Title: .NET and J2EE INTEROPERABILLITY


1
.NET and J2EE INTEROPERABILLITY
  • By
  • PHANIDEEP NARRA

2
OVERVIEW
  • Definition
  • Motivation
  • .NET and J2EE Architectures
  • Interoperability Problems
  • Interoperability Technologies
  • Conclusion and future works
  • Questions

3
DEFINITION
  • What is interoperability?
  • Ability of two or more systems to
    communicate, transfer data among various
    functional units and use the transferred data

4
MOTIVATION
  • Achieving reuse of existing systems
  • - usually highest on the list of considerations
  • Implementing Proof of concept studies
  • - for a new interface with existing environment
  • Migration to microsoft.net
  • - to migrate from J2EE to .NET
  • Achieving lower project costs
  • - .NET has the potential to deliver lower
    project costs

5
Basics of .NET for J2EE Developers
  • Microsoft .NET is a designation that reflects
    Microsofts realignment towards Internet
    operation and distributed applications.
  • Microsoft .NET consists of three main components
  • .NET Framework
  • Visual Studio.NET
  • Windows Server System

6
Basics of J2EE for .NET Developers
  • Sun Microsystems developed Java as both a
    platform and a programming language.
  • There are currently three editions of the Java
    platform
  • J2SE
  • J2EE
  • J2ME

7
Major Differences
  • Three Major differences
  • Operating System Support - J2EE supports many
    OS, whereas .NET does not.

  • Language support .NET supports many languages,
    whereas J2EE does not.
  • Execution Method - .NET produces MSIL, whereas
    JAVA produces BYTECODE.

8
.NET ARCHITECTURE
9
J2EE ARCHITECTURE
10
INTEROPERABILITY PROBLEMS
  • When implementing a .NET and J2EE
    interoperability project, you confront three main
    data exchange challenges
  • The Three challenges are
  • Primitive Data type Mappings - System.String in
    .NET and java.lang.string in JAVA are not the
    same.
  • Non-Existent Data types data types which exist
    in one that do not exist in the other.
  • Complex Data types Ex nested primitive
    datatypes.

11
INTEROPERABILITY PROBLEMS
  • There are few solutions to type compatibility
  • Using Serialization Two Types of serialization
  • Binary Serialization Converts data type to
    binary stream
  • XML Serialization Converts data type to XML
    stream which is then converted to XML document.
  • De-Serialization can be done at the other end to
    get a type compatible data type for that
    environment.
  • Using XML Schemas is a more reliable solution.

12
INTEROPERABILITY PROBLEMS
  • When you use XML serialization you generate an
    XML document.
  • Ensure that this document generated at one
    platform is compatible with the other platform.
  • The XML Schema Solution Provides the
    interoperability contract that specifies the
    format for XML documents
  • XML Schema provides the template for successfully
    linking .NET and JAVA

13
INTEROPERABILITY PROBLEMS
  • Data Exchange recommendations are provided for
    different interoperability scenarios.
  • There are three interoperability scenarios
  • Linking two or more new applications
  • Linking a new application to an existing
    application
  • Linking two existing applications

14
INTEROPERABILITY PROBLEMS
  • Recommendations for linking new applications
  • Use XSD to define common or shared types and then
    generate platform-specific code from those shared
    types.
  • Create a central XSD repository for your
    development teams to provide for consistency in
    generating types across applications.
  • Avoid exposing elements that XSD does not define
    always use types that are published in XSD.
  • Test data types with test utilities before
    writing your application.

15
INTEROPERABILITY PROBLEMS
  • Recommendations for linking new with existing
    apps.
  • Generate XSDs from the data types that the
    existing application exposes.
  • Use these XSDs to generate corresponding data
    type classes in the new applications platform.
  • Follow the recommendations from the first
    scenario.

16
INTEROPERABILITY PROBLEMS
  • Recommendations for linking two existing apps.
  • Solution is to use a common format and a single
    adapter
  • 1. Select one applications data type as a
    common format for exchanging data.
  • 2. Implement an adapter layer on the other
    application to convert its data type to the
    common format.

17
INTEROPERABILITY TECHNOLOGIES
  • There are several technologies used for J2EE and
    .NET interoperability.
  • Two most common technologies used are
  • .NET Remoting
  • XML Web Services

18
INTEROPERABILITY TECHNOLOGIES
  • .NET Remoting
  • Has the advantage of greater performance and easy
    implementation in .NET framework
  • However, JAVA Applications cannot directly
    connect using .NET remoting.
  • They require runtime bridges Ja.NET and
    JNBridgePro.

19
INTEROPERABILITY TECHNOLOGIES
  • A simple .NET remoting implementation consists of
    the following items
  • A remotable application object or server
    component.
  • A host application that listens for client
    requests to the remotable application component.
  • A client application component that makes
    requests to the remotable application component.

20
INTEROPERABILITY TECHNOLOGIES
  • Implementing .NET Remoting involves the following
    phases
  • ? Determining the host application or
    environment.
  • ? Creating the server component.
  • ? Creating the client.
  • ? Editing the configuration files.

21
CONCLUSION FUTURE WORK
  • There are many other technologies which can be
    used for J2EE and .NET interoperability.
  • CORBA and Web Services are major among them.
  • .NET is a product and J2EE is a standard
  • If you use web services, .NET is nice but JAVA is
    scalable.

22
THANK YOU
