Overview of the High Intensity Neutrino Source

1
Overview of the High Intensity Neutrino Source
Jean-Paul Carneiro FNAL Accelerator Physics
Department FNAL Accelerator Physics and
Technology Seminar February 8th 2007
2
Fermilab 8 GeV Superconducting H-minus LINAC
TRANSPORT LINE 1 km
MI10
ACCELERATING SECTION 678 meters
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
3
Fermilab 8 GeV H-minus LINAC Main parameters
INITIAL
ULTIMATE Linac Particles per macropulse
1.56E14 Linac Macropulse Width
3 ms 1 ms Linac Pulse Repetition
Rate 2.5 Hz 10 Hz Linac Beam
Power 0.5 MW 2.0 MW
CREDITS
G. W. Foster (Editor) An 8-GeV Superconducting
Linac Proton Driver http//protondriver.fnal.go
v/SCRF_PD_v56.doc
(2005)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
4
OUTLINE
1 / Accelerating Section Code benchmarking
TRACK (ANL, P. Ostroumov) ASTRA (DESY,
K. Floettmann) 2 / Transport Line
Implementation into TRACK Start-to-end
parallel simulations (1.7 km) 3/ The 60 MeV
Front End Setup (Meson Linac)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
5
PART I THE ACCELERATING SECTION
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
6
ACCELERATING SECTION LAYOUT (P. Ostroumov, ANL)
Z4 m W2.5 MeV
16 m 10 MeV
60 m 120 MeV
140 m 420 MeV
230 m 1.2 GeV
678 m 8.0 GeV
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
7
TRACK / ASTRA BRIEF DESCRIPTION
ASTRA (K. Floettmann, DESY)
TRACK (P. Ostroumov, ANL)
Integration of Equation of motion by
Runge-Kutta Method of Forth Order
id
id
Read arbitrary input distribution
Read 2D and 3D external E fields
id
Read 2D and 3D external B fields
Read only 2D external B fields
Do not handle RFQs
Handle RFQs
3D space charge (Free Space)
3D space charge (Image Charge)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
8
BENCHMARKING METHODOLOGY
Benchmark TRACK/ASTRA from RFQ to last
accelerating cavity ( 674 m, 454 Cavities, 55
Sol., 117 Quads)
First Zero Current (10k particles)
Then for 43.25 mA (200k macro-particles, 3D
Space Charge)
6 beam parameters RMS Trans. Size, RMS Trans.
Emittance RMS Bunch Length, RMS Long.
Emittance Energy, RMS energy spread
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
9
TRACK / ASTRA ZERO CURRENT
KINETIC ENERGY
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
10
TRACK / ASTRA ZERO CURRENT
RMS ENERGY SPREAD
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
11
TRACK / ASTRA ZERO CURRENT
RMS BUNCH LENGTH
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
12
TRACK / ASTRA ZERO CURRENT
RMS LONG. EMITTANCE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
13
TRACK / ASTRA ZERO CURRENT
RMS ENVELOPE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
14
TRACK / ASTRA ZERO CURRENT
RMS TRANSVERSE EMITTANCE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
15
TRACK / ASTRA ZERO CURRENT Résumé
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
16
TRACK / ASTRA 3D Uniform Ellipsoidal Bunch
3D UNIFORM ELLIPSOID 500k macro-particules
(TRACK/ASTRA)
CREDITS T. Wangler, RF Linear Accelerators, p.
277.
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
17
TRACK / ASTRA 3D Uniform Ellipsoidal Bunch
18
TRACK / ASTRA 43.25 mA
RMS ENERGY SPREAD
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
19
TRACK / ASTRA 43.25 mA
RMS BUNCH LENGTH
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
20
TRACK / ASTRA 43.25 mA
RMS LONG. EMITTANCE
RMS LONG. EMITTANCE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
21
TRACK / ASTRA 43.25 mA
RMS TRANSVERSE EMITTANCE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
22
TRACK / ASTRA 43.25 mA
RMS ENVELOPE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
23
TRACK / ASTRA 43.25 mA Résumé
ASTRA
TRACK
UNITS
MeV
8009
8013
KINETIC ENERGY
(-0.04 )
keV
2773
2564
RMS ENERGY SPREAD
(8.15 )
mm
0.345
0.345
RMS BUNCH LENGTH
keV-mm
943
857
RMS NORM. EMIT Z
(10.03 )
mm
1.87
1.76
RMS SIZE X
(6.25 )
1.34
1.32
mm
RMS SIZE Y
(1.52 )
mm-mrad
0.493
0.453
RMS NORM. EMIT X
(8.83 )
RMS NORM. EMIT Y
mm-mrad
0.549
0.566
(3.09 )
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
24
CONCLUSION TRACK / ASTRA BENCHMARKING
TRACK / ASTRA Agreement Within 10 (Zero Current
and 3D Space Charge)
Benchmarking of simulation codes for high
intensity hydrogen ion linacs submitted to
Journal of Instrumentation.
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
25
LCLS INJECTOR ASTRA / PARMELA
SOLENOID
RF GUN SOLENOID
L01
L02
9.4 M
Jean-Paul Carneiro
CALCULATIONS OF THE LCLS INJECTOR USING ASTRA
26
LCLS INJECTOR ASTRA / PARMELA
Jean-Paul Carneiro
CALCULATIONS OF THE LCLS INJECTOR USING ASTRA
27
EXIT L02 (8.42 M) RESUME
UNITS ASTRA PARMELA
MOMEMTUM MeV/c 149.14 149.96
RMS ENERGY SPREAD 0.18 0.17
RMS SIZE X mm 0.32 0.29
RMS NORM. EMIT X mm-mrad 0.98 0.96
RMS SIZE Y mm 0.32 0.29
RMS NORM. EMIT Y mm-mrad 0.98 0.96
RMS BUNCH LENGTH mm 0.90 0.88
(0.5 )
(6)
(10)
(2 )
(10)
(2 )
(2)
Jean-Paul Carneiro
ASTRA SIMULATIONS OF THE LCLS INJECTOR
28
PART II THE TRANSPORT LINE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
29
8 GeV TRANSPORT LINE TO MI LAYOUT (D. Johnson et
al., FNAL)
1 km (8 GeV, Space Charge Off)
Matching Collimation
Stripping foil
ARC 1
ARC 2
DEBUNCHER CAVITY RT-SUPERSTRUCTURE 17 CELL (T.
Khabiboulline, FNAL-TD)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
30
TRANSVERSE PARTICLE DISTRIBUTION AT THE FOIL
(TRACK)
No Collimator
With Collimators
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
31
LONGITUDINAL PHASE SPACE AT THE FOIL (TRACK)
Debuncher OFF
Debuncher ON
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
32
TRANSPORT LINE MAD SIMULATIONS
From D. Johnson (FNAL)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
33
TRANSPORT LINE TRACK / ELEGANT (M. Borland, ANL)
m
DISPERSION
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
34
TRANSPORT LINE TRACK / ELEGANT
BETA FUNCTION
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
35
TRANSPORT LINE TRACK / PARALLEL TRACK (J. Xu,
ANL)
Acc. Section (3D Space Ch.)
Transport Line (No Space Charge)
10 H 40 mn
1 H 18 mn
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
36
TRACK START-TO-END SIMULATIONS
TRANSV. RMS EMITTANCE
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
37
TRACK START-TO-END SIMULATIONS
RMS ENERGY SPREAD
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
38
TRACK SIMULATIONS CONCLUSION NEXT STEPS
Start-to-End simulations (from RFQ to stripping
foil) implemented into TRACK
The 1.7 km beamline runs on parallel (64 CPU) at
ANL-BlueGene computer Takes 1H18 mn to perform,
200k particules.
NEXT STEPS IN HINS SIMULATIONS
1/ Halo Studies (1M to 80M particle distribution
on 64 to 256 CPUs)
2/ Jitter Misalignment Studies (up to 100 CPU
on ANL-JAZZ computer)
3/ Implementation H-minus stripping into TRACK
(Magnetic, Residual Gas and Blackbody radiation)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
39
TRACK SIMULATION BLACKBODY STRIPPING
CREDITS
C. Hill Preliminary Notes H- Ion Stripping in
Transport by Thermal Photons
FERMILAB-Internal Memorandum (Dec. 2004)
unpublished -
H. C. Bryant and G. H. Herling Atomic physics
with a relativistic H- beam Journal of
Modern Optics, January 2006
W. Chou 8 GeV H- Ions Transport and
Injection PAC05
Hills Equation of Total Loss per Unit Length
with
Numerical Application
300 K 1/L7.86E-7 m-1 1.56E14 p/sec 1.28E-9
J 0.15 W/m (1 Hz)
80 K 1/L2.7E-10 m-1 1.56E14 p/sec
1.28E-9 J 5.3E-5 W/m (1 Hz)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
40
PART III THE MESON LINAC
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
41
MESON LINAC LAYOUT (60 MeV, 48 m)
Cooling ring dipole Effective Magnetic Length
1.3 m
SQA Quads Old 8 GeV to MR line Effective
Magnetic Length 45 cm
Main Ring Trim Quads Effective Magnetic Length
35 cm
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
42
MESON LINAC TRACK SIMULATIONS
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
43
MESON HALL SOUTH VIEW
Capture Cavity II Cave
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
44
MESON HALL NORTH VIEW
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
45
MESON LINAC MODULATOR, PULSE TRANSFORMER,
KLYSTRON
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
46
MESON LINAC KLYSTRON, RF CONTROL SYSTEM
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
47
FERMILAB Proton Source LEBT (H. Piekarz, C.
Schmidt, D. Moehs)
Installed in MS6 building
15 mA, 66 µs, 15 Hz
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
48
FERMILAB magnetron H- source (D. Moehs)
20 mA, 3 ms, 1 Hz (January 2007)
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
49
MESON LINAC CONCLUSION
Modulator, Pulse Transformer and Klystron
installed into Meson Hall
Expected delivery time for RFQ Summer 2007
Expected first 2.5 MeV beam Winter 2007
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
50
CONCLUSION and ACKNOWLEDGMENTS
Start-to-End simulation of the 8 GeV H-minus
linac implemented into TRACK
Jitter Studies and impact into stripping
efficiency and MI losses (ESME ?)
Benchmarking the code with experimental datas
(Meson Linac)
Acknowledgments G. Apollinari (FNAL), S. Aseev
(ANL), M. Borland (ANL), K. Floettmann (DESY),
B. Foster (ex-FNAL), I. Gonin, C. Hill (FNAL),
D. Johnson (FNAL), T. Khabiboulline, D. Moehs
(FNAL), B. Mustapha (ANL), P. Ostroumov (ANL), H.
Piekarz (FNAL), C. Schmidt (FNAL), V. Shiltsev
(FNAL), B. Webber (FNAL), D. Wildman (FNAL), J.
Xu (ANL).
Jean-Paul Carneiro FNAL
Accelerator Physics and Technology Seminar, Feb
8th 07
