MSc - Microprocessors

1

• MSc - Microprocessors
• Dr. Konstantinos Tatas
• com.tk_at_fit.ac.cy

2
Useful Information

• Instructor Lecturer K. Tatas
• Office hours TBA
• E-mail com.tk_at_fit.ac.cy
• http//staff.fit.ac.cy/com.tk
• Lecture periods/week 3
• Duration 10 weeks
• ECTS 7 (175 hours)

3
Course Objectives

• By the end of the course students should be able
  to
• Evaluate the complex trade-offs involved in
  embedded system design
• Write detailed embedded system requirements and
  specification documents
• Write executable specifications using UML/SystemC
• Develop applications using ARM Developer Suite
• Write efficient ARM assembly and C programs in
  ARM and Thumb mode
• Analyze program performance using traces
• Use code transformations to improve
  performance/code size/power consumption.

4
Course Outline (1/2)

• Week 1 Introduction to embedded systems
  Embedded microprocessor evolution Design
  metrics and constraints (performance, power,
  cost, time-to-market) and design optimization
  challenges - Distributed and Real-time systems
• Week2 Key embedded system technologies
  Integrated Circuit technology Microprocessor
  technology CAD tool technology Sensor
  technology
• Week 3 Embedded system specification and
  modeling Object-oriented specification
  (UML/C/SystemC) Assignment 1
• Week 4 Computer Architecture Instruction sets
  RISC vs. CISC pipelining - The ARM
  microprocessor architecture - ARM assembly ARM
  mode Thumb mode - ARM and Thumb instruction set
  - ARM conditional execution
• Week 5 Processor I/O Serial I/O Busy/wait
  I/O Interrupts Exceptions Traps ARM
  memory mapped I/O - Caches Memory Management
  Units Protection Units ARM cache and MMU
  Assignment 2

5
Course Outline (2/2)

• Week 6 Assignment 1
• Week 7 Programme design and analysis DFGs
  CDFGs Compilers Assemblers Linkers Basic
  compiler optimizations/code transformations
  Measuring programme speed Trace-driven
  performance analysis Energy optimization
  programme size optimization
• Week 8 Code transformations Loop unrolling
  loop merging loop tiling performance
  optimizing transformations
• Week 9 Test
• Week 10 Assignment 2

6
Course Assessment

• Final exam 40
• Coursework 60
• Assignment 1 15
• Assignment 2 15
• Quizzes 10
• Test 10
• Lab exercises 10

7
References

• Books
• W. Wolf, Computers as Components
• W. Wolf, High-Performance Embedded Computing
• H. Kopetz, Real-Time Systems Design Principles
  for Distributed Embedded Applications
• S. Furber, ARM System-on-Chip Architecture
• P. Panda, Memory Issues in Embedded
  Systems-on-Chip
• F. Vahid and T. Givargis, Embedded System
  Design A Unified Hardware/Software Introduction
• F. Catthoor, Data Access and Storage Management
  for Embedded Programmable Processors

8
Microprocessors for Embedded systems

• Computing systems are everywhere
• Most of us think of desktop computers
• PCs
• Laptops
• Mainframes
• Servers
• But theres another type of computing system
• Far more common...

9
Embedded systems overview

• Embedded computing systems
• Computing systems embedded within electronic
  devices
• Hard to define. Nearly any computing system other
  than a desktop computer
• Billions of units produced yearly, versus
  millions of desktop units
• Perhaps 50 per household and per automobile

Computers are in here...
and here...
and even here...
Lots more of these, though they cost a lot less
each.
10
A short list of embedded systems
Anti-lock brakes Auto-focus cameras Automatic
teller machines Automatic toll systems Automatic
transmission Avionic systems Battery
chargers Camcorders Cell phones Cell-phone base
stations Cordless phones Cruise control Curbside
check-in systems Digital cameras Disk
drives Electronic card readers Electronic
instruments Electronic toys/games Factory
control Fax machines Fingerprint identifiers Home
security systems Life-support systems Medical
testing systems
Modems MPEG decoders Network cards Network
switches/routers On-board navigation Pagers Photoc
opiers Point-of-sale systems Portable video
games Printers Satellite phones Scanners Smart
ovens/dishwashers Speech recognizers Stereo
systems Teleconferencing systems Televisions Tempe
rature controllers Theft tracking systems TV
set-top boxes VCRs, DVD players Video game
consoles Video phones Washers and dryers

• And the list goes on and on

11
Some common characteristics of embedded systems

• Single-functioned
• Executes a single program, repeatedly
• Tightly-constrained
• Low cost, low power, small, fast, etc.
• Reactive and real-time
• Continually reacts to changes in the systems
  environment
• Must compute certain results in real-time without
  delay

12
An embedded system example Digital camera

• Single-functioned -- always a digital camera
• Tightly-constrained -- Low cost, low power,
  small, fast
• Reactive and real-time -- only to a small extent

13
Embedded Software Development Requires as
Much/More Design Effort Than Hardware
14
A System-on-a-Chip Example
Courtesy Philips
15
Design at a crossroadSystem-on-a-Chip

• Embedded applications where cost, performance,
  and energy are the real issues!
• DSP and control intensive
• Mixed-mode
• Combines programmable and application-specific
  modules
• Software plays crucial role

16
Disciplines involved in Embedded System Design

• Digital System Design
• Software Design
• Analog/Mixed-Signal/RF System Design
• Operating Systems
• Microprocessors/Computer Architecture
• Verification
• Testing
• etc

17
Languages traditionally used in Embedded System
Design

• Software design
• C/C
• Java
• Assembly
• Verification
• VHDL/Verilog
• SystemVerilog
• Tcl/tk
• Vera

• Specification/modeling
• UML
• SDL
• C/C
• Hardware design
• VHDL
• Verilog

18
Design challenge optimizing design metrics

• Obvious design goal
• Construct an implementation with desired
  functionality
• Key design challenge
• Simultaneously optimize numerous design metrics
• Design metric
• A measurable feature of a systems
  implementation
• Optimizing design metrics is a key challenge

19
Design challenge optimizing design metrics

• Common metrics
• Unit cost the monetary cost of manufacturing
  each copy of the system, excluding NRE cost
• NRE cost (Non-Recurring Engineering cost) The
  one-time monetary cost of designing the system
• Size the physical space required by the system
• Performance the execution time or throughput of
  the system
• Power the amount of power consumed by the system
• Flexibility the ability to change the
  functionality of the system without incurring
  heavy NRE cost

20
Design challenge optimizing design metrics

• Common metrics (continued)
• Time-to-prototype the time needed to build a
  working version of the system
• Time-to-market the time required to develop a
  system to the point that it can be released and
  sold to customers
• Maintainability the ability to modify the system
  after its initial release
• Correctness, safety, many more

21
Design metric competition -- improving one may
worsen others

• Expertise with both software and hardware is
  needed to optimize design metrics
• Not just a hardware or software expert, as is
  common
• A designer must be comfortable with various
  technologies in order to choose the best for a
  given application and constraints

22
Time-to-market a demanding design metric

• Time required to develop a product to the point
  it can be sold to customers
• Market window
• Period during which the product would have
  highest sales
• Average time-to-market constraint is about 8
  months
• Delays can be costly

23
Losses due to delayed market entry

• Simplified revenue model
• Product life 2W, peak at W
• Time of market entry defines a triangle,
  representing market penetration
• Triangle area equals revenue
• Loss
• The difference between the on-time and delayed
  triangle areas

24
Losses due to delayed market entry (cont.)

• Area 1/2 base height
• On-time 1/2 2W W
• Delayed 1/2 (W-DW)(W-D)
• Percentage revenue loss (D(3W-D)/2W2)100
• Try some examples

• Lifetime 2W52 wks, delay D4 wks
• (4(326 4)/2262) 22
• Lifetime 2W52 wks, delay D10 wks
• (10(326 10)/2262) 50
• Delays are costly!

25
The performance design metric

• Widely-used measure of system, widely-abused
• Clock frequency, instructions per second not
  good measures
• Digital camera example a user cares about how
  fast it processes images, not clock speed or
  instructions per second
• Latency (response time)
• Time between task start and end
• e.g., Cameras A and B process images in 0.25
  seconds
• Throughput
• Tasks per second, e.g. Camera A processes 4
  images per second
• Throughput can be more than latency seems to
  imply due to concurrency, e.g. Camera B may
  process 8 images per second (by capturing a new
  image while previous image is being stored).
• Speedup of B over S Bs performance / As
  performance
• Throughput speedup 8/4 2

26
Three key embedded system technologies

• Technology
• A manner of accomplishing a task, especially
  using technical processes, methods, or knowledge
• Three key technologies for embedded systems
• Processor technology
• IC technology
• Design technology

27
Processor technology

• The architecture of the computation engine used
  to implement a systems desired functionality
• Processor does not have to be programmable
• Processor not equal to general-purpose
  processor

Datapath
Controller
Datapath
Controller
Datapath
Controller
Control logic
index
Registers
Control logic and State register
Register file
Control logic and State register
total
Custom ALU
State register

General ALU
IR
PC
IR
PC
Data memory
Data memory
Program memory
Program memory
Data memory
Assembly code for total 0 for i 1 to
Assembly code for total 0 for i 1 to
Single-purpose (hardware)
General-purpose (software)
Application-specific
28
Processor technology

• Processors vary in their customization for the
  problem at hand

total 0 for i 1 to N loop total
Mi end loop
Desired functionality

General-purpose processor
Single-purpose processor
Application-specific processor
29
General-purpose processors

• Programmable device used in a variety of
  applications
• Also known as microprocessor
• Features
• Program memory
• General datapath with large register file and
  general ALU
• User benefits
• Low time-to-market and NRE costs
• High flexibility
• Pentium the most well-known, but there are
  hundreds of others

30
Single-purpose processors

• Digital circuit designed to execute exactly one
  program
• a.k.a. coprocessor, accelerator or peripheral
• Features
• Contains only the components needed to execute a
  single program
• No program memory
• Benefits
• Fast
• Low power
• Small size

31
Application-specific processors

• Programmable processor optimized for a particular
  class of applications having common
  characteristics
• Compromise between general-purpose and
  single-purpose processors
• Features
• Program memory
• Optimized datapath
• Special functional units
• Benefits
• Some flexibility, good performance, size and power

32
IC technology

• The manner in which a digital (gate-level)
  implementation is mapped onto an IC
• IC Integrated circuit, or chip
• IC technologies differ in their customization to
  a design
• ICs consist of numerous layers (perhaps 10 or
  more)
• IC technologies differ with respect to who builds
  each layer and when

33
IC technology Design Approaches
34
Full-custom design

• All layers are optimized for an embedded systems
  particular digital implementation
• Placing transistors
• Sizing transistors
• Routing wires
• Benefits
• Excellent performance, small size, low power
• Drawbacks
• High NRE cost (e.g., 300k), long time-to-market

35
The Custom Approach
Intel 4004
Courtesy Intel
36
Transition to Automation and Regular Structures
Courtesy Intel
37
(No Transcript)
38
IC technology Design Approaches
IC Technology Implementation Approaches
Custom
Semicustom
Cell-based
Array-based
Standard Cells
Pre-diffused
Pre-wired
Macro Cells
Compiled Cells
(Gate Arrays)
(FPGA's)
39
Semi-custom

• Lower layers are fully or partially built
• Designers are left with routing of wires and
  maybe placing some blocks
• Benefits
• Good performance, good size, less NRE cost than a
  full-custom implementation (perhaps 10k to
  100k)
• Drawbacks
• Still require weeks to months to develop

40
Cell-based Design (or standard cells)
Routing channel requirements are reduced by
presence of more interconnect layers
41
Standard Cell Example
Brodersen92
42
Standard Cell - Example
3-input NAND cell (from ST Microelectronics) C
Load capacitance T input rise/fall time
43
IC technology Design Approaches
IC Technology Implementation Approaches
Custom
Semicustom
Cell-based
Array-based
Standard Cells
Pre-diffused
Pre-wired
Macro Cells
Compiled Cells
(Gate Arrays)
(FPGA's)
44
Programmable Logic Devices

• All layers (diffusion, polysilicon, multi-
  metal) may exist
• Designers can purchase an IC
• Connections on the IC are either created or
  destroyed to implement desired functionality
• Field-Programmable Gate Array (FPGA) and recently
  Gate Arrays are very popular
• Benefits
• Low NRE costs, almost instant IC availability
• Drawbacks
• Bigger, expensive (perhaps 30 per unit), power
  hungry, slower

45
Gate Array Sea-of-gates
Uncommited Cell
Committed Cell(4-input NOR)
46
Sea-of-gate Primitive Cells
Using oxide-isolation
Using gate-isolation
47
Sea-of-gates
Random Logic
Memory Subsystem
LSI Logic LEA300K (0.6 mm CMOS)
48
Prewired Arrays

• Classification of prewired arrays (or
  field-programmable devices)
• Based on Programming Technique
• Fuse-based (program-once)
• Non-volatile EPROM based
• RAM based
• Programmable Logic Style
• Array-Based
• Look-up Table
• Programmable Interconnect Style
• Channel-routing
• Mesh networks

49
Altera MAX
From Smith97
50
Altera MAX Interconnect Architecture
row channel
column channel
LAB
Array-based (MAX 3000-7000)
Mesh-based (MAX 9000)
51
LUT-Based Logic Cell
4
C
....C
1
4
xx
xxxx
xxxx
xxxx
Bits
D
xxxx
4
control
Logic
xx
xx
D
xx
xx
function
x
x
3
xx
of
xx
D
2
xxx
D
1
Logic
xx
x
xx
function
x
x
of
x
x
xxx
F
4
Bits
xxxx
Logic
control
F
xx
xx
3
xx
function
xx
x
x
xx
F
of
xx
2
xxx
F
1
xx
xx
x
xxxxx
x
H
x
P
Multiplexer Controlled
Xilinx 4000 Series
by Configuration Program
52
Array-Based Programmable Wiring
Vertical tracks
53
Transistor Implementation of Mesh
Courtesy Dehon and Wawrzyniek
54
RAM-based FPGA
Xilinx XC4000ex
55
Design Technology

• The manner in which we convert our concept of
  desired system functionality into an
  implementation

Compilation/ Synthesis
Libraries/ IP
Test/ Verification
System specification
System synthesis
Hw/Sw/ OS
Model simulat./ checkers
Compilation/Synthesis Automates exploration and
insertion of implementation details for lower
level.
Behavioral specification
Behavior synthesis
Cores
Hw-Sw cosimulators
Libraries/IP Incorporates pre-designed
implementation from lower abstraction level into
higher level.
RT specification
RT synthesis
RT components
HDL simulators
Test/Verification Ensures correct functionality
at each level, thus reducing costly iterations
between levels.
Logic specification
Logic synthesis
Gates/ Cells
Gate simulators
To final implementation
56
The co-design ladder

• In the past
• Hardware and software design technologies were
  very different
• Recent maturation of synthesis enables a unified
  view of hardware and software
• Hardware/software codesign

The choice of hardware versus software for a
particular function is simply a tradeoff among
various design metrics, like performance, power,
size, NRE cost, and especially flexibility there
is no fundamental difference between what
hardware or software can implement.
57
Independence of processor and IC technologies

• Basic tradeoff
• General vs. custom
• With respect to processor technology or IC
  technology
• The two technologies are independent

58
Design Decision Trade-offs
59
Generalised Design Flow
60
Architecture ReUse

• Silicon System Platform
• Flexible architecture for hardware and software
• Specific (programmable) components
• Network architecture
• Software modules
• Rules and guidelines for design of HW and SW
• Has been successful in PCs
• Dominance of a few players who specify and
  control architecture
• Application-domain specific (difference in
  constraints)
• Speed (compute power)
• Dissipation
• Costs
• Real / non-real time data

61
Platform-Based Design
Only the consumer gets freedom of
choice designers need freedom from
choice (Orfali, et al, 1996, p.522)

• A platform is a restriction on the space of
  possible implementation choices, providing a
  well-defined abstraction of the underlying
  technology for the application developer
• New platforms will be defined at the
  architecture-micro-architecture boundary
• They will be component-based, and will provide a
  range of choices from structured-custom to fully
  programmable implementations
• Key to such approaches is the representation of
  communication in the platform model

SourceR.Newton
62
Platform-based Design System-on-Chip

• Use of predefined Intellectual Property (IP)
• A platform-based system consists of a RISC
  processor, memories, busses and a common language
• Platform-based design poses the problem of
  partitioning a solution between hardware (HDL)
  and software (programming processors)

63
Platforms Enable Simplified SoC Design

• Customer demands
• Fast turn-around time
• Easy access to pre-qualified building blocks
• Web enabled
• Design technology
• Core platforms
• Big IP
• Emerging SoC bus standards
• Embedded software
• HW/SW co-verification

64
And Automation of IP Selection Integration
65
Heterogeneous Programmable Platforms
FPGA Fabric
Embedded memories
Embedded PowerPc
Hardwired multipliers
Xilinx Vertex-II Pro
High-speed I/O
66
Xilinxs products
67
Xilinxs products
68
Comparison of CMOS design methods
Design Method NRE Unit Cost Power Dissipation Complexity of Implementation Time-to-Market Performance Flexibility
µProcessor/DSP low medium high low low low high
PLA low medium medium low low medium low
FPGA low high medium medium medium medium medium
Gate/Array medium medium low medium medium medium medium
Cell Based high low low high high high low
Custom Design high low low high high Very high low
Platform Based high Low/medium low high Medium/low high medium
69
Impact of Implementation Choices
70
Design Economics (1)

• The selling price of an IC ?StotalCtotal/(1-m),
  Ctotal is manufacturing cost for a single IC, m
  desired profit margin
• Costs for produce an IC
• Non-recurring engineering costs (NREs)
• Recurring engineering costs
• Fixed costs

71
Design Economics (2)

• Non-recurring engineering costs (NREs)
• Engineering design cost
• Prototype manufacturing cost
• Recurring costs
• Process
• Package
• Test

72
NRE and unit cost metrics

• Costs
• Unit cost the monetary cost of manufacturing
  each copy of the system, excluding NRE cost
• NRE cost (Non-Recurring Engineering cost) The
  one-time monetary cost of designing the system
• total cost NRE cost unit cost of
  units
• per-product cost total cost / of units

• (NRE cost / of units) unit cost

• Example
• NRE2000, unit100
• For 10 units
• total cost 2000 10100 3000
• per-product cost 2000/10 100 300

73
NRE and unit cost metrics

• Compare technologies by costs -- best depends on
  quantity
• Technology A NRE2,000, unit100
• Technology B NRE30,000, unit30
• Technology C NRE100,000, unit2

• But, must also consider time-to-market

74
Wafer and die cost
Die yield number of good dies/total number of
dies
75
Example

• Assuming
• 20 engineers are employed full-time for a year
  with a 50,000/year average salary
• Additional 200,000 overhead costs of which
  100,000 for total testing
• A wafer cost of 200 per wafer
• A 2 packaging cost per chip
• 10 dies/wafer
• 70 die yield
• 98 final test yield
• A market for 100,000 items
• Calculate the minimum shelf price of the chip

76
Design productivity exponential increase
100,000
10,000
1,000
100
Productivity (K) Trans./Staff Mo.
10
1
0.1
0.01
1981
1995
1997
2007
1983
1987
1989
1991
1993
1999
2001
2003
1985
2005
2009

• Exponential increase over the past few decades

77
The growing design-productivity gap
Design Productivity Crisis (SRC 1997) Potential
Design Complexity and Designer Productivity
Moores Law Standard cell density and speed
Equivalent Added Complexity
58 / yr compounded Complexity Growth Rate
Density (Kgates / mm2)ASIC clock (MHz)
Logic Transistor per Chip ( M )
Productivity ( K) Trans./Staff Mo.
21 / yr compounded Productivity Growth Rate
78
Design productivity gap

• 1981 leading edge chip required 100 designer
  months
• 10,000 transistors / 100 transistors/month
• 2002 leading edge chip requires 30,000 designer
  months
• 150,000,000 / 5000 transistors/month
• Designer cost increase from 1M to 300M
• While designer productivity has grown at an
  impressive rate over the past decades, the rate
  of improvement has not kept pace with chip
  capacity

79
The mythical man-month

• The situation is even worse than the productivity
  gap indicates
• In theory, adding designers to team reduces
  project completion time
• In reality, productivity per designer decreases
  due to complexities of team management and
  communication
• In the software community, known as the mythical
  man-month (Brooks 1975)
• At some point, can actually lengthen project
  completion time! (Too many cooks)

• 1M transistors, 1 designer5000 trans/month
• Each additional designer reduces for 100
  trans/month
• So 2 designers produce 4900 trans/month each

80
Summary

• Embedded systems are everywhere
• Key challenge optimization of design metrics
• Design metrics compete with one another
• A unified view of hardware and software is
  necessary to improve productivity
• Three key technologies
• Processor general-purpose, application-specific,
  single-purpose
• IC Full-custom, semi-custom, PLD
• Design Compilation/synthesis, libraries/IP,
  test/verification

81
Real-time and distributed systems

• Dr. Konstantinos Tatas

82
What is real-time? Is there any other kind?

• A real-time computer system is a computer system
  where the correctness of the system behavior
  depends not only on the logical results of the
  computations, but also on the physical time when
  these results are produced.
• By system behavior we mean the sequence of
  outputs in time of a system.

83
Real-time means reactive

• A real-time computer system must react to stimuli
  from its environment
• The instant when a result must be produced is
  called a deadline.
• If a result has utility even after the deadline
  has passed, the deadline is classified as soft,
  otherwise it is firm.
• If severe consequences could result if a firm
  deadline is missed, the deadline is called hard.
• Example Consider a traffic signal at a road
  before a railway crossing. If the traffic signal
  does not change to red before the train arrives,
  an accident could result.

84
Reliability

• The Reliability R(t) of a system is the
  probability that a system will provide the
  specified service until time t, given that the
  system was operational at the beginning (t-t0)
• The probability that a system will fail in a
  given interval of time is expressed by the
  failure rate, measured in FITs (Failure In Time).

• A failure rate of 1 FIT means that the mean time
  to a failure (MTTF) of a device is 109 h, i.e.,
  one failure occurs in about 115,000 years.
• If a system has a constant failure rate of ?
  failures/h, then the reliability at time t is
  given by
• R(t) exp(-?(t-to))
• MTTF 1/?

85
Example

• What must be the system failure rate so that 99
  of the systems in the field work reliably for the
  first 100,000 hours?

86
Safety
87
Maintainability
88
Name some hard, firm and soft deadline embedded
systems
89
Example

• an automotive company produces 2,000,000
  electronic engine controllers of a special type.
• The following design alternatives are discussed
• (a) Construct the engine control unit as a single
  SRU with the application software in Read Only
  Memory (ROM).The production cost of such a unit
  is 250. In case of an error, the complete unit
  has to be replaced.
• (b) Construct the engine control unit such that
  the software is contained in a ROM that is placed
  on a socket and can be replaced in case of a
  software error. The production cost of the unit
  without the ROM is 248. The cost of the ROM is
  5.
• (c) Construct the engine control unit as a single
  SRU where the software is loaded in a Flash EPROM
  that can be reloaded. The production cost of such
  a unit is 255.
• The labor cost of repair is assumed to be 50 for
  each vehicle. (It is assumed to be the same for
  each one of the three alternatives).
• Calculate the cost of a software error for each
  one of the three alternative designs if 300,000
  cars have to be recalled because of the software
  error (example in Sect. 1.6.1).
• Which one is the lowest cost alternative if only
  1,000 cars are affected by a recall?

90
Distributed RT system model

• From the POV of an outside observer, a real-time
  (RT) system can be decomposed into three
  communicating subsystems
• a controlled object (the physical subsystem, the
  behavior of which is governed by the laws of
  physics),
• a distributed computer subsystem (the cyber
  system, the behavior of which is governed by the
  programs that are executed on digital computers)
• a human user or operator
• The distributed computer system consists of
  computational nodes that interact by the exchange
  of messages.
• A computational node can host one or more
  computational components.

91
Event-Triggered Control Versus Time-Triggered
Control
92
(No Transcript)
