Chapter 5

• Compilation of Imperative, Functional, Logical
  and Object Oriented Languages

2
Compilation of Imperative, Functional, Logical
and Object Oriented Languages

• Compilation of imperative, functional, logical
  and object-oriented languages differ in nature.
• We will explore all four above categories as
• Compilation of Imperative Languages
• The P machine Architecture
• Compilation of Functional Languages
• Compilation of Logic Programming Languages
• Compilation of Object Oriented Languages

3
Compilation of Imperative Languages

• Imperative programming language possess the
  following constructs and concepts which be mapped
  onto the constructs, concepts and instruction
  sequences of abstract or real computer
•       Variable are containers for data objects
  whose contents (values) may changed during the
  execution of the program. The values are changed
  by the execution of statements such as
  assignments.
•       Expression are terms formed from
  constants, names and operators which are
  evaluated during execution.
•       Explicit specification of the control
  flow. The branch instruction goto, which
  exists in most imperative programming languages,
  can be directly compiled into the unconditional
  branch instruction of the target machine.

4
The P machine Architecture

•
• The (abstract) P machine was developed to make
  the Zurich implementation of Pascal portable.
• Anyone wishing to implement Pascal on a real
  computer had only to write an interpreter for
  the instructions of this abstract machine.
•      The Pascal compiler, written in Pascal and
  compiled into P-code, could then be run on the
  real computer.
•       P machine can be implemented by using
  Stack, memory etc.

5
Compilation of Functional Languages
                   Functional programming
languages originated with LISP. LaMa is also
known as functional programming
language.      Imperative languages have (at
least) two worlds, the world of expressions and
the world of statements.      Expression provide
values statements alter the state of variables
or determine the flow of control.      Functiona
l languages only contain expression and the
execution of a functional program involves the
evaluation of the associated program expression
which defines the program result.      Its
evaluation may also involve the evaluation of
many other expression, if an expression calls
other expressions via a function application
however there is no explicit statement-defined
control flow.
6
Compilation of Functional Languages Contd.
A variable in a functional program identifies
an expression unlike in imperative languages,
it does not identify one or more storage
locations.      Its value cannot change as a
result of the execution of the program the only
possibility is the reduction of the expression
it identifies to its value.      The MaMa
machine Architecture was introduced to compile
LaMa language.
7
Compilation of Logic Programming Languages
Three different terminologies are used in
discussions of logic programs.     When
programming is involved, we speak of procedures,
alternatives of procedures, calls, variables,
and so on.      When explaining the logical
foundations, we use words such as variable,
function and predicate symbols, terms, atomic
formulae, and so on.      Finally, term such as
literal, Horn clause, unification and resolution
comes from the mechanization of logic in
automated theorem-proving procedures.       The
WiM machine architecture was introduced to
compile ProLog language.
8
Compilation of Object Oriented Languages
Software systems are becoming increasingly
complex and large.       Thus, there is a
growing need to make the development of such
systems more efficient and more
transparent.       The ultimate objective is to
construct software systems, like present-day
hardware systems (e.g. cars, washing machines
etc) from ready-made standard building blocks,
Attempts to progress towards this objective
cover the following areas (among
other)                     Modularization
                    Reusability of
modules                     Extensibility of
modules                     Abstraction
Object oriented languages afford new
possibilities in these areas.      Thus, object
orientation is viewed as an important paradigm in
relation to management of the complexity of
software systems.
9
The Structure of Compilers
     Compilers for high-level programming
languages are large, complex software
systems.      the development of large software
systems should always begin with the
decomposition of the overall system into
subsystems (modules) with a well-defined and
understood functionality.      The division
used should also involve sensible interfaces
between the modules.      The compiler
structure described in what follows is a
conceptual structure, that is, it identifies
the subtasks of the compilation of a source
language into a target language and specifies
possible interfaces between the modules
implementing these subtasks.      The real
module structure of the compiler will be derived
from this conceptual structure latter.
10
The Structure of Compilers Contd.
     The first coarse structuring of the
compilation process is the division into an
analysis phase and a synthesis
phase.      In the analysis phase the
syntactic structure and some of the semantic
properties of the source program are
computed.      The semantic properties that can
be computed by a compiler are called the
static semantics.      This includes all
semantic information that can be determined
solely from the program in question, without
executing it with the input data.      The
results of the analysis phase comprise either
messages about syntax or semantic errors in the
program (that is, a rejection of the program) or
an appropriate representation of the syntactic
structure and the static semantic properties
of the program.      This phase is (ideally)
independent of the properties of the target
language and the target machine.     The
synthesis phase for a compiler takes this program
representation and converts it (possibly in
several steps) into an equivalent target program.
11
Compiler Subtasks
The compilation process decomposes into a
sequence of sub- processes.      Each
sub-processes receives a representation of the
program and produces a further representation
of a different type or of the same type but
with modified content.      We shall now follow
the sequence of sub-processes step by step to
explain their tasks and the structure of the
program representation.
12
Compiler Subtasks
The compilation process decomposes into a
sequence of sub- processes.      Each
sub-processes receives a representation of the
program and produces a further representation
of a different type or of the same type but
with modified content.      We shall now follow
the sequence of sub-processes step by step to
explain their tasks and the structure of the
program representation.
13
Lexical Analysis
A module, usually called SCANNER, carries
out the lexical analysis of a source
program.      It reads the source program in
from a file in the form of a character string
and decomposes this character string into a
sequence of lexical units of the programming
language, called SYMBOLS. Typical lexical
units include the standard representations for
object of type integer, real, char, boolean and
string, together with identifiers, comments,
punctuation symbols and single or multiple
character operators such as , lt, gt, lt, gt,
, (, ), , , and so on.      The scanner can
distinguish between sequences of space characters
and/or line feeds, which only have a meaning
as separators and can subsequently be ignored,
and relevant sequences of such characters (e.g.
String).      The output of the scanner, if it
does not encounter an error, is a
representation of the source program as a
sequence of symbols or encoded symbols.
14
Lexical Analysis Contd.
For example, the representation is as follows
id(int) sep id(a)com id(b)sem sep (it
include NL) id(a)eq int(2) sem sep (it
include NL) id(b)eq id(a)mul id(a) add
int(1) sem sep (it include NL)
15
Screening

• The task of the screener is to recognize the
  following symbols in the symbol string
  produces by the scanner
• Symbols that have a special meaning in the
  programming language, for example among the
  identifiers, the reserved symbols of the language
  such as , , int, float etc
• Symbols that are irrelevant for the subsequent
  processing and will be eliminated, for example
  string of space characters and line feeds, which
  have been used as separators between symbols, and
  comments
• Symbols that are not part of the program but
  directives to the compiler (program), for example
  the type of diagnosis to be performed, the type
  of compilation protocol desired, and so on
• In addition, the screener is often given the task
  of encoding the symbols of certain classes of
  symbols (such as the identifiers) in a unique way
  and replacing each occurrence of a symbol by its
  code

16
Screening Contd.

• Thus, for example, if all the occurrences of an
  identifier in a program are replaced by the same
  natural number, the character-string
  representation of the identifier need only be
  stored once and thus the problem of having to
  store identifiers of different length is
  concentrated in a specialized part of the program

• In practice, the scanner and screener are usually
  combined into a single procedure (which is simply
  called the scanner
• Conceptually, however, they should be separated,
  because the task of the scanner can be
  accomplished by a finite automaton, while that of
  the screener must necessarily (sensibly) be
  carried out by other functions
• The representation is as follows
• int id(1) com id(2) sem
• id(1) eq int(2) sem
• id(2) eq id(1) mul id(1) add int(1)

17
Syntax Analysis

• The syntax analysis should determine the
  structure of the program over and above the
  lexical structure
• It knows the structure of expressions,
  statements, declarations, and lists of these
  constructs and attempts to recognize the
  structure of a program in the given symbol string

• The corresponding module, called the PARSER,
  must also be able to detect, locate, and diagnose
  errors in the syntax structure, there is a wealth
  of methods for syntax analysis
• There are various equivalent forms of parser
  output.
• In our conceptual compiler structure we use the
  syntax tree of the program as output

18
Semantic Analysis

• The task of semantic analysis is to determine
  those properties of programs, above and beyond
  the (context-free) syntactic properties, that can
  be computed using only the program text.
• These properties are often called static
  semantic properties, unlike dynamic
  properties, which are properties of programs that
  can only be determined when the complied program
  is run.
• Thus, the two terms, static and dynamic are
  associated with the two times, compile time and
  run time.
• The static semantic properties includes
• The type correctness or incorrectness of programs
  in strongly typed languages such as Pascal. A
  necessary condition for type correctness is that
  every identifier must be declared (implicitly or
  explicitly) and there should be no double
  declarations.
• The existence of a consistent type assignment to
  all functions of a program in (functional)
  language with polymorphism. Here, a function
  whose type is only partially defined, for example
  using type variables, can be applied to
  combinations of arguments of a different type and
  essentially do the same thing.

19
Semantic Analysis Contd.

• For example, for the first statement a2 one
  checks whether there is a variable name on the
  left side and whether the type of the right side
  matches that of the left side.
• These two questions are answered positively,
  since a is declared as a variable and lexically,
  the character string 2 is recognized as a
  representation of an integer constant.
• In the second statement baa1 the type of the
  right side has to be computed.
• This computation involves the types of the
  terminal operands (all integer) and rules that
  compute the type of a sum or a product from the
  types of the operands.
• Here, we note that the arithmetic operators in
  most programming languages are overloaded, that
  is, they stand for the operations they designate
  over both integer and real numbers, possibly even
  with different precision.
• In the type computation this overloading is
  eliminated.
• In our example, it is established tat an integer
  multiplication and an integer addition are
  involved.
• Thus, the result of the whole expression is of
  type integer.

20
Machine-independent Optimization

• This is optional phase and does not exist in all
  compilers.
• It does not necessarily belong to either the
  analysis phase or the synthesis phase.
• However, it uses information computed by semantic
  analysis and, unlike the subtasks of the
  synthesis phase, it is machine independent

Address Assignment (Part of Code Generator)

• The synthesis phase of the compilation begins
  with storage allocation and address assignment.
• This involves properties of the target machine
  such as the word length, the address length, the
  directly addressable units of the machine and the
  existence or non-existence of instructions giving
  efficient access to parts of directly accessible
  units.

21
Generation of the Target Program (Part of Code
Generator)

• The code generator generates the instructions of
  the target program.
• For this, it uses the addresses assigned in the
  previous step to address variables.
• However, the time efficiency of the target
  program can often be increased if it is possible
  to hold the values of variables and expressions
  in machine registers.
• Access to these is generally faster than access
  to memory locations.
• Since each machine has only a limited number of
  such registers the code generator must use them
  to the greatest advantage to store frequently
  used values.
• This task is called register allocation.

22
Real Compiler Structures

• So far, we have considered a conceptual compiler
  structure.
• Its modular structure was characterized by the
  following properties.
• The compilation process is divided into a
  sequence of sub-processes.
• Each sub-process communicates with its successor
  without feedback the information flows in one
  direction only.
• The intermediate representation of the source
  program can be described by mechanisms from the
  theory of formal languages, such as regular
  expression, context-free grammars, attribute
  grammars, and so on.
• The distribution of tasks among sub-processes is
  in part based on the correspondence between the
  description mechanisms referred to above and
  automaton models and is in part carried out
  pragmatically in order to split a complex task
  into two separate, more manageable subtasks.

23
Real Compiler Structures contd.

• Why is it not a good real compiler structure?
• In the design of a real compiler (one that is to
  be implemented), the structure is influenced by
  the complexity of the subtasks, the requirements
  on the compiler and the constraints of the
  computer and the operating systems.
• This idea of compiler generation led to the
  development of other description mechanisms and
  generation procedures discuss earlier shows the
  subtasks of the conceptual compiler structure
  that can be describe (in part) by formal
  specifications and for which generation
  procedures exist.
