Title: Physical Memory and Physical Addressing


1
Physical Memory and Physical Addressing
  • By
  • Preeti Mudda
  • Prof Dr. Sin-Min Lee
  • CS147 Computer Organization and Architecture

2
Agenda
  • Physical Memory
  • Random Access Memory
  • Two Types of Ram
  • Dynamic RAM
  • Static RAM
  • Physical Address
  • Word Size
  • Byte Alignment

3
Physical Memory
  • Physical memory is the main memory that has
    direct/indirect access to CPU
  • Physical memory mainly consists of RAM

4
Random Access Memory
  • Random Access Memory (RAM) Any data could be
    accessed in a constant time regardless of its
    physical location.
  • Two Types of RAM
  • DRAM Dynamic Random Access Memory
  • SRAM Static Random Access Memory

5
Dynamic Random Access Memory
  • DRAM is an integrated circuit.
  • Millions of transistors and capacitors are paired
    together to create an array of memory cells
  • Capacitor holds the bit information
  • Transistors behaves like a switch which lets the
    control circuitry to control the state of the
    memory chip by reading or changing the capacitor
    state.

6
DRAM Architecture
  • DRAM Chips are large and rectangular
  • Arrays of memory cells
  • Support logic- used for reading and writing data
    in arrays
  • Refresh Circuitry- maintain the integrity of the
    stored data by periodically refreshing the memory
    cells

7
http//www.cs.duke.edu/courses/fall98/cps104/lectu
res/week10-l2/sld024.htm
8
DRAM
  • Memory cell represents single bit data (logic
    1/logic 0)
  • Cells are imprinted on silicon wafer
  • Array of columns (bitlines)
  • Array of rows (wordlines)
  • Intersection of bitline and wordline is the
    address of the memory cell

9
Support Circuitry
  • Sense amplifiers Amplifies signal or charge
    detected on the memory cell
  • Address logic Select rows and columns
  • Row Address Select(RAS) and Column Address
    Select(CAS) Latch and resolve the row and column
    addresses. It initiates or terminates the
    read/write operation

10
Support Circuitry
  • Read /Write circuitry Store or read the
    information in the memory cell
  • Internals Counters Keep track of the refresh
    sequence or initiate refresh cycle
  • Output Enable logic Prevents the data from
    displaying it unnecessarily.

11
DRAM Read timing
  • Row Address Strobe (RAS)
  • Latch row address and initiate the memory cycle.
  • It is required at the beginning of every
    operation.
  • To enable RAS the voltage transition should be
    from high to low voltage.
  • RAS is an active low and it should maintain low
    voltage as long as RAS is required
  • Complete memory cycle RAS must active for
    minimum amount time and also inactive for minimum
    amount of time.
  • Column Address Strobe
  • Initiate Read/Write Operation
  • CAS must be active before RAS for refresh cycle.

12
DRAM Timing
  • Write Enable(WE)
  • Write enable signal used to choose for read/write
    operation.
  • Low voltage-level signifies a write operation
  • High-voltage level signifies a read operation.
  • Output Enable (OE)
  • This control signal is used to prevent displaying
    the output while read operation.
  • The control signal is grounded when write
    operation is selected.
  • Data IN/OUT(DQs)
  • DQ pins used for input and output

13
http//www.cs.duke.edu/courses/fall98/cps104/lectu
res/week10-l2/sld024.htm
14
http//www.cs.duke.edu/courses/fall98/cps104/lectu
res/week10-l2/sld024.htm
15
Steps to access a cell in DRAM
16
Static RAM
  • Type of semiconductor memory
  • No need to refresh frequently
  • Uses six MOFETS to store each memory bit
  • Size SRAM has m address lines and n data lines
    2m words.

17
SRAM
  • Three different states
  • Standby The circuit is idle
  • Reading Reading the data which has been
    requested
  • Writing Writing the data on to the memory

18
SRAM
http//www.cs.duke.edu/courses/fall98/cps104/lectu
res/week10-l2/sld016.htm
19
SRAM
  • Reading
  • WE_L is dis-asserted (H), OE_L is asserted (L)
  • D data output pin
  • Writing
  • WE_L is asserted (L) where as OE_L is
    dis-asserted (H).
  • D Data input pin.

http//www.cs.duke.edu/courses/fall98/cps104/lectu
res/week10-l2/sld018.htm
20
Physical Address
  • Physical address is a memory address that is
    stored in the form of binary number
  • It is electronically represented on the computer
    address bus circuitry
  • Through this data bus is enabled to access
    particular storage from the main memory cell

21
Physical Memory and Word Size
  • Bits of physical memory are divided into blocks
    of N bits
  • Terminology
  • Group of N bits is called a word
  • N is known as the width of a word or the word
    size

22
Physical Memory Addresses
  • Each word of memory is assigned a unique number
    known as a physical memory address
  • Programmer imagines physical memory to be an
    array of words
  • Note entire word must be transferred

23
Choosing A Word Size
  • Larger word size
  • Implemented with more parallel wires
  • Results in higher performance
  • Higher cost
  • Note architect usually designs all parts of
    computer to use
  • one size for
  • Memory word
  • Integer (general-purpose registers)

24
Byte Addressing
  • View of memory presented to processor
  • Each byte of memory assigned an address
  • Convenient for programmers
  • Underlying memory can still use word addressing

25
Translation Between Byte And Word Addresses
  • Performed by intelligent memory controller
  • CPU can use byte addresses (convenient)
  • Physical memory can use word addresses (efficient)

26
Byte Alignment
  • Refers to integer storage in memory
  • In some architectures
  • Integer in memory must correspond to word in
    underlying physical memory
  • In other architectures
  • Integer can be unaligned, but fetch and store
    operations are much slower

27
Memory Size And Address Space
  • Size of address limits maximum memory
  • Example 32-bit address can represent
  • 232 4,294,967,296
  • unique addresses
  • Known as address space
  • Note word addressing allows larger memory than
    byte addressing

28
Resources
  • Physical Memory
  • IBM article Understanding DRAM operation
  • CS-Duke Lecture notes Memory Systems
  • Wikipedia
  • Howstuffworks website
  • Physical Address
  • http//www.eecs.wsu.edu/hauser/teaching/Arch-F07/
    handouts/Chapter10.pdf
  • Wikipedia
