Camera Technology Presentation

1
Camera Technology Presentation
This information is confidential and is not to be
provided to any third party without Vicon
Industries Inc. prior written consent.
2
Topics for discussion

• What do we see in the market?
• Hot topics
• Vicon Products
• Discussion on what can the transition to IP

3
Analog versus network Cameras

• The majority of manufacturers report 90 of
  camera sales are still analog
• High end projects are experiencing the largest
  shift towards IP

4
Market Trends

• IP video surveillance product sales will increase
  by 200 total between 2010 and 2012,
  significantly disrupting and overtaking analog
  CCTV sales.
• Mainstream 720p/1.3MP cameras cut into the cost
  advantage of analog cameras
• Mainstream hybrid DVRs remove the barriers of
  legacy deployments to migrate to IP
• Maturing IP camera standards will cut costs and
  reduce complexity

5
Megapixel Cameras

• Megapixel camera growth has been estimated by IMS
  to be over 100 per year between 2009 - 2012.
• All major providers of cameras now have megapixel
  cameras in their portfolio
• Megapixel cameras allow users to cover more area
  with a single VMS camera license.
• Significant drops in pricing reduces gap between
  VGA and HD cameras.

6
Resolution Comparison
5MP- 16.4x
3MP- 10x
2MP- 6.25x
1.3MP- 4.25x
Analog
7
Megapixel versus Analog
8
Cropping of the image on the sensor
Horizontal

• Pixels can be cropped off at the sensor
• Only required data is sent conserving bandwidth
  and storage

Vertical
Original
9
How many pixels do you need?
10
Hot Topics H.264

• There is a lot of hype surrounding H.264
• Decoding
• MPEG4 versus H.264
• VGA versus Megapixel

11
Hot Topics H.264 versus MPEG-4
H.264
MPEG4
JPEG
12
Hot Topics Decoding H.264

• Typical PC can decode only two H.264 D1 30 fps
  streams simultaneously.
• The same PC can decode 10 MPEG4 D1 30 fps
  streams

13
Hot Topics On Board Storage

• Key Benefits
• Network fault tolerance
• Redundant video storage at the edge
• Rapid access to critical video evidence
• Automated video recovery
• These benefits can only be realized if the VMS is
  integrated with the camera archives

14
Hot Topics On-board analytics

• Camera manufacturers are starting to embed
  analytics into the cameras
• People Counting
• Virtual Trip Wires
• License Plate Recognition
• Unfortunately these capabilities are not
  integrated into the video management system

15
Hot Topics PSIA and ONVIF

• With the rapid expansion of IP camera offerings
  by incumbent manufacturers and the ongoing
  development of industry specifications
  (ONVIF/PSIA), the video surveillance industry is
  changing.
• Over the last few months, public validation and
  momentum has been swinging towards ONVIF

16
Hot Topics Complex software license schemes

• The majority of NVR solutions sell per camera
  software licenses
• Each camera requires a complex licensing
  procedure
• Replacement cameras typically require technical
  support from manufacturer in order to replace the
  defective unit.
• Vicon cameras do not require a license to operate
  within ViconNet.

17
Vicon Network Cameras
18
Network Block Cameras
NEW
19
MP955IR Bullet Network Camera

• 1.3 Megapixel (1280x1024)
• 8 fps at full resolution
• 3.3 to 12mm lens
• POE
• 24 IR Illuminator (66 ft effective range)
• MPEG4 and JPEG Compression formats

20
900 Series Network Dome Cameras
NEW

• Network cameras specifically designed for use in
  ViconNet projects.

NEW
21
2 Megapixel Cameras
NEW
NEW
NEW
NEW

• 2-megapixel CMOS Sensor
• 39 mm Vari-focal, Auto-iris Lens
• Removable IR-cut Filter for Day Night Function
• Real-time H.264 High Profile, MPEG-4 and MJPEG
  Compression
• Multiple Streams Simultaneously
• Video Cropping for Bandwidth Saving
• Built-in 802.3af Compliant PoE

22
2 Megapixel Camera Sample Image

• Electronic Pan/Tilt/Zoom is a useful feature when
  there is enough detail in the source video.

Outdoor Dome
4x
23
Network Roughneck Dome Cameras

• High-impact dome cameras designed for extreme
  environments
• Advanced feature integration with ViconNet Video
  Management Software
• 30 FPS at 4CIF (NTSC) MPEG4
• In-ceiling and pendant mount adapters available

Surface Mount Roughneck
24
Surveyor Dome Cameras

• Subset of PTZ camera line
• Analog (Coax/UTP/Fiber) and Network models
• Comprehensive range of mounting accessories
• Clear, smoked, chrome, and gold domes

25
Surveyor Mini PTZ DomeNEW

• Message
• The Surveyor Mini is the smallest, high
  performance PTZ dome on the market that offers
  the robust features and functionality of a
  SurveyorVFT in a compact, cost effective package.
• Sales Bullets
• Small Profile
• High Performance
• Low Cost

26
Surveyor Mini Specifications

• Auto-focus, high resolution, day/night camera 10x
  optics
• 570 TVL Lines (maximum) resolution
• Full Frame Rate, 30 IPS at 4CIF H.264 or MPEG41
• Auto Flip Dome Rotation
• Privacy zone masking - 32
• 24V AC Power
• Built-in surge protection for lightening strikes
• Outdoor, indoor, pendant, surface, and flush
  mount modules
• -40 to 132 F temperature range
• Aesthetically similar to SurveyorVFT Series

Note 1 Vicon uses an optimized version of MPEG4.
27
Vicon Open Platform integration with 3rd party
cameras

• Seamless integration of analog and IP
  technologies into a single interface
• Integration of 3rd party cameras is fundamental
  component of Vicon strategy
• Vicon will provide deeper integration of features
  into house brand cameras.

28
Discussion

• What types of capabilities do you see important
  for adoption of network cameras
• What feature(s) do you want Vicon to offer you in
  future products?
• What obstacles prevent your customers from using
  network cameras?
