Title: Task Control: Signals and Alarms Chapter 7 and 8


1
Task ControlSignals and AlarmsChapter 7 and 8
  • B. Ramamurthy

2
Multi-tasking
  • How to create multiple tasks? Ex Xinu create()
  • How to control them?
  • ready()
  • resched()
  • How to synchronize them? How to communicate among
    them?
  • XINU semaphores, send and receive messages
  • How to (software) interrupt a process? signals

3
Examples
  • Consider g myProg.c
  • You want to kill this process after you started
    the compilation..hit cntrl-C
  • Consider execution of a program called badprog
  • gtbadprog
  • It core dumps .. What happened? The error in the
    program results in a signal to kernel to stop and
    dump the offending code
  • Consider kill p ltpidgt
  • Kill issues a termination signal to the process
    identified by the pid

4
Linux Processes
  • Similar to XINU Procs.
  • Lets understand how to create a linux process and
    control it.
  • Chapter 7 and 8 of text book.
  • Chapter 7 multi-tasking
  • Chapter 8 Task communication and synchronization

5
Process creation
  • Four common events that lead to a process
    creation are
  • 1) When a new batch-job is presented for
    execution.
  • 2) When an interactive user logs in / system
    initialization.
  • 3) When OS needs to perform an operation (usually
    IO) on behalf of a user process, concurrently
    with that process.
  • 4) To exploit parallelism an user process can
    spawn a number of processes.

6
Termination of a process
  • Normal completion, time limit exceeded, memory
    unavailable
  • Bounds violation, protection error, arithmetic
    error, invalid instruction
  • IO failure, Operator intervention, parent
    termination, parent request, killed by another
    process
  • A number of other conditions are possible.
  • Segmentation fault usually happens when you try
    write/read into/from a non-existent
    array/structure/object component. Or access a
    pointer to a dynamic data before creating it.
    (new etc.)
  • Bus error Related to function call and return.
    You have messed up the stack where the return
    address or parameters are stored.

7
Process control
  • Process creation in unix is by means of the
    system call fork().
  • OS in response to a fork() call
  • Allocate slot in the process table for new
    process.
  • Assigns unique pid to the new process..
  • Makes a copy of the process image, except for the
    shared memory.
  • both child and parent are executing the same code
    following fork()
  • Move child process to Ready queue.
  • it returns pid of the child to the parent, and a
    zero value to the child.

8
Process control (contd.)
  • All the above are done in the kernel mode in the
    process context. When the kernel completes these
    it does one of the following as a part of the
    dispatcher
  • Stay in the parent process. Control returns to
    the user mode at the point of the fork call of
    the parent.
  • Transfer control to the child process. The child
    process begins executing at the same point in the
    code as the parent, at the return from the fork
    call.
  • Transfer control another process leaving both
    parent and child in the Ready state.

9
Process Creation (contd.)
  • Parent process create children processes, which,
    in turn create other processes, forming a tree of
    processes
  • Generally, process identified and managed via a
    process identifier (pid)
  • Resource sharing
  • Parent and children share all resources
  • Children share subset of parents resources
  • Parent and child share no resources
  • Execution
  • Parent and children execute concurrently
  • Parent waits until children terminate

10
Process Termination
  • Process executes last statement and asks the
    operating system to delete it (exit)
  • Output data from child to parent (via wait)
  • Process resources are deallocated by operating
    system
  • Parent may terminate execution of children
    processes (abort)
  • Child has exceeded allocated resources
  • Task assigned to child is no longer required
  • If parent is exiting
  • Some operating system do not allow child to
    continue if its parent terminates
  • All children terminated - cascading termination

11
Example Code
  1. int retVal
  2. printf(" Just one process so far\n")
  3. printf(" Invoking/Calling fork() system
    call\n")
  4. retVal fork() / create new process/
  5. if (retVal 0)
  6. printf(" I am the child d \n",getpid())
  7. else if (retVal gt 0)
  8. printf(" I am the parent, child has pid d
    \n", retVal)
  9. else
  10. printf(" Fork returned an error d \n",
    retVal)

12
Signals
  • Signals provide a simple method for transmitting
    software interrupts to UNIX process
  • Signals cannot carry information directly, which
    limits their usefulness as an general
    inter-process communication mechanism
  • However each type of signal is given a mnemonic
    name Ex SIGINT
  • See signal.h for others
  • SIGHUP, SIGINT, SIGILL, SIGTRAP, SIGFPE, SIGKILL
  • SIGALRM (sent by kernel to a process after an
    alarm timer has expired)
  • SIGTERM
  • signal (signal id, function) simply arms the
    signal

13
Intercept Signals
Task1
Task2
Two essential parameters are destination process
identifier and the signal code number kill
(pid, signal) Signals are a useful way of
handling intermittent data arrivals or rare
error conditions.
14
Handling Signals
  • Look at the examples
  • Catching SIGALRM
  • Ignoring SIGALRM
  • sigtest.c
  • sigHandler.c
  • pingpong.c
  • See /usr/include/sys/iso/signal_iso.h for signal
    numbers

15
Signals and Alarms
  • include ltsignal.hgt
  • unsigned int alarm( unsigned int seconds )
  • alarm(a) will start a timer for a secsonds and
    will interrupt the calling process after a secs.
  • time(t) will get you current time in the
    variable t declared as time_t t
  • ctime(t) will convert time to ascii format

16
Sample programs
  • Starting new tasks in linux page 165
  • Programs in pages 174-180 on signals and alarms
  • See demos directory for first
  • See page 175 for the second program
  • See page 178 for the second program

17
Pingpong
Parent
PSIG 43
Child
CSIG 42
18
Volatile (from code reading last lecture)
  • A variable should be declared volatile whenever
    its value could change unexpectedly. In practice,
    only three types of variables could change
  • Memory-mapped peripheral registers
  • Global variables modified by an interrupt service
    routine
  • Global variables within a multi-threaded
    application
