Force System Resultant

1
CHAPTER 4 Force System Resultant
2
4.1 Moment of a Force - - - Scalar Formulation

• 1.Moment
• A measure of the tendency of the force to
  cause a body to
• rotate about the point or axis.
• Torque (T) ??
• Bending moment (M) ????

3
2. Vector quantity
(1) Magnitude ( N-m or lb-ft) Mo Fd
d moment arm or perpendicular distance
from point O to the line of
action of force.

(2) Direction Right-Hard
rule A. Sense of rotation ( Force
rotates about Pt.O) Curled
fingers B. Direction and sense of
moment Thumb
4
3.Resultant Moment of Coplanar Force
System
4.2 Cross Product
1. Definition
(1) magnitude of
(2)Direction of
perpendicular to the plane containing A B
5
2. Law of operation (1)
(2)
(3)
3. Cartesian Vector Formulation (1) Cross
product of Cartesian unit vectors.
6
(2) Cross product of vector A B in Cartesian
vector form
7
4.3 Moment of a Force Vector Formulation
1. Moment of a force F about pt. O
Mo r x F where r A position vector
from pt. O to any pt. on the line of action of
force F .
(1) Magnitude MoMo r x F r F
sin?F r sin? F d
(2) Direction Curl the right-hand fingers
from r toward F (r cross F ) and the thumb is
perpendicular to the plane containing r and F.
8
4.4 Principle of moments
Varignons theorem The moment of a force about
a point is equal to the sum of the moment of the
forces components about the point .
9
4.5 Moment of a force about a specified Axis
1. Objective Find the component of
this moment along a specified axis passes
through the point about which the moment of a
force is computed. 2. Scalar analysis (See
textbook) 3. Vector analysis

Point O on axis aa
O
Axis of projection
10

• Moment of a force F about point 0
• Mo r F
• Here, we assume that bb axis is the moment axis
  of Mo
• (2) Component of Mo onto aa axis
• Ma Ma ua
• MaMo cos?
• Mo ?ua( r F ) ? ua
• trip scalar product
• Here
• Mamagnitude of Ma
• ua unit vector define the direction of aa
  axis

11
If
then
4.Method of Finding Moment about a specific axis
(1) Find the moment of the force about point O
Mo r x F (2) Resolving the moment along
the specific axis Ma Maua
(Moua) ua
ua ( r x F )ua
12
4.6 moment of a couple
1. Definition ( couple) ??? Two parallel
forces have the same magnitude, opposite
distances, and are separated by a perpendicular
distance d.
2. Scalar Formulation (1) Magnitude MFd
(2) Direction sense (Right-hand rule)
Thumb indicates the direction Curled
fingers indicates the sense of rotation
3. Vector Formulation
M r x F MMr x F r F sin? F d
13
Remark
(1) The couple moment is equivalent to the sum
of the moment of both couple forces about any
arbitrary point 0 in space.
Mo rAx( -F ) rB x F (-rArB) x F r x
F M
(2) Couple moment is a free vector which can act
at any point in space.
14
4. Equivalent Couples The forces of equal
couples lie either in the same plane or in
planes parallel to one another.
5. Resultant couple moment
Apply couple moment at any point p on a body and
add them vectorially.
MRSMS r x F
15
4.7 Equivalent system
1. Equivalent system
When the force and couple moment system produce
the same external effects of translation and
rotation of the body as their resultant , these
two sets of loadings are said to be equivalent.
2. Principle of transmissibility
The external effects on a rigid body remain
unchanged,when a force, acting a given point on
the body, is applied to another point lying on
line of action of the force.
line of action
Same external effect
Internal effect ?
Internal stresses are different.
16
3. Point O is on the line of action of the force
A
A
A
equivalent
equivalent
o
o
o
Original system
Sliding vector
4. Point O is not on the line of action of the
force
Couple moment
F
F
Mc r x F
Mr x F
A
A
F
r
P
A
F
o
line of action
o
Original system
Force on Point A Force on point O couple
moment on any point p.
17
Example
Point O is on the line of action of the force
Point O is not on the line of action of the force
18
4.8 Resultant of a force couple system

• 1. Objective
• Simplify a system of force and couple
  moments to
• their resultants to study the external
  effects on the
• body.
• 2. Procedures for Analysis
• (1)Force summations
• FRF1F2SF
• (2)Moment summations
• MR0 SMCr1oF1r2oF2 SMC SM0
• MCCouple moment in the system
• MoCouple moment about pt.O of the
  force in the system.

19
4.9 Further Reduction of a force couple system
1. Simplification to a single Resultant Force
(1)Condition FR MR0
or FRMR0 0 (2)Force system
A. Concurrent Force system
B.Coplanar Force System
20
C. Parallel Force System 1. F1 // F2 ////
Fn 2. MR0 perpendicular to FR ,
MR0SM SrF
2. Reduction to a wrench (1) Condition FR
MR0 MR0M M// M
moment component FR M//
moment component // FR
21

• (2) Wrench (or Screw)
• An equivalent system reduces a
  simple resultant
• force FR and couple moment MR0
  at pt.0 to a
• collinear force FR and couple
  moment M// at pt.

FR
MRo
a
b
o
b
FR
FR
a
a
M//
a
b
M//
o
b
p
o
p
b
b
a
a
