System Architecture Directions for Networked Sensors

1
System Architecture Directions for Networked
Sensors

• Qiuhua Cao (qc9b_at_cs)
• Computer Science Department
• University of Virginia

2
Outline

• Hardware Organization of Berkeley Motes
• Critical Issues of Sensor Networks
• Does an OS for the Motes exsit?
• Design Goals of TinyOS
• Concepts in TinyOS
• Examples
• Evaluation and Critiques

3
Hardware Platform-Motes

• Assembled from off-the-shelf components
• 4Mhz, 8bit MCU (ATMEL 90LS8535)
• 512 bytes RAM, 8K ROM
• 900Mhz Radio (RF Monolithics)
• 10-100 ft. range
• Temperature Light Sensor
• LED outputs
• Serial Port

4
(No Transcript)
5
Critical Issues for Sensor Networks

• Highly Limited Device
• power, memory, bandwith
• Inherently Distributed
• large number of nodes coordinate, cooperate with
  each other to fulfill an job
• Devices themselves are the infrastructure
• ad hoc, self-organized
• Highly Dynamic
• failure in common
• variation in connectivity over time

6
Does an OS for the Motes exist?

• Traditional OS design
• wait request, act, respond loop
• monolithic event processing
• full thread/socket POSIX regime
• Alternative
• concurrency and modularity
• never poll, never block
• data flows, events, power management interact

7
Design Goals of TinyOS

• Concurrency-Intensive Operations
• flow information from place to place on-the-fly
• Example simultaneously capture data from
  sensors, processing the data, then send out to
  the network

8
Design Goals of TinyOS (cont.)

• Limited Physical Parallelism and Controller
  Hierarchy
• Less independent controllers
• Less processor-memory-switch level
• Sensor and Actuator directly interact with the
  single-chip micro controller

9
Design Goals of TinyOS (cont.)

• Diversity in Design and Usage
• Sensor network application specific design
• But wide range potential applications
• deep modularity of software needed

10
Design Goals of TinyOS (cont.)

• Robust Operations
• Cross devices redundancy prohibitive
• Individual reliable devices desired
• Application tolerant individual device failures

11
Concepts in TinyOS

• Application graph of components scheduler
• Example INT_TO_LEDS

MIAN
COUNTER
INT_TO_LEDS
CLOCK
LED
12
Concepts in TinyOS (cont.)

• Component
• Implementation (.c file)
• Frame
• a set of commands
• a set of handlers
• a set of tasks
• Interface (.comp)
• Description file (.desc)

13
Concepts in TinyOS (cont.)

• Frame
• Contains all permanent state for component (lives
  across events, commands, and threads)
• Threads, events, and commands execute inside the
  components frame
• Only one per component
• Like static class variables, not internal class
  variables.
• Fixed size
• Statically allocated at compile time

14
Concepts in TinyOS

• Frame example
• Frame declaration

define TOS_FRAME_TYPE AM_obj_frame TOS_FRAME_BEGI
N(AM_obj_frame) int addr char type
char state char data char
msgbuf30 TOS_FRAME_END(AM_obj_frame)

• Use of frame Variables

VAR(state) 0
15

• Commands

• Commands deposit request parameters into its
  frame
• Commands can call lower level commands
• Commands can post tasks
• Commands no-blocking
• Commands needed to return status
• Declaration
• TOS_COMMAND(cmd_name)(cmd_args_list)
• USE
• TOS_CALL_COMMAND(cmd_name)(cmd_args_list)

16
Events

• Deposit information into frame
• Events can call lower level commands
• Post tasks and fire higher level events.
• Events can not be signaled by commands,
• Declaration
• char TOS_EVENT(evnt_name)(evnt_arg_list)
• Use TOS_SIGNAL_EVENT(evnt_name)(evnt_arg_li
  st)

17
Tasks

• Tasks perform work that is computationally
  intensive.
• FIFO scheduler
• Run-to-completion
• Non-preemptable among tasks (concurrent)
• Preemptable by events
• Task declaration
• TOS_TASK(task_name).
• Posting a task
• Asynchronous call to schedule the task for later
  execution
• USE TOS_POST_TASK(avg_task)

18
Commands, Events, Tasks
Both event and cmd can schedule tasks

• Relationship Graph

Higher Level Component
Commands can not signal Events
Issue cmds
Signal events
Tasks preemptive by Envents
Lower Level Component
Tasks non preemptive by Tasks
19
An Component Example

•


Cmd Issued
Cmd accepted
Events handled
Events signaled
20
An Component Example (cont. )

• .comp file interface definition
• TOS_MODULE name ACCEPTS
  command_signatures
• HANDLES       event_signatures
• USES      command_signatures
• SIGNALS      event_signatures

21
An Component Example (cont. )

• .comp file interface definition
• //ACCEPTS
• char TOS_COMMAND(AM_send_msg)(int addr,
• int type, char data)
• void TOS_COMMAND(AM_power)(char mode)
• char TOS_COMMAND(AM_init)()
• //SIGNALS
• char AM_msg_rec(int type, char data)
• char AM_msg_send_done(char success)

22
An Component Example (cont.)

• //HANDLES
• char AM_TX_packet_done(char success)
• char AM_RX_packet_done(char packet)
• //USES
• char TOS_COMMAND(AM_SUB_TX_packet)(char data)
• void TOS_COMMAND(AM_SUB_power)(char mode)
• char TOS_COMMAND(AM_SUB_init)()

23
An Component Example (cont.)

• .c file frame, commands, events implementation
• define TOS_FRAME_TYPE AM_obj_frame
  TOS_FRAME_BEGIN(AM_obj_frame) char state
  TOS_MsgPtr msg TOS_FRAME_END(AM_obj_frame)
• // This task schedules the transmission of
  the Active MessageTOS_TASK(AM_send_task)
  //construct the packet to be sent,fill in dest
  and type if(!TOS_CALL_COMMAND(AM_SUB_TX_PACKET)(VA
  R(msg)))
• VAR(state) 0 TOS_SIGNAL_EVENT(AM
  _MSG_SEND_DONE)(VAR(msg)) return

24

• .c file frame, commands, events implementation
• // Command to be used for power management
  char TOS_COMMAND(AM_POWER)(char mode)
  TOS_CALL_COMMAND(AM_SUB_POWER)(mode)
  VAR(state) 0 return 1 // Handle the
  event of the completion of a message
  transmission char TOS_EVENT(AM_TX_PACKET_DONE)(T
  OS_MsgPtr msg) //return to idle state.
  VAR(state) 0 //fire send done event.
  TOS_SIGNAL_EVENT(AM_MSG_SEND_DONE)(msg) return
  1

25
An Component Example (cont. )

• .desc file
• component modules specified
• the wiring of commands and events across
  component interfaces
• Example
• include modules     module list
  connection list

26
Storage Model

• One frame per component, shared stack

Previous frame
fp(old sp)
Current frame
data
variable
sp
Stack Growth
Next frame
27
Storage Model (cont.)

• Message Buffer
• Strict alternating ownership protocol
• Only TOS_MSG type pointer across component


send_msg
AM
AM is owner of message buffer, the requesting
component can not access this message buffer
send_done
AM gives up the owner of message buffer,
28
Storage Model (cont.)

• char TOS_COMMAND(INT_TO_RFM_OUTPUT)(int val)
  ...   if (!VAR(pending))     VAR(pending)
  1     message-gtval val     message-gtsrc
  TOS_LOCAL_ADDRESS     if (TOS_COMMAND(INT_TO_RFM
  _SUB_SEND_MSG)(TOS_BCAST_ADDR, AM_MSG(INT_READING)
  , VAR(data)))         return 1     else
        VAR(pending) 0 / request failed, free
  buffer /         return 0

29
Scheduler

• Two-level scheduling structure
• Tasks, Events
• FSM execution model
• Each task is like a state in the state machine,
  which the events are like input signals
• Events model
• When there is no event, CPU is put in idle

30
An example of Execution Model
Get_Light

• Clock Event /
• Light Request Command

Light done event / Msg send command
Send_Msg
Sleep
Msg sent event / Power down command
31
Add a task
Calc. Average
Get_Light
Light done event / Post Task
Thread Schedule / Msg send command
Clock Event / Light Request Command
Send_Msg
Sleep
Msg sent event / Power down command
32
An Composition Example
sensing application
Routing Layer
routing
Messaging Layer
packet
Radio Packet
byte
Radio Byte
SW
Temp
HW
bit
RFM
clocks
I2C
ADC
33
An Composition Example
Send_message
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
34
An Composition Example
TX_Packet
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
35
An Composition Example
TX_byte
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
36
An Composition Example
TX_Bit_Event
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
37
An Composition Example
TX_Bit_Done
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
38
An Composition Example
TX_Byte_Done
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
39
An Composition Example
TX_Packet_Done
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
40
An Composition Example
Msg_Send_Done
sensing application
Routing Layer
Messaging Layer
Radio Packet
Radio Byte
SW
Temp
HW
RFM
clocks
I2C
ADC
41
Evaluation

• meet power constraints?

Active Idle Sleep
CPU 5 mA 2 mA 5 µA
Radio 7 mA (TX) 4.5 mA (RX) 5 µA
EE-Prom 3 mA 0 0
LEDs 4 mA 0 0
Photo Diode 200 µA 0 0
Temperature 200 µA 0 0
42
Evaluation

• meet power save?

43
Evaluation

• meet memory constraints?

44
Evaluation

• Meet concurrent-intensive operations?
• Event-driven architecture
• Efficient interrupts/events handling (function
  calls, no user/kernel boundary)
• Modularity?
• Function call (event, command) interface between
  components

45
Critique

• Real-time not addressed
• Non-preemptable FIFO task scheduling
• NO real-time guarantees or overload protection
• Tasks are dispatched to either software or
  hardware to best utilize the whole system
  resources but in TinyOS, all tasks go into
  software.
• Adding event queues at the lowest layers can
  reduce the external event losses
• The OS should collect runtime profiles and
  statistics, perform periodic system maintenance
  operations and maintain system level power state
• No opposite argument

46
Thanks!!

• Any Question??
