Md. Tanvir Al Amin [e-mail] (Presenter)

1
A Service Oriented Architecture for a Multi
Channel Internet TV System

• Md. Tanvir Al Amin tanviralamin_at_gmail.com
  (Presenter)
• Imranul Hoque imranulhoque_at_cse.buet.ac.bd,
• Md. Yusuf Sarwar Uddin yusufsarwar_at_cse.buet.ac.bd
• Department of Computer Science and Engineering,
• Bangladesh University of
• Engineering and Technology,
• Dhaka, Bangladesh.

2
What is an Internet TV

• System for Real time transmission and Reception
  of TV Programs.
• Low Cost Approach, no external setup.
• Easy initiation of new Channels.
• Can Target Clients anywhere, all over the Globe.

3
Existing Solutions

• RTP / RTSP for Transmission
• MBone dependent Solutions
• Owned Solutions by some company
• But
• There is a lack of Robust, Scalable and
• Inter- Operable Architecture in this field.

4
Challenges for Our System

• 3 Objectives
• Robust
• Inter - Operable
• scalable

5
Proposed Architecture
3 System Components
1 TV Broker Server (TBS) 2 TV Program Server
(TPS) 3 Internet TV Client (ITC)
6
TV Broker Server (TBS)
TPS
ITC
TBS
Service Tree (Local)
Fig Work Load of the Broker Server
7
TV Program Server (TPS)
Architecture of TV Program Server
8
Internet TV Client (ITC)
Query
Multicast in LAN
Message
TBS
11 Share
Feedback
Transmission
ITC
TPS
Fig Work Load for an ITC
9
Communication Setup
Blue Channel 1 Green Channel 2 Magenta
Channel 3 Red Control Between TBS and
TPS Black Control between TBS and ITC
10
Service Tree Management
A Hypothetical Service Tree at a moment
11
Service Tree Management
Some new node arrives into scenario
12
Service Tree Management
Some node changes service status
13
Service Tree Management
After a network Reorganization (Periodical)
14
Sequence of Action
Service Request
Authenticate
Get Service Nodes
Provide Node List
Compute Cost
Get Service Param
Adjust Service Tree
Select Service Node
Get Service Node
Get TV Program
ITC
Self
TBS
Self
Self
STM
TPS
15
Success of Our Architecture

• Web Service dependent.
• Easily Deployable
• Dynamic Quality Management
• Hassle free Client side

16
Limitations

• Transmission Not Optimal
• Security Not Considered
• Propagation Delay

17
THANK YOU
