Gram Positive Rods

1
Gram Positive Rods
2
(No Transcript)
3
Listeria

• Small Gram positive rods or coccobacilli (lt2µm)
• Tolerate wide temperature and pH range
• Small haemolytic colonies on blood agar (ß
  haemolysis)
• Facultative anaerobes
• Catalase positive, oxidase negative
• Tumbling motility at 25 degrees
• Aesculin hydrolysed
• Do not grow on MacConkey agar
• Environmental
• Outbreaks related to silage

4
Listeria spp

• L. monocytogenes meningoencephalitis
• septicaemia
• abortion
• pyogenic infection
• L. ivanovii abortion, systemic infection
• L. innocua non-pathogenic
• L. seeligeri
• L. welshimeri
• L. grayi

5
Epidemiology

• Common commensal (tonsils, intestine) and
  environmental organisms
• grow at temperatures 4 - 45C, pH 6.0 - 9.6
• Incidence relates to management/husbandry,
  (silage feeding), seasonal
• predisposed by trauma, immunocompromise, hormonal
  alterations

6
(No Transcript)
7
Diagnosis

• Specimens
• Visceral form liver, kidney or spleen
• Neural form spinal fluid, brain stem
• Abortion placenta, foetal abomasal contents
• Blood smear is not very informative
• Isolation grow aerobically on both blood and
  MacConkey agars at 37C for 24-48h
• Colonies appear transparent after 24 hours and
  greyish in 48 hours. Pathogenic strains show ß
  haemolysis
• L. Monocytogenes is CAMP ve with Staph aureus
• L. Ivanovii is CAMP ve with Rhodococcus equi

CAMP test
8
Listeriosis - Ruminants

• Meningoencephalitis
• Most common form circling disease (small
  ruminants)
• animal circles in one direction only
• unilateral facial paralysis, difficulty in
  swallowing
• fever, blindness, headpressing
• paralysis, death in 2 - 3 days

9
Listeriosis - Ruminants

• In pregnant animals, may localize in placentomes
• cross-over to amniotic fluid, multiplies
• ingested by fetus, causes fetal death, abortion
• In milking cows, mammary gland can be involved
• subclinical mastitis, contamination of milk
• may survive low temp pasteurization inside MØ
• lengthy survival in nature
• growth at low temperatures
• Entry also by nasal mucosa, conjunctivae
• Direct access to nervous system via dental plates
  of trigeminal ganglia

10
Pathogenesis
tooth loss cutting naïve/neonatal
pregnancy animal ? ? ?
oral inoculation epithelial invasion
? ? trigeminal nerve
bacteraemia ? ? ? brain stem
neonatal placentitis ?
septicaemia ? meningoencephalitis
abortion circling disease
11
Silage and sheep
Listeria encephalitis (bacteria in brain)
A Circling disease in sheep B Cranial nerve
paralysis
12
Pathogenic mechanisms

• Facultative intracellular parasites surviving in
  macrophages and epithelial cells
• Cell uptake induced by bacterial protein
  internalin (inlA)
• Inside the cell they escape the phagolysosome,
  multiply in the cytoplasm and via actin based
  motility spread laterally to adjacent cells
• They escape epithelium and are taken up by PMN
  and macrophages
• These cells are killed and the organism may
  spread systemically

13
Pathogenic mechanisms

• Bacteria polymerize actin, form tails
• hollow mesh forms on surface, left behind as
  bacterium moves through cytoplasm, invade
  adjacent cells
• actin depolymerized as organism moves (turnover)

• Major virulence factor mediating intracellular
  survival is a cholesterol binding cytolysin
  called listeriolysin (LLO)
• Shares 40-50 aa similarity to other thiol
  activated toxins
• Mediates escape from phagocytic vesicle

14
LLO

• Cholesterol-directed pore-forming cytolysin (gt22
  members)
• Bind to cholesterol-containing membranes
• Insertion
• Oligomerization (20-80 mers)
• Pore (20-30 nM) formation

15
Epidemiology of Human Listeriosis
enteric Listeria in animals ? contamination of
carcase, milk or food crops ? Ingestion (pate,
soft cheese, coleslaw) ? colonisation of tonsils
and intestine ? ? immunocompetent immunocompr
omised (neonate, elderly, pregnancy)
? ? asymptomatic
septicaemia meningitis
abortion
16
Consequences of human L. monocytogenes infection
17
Associated Foods

• Milk products raw pasteurised
• Cheeses
• Meat and poultry products Raw, cooked ready to
  eat meat and poultry (sporadic and epidemic)
• Seafood fresh, frozen and processed seafood

18
Consequences of human L. monocytogenes infection

• Entry via GI tract, 20 h incubation period
• usually asymptomatic/mild, influenza-like
  symptoms in adult humans, transient
  gastroenteritis
• more serious infection immunocompromised
• CNS infections (encephalitis, meningitis), fatal
  bacteremia
• puerperal sepsis
• crosses placenta ? in utero fetal infection
• stillbirths, preterm labor
• infant born with systemic infection

19
Cutaneous listeriosis (in vets)

• 17 cases, all with lesions on fore or upper arms,
  or hands
• 16 farmers, veterinarians
• 1 butcher
• Most developed lesions 1-4 days after attending
  congenitally infected bovines

20
Erysipelothrix rhusiopathiae

• Gram positive rods (1-2.5µm)
• Commensal widespread in animals, infects man
• Grows 4-37C
• Catalase negative, oxidase negative
• Facultative anaerobic, non-motile
• Opaque, pin-point, non-haemolytic colonies
• infection disease mainly in pigs sheep,
  turkeys, others
• Smooth (S) and rough (R) forms associated with
  different diseases
• Acute septicaemia in pigs, turkeys, sub-acute
  skin lesions in pigs S
• Chronic arthritis in sheep, endocarditis in pigs
  - R

21
Erysipelothrix rhusiopathiae
22
(No Transcript)
23
Pathogenesis
commensal tonsils, RES, bone marrow, many organs
mainly R or R/S depression of host
defences multiplication of virulent strains
(reversion to S?) entry via tonsils or
cuts/abrasions invades neutrophils ? ?
? septicaemia urticarial form arthritis/endoca
rditis fever malaise
persistent anorexia fever
erosive DIC DIC chronic
inflammation haemorrhage lymphadenitis epidermal
lesions fatal ("Diamonds")
24
Swine erysipelas (diamond skin disease)
25
Actinomycete Group

• Gram positive
• Catalase positive
• Many are acid fast (mycolic acid in cw)
• Slow growing - survive in macrophages
• Pleomorphic (coccobacilli to filamentous). Very
  small (lt1µm)
• Many saprophytic some opportunist
• Pathogenic genera
• Actinomyces spp.
• Nocardia spp.
• Arcanobacterium spp.
• Dermatophilus spp.
• Corynebacterium spp.
• Eubacterium spp.
• Rhodococcus spp.

26
Actinomycete diseases

• Pyogenic
• Granulomatous
• Include abscesses, pyelonephritis,
  lymphadenitis, osteomyelitis
• Chronic inflammation focal lesions
• Some highly-host adapted
• CMI protective A/bodies mainly non-protective
• In vitro - sensitive to some antibacterials
• In vivo poor response - intracellular location

27
Actinomyces

• Actinomyces bovis, Actinomyces viscosus,
  Actinomyces suis
• (Most) non-acid fast branching rods

• non-motile
• microaerophilic or anaerobic
• Colonies are non-haemolytic, small and white
• Produce pyogenic, granulomatous reactions -
  sulphur granules

28
Actinomyces bovis

• Normal flora - anaerobic
• Thick yellow pus sulphur granules
• (occ. confused with wooden tongue)
• Causes actinomycosis or Lumpy jaw in cattle
  (other tissues). Invasion through wound/rough
  feed/damaged mucosa Bone infection
  osteomyelitis animal stops eating, loses weight
• Soft tissue infection
• Mastitis

29
Actinomyces bovis

• Infection endogenous
• Organism lives in the mouth normally
• Pathology the result of tissue trauma, lesions
  or prolonged irritation
• Treat lesions small, circumscribed surgery,
  abscesses drained, packed with gauze and iodine
  penicillin

30
Sulphur granules
Gram stain, A. bovis
48 hour culture, A. bovis
31
Lumpy Jaw
32
Actinomyces viscosus

• Mainly dogs (cats, pigs, goats, cattle, horses).
• Fimbriae - adherence to teeth plaque
• Similar lesions to Nocardia (Nocardia rarely
  produces granules)
• Localised, pyogranulomatous lesions
• Two main conditions - Thoracic lesions (pleural,
  pericardial fluid, lung lesions) and
  osteomyelitis
• Treatment prolonged
• Actinomyces suis mastitis in pigs (sows),
  trauma initiates disease

33
Nocardia

• Strictly aerobic
• Gram-positive, pleomorphic (filaments, rods,
  cocci branching)
• Widely distributed soil, water, air, sewage
• 0.5 1.2 µm in size
• Acid fast
• Non-motile
• Non-spore-forming

34
Nocardia

• 12 species pathogenic to birds, goats, cats,
  dogs, fish, horses, cattle and humans
• Nocardia asteroides most frequent nocardial
  pathogen subcutaneous infections in dogs
• N. brasiliensis pneumonia in horses
• Colonies are vivid white occasionally pigmented

35
Nocardia
36
Nocardia

• Organism inhaled, in wound or ingested
• Direct or haematogenous spread
• Prevents phagocytosis
• Chronic invasive pyogenic infections (no sulphur
  granules)
• 3 clinical forms cutaneous, respiratory
  (pyothorax) and systemic (pyrexia, cough,
  neurological, resembles distemper)
• Dogs 3x more common in males, Cats mainly
  thoracic infection
• Treatment difficult and prolonged not
  penicillin

37
Dog, Nocardia
Fluid from chest
4 day culture from fluid
38
Dermatophilus congolensis

• Facultatively anaerobic
• Gram positive, non acid fast
• filamentous, branching filaments mature they
• fragment and release motile flagellate spores
• Septation of filaments
• zoospores (motile) Beaded, Tram-track the
  infectious form
• CO2 chemotactic to zoospores zoospores
  germinate form filament form new zoospores
  repeating the cycle
• Pathogenesis
• Commensal/spore entry injury/ wet damage
• Colonisation keratinase production. Aid spread
  and growth
• Strong host response, neutrophil and lymphocyte
  exudation.
• EPIDERMIS ONLY

39
Dermatophilus congolensis

• Dermatitis cattle, dog, cat, man
• Sheep lumpy wool, strawberry foot
• Horse mud fever, greasy heel, rain scald
• Treatment Pen/Strep. Tetracyclines
• No effective vaccine

Dermatophilus in a horse
Dermatophilus lesions, SHEEP
40
Corynebacterium

• Small pleomorphic, Gram-positive rods
• Chinese letters
• Facultatively anaerobic, non-motile
• Catalase positive, oxidase negative
• Pyogenic
• Common commensals
• Colonies are white, small, dry, non-haemolytic
  (except C.pseudotuberculosis).
• Genus originally created for the important human
  pathogen C. diphtheriae, the cause of diphtheria
  in man

41
CAMP Test
CAMP-Inhibition Test
1. Staphylococcus aureus 2. C.pseudotuberculosis 3
. C.renale 4. Rhodococcus equi
42
(No Transcript)
43
Corynebacterial species of veterinary interest

• C. renale group
• C. renale
• C. pilosum
• C. cystitidis
• All cause cystitis and pyelonephritis in cattle
• Diphtheria group
• C. diphtheriae
• C. ulcerans
• C. pseudotuberculosis
• Various diseases of cats, cattle,
• horses, small ruminants and humans

44
Corynebacterium renale group

• C. renale gt C. cystitidis gt C. pilosum
• Opportunist highly adapted
• Causes cystitis, pyelonephritis, balanoposthitis
• Predisposing factors - pregnancy, parturition,
  post mating
• 90 bulls C. cystitidis - prepuce

45
Cow with C. renale infection
Urine, C. renale
C. renale on milk agar
46
Corynebacterium renale group

• Virulence factors
• Pili - adherence
• Renalin - cell lysis
• Urease
• Caseinase

• Pathogenesis
• Adhere to urogenital mucosa
• Stress
• Proliferation
• Ascending infection
• Inflammation
• Cystitis/pyelonephritis

47
The diphtheria group

• Highly-related (based on DNA hybridisation
  studies)
• C. diphtheriae diphtheria (humans)
• C. pseudotuberculosis various pyogenic
  infections
• C. ulcerans nasal congestion (cats), mastitis
  (cattle)
• Susceptible to infection with ß-corynephages
• C. pseudotuberculosis C. ulcerans zoonotic
  pathogens
• C. diphtheriae normally only a human pathogen

48
Corynebacterium diphtheriae

• Occasionally isolated from infected wounds in
  horses (potential environmental reservoir?)
• Ironically, horses were the original heroes in
  fight against diphtheria

An illustration from the Nov. 17, 1894, issue of
Scientific American, showing doctors drawing
blood from a horse to produce antitoxin for
diphtheria
49
Corynebacterium ulcerans

• Significant increase in human infections caused
  by C. ulcerans
• Same organism isolated from several domestic cats
  with bilateral nasal discharge (2002-2003)
• Strains isolated from domestic cats were found to
  exhibit the predominant types observed among
  human clinical isolates, suggesting that C.
  ulcerans isolated from cats could be a potential
  reservoir for human infection

50
Corynebacterium pseudotuberculosis

• C. pseudotuberculosis (pseudes-tuberculosis)
• Thought to have spread from Europe with expanding
  colonial powers
• 2 biotypes identified
• ovis non-nitrate reducing, infect sheep/goats
  (CLA)
• equi nitrate reducing, infects predominantly
  horses

51
Caseous lymphadenitis (CLA)

• Widespread globally
• Fibrous, encapsulated lesions at various sites
• Devastating visceral form reported in USA
• Significant financial losses to producers/animal
  welfare
• deaths, carcass condemnations at slaughter
• decreased wool, milk production
• decreased reproductive performance

52
Pathogenesis

• C. pseudotuberculosis gains entry to host through
  wounds (shearing, fighting, etc.)
• Normally transfer of pus (direct contact or
  flies)
• Pus contains millions of
• bacterial cells
• Aerosol route of disease
• transfer also suggested
• From point of entry,
• drains to local drainage
• lymph node

53
Pathogenesis

• Cells are phagocytosed as part of innate immune
  response survive and replicate within
  macrophages
• Focus of infection established within lymph node
• Multiple microscopic foci coalesce to form
  pyogranuloma
• Lesion encased within fibrous capsule.
  Infiltration of immune cells forms caseous
  abscess
• Classic onion ring appearance

54
Pathogenesis

• Trafficking of infected phagocytes to other
  tissues allows dissemination of infection
• Cutaneous CLA Superficial lymph nodes,
  occasionally skin
• Visceral CLA (25) lungs, kidneys, brain,
  internal lymph nodes
• Mediastinal abscesses place pressure on trachea ?
  restricted rumination ? chronic wasting

55
Pathogenesis

• Virulence factors
• Phospholipase D (PLD)
• Sphingomyelinase, antichemotactic, lethal for
  neutrophils, complement depletion, increased
  vascular permeability
• Mycolic acid (cell wall lipid)
• Toxicity, survival within macrophages
• Serine protease (Cp40)
• Undefined function, possibly survival within
  macrophages
• Siderophore
• Acquisition of iron from host

56
Pathogenesis

• Aerosol transmission?
• Disease spread in absence of external abscesses
• C. Pseudotuberculosis cultured from trachea of
  infected sheep
• Potential for coughing to aerosolise pus
