Title: THE PROGRAMMABLE LOGIC CONTROLLER


1
THE PROGRAMMABLE LOGIC CONTROLLER
Slovak University of Technology Faculty of
Material Science and Technology in Trnava

2
Programmable Logic Controller (PLC)
  • PLCs have been gaining popularity on the factory
    floor is because of the advantages they offer
  • Cost effective for controlling complex systems.
  • Flexible and can be reapplied to control other
    systems quickly and easily.
  • Computational abilities allow more sophisticated
    control.
  • Trouble shooting aids make programming easier and
    reduce downtime.
  • Reliable components make these likely to operate
    for years before failure.

3
A PLC illustrated with relays
4
Origins of Ladder Diagram
  • The Ladder Diagram (LD) programming language
    originated from the graphical representation used
    to design an electrical control system
  • Control decisions were made using relays
  • After a while Relays were replaced by logic
    circuits
  • Logic gates used to make control decisions
  • Finally CPUs were added to take over the function
    of the logic circuits
  • I/O Devices wired to buffer transistors
  • Control decisions accomplished through
    programming
  • Relay Logic representation (or LD) was developed
    to make program creation and maintenance easier
  • Computer based graphical representation of wiring
    diagrams that was easy to understand
  • Reduced training and support cost

5
Origins of Ladder Diagram
6
What is a Rung?
  • A rung of ladder diagram code can contain both
    input and output instructions
  • Input instructions perform a comparison or test
    and set the rung state based on the outcome
  • Normally left justified on the rung
  • Output instructions examine the rung state and
    execute some operation or function
  • In some cases output instructions can set the
    rung state
  • Normally right justified on the rung

7
Series Vs Parallel Operations
  • Ladder Diagram input instructions perform logical
    AND and OR operations in and easy to understand
    format
  • If all Input Instructions in series must all be
    true for outputs to execute (AND)
  • If any input instruction in parallel is true, the
    outputs will execute (OR)
  • Paralleling outputs allows multiple operations to
    occur based on the same input criteria

8
Ladder Logic Execution
  • Rungs of Ladder diagram are solved from Left to
    right and top to bottom
  • Branches within rungs are solved top left to
    bottom right

9
Non Retentive Coils
  • The referenced bit is reset when processor power
    is cycled
  • Coil -( )-
  • Sets a bit when the rung is true(1) and resets
    the bit when the rung is false (0)
  • PLC5 calls this an OTE Output Enable
  • Negative coil -( / )-
  • Sets a bit when the rung is false(0) and resets
    the bit when the rung is True(1)
  • Not commonly supported because of potential for
    confusion
  • Set (Latch) coil -(S)-
  • Sets a bit (1) when the rung is true and does
    nothing when the rung is false
  • Reset (Unlatch) Coil -(R)-
  • Resets a bit (0) when the rung is true and does
    nothing when the rung is false

10
Contacts
  • Normally Open Contact - -
  • Enables the rung to the right of the instruction
    if the rung to the left is enabled and
    underlining bit is set (1)
  • Normally Closed Contact -/-
  • Enables the rung to the right of the instruction
    if the rung to the left is enabled and
    underlining bit is reset (0)
  • Positive transition contact -P-
  • Enables the right side of the rung for one scan
    when the rung on left side of the instruction is
    true
  • Allen Bradley PLC5 uses -ONS-
  • Negative transition contact -N-
  • Enables the right side of the rung for one scan
    when the rung on left side of the instruction is
    false

11
Retentive Vs Non-retentive Operation
  • Definitions
  • Retentive values or instructions maintain their
    last state during a power cycle
  • Non-retentive values or instructions are reset to
    some default state (usually 0) after a power
    cycle
  • IEC1131 permits values to be defined as retentive
  • A contradiction to this is ladder diagram where 3
    instructions are classified as retentive
  • In most PLCs only timer and coil instructions
    operate as non-retentive

12
Retentive Coils
  • The referenced bit is unchanged when processor
    power is cycled
  • Retentive coil -(M)-
  • Sets a bit when the rung is true(1) and resets
    the bit when the rung is false (0)
  • Set Retentive (Latch) coil -(SM)-
  • Sets a bit (1) when the rung is true and does
    nothing when the rung is false
  • PLC5 uses OTL Output Latch
  • Reset Retentive (Unlatch) Coil -(RM)-
  • Resets a bit (0) when the rung is true and does
    nothing when the rung is false
  • PLC5 uses OUT Output Unlatch

13
Transition Sensing Coils
  • Positive transition-sensing coil -(P)-
  • Sets the bit bit (1) when rung to the left of the
    instruction transitions from off(0) to on(1)
  • The bit is left in this state
  • PLC5 use OSR (One Shot Rising)
  • Negative transition-sensing coil -(N)-
  • Resets the bit (0) when rung to the left of the
    instruction transitions from on(1) to off(0)
  • The bit is left in this state
  • PLC5 uses OSF (One Shot Falling)

14
IEC Comparison Instructions in Ladder
  • If the rung input (EN) is enabled, the
    instruction performs the operation and sets the
    rung output (ENO) based on the comparison
  • Example when EN is true, EQ () function
    compares In1 and to In2 and sets ENO
  • Comprehensive instruction set
  • EQ(), GT (gt), GE (gt), LT (lt), LE (lt), NE (ltgt)

15
Timers in Ladder Diagram
  • There three timer instructions in IEC1131
  • TP - Pulse timer
  • TON - Timer On Delay
  • TOF - Timer Off Delay
  • Time values
  • Time base is 1msec (1/1000 of a sec)
  • Values entered using duration literal format
  • Two possible visualizations Depending on use of
    EN/ENO
  • 1st method requires extra programming if timer
    done status needs to be referenced on other rungs
  • 2nd method sets a bit with Q which can be
    referenced by other logic, ENOEN

16
Timer Operation
  • IN Rung input condition
  • Q Comparison output results
  • Varies with timer types
  • PT Preset Time
  • ET Elapse Time

17
Counters in Ladder Diagram
  • There three counter instructions in IEC1131
  • CTU - Count Up Counter
  • CTD - Count Down Counter
  • CTUD - Count Up/Down Counter
  • All three count rung transitions
  • Two possible visualizations Depending on use of
    EN/ENO
  • 1st method requires extra programming if timer
    done status needs to be referenced on other rungs
  • 2nd method sets a bit with Q which can be
    referenced by other logic, ENOEN

18
Counter Operation
  • Parameters
  • CU/CD Count up/Down
  • Q/QU/QD Comparison Output
  • R Reset to Zero
  • LD Load CV with PV
  • PV Preset Value
  • CV Count Value

19
Execution Control Elements
  • Jump / Label Instructions
  • Jump to a label skips a block of code without it
    being scanned
  • LBL - Named target for a jump operation
  • JMP - Performs a jump when the rung conditions
    are true
  • CALL / RETURN Instructions
  • Used to encapsulate logic and call it as a
    subroutine
  • Causes execution to change between functions or
    subroutines
  • CAL - Passes control to another named function
  • PLC5 uses JSR
  • RET - Exits a function and returns control back
    to the calling routine

20
Different Instruction Presentations
  • The look and feel of IEC 1131-3 is somewhat
    different from the 1Million PLCs that Allen
    Bradley has running in factories throughout the
    world
  • IEC places the input parameters on the outside of
    the instruction block vs the PLC5 where they are
    presented inside of the block

21
Extending the IEC1131-3 Instruction Set
  • IEC1131-3 Provides a very basic set of
    instructions to do simple operations (81 Ladder
    Diagram Instructions)
  • Data Type Conversion - Trunc, Int_to_Sint,
    Dint_to_Real, Bcd_To_Int
  • Boolean Operations - Bit Test, Bit Set, One Shot,
    Semaphores
  • Timers / Counters - Ton, Tp, Ctu, Ctd, Ctud
  • Simple Math - Add, Sub, Mul, Div, Mod, Move, Expt
  • Misc. Math - Abs, Sqrt, Ln, Log, Exp, Sin, Cos,
    Tan, Asin, Acos, Atan
  • Bit Shift - Shl, Shr, Ror, Rol
  • Logic - And, Or, Xor, Not
  • Selection - Sel, Max, Min, Limit, Mux
  • Compare - GT, GE, EQ, LE, LT, NE
  • String - Len, Left, Right, Mid, Concat, Insert,
    Delete, Replace, Find
  • Control - JMP, LBL, JSR, RET
  • All complex operations are left to the user or
    vendor to define
  • File Operations, PID, Diagnostic, For/Nxt Loop,
    Search, Sort are not in IEC1131-3
  • Extensions to the instruction set are permitted
    so that vendors can add instructions that their
    customers need
  • All vendors have defined their own set of
    extensions
  • Rockwell Automation controllers have
    significantly more capabilitywith over 130
    Ladder Instructions

22
PLC HARDWARE
  • The most essential components PLC are
  • Power Supply - 24Vdc, 120Vac, 220Vac.
  • CPU (Central Processing Unit) - This is a
    computer where ladder logic is stored and
    processed.
  • I/O (Input/Output) - A number of input/output
    terminals must be provided so that the PLC can
    monitor the process and initiate actions.
  • Indicator lights - These indicate the status of
    the PLC including power on, program running, and
    a fault. These are essential when diagnosing
    problems.

23
PLC HARDWARE
  • Typical configurations are listed below from
    largest to smallest
  • Rack - A rack is often large (up to 18 by 30 by
    10) and can hold multiple cards. When necessary,
    multiple racks can be connected together. These
    tend to be the highest cost, but also the most
    flexible and easy to maintain.
  • Mini - These are similar in function to PLC
    racks, but about half the size.
  • Shoebox - A compact, all-in-one unit (about the
    size of a shoebox) that has limited expansion
    capabilities. Lower cost, and compactness make
    these ideal for small applications.
  • Micro - These units can be as small as a deck of
    cards. They tend to have fixed quantities of I/O
    and limited abilities, but costs will be the
    lowest.
  • Software - A software based PLC requires a
    computer with an interface card, but
  • allows the PLC to be connected to sensors and
    other PLCs across a network.

24
INPUTS FOR A PLC
  • Inputs for a PLC come in a few basic varieties,
    the simplest are AC and DC inputs. Sourcing and
    sinking inputs are also popular
  • Sinking - When active the output allows current
    to flow to a common ground. This is best selected
    when different voltages are supplied.
  • Sourcing - When active, current flows from a
    supply, through the output device and to ground.
    This method is best used when all devices use a
    single supply voltage.

25
INPUTS FOR A PLC
  • In smaller PLCs the inputs are normally built in
    and are specified when purchasing the PLC.
  • For larger PLCs the inputs are purchased as
    modules, or cards, with 8 or 16 inputs of the
    same type on each card.
  • Inputs are normally high impedance. This means
    that they will use very little current.

26
INPUTS FOR A PLC
  • There are many trade-offs when deciding which
    type of input cards to use.
  • DC voltages are usually lower, and therefore
    safer (i.e., 12-24V).
  • DC inputs are very fast, AC inputs require a
    longer on-time. For example, a 60Hz wave may
    require up to 1/60sec for reasonable recognition.
  • DC voltages can be connected to larger variety of
    electrical systems.
  • AC signals are more immune to noise than DC, so
    they are suited to long distances, and noisy
    (magnetic) environments.
  • AC power is easier and less expensive to supply
    to equipment.
  • AC signals are very common in many existing
    automation devices.

27
PLC Input Circuits
28
Output Modules
  • External power supplies are connected to the
    output card and the card will switch the power on
    or off for each output. Typical output voltages
    are listed below, and roughly ordered by
    popularity.
  • 120 Vac
  • 24 Vdc
  • 12-48 Vac
  • 12-48 Vdc
  • 5Vdc (TTL)
  • 230 Vac

29
PLC Output Circuits
30
24Vdc Output Card (Sinking)
31
24Vdc Output Card With a Voltage Input (Sourcing)
32
Relay Output Card
33
MEMORY TYPES
RAM (Random Access Memory) - this memory is fast,
but it will lose its contents when power is
lost, this is known as volatile memory. Every
PLC uses this memory for the central CPU when
running the PLC. ROM (Read Only Memory) - this
memory is permanent and cannot be erased. It is
often used for storing the operating system for
the PLC. EPROM (Erasable Programmable Read Only
Memory) - this is memory that can be programmed
to behave like ROM, but it can be erased with
ultraviolet light and reprogrammed. EEPROM
(Electronically Erasable Programmable Read Only
Memory) - This memory can store programs like
ROM. It can be programmed and erased using a
voltage, so it is becoming more popular than
EPROMs.
34
MEMORY ADDRESSES
The memory in a PLC is organized by data type as
shown in Figure
35
PROGRAM FILES
  • In a PLC-5 (Allen-Bradley PLCs ) the first three
    program files, from 0 to 2, are defined by
    default
  • File 0 contains system information and should not
    be changed
  • File 1 is reserved for SFCs.
  • File 2 is available for user programs and the PLC
    will run the program in file 2 by default.
  • Other program files can be added from file 3 to
    999. Typical reasons for creating other programs
    are for subroutines.

36
DATA FILES
  • Data files are used for storing different
    information types, as shown in Figure

37
Allen-Bradley Data Types
38
Bit Level Addressing
Memory bits are normally indicated with a forward
slash followed by a bit number /n.
39
Integer Word Addressing
  • Entire words can be addressed as shown in Figure.
  • These values will normally be assumed to be 2s
    compliment, but some functions may assume
    otherwise

40
Literal Data Values
  • Data values do not always need to be stored in
    memory, they can be define literally.
  • Figure shows an example of two different data
    values

41
File Addressing
  • Sometimes we will want to refer to an array of
    values, as shown in Figure.
  • This data type is indicated by beginning the
    number with a pound or hash sign .

42
Indirect Addressing
  • Indirect addressing is a method for allowing a
    variable in a data address, as shown in Figure.
  • The indirect (variable) part of the address is
    shown between brackets and .

43
Expression Data Values
  • Expressions allow addresses and functions to be
    typed in and interpreted when the program is run.
  • The example in Figure will get a floating point
    number from file 8, location 3, perform a sine
    transformation, and then add 1.3.

44
An Example of Ladder Logic Functions
  • The basic operation is such that while input A is
    true the functions will be performed.

45
User Bit Memory
  • The bit memory can be accessed with individual
    bits or with integer words.

46
Status Bits and Words (Allen-Bradley Micrologic )
47
BOOLEAN LOGIC DESIGN
  • Boolean Operations

48
The Basic Axioms of Boolean Algebra
Duality interchange AND and OR operators, as well
as all Universal, and Null sets. The resulting
equation is equivalent to the original.
49
Reverse Engineering of a Digital Circuit
50
KARNAUGH MAPS
51
KARNAUGH MAPS
52
KARNAUGH MAPS
53
Sequential Design Techniques
54
PROCESS SEQUENCE BITS
  • The steps for this design method are
  • Understand the process.
  • Write the steps of operation in sequence and give
    each step a number.
  • For each step assign a bit.
  • Write the ladder logic to turn the bits on/off as
    the process moves through its states.
  • Write the ladder logic to perform machine
    functions for each step.
  • If the process is repetitive, have the last step
    go back to the first.

55
Process Sequence Bits Without Latches
56
TIMING DIAGRAMS
  • Timing diagrams can be valuable when designing
    ladder logic for processes that are only
    dependant on time. The basic method is
  • 1. Understand the process.
  • 2. Identify the outputs that are time dependant.
  • 3. Draw a timing diagram for the outputs.
  • 4. Assign a timer for each time when an output
    turns on or off.
  • 5. Write the ladder logic to examine the timer
    values and turn outputs on or off.

57
TIMING DIAGRAMS
Description A handicap door opener has a button
that will open two doors. When the button is
pushed (momentarily) the first door will start to
open immediately, the second door will start to
open 2 seconds later. The first door power will
stay open for a total of10 seconds, and the
second door power will stay on for 14 seconds.
Use a timing diagram to design the ladder logic.
58
FLOWCHART BASED DESIGN
  • A flowchart is ideal for a process that has
    sequential process steps.
  • The symbols used for flowcharts are

59
FLOWCHART BASED DESIGN
  • The general method for constructing flowcharts
    is
  • 1. Understand the process.
  • 2. Determine the major actions, these are drawn
    as blocks.
  • 3. Determine the sequences of operations, these
    are drawn with arrows.
  • 4. When the sequence may change use decision
    blocks for branching.

60
A Flowchart for a Tank Filler
61
BLOCK LOGIC
  • STEP 1 Add labels to each block in the flowchart

62
BLOCK LOGIC
63
BLOCK LOGIC
64
BLOCK LOGIC
The ladder logic for operation F2 is simple, and
when the start button is pushed, it will turn off
F2 and turn on F3. The ladder logic for
operation F3 opens the inlet valve and moves to
operation F4
65
BLOCK LOGIC
The ladder logic for operation F4 turns off F4,
and if the tank is full it turns on F6, otherwise
F5 is turned on. The ladder logic for operation
F5 is very similar. The ladder logic for
operation F6 turns the outlet valve on and turns
off the inlet valve. It then ends operation F6
and returns to operation F2
66
STATE BASED DESIGN
  • A State based system can be described with system
    states, and the transitions between those states.

67
STATE BASED DESIGN
  • The most essential part of creating state
    diagrams is identifying states. Some key
    questions to ask are

1. Consider the system What does the system
do normally? Does the system behavior
change? Can something change how the system
behaves? Is there a sequence to actions?
2. List modes of operation where the system is
doing one identifiable activity that will
start and stop. Keep in mind that some
activities may just be to wait.
68
STATE BASED DESIGN
  • Consider the design of a coffee vending machine.
  • The first step requires the identification of
    vending machine states as shown in

69
STATE BASED DESIGN
  • STATES
  • idle - the machine has no coins and is doing
    nothing,
  • inserting coins - coins have been entered and
    the total is displayed,
  • user choose - enough money has been entered and
    the user is making coffee selection,
  • make coffee - the selected type is being made,
  • service needed - the machine is out of coffee,
    cups, or another error has occurred.

70
STATE BASED DESIGN
  • The states are then drawn in a state diagram as
    shown in

71
Basic PLC Function Categories
  • Lists
  • - shift registers/stacks
  • - sequencers
  • Program Control
  • - branching/looping
  • - immediate inputs/outputs
  • - fault/interrupt detection
  • Input and Output
  • - PID
  • - communications
  • - high speed counters
  • - ASCII string functions
  • Combinatorial Logic
  • - relay contacts and coils
  • Events
  • - timer instructions
  • - counter instructions
  • Data Handling
  • - moves
  • - mathematics
  • - conversions
  • Numerical Logic
  • - boolean operations
  • - comparisons

72
Move Functions
  • MOV(value, destination) - moves a value to a
    memory location
  • MVM(value, mask, destination) - moves a value to
    a memory location, but with a mask to select
    specific bits.

73
Mathematical Functions
74
Advanced Mathematical Functions
75
Conversions
  • The example function will retrieve a BCD number
    from the D type (BCD) memory and convert it to a
    floating point number that will be stored in
    F82.

76
Statistic Functions
  • When A becomes true the average (AVE) conversion
    will start at memory location F80 and average a
    total of 4 values. The control word R61 is used
    to keep track of the progress of the operation,
    and to determine when the operation is complete.

77
Block Operation Functions
  • A basic block function is shown in Figure 10.13.
    This COP (copy) function will copy an array of 10
    values starting at N750 to N740.

78
Comparison Functions
  • Comparison functions are shown in Figure.
  • The example shows an EQU (equal) function that
    compares two floating point numbers. If the
    numbers are equal, the output bit B35/1 is true,
    otherwise it is false.

79
Boolean Functions
  • The function shown will obtain data words from
    bit memory, perform and operation, and store the
    results in a new location in bit memory. These
    functions are all oriented to word level
    operations. The ability to perform Boolean
    operations allows logical operations on more than
    a single bit.

80
Boolean Function Example
81
Shift Register Functions
82
Shift Register Variations
83
Buffers and Stack Types
Stacks store integer words in a two ended buffer.
There are two basic types of stacks
first-on-first-out (FIFO) and last-in-first-out
(LIFO).
84
The Basic Sequencer Instruction
  • A PLC sequencer uses a list of words in memory.
    It recalls the words one at a time and moves the
    words to another memory location or to outputs.
    When the end of the list is reached the sequencer
    will return to the first word and the process
    begins again.

85
A JMP Instruction
  • These functions allow parts of ladder logic
    programs to be included or excluded from each
    program scan

86
A Fault Recovery Program
87
A Timed Interrupt Program
  • A timed interrupt will run a program at regular
    intervals. To set a timed interrupt the program
    in file number should be put in S231. The
    program will be run every S230times 1
    milliseconds.

88
Immediate I/O Instructions
  • Input, Program and Output Scan

89
Immediate Inputs and Outputs
90
Design techniques
  • This state diagram shows three states with four
    transitions.
  • There is a potential conflict between transitions
    A and C.

91
The Main Program for the State Diagram
92
Subroutines for the States
93
A Modified State Diagram to Prevent Racing
  • Figure shows a technique that blocks race
    conditions by blocking a transition out of a
    state until the transition into a state is
    finished. The solution may not always be
    appropriate.

94
Design cases. If-Then.
  • Problem Convert the following C/Java program to
    ladder logic.

void main() int A for(A 1 A lt 10 A) if
(A gt 5) then A add(A) int add(int x) x
x 1 return x
95
INSTRUCTION LIST PROGRAMMING
  • A simple example is shown in Figure using the
    definitions found in the IEC standard

96
A Structured Text Example Program
  • This program counts from 0 to 10 with a loop.

PROGRAM main VAR i INT END_VAR i
0 REPEAT i i 1 UNTIL i gt
10 END_REPEAT END_PROGRAM
97
FUNCTION BLOCK PROGRAMMING
  • A Simple Comparison Program.
  • In this program the inputs N70 and N71 are used
    to calculate a value sin(N70) ln(N71). The
    result of this calculation is compared to N72.
    If the calculated value is less than N72 then
    the output O000/01 is turned on, otherwise it is
    turned off.

98
Creating function blocks
  • Figure shows a divide function block created
    using ST

99
The IEC 61499 Standard
  • A standardization project of IEC Technical
    Committee 65 (TC65) to standardize the use of
    function blocks in distributed industrial-process
    measurement and control systems (IPMCSs).
  • Work item approved 1991 assigned to Working
    Group 6 (WG6) 1993
  • Experts from USA, Germany, Japan, UK, Sweden,
    France, Italy
  • Also responsible for IEC 61131-3 (Programmable
    Controller Languages) and 61131-8 (Programmable
    Controller Language Guidelines)

100
Function Blocks The Architectural Dialectic
101
Architectural Co-Evolution
  • IEC 61499
  • Parent organization IEC
  • Working group TC65/WG6
  • Goal Standard model (function blocks) for
    control encapsulation distribution
  • Started 10/90
  • Active development 3/92
  • Trial period 2001-03
  • Completion 2005
  • Holonic Manufacturing Systems (HMS)
  • Parent organization IMS
  • Working group HMS Consortium
  • Goal Intelligent manufacturing through holonic
    (autonomous, cooperative) modules
  • Feasibility study 3/93-6/94
  • First phase 2/96 - 6/00
  • Second phase 6/00-6/03

102
Intelligent Systems Requirements ofThe IP
Value-Add Chain
103
Architectural Requirements
  • Component-Based
  • Support encapsulation/protection of Intellectual
    Property (IP)
  • IP Portable across Software Tools and Runtime
    Platforms
  • Distributed
  • Map IP modules into distributed devices
  • Integrate IP Modules into distributed
    applications
  • Functionally Complete
  • Control/Automation/Diagnostics components
  • Machine/Process Interface components
  • Communication Interface components
  • Human/Machine Interface (HMI) components
  • Software Agent ("Holonic") components
  • Extendable
  • Encapsulate new types of IP
  • Create new IP through Functional Composition of
    existing IP modules
  • OPEN!
  • Multiply the value of IP through widest possible
    deployment
  • Benefits available to all market players

104
What is an Open Architecture?
  • An architecture whose functional units are
    capable of exhibiting portability,
    interoperability and configurability
  • portability Software tools can accept and
    correctly interpret library elements produced by
    other software tools.
  • interoperability Devices can operate together to
    perform the functions specified by one or more
    distributed applications.
  • configurability Devices and their software
    components can be configured (selected, assigned
    locations, interconnected and parameterized) by
    multiple software tools.
  • architecture The structure and relationship
    among functional units in a system.
  • functional unit An entity of hardware or
    software, or both, capable of accomplishing a
    specified purpose.

105
Requirements for an Open Distributed Architecture
106
IEC 61131-3 Function BlocksComponent-Based
Encapsulation and Reuse
107
IEC 61499 Basic Function Block TypesEncapsulatio
n and Reuse
108
The Execution Control Chart (ECC)An
Event-Driven State Machine
109
Functional Composition and ReuseIEC 61499
Composite Function Block Types
110
IEC 61499 Service Interface Function Blocks
  • Access to Resource functionality, e.g., I/O, HMI,
    comms
  • Modeled as sequences of service primitives per
    ISO TR 8509

111
IEC 61499 Communication Service
InterfacesPublish/Subscribe Model
112
IEC 61499 Communication Service
InterfacesClient/Server Model
113
IEC 61499 Distributed System Architecture
114
IEC 61499 Device Architecture
115
IEC 61499 Resource Architecture
  • Resource schedules executes FB algorithms
  • Resource maps Communications Process I/O
    Functions to Service Interface Function Blocks

116
Standard Event Processing Function Blocks
  • E_SPLIT/E_MERGE/E_REND - Event split, merge,
    rendezvous
  • E_PERMIT - Permissive event propagation
  • E_SELECT - 1 of 2 (boolean) event selection
  • E_SWITCH - 1 of 2 (boolean) event demultiplexing
  • E_DELAY - Event delay (timer)
  • E_CYCLE - Periodic event generation
  • E_RESTART - Generation of COLD/WARM restart, STOP
    events
  • E_TRAIN/E_TABLE/E_N_TABLE - Finite trains of
    events
  • E_SR/E_RS/E_D_FF - Event-driven bistables
  • E_R_TRIG/E_F_TRIG - Event-driven rising/falling
    edge detection
  • E_SR/E_RS/E_D_FF - Event-driven bistables
  • E_CTU - Event-driven up-counter
  • See IEC 61499-1, Annex A

117
Conversion of IEC 61311-3 Function Blocks to 61499
118
IEC 61499 Device Management Architecture
  • Separation of Concerns
  • Software Tools vs. Runtime Device
  • Communication Services vs. Management Services

119
Dynamic Configuration in IEC 61499 The Device
Management Service Interface
120
The IEC 61499 System Management Model
121
IEC 61499 Software Tool Models
122
IEC 61499-2 Software Tool Requirements
  • Exchange of library elements
  • Information to be provided by the supplier of
    library elements
  • Display of declarations
  • Modification of declarations
  • Validation of declarations
  • Implementation of declarations
  • System operation, testing and maintenance

123
Open Distributed Systems The IEC 61499 Solution
124
Methodology for Distributed Applications
  • 1. Obtain or develop a library of function block,
    resource and device types.
  • 2. Define and develop the application.
  • 3. Map function block instances from the
    application to distributed resources.
  • 4. Configure devices and resources.
  • 5. Configure communication connections, using
    communication service interface function blocks
    to implement the event connections and data
    connections of the application across resource
    boundaries

125
Application Example Orange Sorter
126
Distributed Orange Sorter Application
127
Using Libraries
Example process/PIDD_TANK
128
A Centralized Application
129
Mapping to Distributed Devices
130
Configuring Devices (1) - Setting Parameters
131
Configuring Devices (2) - Editing Resources
132
Running the Distributed Configuration
133
Pattern Local Multicast
134
Pattern Layered MVC (Model/View/Controller)
135
Realization Simulation gt Physical Interface
136
Elements of the Engineering Architecture
137
Engineering Methodology
  • 1. Sketch describe the problem to be solved.
  • 2. Develop test Views.
  • 3. Animate the desired operational sequences.
  • 4. Develop test Models.
  • 5. Develop test Controllers.
  • 6. Develop test Diagnostic fault recovery
    elements.
  • 7. Perform distribution design.
  • 8. Integrate to physical components and systems.

138
An Example
139
View Development Framework
140
Model Development Framework
141
Controller Development Framework
142
Low-Level Diagnostics
143
Distribution Design
144
Physical Design
145
Pattern Mechatronic
About PowerShow.com
