Title: Etisalat IPv6


1
Etisalat IPv6 Deployment Strategy Arab Regional
Workshop on IP STRATEGIES AND IDN ISSUES Damascus
Syria 16-18,May 2006 By A. Moeen
Aqrabawi Senior Engineer Planning Converged
Network Etisalat aqrabawi_at_eim.ae ipv6_at_nic.ae
2
Agenda
  • Introduction to IPv6 deployment and strategies
  • IPv6 Deployment at the Etisalat Backbone Network
  • IPv6 Deployment at the Etisalat Internet
    Exchanges
  • IPv6 Deployment at the Etisalat Access Networks
  • Current Etisalat IPv6 Deployment Status
    Experience

3
Introduction to IPv6 Deployment
4
Motivation to Adopt IPv6
  • Larger address space for global reachability and
    scalability
  • Simplified header for routing efficiency and
    performance
  • Efficient support for routing and route
    aggregation
  • Server-less auto-configuration, easier
    renumbering, multi-homing, and improved plug and
    play support
  • Security with mandatory IP Security (IPSec)
    support for all IPv6 devices
  • Improved support for Mobile IP and mobile
    computing devices
  • Enhanced multicast support with increased
    addresses and efficient mechanisms

5
IPv4 Address Space Report Regional Internet
Registry RIRs
http//bgp.potaroo.net/ipv4/
  • IPv4 Address Space Exhaustion Predictors
  • Complete Exhaustion of all available IPv4
    Address Space
  • Report Showed on 2004 July 2040
  • Report Showed on 2006 May 2027
  • Exhaustion of the IPv4 Unallocated Address Pool
  • Report Showed on 2004 October
    2018
  • Report showed on 2006 Sep 2011

6
Emirates IPv4 Address Space Report / UAEnic (LIR)
Address Space IPs Year. Utilization.
194.170.0.0/16 65,534 1995 100
195.229.0.0/16 65,534 1997 100
213.42.0.0/16 65,534 1999 100
217.164.0.0/15 131,070 2001 50
83.110.0.0/15 Additional /15 131,070 131,070 2004 2006 50 5
7
Before Deploying IPv6
  • Before beginning to plan to deploy IPv6, you
    should familiarize yourself with IPv6 , Most of
    the definition of IPv6 is under the control of
    the Internet Engineering Task Force (IETF) refer
    to http//www.ietf.org
  • What the others are doing !?, The IPv6 Forum was
    created in 1999 to promote and advocate the IPv6
    protocols and their deployment http//www.ipv6foru
    m.com
  • You need to know some IPv6 basics like
  • IPv6 address types and formats
  • ICMPv6, neighbor discovery, security, and
    mobility
  • IPv6 routing protocol OSPFv3, BGP4,IS-IS,
    RIPng, EIGRPv6
  • IPv6 integration and coexistence strategies
    ,vendors support
  • IPv6 host configuration (Solaris,
    Microsoft, and FreeBSD)
  • What to test in IPv6 and How !?
  • How to connect to the IPv6 Internet
  • You need to answer questions like Why
    (Motivation) !?, What is your strategy, Scope,
    Plan, Budget and timeline !?, and how you are
    going to deploy !? .

8
How to Plan Deploying IPv6 ?
Service Providers
  • ISPs should plan IPv6 deployment in three phases
  • Providing an IPv6 service at the customer access
    level
  • Running IPv6 within the core infrastructure
    itself
  • Interconnecting with other IPv6 service providers

Enterprises
  • Two key ways of evaluating and assessing IPv6
    products and services are
  • Set up an IPv6 domain and connect to an existing
    network
  • Set up two or more IPv6 domains and interconnect
    them over your existing IPv4 infrastructures

9
Pre-Deployment Tasks
  • Before deploying IPv6,
  • Get and Plan your IPv6 address space,
    (service provider) you need to register for
    an IPv6 address contact RIRs LIRs , (enterprise)
    request an IPv6 prefix from your service provider
  • Set up your DNS,
  • Select IPv6 Network management tools,
  • And select required routing protocols.

10
Deployment Strategies
  • A wide range of techniques have been identified
    and implemented worldwide, basically falling into
    the following categories
  • (1) dual-stack techniques, to allow IPv4 and IPv6
    to co-exist in the same devices and networks
  • (2) tunneling techniques, to avoid dependencies
    when upgrading hosts, routers, or regions
  • (3) translation techniques, to allow IPv6-only
    devices to communicate with IPv4-only devices
  • (4) Dedicated Data Links, new IPv6 sites or
    migrating existing sites.
  • All of these are used in combination

11
IPv6 Deployment at Etisalat Network Backbone
12
Etisalat Network
Internet Providers International Customers
Internet Exchange AUH
Data Access PoPs
Internet Exchange Dubai
MPLS Multi Services Transport Core Network
Metro NGN
Data Centres Dubai
Voice Access sites
Data Centres Abu Dhabi
Video Access Sites
13
Etisalat Core Network IPv6 over MPLS
  • IPv6 over MPLS backbones enables isolated IPv6
    domains to communicate with each other over an
    MPLS IPv4 core network. (Etisalat MSC is a
    transparent Core network)

14
IPv6 Deployment in MPLS Multi-Services Network
Backbone plans
  • IPv6 Fixed-Mobile Convergence Services (FMC)
    support
  • Mobile IPv6 clients and seamless handover
    support
  • IP multimedia subsystem (IMS-IPv6) support
  • IPv6 VPN services
  • IPv6 integration with MPLS/GMPLS
  • IPv6 over MPLS
  • MPLS based IPv6 tunneling

15
IPv6 Deployment at Etisalat Internet Exchange
(EMIX)
16
Emirates Internet Exchange (EMIX) www.emix.ae
  • EMIX established (1998) , it is the first Network
    Access Point (NAP), in the GCC, Middle East and
    one of the first NAPs in the African and Asian
    regions, built on multiples of STM-1/STM-4 Fiber
    Optic Cables.
  • 40 STM-1/4 links (6200 Mbps) Total Bandwidth
  • From three cable providers in the region Flag and
    SMW-3 and SMW-4.
  • Distributed between eastern side and western side
    of the world.

17
EMIX Customers and Peering Links
Kuwait QualityNet
Peering Malaysia Exchange
Peering GLOBIX
Peering Hurricane Electric
Peering TimeWarner Telecom
Peering NACAMAR
Peering COLT
Peering Internet Solution
18
IPv6 Deployment plans - EMIX
  • Run BGP4 Routing protocol
  • Peering with IPv6 International Providers
  • Dedicated (Native) IPv6 links
  • IPv6 over IPv4 tunnels with peers
  • Peering with EMIX customers
  • Dedicated (Native) IPv6 Links
  • IPv6 over IPv4 tunnels
  • Providing IPv6 Connectivity

19
IPv6 Deployment at the Access Networks
20
Etisalat Provides (Access)
  • Telephony and Voice
  • GSM, WAP, GPRS, and 3G
  • ISDN
  • Leased Circuits
  • Public ATM
  • Frame Relay
  • Fax Plus/Fax On Demand
  • Video Conferencing
  • Short/Multimedia Messaging Service (SMS/MMS)

21
Internet Services (Access)
  • Dial-up
  • ISDN
  • ADSL
  • Cable Modem
  • Wireless Internet Access (IWAN)
  • Internet Leased Line
  • Internet over ATM
  • WLAN Hot Spots

22
Etisalat Data Centers (Access)
  • Hosting
  • Shared Web Hosting
  • Virtual e-mail
  • Co-location
  • Managed hosting services
  • E-Storage

E-commerce E-Security Services
  • Digital certification - Public Key Infrastructure
    (PKI)
  • E-Payment e-Shopping
  • Managed security Services

23
Etisalat Data Centers - Continue
  • Multiple Sites in both Dubai Abu Dhabi
  • Space in excess of 6300 sq meter
  • Dual Power Sources, 900kva
  • Internet access 10/100 M, GE
  • Secure Access (Firewall, Load balancers, Global
    LB)
  • SAN, 96 terabyte
  • ISO 90012000 , SunTone and BS7799 certified
  • Physical Security- Continuous video surveillance
    cameras motion detectors, Smart card or
    Biometric reader for customers

24
Etisalat IPv6 at the Access plans
  • IPv6 at the Data Access PoPs
  • IPv6-over-IPv4
  • Dynamic Tunnels
  • Tunnel Brokers
  • Dedicated IPv6 links
  • DHCPv6
  • IPv6 at the Voice Access
  • SIPv6, Mass Mobile services and applications
  • IPv6 Soft Switches
  • IPv6 Mobile/GSM/IMS and voice clients
  • IPv6 at the Video Access
  • IPv6 for Live streaming
  • IPv6 for VoD

25
Etisalat IPv6 at the Data Centers
  • Working on two areas
  • 1. Testing the Internet infrastructure systems
    and applications support to IPv6
  • 2. Provide options for hosted customers services
    (Co-location)
  • Internet Infrastructure Systems/Applications
  • DNS
  • WEB
  • PROXY
  • MAIL
  • Databases
  • NTP
  • NAS/SAN , NFS,FTP and backup applications
  • Gaming and Streaming
  • NMS and IPv6 monitoring and traffic reporting
    tools
  • (IPv6 Security), State full IPv6 firewalls and
    Internet Security Systems, IPSec and ISAKMP.

26
Current Etisalat IPv6 Deployment Status
27
Etisalat IPv6 Project Objectives
  • Build scalable nation-wide IPv6 native test
    network.
  • Ensure IPv6 standards compliance for Etisalat
    current and future systems.
  • Establish test environment to evaluate the
    compliance of hardware and software with IPv6
    standards
  • Work towards exposure of the IPv6 standards
    within Universities, Colleges and Research
    Centers in UAE.

28
Contract Clause for all new tenders to confirm
IPv6 compliance. Added in year 2001
  • All the supplied systems (hardware/Software)
    wherever IP connectivity is required should
    support IPv6 and IPv4 (simultaneously if
    required) with latest standards of IETF, ITU,
    ANSI and other governing Communication standards.
  • If the system is not compliant to the above, the
    supplier should indicate the roadmap to implement
    IPv6 and clearly state when the system would be
    compliant to IPv6. The upgrade should be free of
    cost.
  • Further the vendor should confirm that the
    product would be kept abreast with the IPv6
    development.
  • Note- For existing systems Concerned
    sections should obtain the Statement of
  • Direction towards IPv6 from the
    Vendors who supplied those systems.

29
Etisalat IPv6 Network
30
Etisalat IPv6 project tasks
Milestone Due Date Status
Form Etisalat IPv6 Task Force after the Global IPv6 Summit held in Dubai. (February 2001) May, 2001 Completed
Test IPv6 with 6Bone (via SPRINTv6) Oct, 2001 Completed
Obtain Global Unicast IPv6 Addresses from (RIPE NCC) Oct, 2001 Completed
Building Etisalat Basic IPv6 basic network infrastructure Feb, 2002 Completed
(BGP) Peering with ISPs. June,2002 Completed
Testing in Etisalat Labs Mar, 2003 In Progress
1
2
3
4
5
6
31
Etisalat IPv6 project tasks Cont.
Milestone Due Date Status
IPv6 Systems Infrastructure. (DNS,WEB) July, 2003 Completed
www.ipv6.ae , Lab.ipv6.ae Publishing. Oct, 2003 Completed
Verifying networks and services elements IPv6 support. May, 2004 Completed
Testing with regional ISPs and with EMIX Customers. N/A In Progress
Native IPv6 Peering at EMIX/NY6IX Q1, 2005 In Progress
Building GCC native IPv6 Network N/A In Progress
7
8
9
10
11
12
32
Etisalat IPv6 (Converged Network CN) Task Force
Chairman
Secretariat
Working Groups
IPv6 Steering Committee
Planning Group
Services
Backbone
Access
Lab
Security
OPS SYS SEC
OPS NW
PRG MGR
ENG QA OCS
ENG NMS
E/PLG
ENG
E/PLG
ENG
ENG
ENG
ENG
ENG
E/PLG
NW
ENG
ENG
SEC
SYS
33
Etisalat IPv6 Project Roadmap
Early Lab testing
Peering/Testing with IPv6 Over IPv4 Tunnels
Native IPv6 Peering ?
IPv6 Networks testing ?
IPv6 Application testing ?
34
Next Steps
  • Connectivity with research centers within UAE
    (Native and Tunneling)
  • Focus on IPV6 applications
  • Continuous awareness
  • Establish native IPv6 connectivity with GCC/ EMIX
    Customers and providers

35
Etisalat IPv6 Contribution
  • First in the region to test the IPv6 with 6Bone
    2001
  • Sponsored First Gulf IPv6 summit in 2001in Dubai
  • First in the region to obtain IPv6 Global Address
    Space
  • First to present/showcase IPv6 in the RIPE NCC
    regional meetings in 2003
  • First to present IPv6 in the regional symposium
    on eGoverment
  • First to present the IPv6 in the ITU/BDT Arab
    regional meetings
  • The first IPv6 task force in the UAE
  • The first company in the region to have Internal
    IPv6 Forums
  • Second regional IPv6 summit 2005 in Abu Dhabi
  • Etisalat awarded network pioneer for its
    initiatives on IPv6 in the middle east by network
    middle east magazine June,14 2005
  • Etisalat Participated in more than 100 IPv6
    events since 2001

36
  • Thank
  • You
About PowerShow.com
