Title: ECE544: Communication Networks-II Spring 2014


1
ECE544 Communication Networks-II Spring 2014
  • D. Raychaudhuri
  • Lecture II

Includes teaching materials from L. Peterson, J.
Kurose
2
Todays Lecture
  • Recap of network architecture top-down design
  • architecture paper discussion
  • Shared media (MAC) protocols
  • Ethernet
  • Token ring
  • IEEE 802.11

3
Link Layer Introduction
  • Some terminology
  • hub/repeater (layer 1), bridge/LAN switch (layer
    2), router (layer 3), host (layers 1-3 app)
  • Links are communication channels that connect
    adjacent nodes along communication path
    (point-to-point, shared, wired, wireless)
  • Layer-2 frame encapsulates payload/datagram/IP
    packet/service unit

4
Link Layer Services
  • Data-link layer transfer datagram from one node
    to adjacent node over a link
  • Framing encapsulate datagram into frame, adding
    header, trailer.
  • Identify what set of bits constitute a frame,
    that is, determining the beginning and the end of
    a frame
  • channel access if shared medium
  • MAC addresses used in frame headers to identify
    source, destination
  • different from IP address!
  • Reliable delivery between adjacent nodes
  • Error detection
  • Error recovery forward error correction code,
    retransmission (ARQ)

5
Link Layer Communication
  • Link layer implemented in adaptor (NIC) and
    driver (Ethernet card, WLAN card)
  • Sending side encapsulates higher layer payload
    in a frame, adds error checking bits, flow
    control, etc.
  • Receiving side error detection, flow control,
    extracts payload, passes to the receiving node

6
Layer 2 vs. Layer 3
  • Layer 2 switching
  • Based on MAC address
  • Self configuring and plug play
  • Transparent to protocols above the MAC layer
  • Fast and inexpensive
  • Does not limit the scope of broadcasts
  • Does not scale to extremely large networks
  • Layer 3 routing
  • Based on IP address
  • Must get IP address (DHCP or manual assign)
  • Easily connect LANs that uses different link
    protocols
  • Scalable to large network by subnet routing
  • Broadcast limited only in a subnet

7
  • Link Layer Techniques
  • Encoding (more Physical Layer stuff)
  • Framing PPP Protocol
  • Error Detection Correction
  • ARQ
  • Self study topics (see Ch2 slides)

8
Binary Encoding
  • Binary Encoding turn the binary data (bits) into
    signals to transmit on cable or optical fiber
    link (physical layer stuff, but better to know)
  • Baseband, not modulate to high frequency
  • Nonreturn To Zero (NRZ) 1high signal, 0low
    signal
  • May stay on high or low signal too long for a
    long strings of consecutive 1s or 0s gt baseline
    wander, clock recovery problems.
  • Nonreturn to Zero Inverted (NRZI) 1 signal
    transition (low to high, or high to low), 0no
    change.
  • Solve the problem of consecutive 1s, but not
    consecutive 0s

9
Manchester Encoding
  • Manchester Encoding NRZ_encode data XOR clock
  • Clock cycle (a low/high pair) 2 x signal
    interval
  • Baud rate (the signal change rate) 2 x bitrate
  • 0 high-to-low transition, 1 low-to-high
    transition
  • Clock recovery
  • Variation Differential Manchester
  • 1 the first half of the signal equal to the
    last half of the previous bits signal
  • 0 the first half of the signal opposite to the
    last half of the previous bits signal

10
Point-to-Point Data Link Protocol
  • Two types of links
  • point-to-point link (easier than broadcast link)
  • one sender, one receiver on the link, NO Media
    Access Control
  • no need for explicit MAC addressing
  • e.g., dialup link, ISDN line
  • Broadcast (shared wire or medium)
  • popular point-to-point DLC protocols
  • PPP (point-to-point protocol) byte-oriented
  • PPP for dial-up access
  • PPP over Ethernet (DSL)
  • HDLC (High level data link control) bit-oriented

Modem
PPP
11
PPP Functions
  • Framing encapsulation of network-layer datagram
    in data link frame
  • Identify what set of bits constitute a frame,
    that is, determining the beginning and the end of
    a frame
  • carry data of any network layer protocol (not
    just IP) at same time
  • ability to demultiplex upwards
  • bit transparency must carry any bit pattern in
    the data field
  • error detection (no correction)
  • connection liveness detect, signal link failure
    to network layer
  • network layer address negotiation endpoint can
    learn/configure each others network address
  • PPP
  • no error correction/recovery
  • no flow control
  • out of order delivery OK
  • no need to support multipoint links (e.g.,
    polling)

12
PPP Data Frame
  • Flag delimiter (framing)
  • Address
  • Control
  • Protocol upper layer protocol to which frame
    carried (e.g. IP)
  • Info upper layer data
  • Check CRC

Octet 1
1 or 2
1
variable
2 or 4
1
1
00000011
01111110
11111111
protocol
info
CRC
01111110
flag
control
address
13
Byte Stuff
  • data transparencyrequirement data field must
    be allowed to include flag pattern lt01111110gt
  • Q is received lt01111110gt data or flag?
  • Sender adds (stuffs) extra lt 01111110gt byte
    after each lt 01111110gt data byte
  • Receiver
  • two 01111110 bytes in a row discard first byte,
    continue data reception
  • single 01111110 flag byte

14
PPP Link Control Protocol (LCP)
  • Before exchanging network-layer data, data link
    peers must
  • configure PPP link (max. frame length,
    authentication)
  • learn/configure network
  • layer information
  • for IP carry IP Control Protocol (IPCP) msgs
    (protocol field 8021) to configure/learn IP
    address

15
High-Level Data Link Control (HDLC)
  • Bit oriented protocol view the frame as a
    collection of bits, does not care byte
    boundaries.
  • Sentinel characters 01111110 transmitted as the
    link is idle for synchronization
  • Bit stuffing to distinguish the data pattern
    01111110 in the body from the special
    beginning/end sequence
  • after transmitting any 5 consecutive 1s in body,
    insert a 0
  • 011111xxxx gt 0111110xxx

16
Error Detection
  • EDC Error Detection and Correction bits
    (redundancy)
  • D Data protected by error checking, may
    include header fields
  • Error detection not 100 reliable!
  • protocol may miss some errors, but rarely
  • larger EDC field yields better detection and
    correction

17
Parity Checking
  • Two Dimensional Bit Parity
  • Detect and correct single bit error
  • Single Bit Parity
  • Detect single bit errors

18
Internet Checksum
  • Goal detect errors (e.g., flipped bits) in
    transmitted segment (note used at transport
    layer)
  • Sender
  • treat segment contents as sequence of 16-bit
    integers
  • checksum addition (1s complement sum) of
    segment contents, and take the ones complement of
    the result
  • sender puts checksum value into UDP checksum
    field
  • Receiver
  • compute checksum of received segment
  • check if computed checksum equals checksum field
    value
  • NO -error detected
  • YES -no error detected. But maybe errors
    (internet checksum not very strong for error
    detection, but simple)

19
Cyclic Redundancy Check (CRC)
  • A (n1)-bit message M can be represented as a
    polynomial of degree n. For example,
  • X 10011010
  • M(X) X7 X4 X3 X
  • Choose k1 bit pattern (divisor), C(X), a polyn
    of degree k
  • goal get k CRC bits, Y, such that
  • PltM,Ygt exactly divisible by C (modulo 2)
  • receiver knows C, divides ltM,Ygt by C. If
    non-zero remainder error detected!
  • can detect all burst errors less than k1 bits

n bits
k bits
Y CRC
M data bits to be sent
M x 2k XOR R
20
CRC Example
  • Goal design P(X) such that it is exactly
    divisible by C(X)
  • T(X) M(X) Xk (add k zeros to the end of the
    message)
  • Subtract the remainder from T(X) to get P(X).
  • P(X) is now exactly divisible by C(X).
  • Corresponding to the complete transmitted message
  • (Remember all addition/subtract use modulo-2
    arithmetic)

21
Automatic Repeat reQuest(ARQ)
  • Stop-and-wait ARQ
  • Transmit a frame and wait for acknowledge
  • If positive acknowledge (ACK) from receiver, send
    next frame
  • If ACK does not arrive after a certain period of
    time (Timeout), retransmits the frame
  • Simple, low efficiency
  • Go-back-N ARQ
  • Transmit frames continuously, no waiting
  • The receiver only acks the highest-numbered
    frames received in sequence
  • ACK comes back after a round-trip delay
  • If timeout, the sender retransmits the frames
    that are not acked and N-1 succeeding frames that
    were transmitted during the round-trip delay (N
    frames transmitted during a round-trip delay)
  • Need buffer at transmitter, does not have to
    buffer the frames at the receiver,
  • moderate efficiency and complexity. Less
    efficient when the round-trip delay is large and
    data transmission rate is high
  • Selective-repeat
  • Transmit continuously, no waiting
  • The receiver acks all successfully received
    frames
  • The sender only retransmits (repeats) the unacked
    frames when their timers expire
  • Most efficient, but most complex, buffer needed
    at both transmitter and receiver, need per frame
    timer

22
Sliding Window
  • Reliable delivery retransmission
  • Ordered delivery preserve the order in which the
    frames are transmitted
  • Receiver does not pass along (buffer)
    out-of-order frames
  • Flow control feedback mechanism by which the
    receiver is able to throttle the sender
  • Inform the sender of how much frames the receiver
    has room to receive

23
Sliding Window (Cont)
  • Send window size (SWS) the upper bound on the
    number of unacked frames that the sender can
    transmit,
  • set according to the round-trip delay to keep the
    pipe full (recall bandwidth x delay product
    represents the amount of data that could be in
    transit)
  • LAR the sequence of the last ack received
  • LFS the sequence of the last frame sent
  • Receiver window size (RWS) the upper bound on
    the number of out-of-order frames that the
    receiver is willing to accept
  • LAF the sequence of the largest acceptable
    frame
  • LFR the sequence of the last frame received
  • SeqNumToAck the largest sequence not yet
    acked, such that all frames with seq lt
    SeqnumToAck have been received

24
Sliding Window
  • LFS-LARltSWS, LAF-LFRltRWS
  • Finite Seq. wraps around
  • SWS lt (MaxSeqNum1)/2 when RWSSWS to distinguish
    between different incarnations of the same seq.

25
Shared Media Networks
  • MAC (medium access control)
  • ALOHA, Slotted ALOHA
  • CSMA/CD, CSMA/CA
  • Token Ring
  • TDMA, Dynamic TDMA
  • FDMA, CDMA
  • LAN Technologies
  • IEEE 802.3 Ethernet
  • IEEE 802.5 Token Ring
  • IEEE 802.11 Wireless LAN

26
Medium Access Sublayer
  • Medium access control (MAC) sublayer is not
    relevant on point-to-point links
  • The MAC sublayer is only used in broadcast or
    shared medium/channel networks
  • All communication entities share a common
    channel
  • Wired networks Ethernet LAN
  • Wireless Mobile Networks Satellite, Cellular,
    Wireless LAN,

27
Media Access Protocol
  • Shared broadcast channel
  • two or more simultaneous transmissions by nodes
    interference
  • Collision if node receives two or more signals at
    the same time
  • MAC protocol
  • Determines how nodes share channel, i.e.,
    determine when node can transmit
  • Ideally, if broadcast channel of rate R bps
  • When one node wants to transmit, it can send at
    rate R.
  • When M nodes want to transmit, each can send at
    average rate R/M (fairness)

28
MAC Classification
  • Channel Partitioning
  • divide channel into smaller pieces (time slots,
    frequency, code)
  • allocate piece to node for exclusive use
  • TDMA, CDMA, FDMA
  • Random Access
  • channel not divided
  • When node has frame to send, transmit with the
    total channel bandwidth
  • No coordination between nodes, control is
    completely distributed
  • two or more nodes transmit simultaneously
    ?collision
  • random access MAC protocol should specify
  • how to detect collisions
  • how to recover from collisions (e.g., via delayed
    retransmissions)
  • Examples ALOHA, Slotted ALOHA, CSMA/CD, CSMA/CA
  • Taking turns
  • Nodes take turns
  • Token ring
  • Hybrid
  • Combine two or more techniques together

29
Pure (Unslotted) ALOHA
  • Early packet radio network created at the U. of
    Hawaii in 1970
  • Uplink channel (clients-gthub) and downlink
    channel (hub-gtclients) uses different frequencies
  • Client nodes send data frames to the central hub
    using the shared uplink channel.
  • The hub immediately re-send the received frames,
    allowing clients to determine whether or not
    their data had been received properly.
  • Simplest form of random access, provides basis
    for more advance contention MAC

Hub
Client
30
Aloha Algorithm
  • Aloha Algorithm
  • Nodes transmit immediately whenever they have a
    frame to send
  • No synchronization among nodes
  • If collision, retransmit after random delay
  • random delay prevents the same frames from
    colliding over and over again
  • collision window or vulnerable period
  • frame sent at t0 collides with other frames sent
    in t0-1,t01

31
Pure Aloha efficiency
  • Assume that the aggregate frame arrival is
    Poisson Process
  • P k arrivals in a time-interval
  • G the mean number of aggregate arrivals (all
    nodes in network) in the time interval
  • time-interval one frame transmission time
  • Conditional successful probability for one frame
    transmission attempt is
  • P0 P 0 other attempts in 2 time-intervals
    e-2G
  • The probability of successful transmission
  • S GP0 Ge-2G
  • S is optimum at G1/2
  • S1/2e 0.184

32
Slotted Aloha
  • Operation
  • when node obtains fresh frame, it transmits at
    the beginning of next slot
  • no collision, node can send new frame in next
    slot
  • if collision, wait a random number of slots and
    try to send again
  • Assumptions
  • all frames same size
  • time is divided into equal size slots, time to
    transmit 1 frame
  • nodes start to transmit frames only at beginning
    of slots
  • nodes are synchronized
  • if 2 or more nodes transmit in slot, detect
    collision
  • Feedback channel about whether packet is received
    or not (half-duplex)

33
Efficiency of Slotted ALOHA
  • Aggregate frame arrival is Poisson Process
  • P k arrivals in a time-interval
  • G the mean number of aggregate arrivals (for all
    nodes in network) in this interval
  • time-interval slot (one frame transmission
    time)
  • Successful probability for each slot is
  • S P 1 attempt in a slot Ge-G
  • S is optimum at G1
  • S1/e 0.368
  • (slotted aloha reduce the potential collision
    period from 2t to t by node synchronization)

34
Performance of ALOHA
  • Throughput versus offered traffic for ALOHA
    systems
  • The main reason for poor channel utilization of
    ALOHA (pure or slotted) is that all stations can
    transmit at will, without paying attention to
    what the other stations are doing.

35
Carrier Sense Multiple Access (CSMA)
  • CSMA listen before transmit
  • If channel sensed idle transmit
  • If channel sensed busy, defer transmission
  • Human analogy dont interrupt others!
  • Can collisions occur in this scheme?
  • Two nodes might attempt to transmit a frame at
    the same time
  • Propagation delay means two nodes may not hear
    each others transmission immediately
  • Several variants of CSMA protocols
  • Non-Persistent CSMA
  • 1-Persistent CSMA
  • P-Persistent CSMA

36
Non-persistent CSMA
  • To send data, a node first listens to the channel
    to see if anyone else is transmitting.
  • If so, the node waits a random period of time
    (instead of keeping sensing until the end of the
    transmission) and repeats the algorithm.
    Otherwise, it transmits a frame.
  • If a collision occurs, the node waits a random
    amount of time and starts all over again.

37
1-persistent CSMA
  • Algorithm
  • To send data, a node first listens to the channel
    to see if anyone else is transmitting.
  • If so, the node waits (keeps sensing it) until
    the channel becomes idle. Otherwise, it transmits
    a frame.
  • If a collision occurs, the node waits a random
    amount of time and starts all over again.
  • It is called 1-persistent because the station
    transmits with a probability of 1 whenever it
    starts sensing the channel and finds the channel
    idle. (Greedy)

38
P-persistent CSMA
  • Assume channels are slotted
  • One slot contention period (i.e., one round
    trip propagation delay)
  • Algorithm
  • Sense the channel
  • If channel is idle, transmit a packet with
    probability p
  • if a packet was transmitted, go to step 2
  • if a packet was not transmitted, wait one slot
    and go to step 1
  • If channel is busy, wait one slot and go to step
    1.
  • In other words, wait until idle and then transmit
    with probability p
  • Detect collisions
  • If a collision occurs, wait a random amount of
    time and go to step 1

39
Propagation Delay
B
A
C
D
  • D only sense As transmission after a propagation
    delay t
  • If t is larger than packet transmission time,
    too much time wasted.
  • CSMA in satellite communication? No.
  • Distance propagation delay determine collision
    probability

The size (length) of the network must be limited!
40
CSMA Performance Analysis
  • Assumptions
  • Constant length packets
  • No errors, except those caused by collisions
  • Collision entire packet transmission time wasted
  • Each host can sense the transmissions of all
    other hosts
  • The propagation delay is small compared to the
    transmission time

41
Analysis of Non-persistent CSMA
Unsuccessful transmission period
Successful transmission period
Normalized Time
a
a the ratio of propagation delay to packet
transmission time
a
1
1
Y
a
Busy period
Idle period
Busy period
  • Poisson arrival, P(k arrivals in time duration t)
  • Prob. of success transmission S U x I/(BI)
  • Mean B Y 1 a , mean I 1/G
  • U Ge-Ga
  • FY(y)Pno packet occur in an duration of a-y
    e-G(a-y) (CDF)

42
Comparison of the channel utilization versus load
for various random access protocols
43
CSMA with Collision Detection
  • CSMA/CD (Carrier Sense Multiple Access with
    Collision Detection) protocol further improves
    ALOHA by aborting transmissions as soon as a
    collision is detected.
  • Operation
  • To send data, a node first listens to the channel
    to see if anyone else is transmitting.
  • If not, it transmits a frame
  • If channel busy, deferral as in CSMA
  • the node wait a random period of time and repeats
    the algorithm (non-persistent), or waits until
    the end of the transmission (1-persistent)
  • The node will detect the collision, if collision
    detected, abort its transmission (reducing
    channel wastage), waits a random amount of time,
    and starts all over again.

44
How to Detect Collision
  • Prerequisite A node can listen while talking
  • Easy in wired LANs measure signal strength,
    compare Tx and Rx signals
  • Difficult in wireless LANs receiver shut off
    while transmitting

Tx
Rx
45
CSMA/CA
  • Wireless LANs
  • How can a node detect collision if it cannot
    listen while talking?
  • Collision Avoidance
  • Random Backoff (instead of 1-persistent)
  • Request-to-send (RTS)/clear-to-send (CTS)
  • CS no longer works well
  • Rules
  • carrier gt do not transmit
  • no carrier gt OK to transmit
  • But the above rules do not always apply to
    wireless.

46
Problems with carrier sensing
Hidden terminal problem
Y
Z
W
W finds that medium is free and it transmits a
packet to Z
no carrier gt OK to transmit
/
47
Problems with carrier sensing
Exposed terminal problem
Z
W
Z is transmitting to W
Y
X
Y will not transmit to X even though it cannot
interfere
/
Presence of carrier gt hold off transmission
48
Solving Hidden Node problem with RTS/CTS
Y
Z
X
W
Note RTS/CTS does not solve exposed terminal
problem. In the example above, X can send RTS,
but CTS from the responder will collide with Ys
data.
49
RTS/CTS exchange example
SIFS
DIFS
Frame
RTS
Transmitter
ACK
CTS
Receiver
8192 ?s
352 µs
304 µs
304 µs
10 µs
10 µs
10 µs
Other
NAV (RTS)
NAV (CTS)
  • RTS CTS Frame ACK exchange invoked when
    frame size is large
  • NAV (Network Allocation Vector)
  • NAV maintains prediction of future traffic on the
    medium based on duration information that is
    announced in RTS/CTS frames prior to actual
    exchange of data

50
Taking Turns MAC protocols
  • Token passing
  • control token passed from one node to next
    sequentially.
  • token message
  • concerns
  • token overhead
  • complexity
  • single point of failure (token)
  • Polling
  • master node invites slave nodes to transmit in
    turn
  • concerns
  • polling overhead
  • single point of failure (master)

51
TDMA
  • Time Division Multiple Access (TDMA)

52
Fixed TDMA
  • access to channel in "rounds"
  • each station gets fixed length slot (length
    packet transmission time) in each round
  • unused slots go idle Not efficient
  • example 6-station LAN, 1,3,4 have pkt, slots
    2,5,6 idle

53
Dynamic TDMA
  • In dynamic TDMA, a scheduling algorithm
    dynamically reserves a variable number of
    timeslots in each frame to variable user data
    streams, based on the traffic demand of each user
    data stream.
  • Negotiations (beforehand) to determine how to
    allocate slots dynamically.

Frame header and schedule
54
FDMA
  • FDMA frequency division multiple access
  • channel spectrum divided into frequency bands
  • each station assigned a frequency band
  • unused transmission time in frequency bands go
    idle if assignment fixed
  • Inefficient gt make it dynamically assigned to
    different stations based on traffic demand
  • OFDMA

Frequency bands
55
Spread Spectrum and CDMA
  • What if we dony not divide up the channel by
    time (as in TDMA), or frequency (as in FDMA)? Is
    collision inevitable?
  • Not if collision is no longer damaging!
  • Is there any way to decode bits garbled by other
    overlapping frames?
  • Code Division Multiple Access (CDMA) based on
    Spread Spectrum
  • Another perspective to solve multiple access
    problems
  • Spread Spectrum is a PHY innovation, not a MAC
    technique.
  • CDMA encodes data with a special code associated
    with each user and uses the constructive
    interference properties of the special codes to
    perform the multiplexing.

56
Spread Spectrum
  • Idea
  • spread signal over wider frequency band than
    required
  • originally deigned to thwart jamming
  • Frequency Hopping
  • transmit over random sequence of frequencies
  • sender and receiver share
  • pseudorandom number generator
  • seed

57
Spread Spectrum (cont)
  • Direct Sequence
  • for each bit, send XOR of that bit and n random
    bits
  • random sequence known to both sender and receiver
  • called n-bit chipping code

58
Code Division Multiple Access (CDMA)
  • Multiplexing Technique used with spread spectrum
  • Start with data signal rate D
  • Called bit data rate
  • Break each bit into k chips according to fixed
    pattern specific to each user
  • Users code
  • New channel has chip data rate kD chips per
    second
  • E.g. k6, three users (A,B,C) communicating with
    base station R
  • Code for A lt1,-1,-1,1,-1,1gt
  • Code for B lt1,1,-1,-1,1,1gt
  • Code for C lt1,1,-1,1,1,-1gt

59
LAN technologies
  • Ethernet
  • Token Ring
  • Wireless LAN

60
Ethernet Overview
  • History
  • developed by Xerox PARC in mid-1970s
  • roots in Aloha packet-radio network
  • standardized by Xerox, DEC, and Intel in 1978
  • similar to IEEE 802.3 standard
  • CSMA/CD
  • Evolution Bus topology (90s) ? Star topology
    (now)
  • Most successful access network technology

Advance
61
Ethernet Frame
  • Preamble 8 bytes
  • 7 bytes with pattern 10101010 followed by one
    byte with pattern 10101011
  • used to synchronize receiver, sender clock rates
  • Addresses6 bytes
  • if adapter receives frame with matching
    destination address, or with broadcast address,
    it passes data in frame to net-layer protocol,
    otherwise, adapter discards frame
  • Type 2 bytes
  • indicates the higher layer protocol (mostly IP
    but others also supported)
  • CRC 4 bytes
  • checked at receiver, if error is detected, the
    frame is simply dropped
  • Body 46-1500 bytes
  • Sending adapter encapsulates IP datagram (or
    other network layer protocol packet) in Ethernet
    frame

Octets
46-1500
8
6
4
2
6
Src
Dest
CRC
Preamble
Type
Body
addr
addr
64-1518
72-1526
62
MAC Address
  • MAC Addresses
  • unique, 48-bit unicast address assigned to each
    adapter
  • example 38102be4b102
  • broadcast all 1s, ffffffffffff
  • multicast multicast flag (the lowest bit of the
    1st octet) 1
  • 01-00-5E-00-00-00 to 01-00-5E-7F-FF-FF for IP
    multicast
  • IP multicast group address mapped to the lower
    order 23 bits of MAC address (not one-to-one
    mapping)
  • Unique MAC address allocation administered by
    IEEE
  • manufacturer buys portion of MAC address space
  • the first three octets as vendor-specific

63
MAC Address vs. IP Address
  • 48-bit MAC address
  • Layer 2
  • Used to get packet from one interface to another
    within the same LAN/subnet (Ethernet, token
    ring)
  • Flat
  • Unique
  • No change when moving
  • 32-bit IP address
  • Network layer
  • Used to get packet to destination IP subnet
  • Hierarchical
  • Change when moving
  • Depending on IP subnet to which node is attached
  • IP to MAC address translation ARP (more later)

64
Different Flavors of Ethernet Format
  • Ethernet version II
  • IEEE 802.3

43-1497
Octets
4
1
1
8
6
2
6
1
Src
Dest
FCS
Body
Length
Preamble
MAC
MAC
Logical Link Control
Datalink Header
Data CRC (FCS)
  • Length the length of the data in the frame
    (excluding preamble, CRC, DLC addresses, and the
    Length field itself)
  • Destination Service Access Point (DSAP) a
    pointer to a memory buffer in the receiving
    station. It tells the receiving NIC in which
    buffer to put this information. useful in
    situations where users are running multiple
    protocol stacks, etc...
  • Source Service Access Point (SSAP)
  • Control the type of LLC frame
  • Distinguish Ethertypes and Control field
  • Ethertypes value gt 0x05DC (1500), Length lt 1500

65
Unreliable, connectionless service
  • Connectionless No handshaking between sending
    and receiving adapter.
  • Unreliable receiving adapter doesnt send acks
    or nacks to sending adapter
  • stream of datagrams passed to network layer can
    have gaps
  • gaps will be filled if app is using TCP
  • otherwise, app will see the gaps

66
Ethernet CSMA/CD
  • If sender senses channel idle, it starts to
    transmit frame. If it senses channel busy, waits
    until channel idle and then transmits
    (1-persistent CSMA)
  • Inter-frame gap time to send 96 bits (9.6 ms for
    10Mbps)
  • If adapter transmits entire frame without
    detecting another transmission, the adapter is
    done with frame !
  • If adapter detects another transmission while
    transmitting, aborts and sends 32-bit jam signal
    (collision detection)
  • After aborting, sender enters exponential backoff
  • after the mth collision, adapter chooses a K at
    random from 0,1,2,,2m-1. Then waits K?512 bit
    times (k x 51.2 us in 10 Mbps Ethernet) and
    returns to Step 1
  • give up after several tries (usually 16)

67
Ethernet CSMA/CD (Cont)
  • Exponential Backoff
  • Goal adapt retransmission attempts to the
    estimated current of active stations or load
  • heavy load random wait will be longer
  • first collision choose K from 0,1 delay is
    K?512 bit (51.2 ms in 10 Mbps) transmission times
  • after second collision choose K from 0,1,2,3
  • after ten collisions, choose K from
    0,1,2,3,4,,1023
  • Jam Signal
  • make sure all other transmitters are aware of
    collision
  • 32 bits
  • Frame 64 (preamble) 32 (jamming sequence) 96
    bits Runt Frame

68
Collisions
  • Worst case
  • A sends at t, As frame arrives B at td
  • B begins transmitting at td and collides with
    As frame
  • B sends runt frame, the runt frame arrives A at
    t2d
  • To detect collision, A must continue transmit
    until t2d. A must transmit for 2d.
  • Round-trip delay about 51.2 us for 2500m long
    Ethernet with 4 repeater
  • Corresponds to 512 bits for 10 Mbps Ethernet
  • So min frame size 512 bits

The longer the propagation delay, the higher
probability of collision.
69
10BaseT and 100BaseT
  • 10/100 Mbps rate latter called fast ethernet
  • T stands for Twisted Pair
  • Star toplogy, max 100m between node and hub
  • Hubs physical-layer repeaters
  • bits coming from one link go out all other links
    at the same rate
  • no frame buffering
  • no CSMA/CD at hub adapters detect collisions
  • provides net management functionality

70
Legacy Ethernet
  • 10Base5
  • Bus topology with coaxial cable
  • 10 Mbps, Up to 500m each segment
  • No more than 4 repeaters between any pair of
    stations
  • Max 2500 m
  • Max 1024 hosts
  • 10Base2
  • Daisy chain
  • Up to 200m

10 Base5 Ethernet
71
Gbit Ethernet
  • uses standard Ethernet frame format
  • allows for point-to-point links and shared
    broadcast channels
  • in shared mode, CSMA/CD is used short distances
    between nodes required for efficiency
  • uses hubs
  • Full-Duplex at 1 Gbps for point-to-point links
  • 10 Gbps now

72
Ethernet Performance
  • Max throughput lt1 as a function of span
  • As propagation delay increases, efficiency
    decreases
  • instability can occur unless load is reduced
    under congestion conditions
  • retransmission backoff policy for stability

stable policy (retx backoff)
Capacity Limit
0.8
unstable policy (no backoff)
Overload region
Traffic margin
Thru
load lines
stable policy (backoff too high)
Normal operating point
Offered Traffic
73
Wireless LANs
  • 802.11 a/b/g different Phy technologies
  • 802.11 b/g 20 MHz channel in 2.4 GHz, up to 11
    Mbps (802.11b), 54 Mbps (802.11g) phy data rate
  • 802.11a 20 MHz channel in 5GHz, up to 54 Mbps
    phy data rate
  • 802.11n
  • 130 Mbps phy data rate on 20 MHz channel (2 x 2
    MIMO)
  • 300 Mbps phy data rate on 40 MHz channel (channel
    bonding with 2 x 2 MIMO)

See supplementary WLAN tutorial slides
74
Todays Homework
  • Peterson Davie, Chap 2, 4th ed
  • 2.6
  • 2.18
  • 2.23
  • 2.33
  • 2.44
  • 2.42
  • Download and review Ethernet and 802.11 MAC
    specs, and study IEEE 802.11 Wireless LAN
    Overview slides
  • Due 2/7
About PowerShow.com
