Title: Chapter 7 : Building a Text-based user interface.


1
Chapter 7 Building a Text-based user interface.
2
Objectives
  • After studying this chapter you should understand
    the following
  • independence of servers from clients
  • likeliness of the user interface to change
  • i/o streams
  • structure of a simple text-based user interface
  • purpose and structure of a while loop
  • how existing classes can be composed to define a
    new class.

3
Objectives
  • Also, you should be able to
  • use input/output objects to read and write data
  • build a simple text-based user interface
  • use and trace a basic while statement
  • define classes whose implementations contain
    other classes as components.

4
Relating User-interface and Model
  • Model objects that solve problem at hand.
  • User interface interacts with user, getting
    input from user, and giving output to user,
    reporting on status of model.
  • Flexibility in design identifying these as
    separate subsystems.

5
Stream-based I/O
  • Data streams sequence of bytes.
  • character stream sequence of characters
  • input stream stream is a source of data for an
    application.
  • output stream stream is appliction destination
    (or sink).

6
Standard Input and Output streams
standard output
characters to display
7
Writing standard output
  • System.out provides methods for writing to
    standard output.

public void println (String s) Write specified
String to standard output and then terminate the
line. public void print (String s) Write the
specified String to standard output. public void
println () Terminate current line by writing line
terminator to standard output. public void flush
() Flush stream write buffered output to
standard output and flush that stream.
8
Input nhUtilities.basicIO.BasicFileReader
  • Constructors

public BasicFileReader () Create a
BasicFileReader attached to standard
input. public BasicFileReader (String
fileName) Create a BasicFileReader attached to
the named file.
9
Input nhUtilities.basicIO.BasicFileReader
  • Command

public void readInt () Read a new int from input
stream. The digit string is interpreted as a
decimal integer. Characters following any white
space in input stream must have format of an
optionally signed decimal integer.
10
readInt
BasicFileReader
standard input
lastInt

?

1 2 3 4 5 a b c
Application
before executing readInt()
BasicFileReader
standard input
lastInt

12345

a b c
Application
after executing readInt()
11
Input nhUtilities.basicIO.BasicFileReader
  • Query

public int lastInt () int most recently read by
readInt. require this.readInt() has been
successfully performed.
12
Input nhUtilities.basicIO.BasicFileReader
  • Other commands for reading from the input stream

public void readChar () Read a new character from
this input stream. public void readDouble () Read
a new double from this input stream. public void
readLine () Read the rest of the line from this
input stream. public void readWord () Read a new
word from this input stream.
  • readDouble and readWord skip white space at
    beginning of stream.
  • readDouble requires characters after white space
    have format of an optionally signed double
    literal.
  • readWord reads a sequence of nonwhite space
    characters.

13
Input nhUtilities.basicIO.BasicFileReader
  • Other queries

public char lastChar () Character most recently
read by readChar. require this.readChar() has
been successfully performed. public double
lastDouble () double most recently read by
readDouble. require this.readDouble() has been
successfully performed. public String lastString
() String most recently read by readWord or
readLine. require this.readWord() or
this.readLine() has been successfully
performed.
14
Input nhUtilities.basicIO.BasicFileReader
  • Other queries

public boolean eof () End of input stream has
been reached.
15
Building an interface for Rectangle
  • Build an interface that lets user specify
    dimensions of the Rectangle and ask for property
    to be displayed.

class RectangleTUI A simple text-based interface
for Rectangles. public RectangleTUI () Create
a new RectangleTUI instance. public void start
() Run the interface.
16
Building an interface for Rectangle
  • Application creates interface and executes start

public class RectangleExample public static
void main (String argv) (new
RectangleTUI()).start()
17
Building an interface for Rectangle
  • RectangleTUI properties

private Rectangle rectangle // the
model private BasicFileReader in //standard
input
  • Instance variables are initialized in constructor

public RectangleTUI () this.rectangle
null this.in new BasicFileReader()
18
Building an interface for Rectangle
private void createRectangle () Create a new
Rectangle with user-provided dimensions. Uses
readIntWithPrompt to get dimensions from user.
  • To get Rectangle dimensions from user

private int readIntWithPrompt (String prompt)
System.out.print(prompt) System.out.flush()
in.readInt() in.readLine() return
in.lastInt()
19
Building an interface for Rectangle
  • private void createRectangle ()
  • int length
  • int width
  • length readIntWithPrompt( "Rectangle length
    (a non-negative integer) ")
  • width readIntWithPrompt( "Rectangle width (a
    non-negative integer) ")
  • this.rectangle new Rectangle(length,width)

20
Building an interface for Rectangle
  • RectangleTUI is a client of Rectangle.
  • Constructor creates an instance of Rectangle
    using input values from user.
  • But, Rectangle has pre-conditions to keep

public Rectangle (int length, int width) Create a
new Rectangle with specified length and
width. require length gt 0 width gt 0
  • User may enter negative values for length or
    width.

21
While statement
while ( condition ) statement
22
Re-implementing createRectangle
private void createRectangle () //initialize
to insure at least one execution of loops int
length -1 int width -1 while (length lt
0) length readIntWithPrompt( "Rectangle
length (a non-negative integer) ") while
(width lt 0) width readIntWithPrompt(
"Rectangle width (a non-negative integer) ")
// assert length gt0 width gt 0
this.rectangle new Rectangle(length,width)
23
Building an interface for Rectangle
  • private void displayMenu ()
  • Display the menu to the user.
  • private void executeChoice (int choice)
  • Perform the indicated action, and display results
    to the user.

24
Building an interface for Rectangle
  • Name operation choices with identifiers

private static final int LENGTH 1 private
static final int WIDTH 2 private static final
int AREA 3 private static final int PERIMETER
4 private static final int NEW 5 private
static final int EXIT 0 private static final
int NO_CHOICE -1
25
Building an interface for Rectangle
  • public void start ()
  • createRectangle()
  • int choice NO_CHOICE
  • while (choice! EXIT)
  • displayMenu()
  • choice readIntWithPrompt("Enter choice ")
  • executeChoice(choice)

26
Building an interface for Rectangle
  • private void displayMenu ()
  • System.out.println()
  • System.out.println("Enter number denoting action
    to perform")
  • System.out.println("Display length............."
    LENGTH)
  • System.out.println("Display width.............."
    WIDTH)
  • System.out.println("Display area..............."
    AREA)
  • System.out.println("Display perimeter.........."
    PERIMETER)
  • System.out.println("Create new rectangle......."
    NEW)
  • System.out.println("Exit......................."
    EXIT)

27
Building an interface for Rectangle
  • private void executeChoice (int choice)
  • System.out.println()
  • if (choice LENGTH)
  • System.out.println("Length is "
    rectangle.length())
  • else if (choice WIDTH)
  • System.out.println("Width is "
    rectangle.width())
  • else if (choice AREA)
  • System.out.println("Area is "
    rectangle.area())
  • else if (choice PERIMETER)
  • System.out.println("Perimeter is "
    rectangle.perimeter())
  • else if (choice NEW)
  • createRectangle()
  • else if (choice EXIT)
  • System.out.println("Goodbye.")
  • else
  • System.out.println(choice " is not valid.")

28
Using composition
  • Build an application that lets a user access a
    locked oracle.
  • user can get a fortune from oracle only by
    providing correct key.
  • Use classes CombinationLock and Oracle.
  • Create two new classes,
  • one modeling a locked oracle, and
  • other defining user interface.

29
Using composition
  • public class Oracle
  • A dispenser of fortunes. An Oracle gives a
    fortune only if it is awake normal sequence of
    actions is wake Oracle get fortune put the
    Oracle back to sleep.
  • public Oracle () Create new Oracle. This
    Oracle is initially asleep. ensure
    !this.isAwake()
  • public boolean isAwake () This Oracle is
    awake.
  • public String fortune ()
  • The prophecy currently seen by this Oracle.
    require this.isAwake()
  • public void awaken () Wake this Oracle.
    Oracle will divine a fortune when it wakes.
  • public void sleep () Put this Oracle to sleep.

30
Using composition
  • public class LockedOracle
  • A keyed dispenser of fortunes. A LockedOracle
    will give a fortune only if the correct key is
    provided. A LockedOracle must be told to conjure
    a fortune before the fortune can be retrieved.
  • public static final String NO_FORTUNE
  • String indicating no fortune has been conjured.
  • public LockedOracle (int key)
  • Create new LockedOracle with the specified
    key.require 0 lt key key lt 999
  • public String fortune ()
  • The prophecy currently seen by this
    LockedOracle. If a fortune has not been
    conjured, the String NO_FORTUNE is returned.
  • public void conjureFortune (int keyToTry)
  • Prophesy. This LockedOracle will make a prophecy
    only if the correct key is presented.require 0
    lt keyToTry keyToTry lt 999

31
Using composition
  • Composition process of defining a new class by
    putting together existing classes.
  • An instance of the new class, the composite,
    references instances of the existing classes, its
    components.

32
Implementing LockedOracle
  • LockedOracle class defined to be a composite,
    with CombinationLock and Oracle components.

33
Implementing LockedOracle
private CombinationLock lock private Oracle
oracle private String fortune //current
prophesy public static final String NO_FORTUNE
"Sorry, no fortune for you."
  • Instance variables are initialized in constructor

public LockedOracle (int key) lock new
CombinationLock(key) lock.close() oracle
new Oracle() fortune NO_FORTUNE
34
Implementing LockedOracle
public String fortune () return this.fortune
  • Command conjureFortune first attempts to open
    lock, and wakes oracle only if it succeeds

public void conjureFortune (int keyToTry)
lock.open(keyToTry) if (lock.isOpen())
oracle.awaken() fortune
oracle.fortune() oracle.sleep() lock.close()
else fortune NO_FORTUNE
35
Implementing the User interface
  • class LockedOracleTUI
  • A simple text-based interface for a LockedOracle.
  • public LockedOracleTUI (LockedOracle oracle)
  • Create a new interface for the specified
    LockedOracle.
  • public void start ()
  • Run the interface.

36
Implementing the User interface
  • Application creates an oracle and an interface,
    and executes interfaces start method

public class OracleExample public static void
main (String argv) LockedOracle oracle
new LockedOracle(123) LockedOracleTUI ui
new LockedOracleTUI(oracle) ui.start()

37
Implementing the User interface
  • Instance variables and constructor.

private LockedOracle oracle private
BasicFileReader in public LockedOracleTUI
(LockedOracle oracle) this.oracle
oracle this.in new BasicFileReader()
38
Implementing the User interface
  • Specify private helper methods

private boolean readYes (String prompt) Read a
yes or no response from the user. Return true if
user keys yes. private int readKey (String
prompt) Read and return a legal key. ensure 0
lt this.readKey() this.readKey() lt 999
39
Implementing the User interface
  • public void start ()
  • String fortune
  • boolean goOn true
  • while (goOn)
  • goOn readYes("Fortune? (Key yes or no) ")
  • if (goOn)
  • int key readKey("Enter key (0-999) ")
  • oracle.conjureFortune(key)
  • fortune oracle.fortune()
  • System.out.println(fortune)
  • System.out.println()
  • System.out.println("Good-bye.")

40
Summary
  • Built a simple text-based user interface.
  • We reviewed the relationship between client and
    server
  • a client is dependent on its server,
  • a server is independent of its client.

41
Summary
  • In designing a system, it is preferable to make
    stable components independent of those likely to
    require change.
  • Since user interface is considerably less stable
    than model, we favor designs in which the user
    interface acts as client to the model.
  • In cases where model must collaborate with the
    user interface, need to minimize interface for
    this collaboration.

42
Summary
  • Introduced i/o streams.
  • A stream is a sequence of bytes, sometimes viewed
    as characters, to which an application can append
    data (an output stream) or from which an
    application can read data (an input stream).
  • Java has an extensive library of classes to deal
    with streams.
  • Use only basic functionality
  • from the predefined object System.out for output,
  • BasicFileReader class from nhUtilities.basicIO
    package for input.

43
Summary
  • Presented two simple applications with their
    text-based user interfaces.
  • Introduced while statement or while-loop a Java
    construct that specifies a sequence of actions to
    be repeated until a condition fails to hold.

44
Summary
  • In design of LockedOracle composed existing
    classes to construct a new class.
  • The relation between a composite class and its
    component classes is called the has-a relation.
  • LockedOracle class wraps Oracle, adapting its
    specification to that required by the system the
    adapter pattern.
About PowerShow.com
