval scale and/or
  summarised.
• A preliminary study may have found, for example
  that there are 4 main uses for spreadsheets in
  business Finance, Timesheets, Inventory and
  General Calculation. Businesses may be asked to
  rank these in order of importance, or to rate
  their usefulness.
• Categorical data is much more difficult to deal
  with. Processes are time consuming and highly
  subjective There are relatively few statistical
  tools which deal effectively with categorical
  data.
• The inclusion of valid Categorical data,
  suitably summarised can add both validity and
  reliability to your study.

125
Descriptive Data

• Descriptive data is simply a verbal description
  of something that happened, or what a respondent
  did, or a quote from an interview.
• It is the most difficult to deal with
  effectively. There are methods for extracting
  summary information from such data (see Grounded
  Theory Glazer Strauss) however, these are not
  for the novice researcher in IT, as they are very
  time consuming.
• The best use for such data is for illustration
  and supporting evidence elsewhere.
• The inclusion of appropriate Descriptive data,
  suitably selected can improve the overall
  validity of your study.

126
Types Of DataReferences (SW Library)

• Research methods in education and the social
  sciences / Research Methods - Block 5
  Classification and measurement. - Milton Keynes
  Open University Press, 1979. - (DE304 a third
  .. - 0335074405
• Research methods in education and the social
  sciences / Research Methods. - Block 6 Making
  sense of data. - Milton Keynes Open University
  Press, 1979. - (DE304 a third level course. -
  0335074413

127
Types of Data References (SW Library)

• Chatfield, Christopher. - Statistics for
  technology a course in applied statistics. -
  2nd. - London Penguin Books, 1978. - 0412157500

• Kranzler, Gerald. - Statistics for the terrified
  / Gerald D. Kranzler, Janet P. Moursund. -
  Englewood Cliffs, N.J. Prentice Hall London
  Prentice-Hall International, 1995. 0131838318
• Pentz, Mike. - Handling experimental data. -
  Milton Keynes Open U.P., 1988. - 0335158242
• Salkind, Neil J.. - Statistics for people who
  (think they) hate statistics. - Thousand Oaks,
  Calif. London Sage, 2000. - 0761916210

128
6b Extracting Data For Analysis

• Data produced by the research process does not
  have to be numerical in order to be of value.
  However, statistical techniques work best where
  the data uses numerical values, or can be
  converted to numerical scales.

129
Survey Data

• Questionnaire data should be the easiest data to
  extract. Ideally the questionnaire will have been
  designed with the methods of analysis in mind, so
  that questions are framed in such a way as to
  facilitate graphical representation and
  statistical testing.
• Interview Data can be more problematic you may
  need to invent categories, and to count up
  instances of different cases, both in the same
  interview, and with different subjects.

130
Questionnaire Data Examples

• Percentage of Respondents using Broadband 82
• In the survey, 93 of people used their computer
  to access the internet, compared to 37 who used
  it for word-processing, and 7 who used it to
  develop programs.
• 87 of Linux users rated their operating system
  as good or very good, compared to 64 of Windows
  users.
• The average number of hours spent on the computer
  each week by men was 9.3, compared to 3.7 for
  women.

131
Interview Data Examples

• 5 out of the 6 interviewees were using
  Broadband.
• During the interview, all interviewees mentioned
  the positive benefits of moving to broadband. For
  example one respondent said My daughter can use
  the phone while I am replying to emails.
  Altogether there were 25 instances in the
  interviews where benefits were named, as opposed
  to only three cases where drawbacks were noted.
• These cases broke down as follows
• 20 of cases referred to accessibility issues
• 60 of cases referred to improved speed
• 20 of cases referred to improved compatibility
• However, it must be noted that all the drawbacks
  were cited by a respondent who reportedly used
  the internet for over 70 hours per week. The
  other five respondents use was an average of
  15.7 hours, with totals ranging from 4 hours to
  25 hours.

132
Observational Data

• Pure observational field notes are unlikely to
  contain numerical data. As with interview data,
  you may have to invent appropriate categories
  an
