Exercise Physiology

1
Exercise Physiology

• J.M. Cairo, Ph.D.
• LSU Health Sciences Center
• New Orleans, Louisiana
• jcairo_at_lsuhsc.edu

2
Somatic Factors Sex and Age Body Dimension Health
Psychic Factors Attitude Motivation
Training Adaptation

• Bioenergetics
• Storage Fuels
• Fuel Intake
• Oxygen Uptake
• Cardiac Output
• Heart Rate
• Stroke Volume
• (A-V)O2 Difference
• Pulmonary Ventilation

Environment Temperature Altitude Inhaled Gases
Nature of Work Intensity Duration Rhythm Technique
Position
Energy Yielding Processes
From Astrand and Rodahl, Textbook of Work
Physiology, New York McGraw-Hill, 1972
Physical Performance Capacity
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
From Richardson, DR, Randall, DC, Speck, DF
Cardiopulmonary System. Madison, CT, Fence
Creek, 1998
9
From Wasserman, K., Hansen, J.E., Sue, D.Y.,
Casaburi, R, and Whipp, B.J. Principles of
Exercise Testing and Interpretation, 3rd Edition.
Philadelphia, Lippincott Williams and Wilkins,
1999.
10
The Fick Principle

• VO2 Q x (CaO2 - CvO2)

11
(No Transcript)
12
RESTING CONDITIONS FOR A TYPICAL HEALTHY ADULT
VO2 250 ml/min Q 5
L/min CaO2 200 ml/L of whole
blood CvO2 150 ml/L of whole
blood CaO2-CvO2 50 ml/L of whole blood
13
MAXIMUM EXERCISE RESPONSE FOR A WORLD CLASS
ATHLETE
VO2 5000 ml/min Q 25
L/min CaO2 200 ml/L of whole
blood CvO2 20 ml/L of whole blood CaO2-CvO2
180 ml/L of whole blood
14
(No Transcript)
15
(No Transcript)
16
Cardiac Output


Heart Rate
Stroke Volume


Preload
Contractility
-
Afterload
17
(No Transcript)
18
(No Transcript)
19
HRMAX 220 - age (yrs)
20
(No Transcript)
21
(No Transcript)
22
PRELOAD
Volume of blood in the ventricle at the end of
diastole LVEDV
Venous Return
23
Frank-Starling Mechanism
Stroke Volume
LVEDV
24
PRELOAD
Volume of blood in the ventricle at the end of
diastole LVEDV
Venous Return
Skeletal Muscle Pump
Venous Tone
Thoraco-abdominal Pump
25
Contractility
Stroke Volume
LVEDV
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Factors influencing the Pulmonary Response to
Exercise

• Ventilation
• Diffusion of Oxygen and Carbon Dioxide Across the
  Alveolar-Capillary Membrane
• Perfusion
• Ventilation/Perfusion
• O2 and CO2 Transport
• O2 uptake by the tissues

34
(No Transcript)
35
Control of Breathing During Exercise

• Immediate Response
• Neural Component
• Central Command
• Learned Response
• Direct Connection from Motor Cortex
• Coordination in Hypothalamus
• Proprioceptors or Mechanoreceptors

From Levitzky, MG Pulmonary Physiology, 5th
Edition. New York, McGraw-Hill, 1999
36
Control of Breathing During Exercise

• Response to Moderate Exercise
• Arterial Chemoreceptors
• Metaboreceptors
• Nociceptors
• Cardiac Receptors
• Venous Chemoreceptors
• Temperature Receptors

• Response to Severe Exercise
• Arterial Chemoreceptors
• Central Chemoreceptors

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
Factors Influencing the Maintenance of the
Arterial Oxygen Content (CaO2)

• Increase in Alveolar Ventilation
• Decrease in VD/VT
• Increased Perfusion of the Lungs
• Decrease in Pulmonary Vascular Resistance
• Recruitment and Distension of Pulmonary
  Capillaries
• Improvement in VA/QC
• Increased Diffusion of O2 and CO2 across the
  Alveolar-Capillary Membrane

41
Effective Ventilation VD/VT
0.40
VD/VT
0.25
Rest
Max
42
Factors Influencing Unloading/Uptake of Oxygen at
the Tissues (?CvO2)

• Shifting of the Oxyhemoglobin Dissociation Curve
  to the Right
• Increase in Core Temperature
• Increase in CO2 Production
• Increase in H

43
Somatic Factors Sex and Age Body Dimension Health
Psychic Factors Attitude Motivation
Training Adaptation

• Bioenergetics
• Storage Fuels
• Fuel Intake
• Oxygen Uptake
• Cardiac Output
• Heart Rate
• Stroke Volume
• (A-V)O2 Difference
• Pulmonary Ventilation

Environment Temperature Altitude Inhaled Gases
Nature of Work Intensity Duration Rhythm Technique
Position
Energy Yielding Processes
Physical Performance Capacity
44
MAXIMUM EXERCISE RESPONSE FOR A WORLD CLASS
ATHLETE
VO2 5000 ml/min Q 25
L/min CaO2 200 ml/L of whole
blood CvO2 20 ml/L of whole blood CaO2-CvO2
180 ml/L of whole blood
45
MAXIMUM EXERCISE RESULTS FOR A TYPICAL HEALTHY
ADULT
VO2 2500 ml/min Q 15 L/min CaO2 200
ml/L of whole blood CvO2 33 ml/L of whole
blood CaO2-CvO2 167 ml/L whole blood
46
Principles of Physical Training

• Overload
• Specificity
• Reversibility

47
Training for Improved Aerobic Endurance

• Type of Exercise
• Intensity
• Duration
• Frequency

48
Anaerobic Threshold

• The anaerobic threshold is defined as the level
  of exercise VO2 above which aerobic energy is
  supplemented by anaerobic mechanisms and is
  reflected by an increase in lactate and
  lactate/pyruvate ratio in skeletal muscle and
  arterial blood.
• See Wasserman, K., Hansen, J.E., Sue, D.Y.,
  Casaburi, R, and Whipp, B.J. Principles of
  ExerciseTesting and Interpretation, 3rd Edition.
  Philadelphia, Lippincott Williams and Wilkins,
  1999.

49
(No Transcript)
50
Karvonen Formula for Prescribing Exercise Heart
Rate

• HREx HRRest 0.60 (HRMax HRRest)

51
Detraining and VO2 MAX

• Decreased maximum attainable cardiac output and
  arteriovenous O2 difference
• Initial (12-14 days)
• Decrease due to decreased stroke volume
• Decreased plasma volume
• Prolonged (3 weeks 12 weeks)
• Attenuation of arteriovenous O2 difference
  changes
• Decreased muscle mitochondrial density

52
Effects of Endurance Training on Skeletal Muscle
Morphology

• Capillary Density
• Myoglobin
• Mitochondria

53
Effects of Endurance Training on Skeletal Muscle
Metabolism

• Mobilization of FFA
• Transport of FFA from Cytoplasm to the
  Mitochondria
• Mitochondrial Oxidation of FFA
• Beta-oxidation
• Lactate Removal

54
(No Transcript)
55
(No Transcript)
56
Effect of Conditioning on Heart Rate Response
57
(No Transcript)
58
(No Transcript)
59
Effects of Chronic Physical Activity on Aerobic
Function
Resting Values Effect
Oxygen Consumption Unchanged
Heart Rate Decreased
Systolic Blood Pressure Unchanged-Decreased
Diastolic Blood Pressure Unchanged-Decreased
Rate-Pressure Product Decreased
60
Effects of Chronic Physical Activity on Aerobic
Function
Submaximal Values Effect Effect
Oxygen Consumption Oxygen Consumption Unchanged-Decreased
Cardiac Output Cardiac Output Unchanged
Heart Rate Heart Rate Decreased
Stroke Volume Stroke Volume Increased
Systolic Blood Pressure Systolic Blood Pressure Decreased
Rate-Pressure Product Rate-Pressure Product Decreased
Minute Ventilation Minute Ventilation Decreased
61
Effects of Chronic Physical Activity on Aerobic
Function
Maximal Values Effect
Oxygen Consumption Increased
Cardiac Output Increased
Heart Rate Unchanged-Decreased
Stroke Volume Increased
Arteriovenous O2 Difference Increased
Systolic Blood Pressure Unchanged
Rate-Pressure Product Unchanged
Ejection Fraction Increased
62
(No Transcript)
63
(No Transcript)
64
Exercise Testing Strategies

• Incremental versus steady state tests
• Modes of exercise
• Treadmills
• Bruce versus Balke Protocol
• Cycles
• Ramp Protocol

65
Noninvasive Measurements

• Respiratory
• Vt
• Fb
• VE
• FIO2
• FEO2
• FECO2
• Pulse oximetry
• PtcO2, PtcCO2

66
Noninvasive Measurements

• Cardiovascular
• Heart rate
• Arterial blood pressure
• Electrocardiogram
• Modified chest leads
• 12 lead ECG

67
Normal ECG Changes During Exercise

• P wave increases in height
• R wave decreases in height
• J point becomes depressed
• ST segment becomes sharply up sloping
• QT interval shortens
• T wave decreases in height

68
(No Transcript)
69
Reasons for Stopping a Test

• ECG criteria
• Severe ST segment depression (gt3 mm)
• ST segment elevation (gt1 mm in non-Q wave lead)
• Frequent ventricular extrasystole
• Onset of ventricular tachycardia
• New atrial fibrillation or supraventricular
  tachycardia
• Development of new bundle branch block (if the
  test is primarily to detect underlying coronary
  disease)
• New second or third degree heart block

70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
Invasive Measurements

• Arterial blood gases
• pHa, PaCO2, PaO2
• Blood lactate levels
• Pulmonary artery catheterization
• Pulmonary vascular pressures (PA, PAWP)
• Mixed venous blood gases (pHv, PvCO2, PvO2)

74
Derived Variables

• Peak VO2 versus VO2Max
• Respiratory
• VD/VT
• VD/VT PaCO2- PECO2/PaCO2
• P(A-a)O2
• P(a-et)CO2
• Breathing reserve
• Breathing reserve MVV VE max

75
Derived Variables

• Cardiovascular
• Heart rate reserve
• HR reserve HRmax (predicted) HRmax (achieved)
• O2 pulse
• O2 pulse VO2/HR SV X (CaO2-CvO2)

76
Reasons for Stopping a Test

• Symptoms and signs
• Patient requests stopping because of severe
  fatigue
• Severe chest pain, dyspnea, or dizziness
• Fall in systolic blood pressure (gt20 mmHg)
• Rise in blood pressure (gt300 mmHg, diastolic gt
  130 mmHg)
• Ataxia

77
Case 20020240

• Resting Data
• Age 75 yrs
• Sex Male
• VC 3.5L (100)
• IC 2.3L (102)
• TLC 6.0L (110)
• FEV1 3.90L (95)
• FEV1/VC 80
• MVV 100L
• Hct 44

• Exercise Data
• VO2 (Peak) 1.75L (100)
• HRMAX 140 bpm
• SBP 155/84 180/75
• VEMAX 70L/min
• VD/VT 0.35 0.25
• P(A-a)O2 20 torr
• ?AT 1.4L

Patient stopped exercise due to dyspnea
78
Case 20000512

• Exercise Data
• VO2 (Peak) 1.55L(58)
• HRMAX 168 bpm
• SBP 150/92 205/120
• VEMAX 48L
• VD/VT 0.40 0.30
• P(A-a)O2 20 torr
• ?AT 1.30L

• Resting Data
• Age 48 yrs
• Sex Male
• VC 4.75L (93)
• IC 3.94L (95)
• TLC 5.90L (98)
• FEV1 3.90L (93)
• FEV1/VC 80
• MVV 90L

Patient stopped exercise due to angina and
presence of multiple PVBs
79
Findings Suggesting High Probability of Coronary
Artery Disease

• ST segment depression 2 mm
• Downsloping ST segment depression
• Early positive response within 6 minutes
• Persistence of ST depression for more than 6
  minutes into recovery
• ST segment depression in 5 or more leads
• Exertional hypotension

80
(No Transcript)
81
(No Transcript)
82
Case 20011120

• Resting Data
• Age 60 yrs
• Sex Male
• VC 3.75L (80)
• IC 2.75L (70)
• TLC 6.53L (130)
• FEV1 2.80L (65)
• FEV1/VC 60
• MVV 65L

• Exercise Data
• VO2 (Peak) 1.75L (68)
• HRMAX 128 bpm
• SBP 135/88 200/110
• VEMAX 60L/min
• VD/VT 0.40 0.38
• P(A-a)O2 45 torr
• ?AT 1.10L

Patient stopped exercise due to extreme dyspnea
83
Case 20011452

• Resting Data
• Age 70 yrs
• Sex Male
• VC 3.65L (78)
• IC 2.28L (72)
• TLC 6.03L (81)
• FEV1 2.20L (6)
• FEV1/VC 60
• MVV 95L
• DLCO 10.8 (35)

• Exercise Data
• VO2 (Peak) 1.32L (65)
• HRMAX 152 bpm
• SBP 175/86 227/90
• VEMAX 90L/min
• VD/VT 0.45 0.48
• P(A-a)O2 45/68 torr
• PaO2 64/52 torr
• ?AT 0.95L

Patient stopped exercise due to extreme dyspnea
84
Case 2001367

• Resting Data
• Age 60 yrs
• Sex Male
• VC 1.75L (40)
• IC 1.55L (42)
• TLC 8.03L (120)
• FEV1 0.54L (15)
• FEV1/VC 30
• MVV 35L
• DLCO 19 (59)

• Exercise Data
• VO2 (Peak) 1.75L (68)
• HRMAX 128 bpm
• SBP 135/88 200/110
• VEMAX 60L/min
• VD/VT 0.40 0.38
• P(A-a)O2 45 torr
• ?AT 1.10L

Patient stopped exercise due to extreme dyspnea
85
Temperature Regulation
86
Definitions

• Core Temperature
• Measured as oral, aural, or rectal temperature
• Temperature of deep tissues of the body
• Remains relatively constant (?1ºF or ?0.6ºC)
  unless a person develops a febrile condition
• Nude person can maintain core temperature even
  when exposed to temperatures as low as 55ºF or as
  high as 130ºF in dry air
• Skin Temperature
• Rises and falls with the temperature of the
  surroundings

87
(No Transcript)
88
(No Transcript)
89
REGULATION OF BODY TEMPERATURE
90
Heat Production

• Laws of Thermodynamics
• Heat is a by-product of metabolism
• Basal metabolic rate of all cells of the body
• Effect of muscular activity on metabolic rate
• Effect of endocrinology on metabolic rate (i.e.,
  thyroxin, growth hormone, testosterone)
• Effect of autonomic nervous system on metabolic
  rate

91
Heat Loss

• How fast is heat transferred from deep tissues to
  the skin
• How rapidly is heat transferred from the skin to
  the surrounding environment

92
How Fast Is Heat Transferred From Deep Tissues to
Skin

• Insulation Systems
• Skin and subcutaneous tissue (i.e., fat)
• Blood Flow
• Cutaneous circulation

93
(No Transcript)
94
(No Transcript)
95
How Fast Is Heat Loss From the Skin to the
Surrounding Environment

• Radiation
• Conduction
• Evaporation

96
Definitions

• Radiation
• Loss of heat by infrared heat rays (5-20?m or
  10-20X wavelength of visible light)
• Conduction
• Loss of heat from the body to a solid object
• Evaporation
• Loss of heat from the body through water vapor to
  the surrounding atmosphere
• Convection
• Effects of changes in the external environment
  (e.g., wind and water)

97
(No Transcript)
98
Wind Chill Factor

• Effect of wind on skin temperature temperature
  of calm air that would produce equivalent cooling
  of exposed skin
• Cooling effect of air convection equals the
  square root of the wind velocity
• For example, air temperature feels twice as cold
  at a wind velocity of 4 mph than if the wind
  velocity is 1 mph

99
ºF 35.74 0.6215T - 35.75V(100.16)
0.4275V(100.16)
100
(No Transcript)
101
(No Transcript)
102
Regulation of Body Temperature Role of the
Hypothalamus

• Anterior Hypothalamus Preoptic Area
• Heat-sensitive neurons
• Demonstrate a 10-fold increase in firing rate
  when there is a 10C increase in body temperature
  resulting in profuse sweating and cutaneous
  vasodilation
• Cold-sensitive neurons
• Increase in firing rate to a decrease in body
  temperature resulting in cutaneous
  vasoconstriction and inhibition of sweat
  production

103
Temperature RegulationSkin and Deep Tissue
Receptors

• Although the skin contains both cold and warmth
  sensory receptors, there are far more cold
  receptors than warmth receptors (10 times more
  cold than warmth)
• Stimulation of these cold receptors will result
  in shivering, inhibition of sweating, and
  promotion of cutaneous vasoconstriction

104
Temperature RegulationSkin and Deep Tissue
Receptors

• Deep tissue receptors are found in spinal cord,
  in the abdominal viscera, and in the great veins
  in the upper abdomen and thorax
• Although these receptors are exposed to core body
  temperature rather than skin temperature, they
  function like the skin receptors in that they are
  concerned with preventing hypothermia

105
Hormonal Control of Temperature

• Chemical Thermogenesis
• Ability of norepinephrine and epinephrine to
  uncouple oxidative phosphorylation
• Brown fat
• Thyrotropin-releasing hormone ?
  Thyroid-stimulating hormone ? Thyroxine
• Stimulated by cooling of the anterior
  hypothalamic-preoptic area
• Requires several weeks of exposure to cold to
  cause hypertrophy of the thyroid gland

106
(No Transcript)
107
(No Transcript)
108
Abnormalities of Body Temperature Regulation

• Fever
• Effect of pyrogens
• Brain lesions
• Heatstroke
• Frostbite
• Malignant Hyperthermia
