Title: CHAPTER 4: POLYMER STRUCTURES


1
CHAPTER 4POLYMER STRUCTURES
Spherulite, rubber specimen. Chain-folded
lamellar crystallites, 10 nm thick, 30,000
2
c04cof01
3
4.1 Structures of Polymers
  • Introduction and Motivation
  • Polymers are extremely important materials (i.e.
    plastics)
  • Have been known since ancient times cellulose,
    wood, rubber, etc..
  • Biopolymers proteins, enzymes, DNA
  • Last 50 years tremendous advances in synthetic
    polymers
  • Just like for metals and ceramics, the properties
    of polymers
  • Thermal stability
  • Mechanical properties
  • Are intimately related to their molecular
    structure

4
4.1 Ancient Polymers
  • Originally natural
  • polymers were used
  • Wood
  • Rubber
  • Cotton
  • Wool
  • Leather
  • Silk

Oldest known use Rubber balls used by Incas Noah
used pitch (a natural polymer) for the ark
Noah's pitch Genesis 614 "...and cover it inside
and outside with pitch."
gum based resins extracted from pine trees
5
4.2 Polymer Composition
  • Most polymers are hydrocarbons
  • i.e., made up of H and C
  • Saturated hydrocarbons
  • Each carbon singly bonded to four other atoms
  • Example
  • Ethane, C2H6

6
4.2 Unsaturated Hydrocarbons
  • Double triple bonds somewhat unstable can
    form new bonds
  • Double bond found in ethylene or ethene - C2H4
  • Triple bond found in acetylene or ethyne - C2H2

7
4.2 Structures of Polymers
  • about hydrocarbons
  • Why? Most polymers are hydrocarbon (e.g. C, H)
    based
  • Bonding is highly covalent in hydrocarbons
  • Carbon has four electrons that can participate in
    bonding, hydrogen has only one
  • Saturated versus unsaturated
  • Unsaturated species contain carbon-carbon
    double/triple bonds
  • Possible to substitute another atom on the carbon
  • Saturated carbons have four atoms attached
  • Cannot substitute another atom on the carbon

Saturated
Unsaturated
8
4.2 Isomerism
  • Isomerism
  • two compounds with same chemical formula can have
    quite different structures
  • for example C8H18
  • normal-octane

?
Isomerism compounds of the same chemical
composition but different atomic arrangements
(i.e. bonding connectivity)
2,4-dimethylhexane
9
c04eqf02
4.2 Hydrocarbon Molecules
Acetylene Ethyne
Ethylene Ethene
Hydrocarbons have strong chemical bonds, but
interact only weakly with one another (van der
Waals forces)
(normal) butane
isobutane
c04eqf02
10
4.2
11
c04eqf03
4.3 Polymer Molecules
Molecules are gigantic Macromolecules Repeat
units Monomer
12
c04tf02
c04tf02
13
4.3 Polymers
  • Polymer molecules
  • what is a polymer?
  • Polymers are molecules (often called
    macromolecules) formed from a series of building
    units (monomers) that repeat over and over again
  • polymers can have a range of molecular weights
  • There are many monomers
  • Can make polymers with different monomers, etc..

n is often a very large number! e.g. can make
polyethylene with MW gt 100,000! 3600 mers 7200
carbons
14
4.4 Polymerization and Polymer Chemistry
  • Free radical polymerization
  • Initiator example - benzoyl peroxide

15
4.4 Polymer chemistry
  • Polymers are chain molecules. They are built up
    from simple units called monomers.
  • E.g. polyethylene is built from ethylene units
    which are assembled into long chains

Polyethylene or polythene (IUPAC name
poly(ethene)) is a thermoplastic commodity
heavily used in consumer products (notably the
plastic shopping bag). Over 60 million tons of
the material are produced worldwide every year.
16
4.4 Structures of Polymers
  • Chemistry of polymer molecules
  • Basic idea of how you make polymers
  • Stick with ethylene
  • Gas at STP
  • To polymerize ethylene, typically increase T, P
    and/or add an initiator

R is an initiator that is responsible for
activating the monomer to begin chain growth
(hence the name)
After many additions of monomer to the growing
chain
17
c04eqf08
Tetrafluoroethylene monomer polymerize to form
PTFE or polytetrafluoroethylene
poly(tetrafluoroethene) or poly(tetrafluoroethylen
e) (PTFE) is a synthetic fluoropolymer. PTFE is
the DuPont brand name Teflon. Melting 327C
Vinyl chloride monomer leads to poly(vinyl
chloride) or PVC
PVC manufacturing toys, packaging, coating,
parts in motor vehicles, office supplies,
insulation, adhesive tapes, furniture, etc.
Consumers shoe soles, children's toys, handbags,
luggage, seat coverings, etc. Industrial
sectors conveyor belts,
printing rollers. Electric and electronic
equipment circuit boards, cables, electrical
boxes, computer housing.
18
Chemistry and Structure of Polyethylene
Adapted from Fig. 4.1, Callister Rethwisch 3e.
Note polyethylene is a long-chain hydrocarbon -
paraffin wax for candles is short polyethylene
Polymer many mers
Adapted from Fig. 14.2, Callister 6e.
19
Structures of Polymers
  • Polymer chemistry
  • In polyethylene (PE) synthesis, the monomer is
    ethylene
  • Turns out one can use many different monomers
  • Different functional groups/chemical composition
    polymers have very different properties!

Monomers
20
Homopolymer and Copolymer
  • Polymer chemistry
  • If the polymer is formed from one monomer (i.e.
    all the repeat units are the same type) this is
    called a homopolymer
  • If the polymer is formed from multiple types of
    monomers (i.e. all the repeat units are not the
    same type) this is called a copolymer
  • Also note the monomers shown before are
    referred to as bifunctional
  • Why? The reactive bond that leads to
    polymerization (the CC double bond in ethylene)
    can react with two other units
  • Other monomers react with more than two other
    units e.g. trifunctional monomers

21
The Top 10 Bulk or Commodity
22
4.5 MOLECULAR WEIGHT
Molecular weight, M Mass of a mole of chains.
high M
Not all chains in a polymer are of the same
length i.e., there is a distribution of
molecular weights
23
Structures of Polymers
  • Molecular weight
  • The properties of a polymer depend on its length
  • synthesis yields polymer distribution of lengths
  • Define average molecular weight
  • Two approaches are typically taken
  • Number average molecular weight (Mn)
  • Weight-average molecular weight (Mw)

24
MOLECULAR WEIGHT DISTRIBUTION
Adapted from Fig. 4.4, Callister Rethwisch 3e.
Mi mean (middle) molecular weight of size
range i
xi number fraction of chains in size range i
wi weight fraction of chains in size range i
25
Structures of Polymers
  • Molecular weight
  • Are the two different?
  • Yes, one is essentially based on mole fractions,
    and the other on weight fractions
  • They will only be the same if all the chains are
    exactly the same MW!
  • If not Mw gt Mn

Get Mn from this
Get Mw from this
26
Structures of Polymers
  • Molecular weight
  • Other ways to define polymer MW
  • Degree of polymerization
  • Represents the average number of mers in a chain.
    The number and weight average degrees of
    polymerization are

m is the mer MW in both cases. In the case of a
copolymer (something with two or more mer units),
m is determined by
fj and mj are the chain fraction and molecular
weight of mer j
27
Structures of Polymers
  • Example Problem 4.1
  • Given the following data determine the
  • Number average MW
  • Number average degree of polymerization
  • Weight average MW
  • How to find Mn?
  • Calculate xiMi
  • Sum these!

28
Structures of Polymers
  • Example Problem 4.1
  • Number average degree of polymerization
  • (MW of H2CCHCl is 62.50 g/mol)
  • How to find Mw?
  • Calculate wiMi
  • Sum these!

29
Degree of Polymerization, DP
  • DP average number of repeat units per chain

DP 6
mol. wt of repeat unit i
Chain fraction
30
c04tf04a
c04tf04a
31
c04tf04b
c04tf04b
32
4.6 Polymers Molecular Shape
  • Molecular Shape (or Conformation) chain bending
    and twisting are possible by rotation of carbon
    atoms around their chain bonds
  • note not necessary to break chain bonds to alter
    molecular shape

Adapted from Fig. 4.5, Callister Rethwisch 3e.
  • C-C bonds are typically 109 (tetrahedral, sp3
    carbon)
  • If you have a macromolecule with hundreds of C-C
    bonds, this will lead to bent chains

33
Structures of Polymers
  • Molecular shape
  • Taking this idea further, can also have rotations
    about bonds
  • Leads to kinks, twists
  • the end-to-end distance of a polymer chain in
    the solid state (or in solution) is usually much
    less than the distance of the fully extended
    chain!
  • This is not even taking into account that you
    have numerous chains that can become entangled!

34
  • 4.7 Molecular structure
  • Physical properties of polymers depend not only
    on their molecular weight/shape, but also on the
    difference in the chain structure
  • Four main structures
  • Linear polymers
  • Branched polymers
  • Crosslinked polymers
  • Network polymers

35
4.7 Molecular Structures for Polymers
Adapted from Fig. 4.7, Callister Rethwisch 3e.
36
Linear polymers
  • polymers in which the mer units are connected
    end-to-end along the whole length of the chain
  • These types of polymers are often quite flexible
  • Van der waals forces and H-bonding are the two
    main types of interactions between chains
  • Some examples polyethylene, teflon, PVC,
    polypropylene

37
Branched polymers
  • Polymer chains can branch
  • Or the fibers may aligned parallel, as in fibers
    and some plastic sheets.
  • chains off the main chain (backbone)
  • This leads to inability of chains to pack very
    closely together
  • These polymers often have lower densities
  • These branches are usually a result of
    side-reactions during the polymerization of the
    main chain
  • Most linear polymers can also be made in branched
    forms

38
Crosslinked polymers
  • Molecular structure
  • adjacent chains attached via covalent bonds
  • Carried out during polymerization or by a
    non-reversible reaction after synthesis (referred
    to as crosslinking)
  • Materials often behave very differently from
    linear polymers
  • Many rubbery polymers are crosslinked to modify
    their mechanical properties in that case it is
    often called vulcanization
  • Generally, amorphous polymers are weak and
    cross-linking adds strength vulcanized rubber is
    polyisoprene with sulphur cross-links

39
Network polymers
  • polymers that are trifunctional instead of
    bifunctional
  • There are three points on the mer that can react
  • This leads to three-dimensional connectivity of
    the polymer backbone
  • Highly crosslinked polymers can also be
    classified as network polymers
  • Examples epoxies, phenol-formaldehyde polymers

40
POLYMER MICROSTRUCTURE
Covalent chain configurations and strength
Direction of increasing strength
Adapted from Fig. 14.7, Callister 6e.
2
41
4.8 Molecular configurations
Classification scheme for the characteristics of
polymer molecules
isomerism different molecular configurations
for molecules (polymers) of the same
composition Stereoisomerism Geometrical Isomerism
42
c04eqf23
4.8 Molecular Configurations Repeat unit R Cl,
CH3, etc
Configurations to change must break bonds
Stereoisomers are mirror images cant
superimpose without breaking a bond
43
c04eqf11
Head to-tail
Typically the head-to-tail configuration dominates
Head to-head
44
Structures of Polymers
  • Stereoisomerism
  • Denotes when the mers are linked together in the
    same way (e.g. head-to-tail), but differ in their
    spatial arrangement
  • This really focuses on the 3D arrangement of the
    side-chain groups
  • Three configurations most prevalent
  • Isotactic
  • Syndiotactic
  • Atactic

45
ISOTACTIC
  • Stereoisomerism
  • Isotactic polymers
  • All of the R groups are on the same side of the
    chain

Isotactic configuration
  • Note All the R groups are head-to-tail
  • All of the R groups are on the same side of the
    chain
  • Projecting out of the plane of the slide
  • This shows the need for 3D representation to
    understand stereochemistry!

46
SYNDIOTACTIC
  • Stereoisomerism
  • Syndiotactic polymers
  • The R groups occupies alternate sides of the chain

Syndiotactic configuration
  • Note The R groups are still head-to-tail
  • R groups alternate one of out of the plane, one
    into the plane

47
ATACTIC
  • Stereoisomerism
  • Atactic polymers
  • The R groups are random

Atactic configuration
  • R groups are both into and out of the plane, no
    real registry
  • Two additional points
  • Cannot readily interconvert between stereoisomers
    bonds must be broken
  • Most polymers are a mix of stereoisomers, often
    one will predominate

48
c04eqf12
StereoisomerismHead-to-tail
isotactic configuration
Syndiotactic conformation
Atactic conformation
49
cis/trans Isomerism
cis cis-isoprene (natural rubber) H atom and CH3
group on same side of chain
trans trans-isoprene (gutta percha) H atom and
CH3 group on opposite sides of chain
50
c04eqf18
Geometrical Isomerism
c04eqf18
51
4.9 Plastics
  • variety of properties due to their rich chemical
    makeup
  • They are inexpensive to produce, and easy to
    mold, cast, or machine.
  • Their properties can be expanded even further in
    composites with other materials.

52
Glass-rubber-liquid
  • Amorphous plastics have a complex thermal profile
    with 3 typical states

Glass phase (hard plastic)
Leathery phase
Log(stiffness)Pa
Rubber phase (elastomer)
Liquid
53
THERMOPLASTICS
  • Thermosetting and thermoplastic polymers
  • Another way to categorize polymers how do they
    respond to elevated temperatures?
  • Thermoplastics these materials soften when
    heated, and harden when cooled this process is
    totally reversible
  • This is due to the reduction of secondary forces
    between polymer chains as the temperature is
    increased
  • Most linear polymers and some branched polymers
    are thermoplastics

54
THERMOSETS
  • Thermosetting and thermoplastic polymers
  • Thermosets these materials harden the first
    time they are heated, and do not soften after
    subsequent heating
  • During the initial heat treatment, covalent
    linkages are formed between chains (i.e. the
    chains become cross-linked)
  • Polymer wont melt with heating heat high
    enough it will degrade
  • Network/crosslinked polymers are typically
    thermosets
  • Polymers which irreversibly change when heated
    are called thermosets.
  • Most often, the change involves cross-linking
    which strengthens the polymer (setting).
  • Thermosets will not melt, and have good heat
    resistance.
  • They are often made from multi-part compounds and
    formed before setting (e.g. epoxy resin).
  • Setting accelerates with heat, or for some
    polymers with UV light.

55
Thermoplastics
  • Polymers which melt and solidify without chemical
    change are called thermoplastics.
  • They support hot-forming methods such as
    injection-molding and FDM.

56
THERMOPLASTICS VS THERMOSETS
Thermoplastics --little cross linking
--ductile --soften w/heating
--polyethylene (2) polypropylene (5)
polycarbonate polystyrene (6)
Thermosets --large cross linking
(10 to 50 of mers) --hard and brittle
--do NOT soften w/heating --vulcanized
rubber, epoxies, polyester resin,
phenolic resin
Adapted from Fig. 15.18, Callister 6e. (Fig.
15.18 is from F.W. Billmeyer, Jr., Textbook of
Polymer Science, 3rd ed., John Wiley and Sons,
Inc., 1984.)
3
57
4.10 Structures of Polymers
  • Copolymers
  • Idea polymer that contains more than one mer
    unit
  • Why? If polymer A has interesting properties,
    and polymer B has (different) interesting
    properties, making a mixture of polymer should
    lead to a superior polymer

Random copolymer exactly what it sounds like
Alternating copolymer ABABABA
58
Structures of Polymers
  • Copolymers
  • Idea polymer that contains more than one mer
    unit
  • Why? If polymer A has interesting properties,
    and polymer B has (different) interesting
    properties, making a mixture of polymer should
    lead to a superior polymer

Block copolymers. Domains of pure mers
Graft copolymers. One mer forms backbone,
another mer is attached to backbone and is a
sidechain (it is grafted to the other polymer)
59
Copolymers
Adapted from Fig. 4.9, Callister Rethwisch 3e.
  • two or more monomers polymerized together
  • random A and B randomly positioned along chain
  • alternating A and B alternate in polymer chain
  • block large blocks of A units alternate with
    large blocks of B units
  • graft chains of B units grafted onto A backbone
  • A B

random
alternating
block
graft
60
Copolymers
  • Polymers often have two different monomers along
    the chain they are called copolymers.
  • With three different units, we get a terpolymer.
    This gives us an enormous design space

61
4.11 Polymer structure
  • The polymer chain layout determines a lot of
    material properties
  • Amorphous
  • Crystalline

62
Crystallinity in Polymers
Adapted from Fig. 4.10, Callister Rethwisch 3e.
  • Ordered atomic arrangements involving molecular
    chains
  • Crystal structures in terms of unit cells
  • Example shown
  • polyethylene unit cell
  • Polymers can be crystalline (i.e. have long
    range order)
  • However, given these are large molecules as
    compared to atoms/ions (i.e. metals/ceramics) the
    crystal structures/packing will be much more
    complex

63
Structures of Polymers
  • Polymer crystallinity
  • (One of the) differences between small molecules
    and polymers
  • Small molecules can either totally crystallize or
    become an amorphous solid
  • Polymers often are only partially crystalline
  • Why? Molecules are very large
  • Have crystalline regions dispersed within the
    remaining amorphous materials
  • Polymers are often referred to as semicrystalline

64
Structures of Polymers
  • Polymer crystallinity
  • Another way to think about it is that these are
    two phase materials (crystalline, amorphous)
  • Need to estimate degree of crystallinity many
    ways
  • One is from the density

65
Structures of Polymers
  • 4.11 Polymer crystallinity
  • What influences the degree of crystallinity
  • Rate of cooling during solidification
  • Molecular chemistry structure matters
  • Polyisoprene hard to crystallize
  • Polyethylene hard not to crystallize
  • Linear polymers are easier to crystallize
  • Side chains interfere with crystallization
  • Stereoisomers atactic hard to crystallize
    (why?) isotactic, syndiotactic easier to
    crystallize
  • Copolymers more random harder to crystallize

66
4.11 Polymer Crystallinity (cont.)
  • Polymers rarely 100 crystalline
  • Difficult for all regions of all chains to become
    aligned

crystalline
region
Degree of crystallinity expressed as
crystallinity. -- Some physical properties
depend on crystallinity. -- Heat
treating causes crystalline regions to
grow and crystallinity to
increase.
amorphous
region
Adapted from Fig. 14.11, Callister 6e. (Fig.
14.11 is from H.W. Hayden, W.G. Moffatt, and J.
Wulff, The Structure and Properties of Materials,
Vol. III, Mechanical Behavior, John Wiley and
Sons, Inc., 1965.)
67
4.11 MOLECULAR WEIGHT CRYSTALLINITY
Molecular weight, Mw Mass of a mole of
chains.
Tensile strength (TS) --often increases
with Mw. --Why? Longer chains are entangled
(anchored) better.
Crystallinity of material that is
crystalline. --TS and E often increase
with crystallinity. --Annealing causes
crystalline regions to grow.
crystallinity increases.
Adapted from Fig. 14.11, Callister 6e. (Fig.
14.11 is from H.W. Hayden, W.G. Moffatt, and J.
Wulff, The Structure and Properties of Materials,
Vol. III, Mechanical Behavior, John Wiley and
Sons, Inc., 1965.)
4
68
4.12 Polymer Crystallinity
  • 4.12 Polymer crystals
  • Chain folded-model
  • Many polymers crystallize as very thin platelets
    (or lamellae)
  • Idea the chain folds back and forth within an
    individual plate (chain folded model)
  • Crystalline regions
  • thin platelets with chain folds at faces
  • Chain folded structure

69
4.12 Single Crystals
  • Electron micrograph multilayered single
    crystals (chain-folded layers) of polyethylene
  • Single crystals only for slow and carefully
    controlled growth rates

Adapted from Fig. 4.11, Callister Rethwisch 3e.
70
4.12 Semicrystalline Polymers
  • Some semicrystalline polymers form spherulite
    structures
  • Alternating chain-folder crystallites and
    amorphous regions
  • Spherulite structure for relatively rapid growth
    rates

Spherulite surface
Adapted from Fig. 4.13, Callister Rethwisch 3e.
71
Structures of Polymers
  • Polymer crystals
  • More commonly, many polymers that crystallize
    from a melt form spherulites
  • One way to think of these the chain folded
    lamellae have amorphous tie domains between
    them
  • These plates pack into a spherical shape
  • Polymer analogues of grains in polycrystalline
    metals/ceramics

72
Photomicrograph Spherulites in Polyethylene
Cross-polarized light used -- a maltese cross
appears in each spherulite
Adapted from Fig. 4.14, Callister Rethwisch 3e.
73
c04eqf03
END of chapter 4
About PowerShow.com
