Title: Data Basics


1
Data Basics
2
Data Matrix
  • Many datasets can be represented as a data
    matrix.
  • Rows corresponding to entities
  • Columns represents attributes.
  • N size of the data
  • D dimensionality of the data
  • Univariate analysis the analysis of a single
    attribute.
  • Bivariate analysis simultaneous analysis of two
    attributes.
  • Multivariate analysis simultaneous analysis of
    multiple attributes.

3
Example for Data Matrix
4
Attributes
  • Categorical Attributes
  • composed of a set of symbols
  • has a set-valued domain
  • E.g., Sex with domain(Sex) M, F, Education
    with domain(Education) High School, BS, MS,
    PhD.
  • Two types of categorical attributes
  • Nominal
  • values in the domain are unordered
  • Only equality comparisons are allowed
  • E.g. Sex
  • Ordinal
  • Values are ordered
  • Both equality and inequality comparisons are
    allowed
  • E.g. Education

5
Attributes Cont.
  • Numeric Attributes
  • Has real-valued or integer-valued domain
  • E.g. Age with domain (Age) N, where N denotes
    the set of natural numbers (non-negative
    integers).
  • Two types of numeric attributes
  • Discrete values take on finite or countably
    infinite set.
  • Continuous values take on any real value
  • Another Classification
  • Interval-scaled
  • for attributes only differences make sense
  • E.g. temperature.
  • Ratio-scaled
  • Both difference and ratios are meaningful
  • E.g. Age

6
Algebraic View of Data
  • If the d attributes in the data matrix D are all
    numeric
  • each row can be considered as a d-dimensional
    point
  • or equivalently, each row may be considered a
    d-dimensional column vector
  • Linear combination of the standard basis vectors

7
Example of Algebraic View of Data
8
Geometric View of Data
9
Distance of Angle
10
(No Transcript)
11
(No Transcript)
12
Example of Distance and Angle
13
Mean and Total Variance
14
Centered Data Matrix
  • The centered data matrix is obtained by
    subtracting the mean from all the points

15
Orthogonality
  • Two vectors a and b are said to be orthogonal if
    and only if
  • It implies that the angle between them is 90? or
    p/2 radians.

16
Orthogonal Projection
P orthogonal projection of b on the vector a R
error vector between points b and p
17
Example of Projection
18
Linear Independence and Dimensionality
  • the set of all
    possible linear combinations of the vectors.
  • If then
    we say that v1, , vk is a spanning set for
    .

19
Row and Column Space
  • The column space of D, denoted col(D) is the set
    of all linear combinations of the d column
    vectors or attributes
  • The row space of D, denoted row(D), is the set of
    all linear combinations of the n row vectors or
    points
  • Note also that the row space of D is the column
    space of

20
Linear Independence
21
Dimension and Rank
  • Let S be a subspace of Rm.
  • A basis for S a set of linearly independent
    vectors v1, , vk , and span(v1, , vk)
    S.
  • orthogonal basis for S If the vectors in the
    basis are pair-wise orthogonal
  • If in addition they are also normalized to be
    unit vectors, then they make up an orthonormal
    basis for S.
  • For instance, the standard basis for Rm is an
    orthonormal basis consisting of the vectors

22
  • Any two bases for S must have the same number of
    vectors.
  • Dimension The number of vectors in a basis for
    S, denoted as dim(S).
  • For any matrix, the dimension of its row and
    column space are the same, and this dimension is
    also called as the rank of the matrix.

23
Data Probabilistic View
  • Assumes that each numeric attribute Xj is a
    random variable, defined as a function that
    assigns a real number to each outcome of an
    experiment.
  • Given as Xj O ? R, where O, the domain of Xj ,
    called as the sample space
  • R, the range of Xj , is the set of real numbers.
  • If the outcomes are numeric, and represent the
    observed values of the random variable, then Xj
    O ? O is simply the identity function Xj (v) v
    for all v ? O.

24
Data Probabilistic View
  • A random variable X is called a discrete random
    variable if it takes on only a finite or
    countably infinite number of values in its range.
  • X is called a continuous random variable if it
    can take on any value in its range.

25
Example
  • Be default, consider the attribute X1 to be a
    continuous random variable, given as the identity
    function X1(v) v, since the outcomes are all
    numeric.
  • On the other hand, if we want to distinguish
    between iris flowers with short and long sepal
    lengths, we define a discrete random variable A
    as follows
  • In this case the domain of A is 4.3, 7.9. The
    range of A is 0, 1, and thus A assumes non-zero
    probability only at the discrete values 0 and 1.

26
(No Transcript)
27
Example Bernoulli and Binomial Distribution
  • only 13 irises have sepal length of at least 7cm
  • In this case we say that A has a Bernoulli
    distribution with parameter p ? 0, 1. p denotes
    the probability of a success, whereas 1- p
    represents the probability of a failure

28
Example Bernoulli and Binomial Distribution
  • Let us consider another discrete random variable
    B, denoting the number of irises with long sepal
    lengths in m independent Bernoulli trials with
    probability of success p.
  • B takes on the discrete values 0,m, and its
    probability mass function is given by the
    Binomial distribution
  • For example, taking p 0.087 from above, the
    probability of observing exactly k 2 long sepal
    length irises in m 10 trials is given as

29
full probability mass function for different
values of k
30
Probability Density Function
  • If X is continuous, its range is the entire set
    of real numbers R.
  • probability density function specifies the
    probability that the variable X takes on values
    in any interval a, b ? R

31
Cumulative Distribution Function
  • For any random variable X, whether discrete or
    continuous, we can define the cumulative
    distribution function (CDF) F R ? 0, 1, that
    gives the probability of observing a value at
    most some given value x

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
Probability Density Function f(x)
  • What is P(Xx) when x is on a real domain
  • f(x) gt0 and

46
Normal Distribution
  • Let us assume that these values follow a Gaussian
    or normal density function, given as

47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
Bivariate Random Variables
  • considering a pair of attributes, X1 and X2, as a
    bivariate random variable

54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
In 2-Dimensions
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
Multivariate Random Variable
79
Multivariate Random Variable
80
Numeric Attribute Analysis
  • Sample and Statistics
  • Univariate Analysis
  • Bivariate Analysis
  • Multivariate Analysis
  • Normal Distribution

81
Random Sample and Statistics
  • Population is used to refer to the set or
    universe of all entities under study.
  • However, looking at the entire population may not
    be feasible, or may be too expensive.
  • Instead, we draw a random sample from the
    population, and compute appropriate statistics
    from the sample, that give estimates of the
    corresponding population parameters of interest.

82
Univariate Sample
  • Let X be a random variable, and let xi (1 i
    n) denote the observed values of attribute X in
    the given data, where n is the data size.
  • Given a random variable X, a random sample of
    size n from X is defined as a set of n
    independent and identically distributed (IID)
    random variables S1, S2, , Sn.
  • since the variables Si are all independent, their
    joint probability function is given as

83
Multivariate Sample
  • xi the value of a d-dimensional vector random
    variable Si (X1,X2, ,Xd ).
  • Si are independent and identically distributed,
    and thus their joint distribution is given as
  • Assume d attributes X1,X2, ,Xd are
    independent, (1.43) can be rewritten as

84
Statistic
  • Let Si denote the random variable corresponding
    to data point xi , then a statistic ˆ? is a
    function ˆ? (S1, S2, , Sn) ? R.
  • If we use the value of a statistic to estimate a
    population parameter, this value is called a
    point estimate of the parameter, and the
    statistic is called as an estimator of the
    parameter.

85
(No Transcript)
86
Numeric Attribute Analysis
  • Sample and Statistics
  • Univariate Analysis
  • Bivariate Analysis
  • Multivariate Analysis
  • Normal Distribution

87
Univariate Analysis
Univariate analysis focuses on a single attribute
at a time, thus the data matrix D can be thought
of as a n 1 matrix, or simply a column vector.
88
Univariate Analysis
X is assumed to be a random variable, and each
point xi (1 i n) is assumed to be the value
of a random variable Si , where the variables Si
are all independent and identically distributed
as X, i.e., they constitute a random sample drawn
from X. In the vector view, we treat the sample
as an n-dimensional vector, and write X ? Rn.
89
What can sample analysis do?
  • Unknown f(X) and F(X)
  • Parameters(µ,d)

90
Empirical Cumulative Distribution Function
  • Where

91
Inverse Cumulative Distribution Function
92
Empirical Probability Mass Function
  • Where

93
Measures of Central Tendency (Mean)
  • Population Mean

Sample Mean (Unbiased, not robust)
94
Measures of Central Tendency (Median)
  • Population Median

or
Sample Median
95
Measures of Central Tendency (Mode)
  • Sample Mode
  • may not be very useful
  • but not affected by the outliers too much

96
Example
97
Measures of Dispersion (Range)
  • Range

Sample Range
  • Not robust, sensitive to extreme values

98
Measures of Dispersion (Inter-Quartile Range)
  • Inter-Quartile Range (IQR)

Sample IQR
  • More robust

99
Measures of Dispersion (Variance and Standard
Deviation)
Variance
Standard Deviation
100
Measures of Dispersion (Variance and Standard
Deviation)
Variance
Standard Deviation
Sample Variance Standard Deviation
101
Normalization
Linear Normalization
Z-Score
102
Normalization Example
103
Topics
  • Sample and Statistics
  • Univariate Analysis
  • Bivariate Analysis
  • Multivariate Analysis
  • Normal Distribution

104
Bivariate Analysis
Bivariate analysis focuses on Two attributes at a
time, thus the data matrix D can be thought of as
a n 2 matrix, or two column vectors.
105
Empirical Joint Probability Mass Function
or
where
106
Measures of Central Tendency (Mean)
  • Population Mean

Sample Mean
107
Measures of Association (Covariance)
Covariance
Sample Covariance
108
Measures of Association (Correlation)
Correlation
Sample Correlation
109
Measures of Association (Correlation)
110
Correlation Example
111
Topics
  • Sample and Statistic
  • Univariate Analysis
  • Bivariate Analysis
  • Multivariate Analysis
  • Normal Distribution

112
Multivariate Analysis
Multivariate analysis focuses on multiple
attributes at a time, thus the data matrix D can
be thought of as a n d matrix, or d column
vectors.
113
Measures of Central Tendency (Mean)
  • Population Mean

Sample Mean
114
Measures of Association (Covariance Matrix)
115
Measures of Association (Correlation)
Correlation
Sample Correlation
116
Topics
  • Sample and Statistic
  • Univariate Analysis
  • Bivariate Analysis
  • Multivariate Analysis
  • Normal Distribution

117
Univariate Normal Distribution
118
Multivariate Normal Distribution
119
  • Thank You!

120
(No Transcript)
121
(No Transcript)
122
(No Transcript)
123
(No Transcript)
124
(No Transcript)
125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
