Title: Securing Java applets


1
Securing Java applets
  • Erik Poll
  • Security of Systems (SOS) group
  • University of Nijmegen
  • www.cs.kun.nl/erikpoll

2
Overview
  • Security problems of Java Card applets or
    any other piece of software, for that matter
  • Work in the EU-IST project VerifiCard
  • Work on formal techniques for applet verification
    in Nijmegen

3
Java applet
  • Java application (piece of software) that is
    deployed independently on some platform, with
    some operating system (OS), eg
  • Java Card smart card applet
  • mobile phone (eg midlet on MIDP phone)
  • PDA
  • web browser
  • PC
  • airplane

4
Old vs new smart cards
  • one program (applet)
  • written in machine-code, specific to chip and OS
  • burnt into ROM
  • Applet written in high-level language (Java Card)
  • compiled into bytecode
  • stored in EEPROM
  • interpreted on card
  • Options
  • multi-application several applets on one card
  • post-issuance adding or deleting applets on card

5
Java Card architecture
applet
applet
applet
Java Card platform (JCRE) - miniature OS
JC Virtual Machine
JC API
Global Platform
smart card hardware
6
Production of a Java Card applet
bytecode verifier
cap generator
compiler
byte code
source code
cap file
  • Options
  • only pre-loaded applets
  • only digitally signed applets (using Global
    Platform)

download
Remaining issue how do we certify these
pre-loaded or signed applets?
7
Security questions
  • Is my applet correct and secure?
  • correct is necessary precondition for secure
  • Is the platform correct and secure ?
  • Is someone elses applet is not malicious
  • ie. will it not
  • annoy users,
  • interfere with other applets, or
  • damage the platform ?

8
Java applet security
  • language level security
  • basic guarantees (no buffer overflows)
  • platform level security
  • imposes additional restrictions to protect
    platform other applets (firewall/sandbox)
  • application level security
  • applet responsible for own specific correctness
    security needs

9
Buffer overflows
  • Example
  • Application asks for 4-digit PIN code
  • User supplies a 5-digit PIN code 12345
  • What happens in the memory ?

0
0
k
i
r
e
0
0
0
4
1
2
3
5
10
Buffer overflows
  • Single biggest cause of bugs security holes
  • 30-70 of all security alerts www.cert.org/advisor
    ies
  • 36 of all bugs at Microsoft
  • Possible - and frequent - in C, C
    although there are good tools to detect them...
  • Impossible in modern languages Java, C
  • Conclusion dont use C(), use Java or C

11
Java applet security
  • language level security
  • basic guarantees (no buffer overflows)
  • platform level security
  • imposes additional restrictions to protect
    platform other applets (firewall/sandbox)
  • application level security
  • applet responsible for own specific correctness
    security needs

12
Security questions
  • Is my applet correct and secure?
  • correct is necessary precondition for secure
  • Is the platform correct and secure ?
  • Is someone elses applet is not malicious
  • ie. will it not
  • annoy users,
  • interfere with other applets, or
  • damage the platform ?
  • Security evaluations must answer these questions

13
  • NB Even perfectly secure applet running on
    perfectly secure platform may suffer from
    malicious applets
  • For example
  • a malicious applet on mobile phone could simply
    ask user to type in the PIN code
  • Protection against such Trojan Horses will
    require human source code inspection of
    untrusted, potentially hostile, applets ?

14
How do we certify software ?
  • testing
  • but testing that applet does what it should do is
    easier
  • than testing that applet does not do what it
    should not do
  • coding standards, design standards
  • code reviews
  • formal methods...

15
VerifiCard
16
VerifiCard
  • EU-funded project for developing and applying
    formal methods for the specification and
    verification of the Java Card
  • platform and
  • applets
  • Partners universities, research institutes,
    smart card manufacturers
  • www.verificard.org

17
Why formal methods ? (I)
  • required by highest levels of certification in
    Common Criteria
  • and there are increasing demands for higher
    levels of CC security evaluation

18
Why formal methods ? (II)
  • Central problem in ensuring that software is
    correct or secure
  • We have long documents in English giving
    functional specs, security requirements, ...
  • How to ensure that
  • these specs are consistent complete ?
  • our implementations actually meet them ?
  • If we can express parts of these documents in
    formal languages, we have more options...

19
Work on platform level
  • At INRIA TUM
  • Formalisation of Java Card Virtual Machine
  • Development of a provably correct byte code
    verifier
  • This relies on the use of mechanical theorem
    provers

20
Work on applet level
  • At INRIA, SICS, Kaiserslautern, Nijmegen
  • Formal specification and verification of Java
    Card applets, in particular using JML

21
Java Card applet specification and verification
using JML
22
JML (Gary Leavens et al)
  • Formal specification language for Java
  • JML specs added as annotations is Java source
    code files
  • Easy to learn
  • small extension of Java syntax
  • Supported by a range of tools

23
JML Example
Java compiler ignores this line
but JML tools will parse it
  • //_at_ requires amount gt 0
  • public void debit(int amount)
  • ....

this precondition makes an assumption explicit
19 of bugs are due to lack of input validation
24
JML Example
  • //_at_ requires amount gt 0
  • ensures balance \old(balance) amount
  • signals (PurseException)
  • balanace \old(balance)
  • _at_/
  • public void debit(int amount)
  • ....

this precondition makes an assumption explicit
19 of bugs are due to lack of input validation
25
JML Example
  • private int balance
  • final static int MAX_BALANCE
  • /_at_ invariant 0 lt balance
  • balance lt MAX_BALANCE
  • _at_/

26
JML Example
  • private byte pin
  • /_at_ invariant
  • pin ! null
  • pin.length 4
  • (\forall int i 0 lt i i lt 4
  • 0 lt pini pini lt
    9)
  • _at_/

27
JML Example
  • private byte appletState
  • /_at_ constraint
  • \old(appletState) BLOCKED
  • gt appletState BLOCKED
  • constraint
  • \old(appletState) ! PERSONALISED
  • gt appletState ! PERSONALISED
  • _at_/

28
Using JML
  • Many soundness/safety properties of Java (Card)
    program can be easily specified in JML
  • Such properties help in understanding code
  • For such properties we can use tools to check
    that implementations satisfy them
  • There are different tools, offering different
    levels of assurance at different costs...

29
Tools for JML
  • parser type-checker
  • no typos in specs
  • runtime assertion checker (Iowa State, Gary
    Leavens)
  • tests if any specs are violated at runtime
  • static checker ESC/Java (Compaq, Rustan Leino et
    al.)
  • automatic verification of simple properties
  • interactive program verifier LOOP (Nijmegen)
  • interactive verification of any property

30
Testing verification
  • Testing considers a limited set of inputs
  • Verification covers all possible inputs
  • Testing is easier with a formal (JML) spec that
    we can test against

31
Applet verification achievements
  • Verification of real industrial smart card applet
    (EMV applet)
  • Verification revealed uncaught exceptions that
    were not detected during normal testing
  • Gemplus has developed JACK tool supporting JML,
    integrated in IDE their developers use

32
Conclusions about applet verification
  • Formal specification languages and tools can help
    when doing a code review
  • Interactive program verification probably still
    too costly, but automated program verification
    seems to provide good return-on-investment
  • How far can we push level of automation ?
  • Will Moores law rescue us here ?

33
Conclusions
34
Old vs new generation smart cards
  • Some points to note
  • some security concerns are the same, eg
  • is the smart card OS correct and secure ?
  • is our application correct and secure ?
  • possible advantages of Java Card
  • Java Card OS better studied than others
  • our knowledge of and tools for Java may allow
    better cheaper security evaluations

35
Conclusions
  • Java Card interesting opportunity to apply
    state-of-the-art formal methods developed in
    academia for Java.
  • Increasing need about (security) certification of
    software.
    Central challenge How can we express security
    requirements in a (semi)-formal way ?
