Title: TinyOS


1
TinyOS
  • Disclaimer
  • Information included in this slides came from
    multiple sources. We have tried our best to cite
    the sources. Please refer to the Table of
    References slide (2) to learn about the sources,
    when applicable.
  • The slides should be used only for academic
    purposes (e.g., in teaching a class) and should
    not be used for commercial purposes.

2
Table of References
Slides Source
5 http//en.wikipedia.org/wiki/TinyOS
6 www.cs.virginia.edu/cl7v/cs851-talks/tinyos_chenyang.ppt
7-13 www.telematica.polito.it/wsn/ppt/WSN2_TinyOS.pdf
15-17 http//www.pages.drexel.edu/kws23/tutorials/motes/motes.html
18-29 http//www.cmi.ac.in/sdatta/SE/doc/tutorial/lesson1.html http//www.tinyos.net/dist-2.0.0/tinyos-2.x/doc/html/tutorial/lesson1.html
3
Agenda
  • Why was TinyOS needed?
  • Introduction to TinyOS
  • Goals/Objectives behind TinyOS
  • Requirements of WSN for Operating System
  • TinyOS as a Solution
  • TinyOS Model
  • Data Model
  • Thread Model
  • Programming Model
  • Component Model
  • Network Model
  • Example Application

4
Need of TinyOS
  • Problems with traditional OS
  • Multithreaded Architecture not useful
  • Large Memory Footprint
  • Does not help to conserve energy and power
  • Requirements for Wireless Sensor Networks
  • Efficient utilization of energy and power
  • Small Footprint
  • Should support diversity in design and usage
  • More emphasis on Concurrent execution

5
Introduction to TinyOS
  • TinyOS began as a collaboration between
    University of California, Berkeley and Intel
    Research.4
  • It is a free open source operating system
    designed for wireless sensor networks.
  • It is an embedded operating system written in
    NesC
  • It features a component based architecture.

6
TinyOS as a Solution
  • Component based architecture allows frequent
    changes while still keeping the size of code
    minimum.
  • Event based execution model means no user/kernel
    boundary and hence supports high concurrency.
  • It is power efficient as it makes the sensors
    sleep as soon as possible.
  • Has small footprint as it uses a non-preemtable
    FIFO task scheduling.

7
TinyOS Models
  • TinyOS models-
  • Data Model
  • Thread Model
  • Programming Model
  • Component Model
  • Network Model

8
Data Memory Model
  • Static Memory Allocation
  • No Heaps or any other dynamic
  • structures used.
  • Memory requirements determined
  • at compile time.
  • This increases the runtime efficiency.
  • Global variables
  • Allocated on per frame basis.
  • Local Variables
  • Saved on the stack
  • Defined in the function/method

9
Thread Model
  • Power-Aware Two-levels Scheduling
  • Long running tasks and interrupt events
  • Sleep unless tasks in queue, wakeup on event
  • Tasks
  • Time-flexible, background jobs
  • Atomic with respect to other tasks
  • Can be preempted by events
  • Events
  • Time-critical, shorter duration
  • Last-in first-out semantic (no priority)
  • Can post tasks for deferred execution

10
Programming Model
  • Separation construction/composition
  • Construction of Modules
  • Modules implementation similar to C coding
  • Programs are built out of components
  • Each component specifies an interface
  • Interfaces are hooks for wiring components
  • Composition of Configurations
  • Components are statically wired together
  • Increases programming efficiency (code reuse) an
    runtime efficiency (static defs.)

11
Component Model
  • Components should use and provide bidirectional
    interfaces.
  • Components should call and implement commands
    and signal and handle events.
  • Components must handle events of used interfaces
    and also provide interfaces that must implement
    commands.

12
Component Model Hierarchy
  • Commands
  • Flow downwards
  • Non Blocking requests
  • Control returns to caller
  • Events
  • Flow upwards
  • Post task, signal higher level events, call lower
    level cmds
  • Control returns to signaler
  • To avoid cycles
  • Events can call commands
  • Commands can NOT signal events

13
Network Model
14
nesC
  • nesC (network embedded system C) is a language
    used to build applications in TinyOS.
  • It is designed such a way to exhibit the concepts
    and execution model of TinyOS.
  • Refer the tutorial given below to see a simple
    program in nesC.
  • http//docs.tinyos.net/index.php/The_simplest_Tin
    yOS_program

15
Example application
  • In the diagram on next slide the module BC.nc
    provides the interface Bint.
  • The implementation for the module defines a
    command Bint.Bcmnd and an event Bint.Bevnt.
  • To access command Bint.Bcmnd in the declaration
    of our module we would say it uses the interface
    Bint.
  • A.nc is the configuration file which wires the
    interface of module AM.nc to the interface of
    module BC.nc

16
Refhttp//www.pages.drexel.edu/kws23/tutorials/m
otes/motes.html
17
Continued..
  • Module AM.nc has access to all of the commands
    provided by BC.nc
  • The implementation might also contain a task
    where it uses the command from C.nc
  • Also the fundamental rule of nesC states that
    any module that uses a command from another
    module must address all of the events provided by
    the other module.
  • Therefore AM.nc must also contain code to address
    the event Bint.Bevnt.

18
Example Application - Blink
  • Blink.nc
  • configuration Blink
  • implementation   components Main, BlinkM,
    SingleTimer, LedsC   Main.StdControl -gt
    BlinkM.StdControl   Main.StdControl -gt
    SingleTimer.StdControl   BlinkM.Timer -gt
    SingleTimer.Timer   BlinkM.Leds -gt LedsC
  • NotePlease refer to the tutorial on the
    TinyOS website to get more information

19
Blink.nc Module
  • In the Blink.nc file you can see it consists of
    the configuration Blink.
  • A configuration can have uses and provides
    clauses.
  • The real configuration is written in
    implementation section and the components line
    specifies the components it references i.e. in
    this case Main, BlinkM, SingleTimer, and LedsC.

20
Blink.nc Module..Continued
  • Main is a component that is executed first in a
    TinyOS application.
  • Main.StdControl.init() command is the first
    command executed in TinyOS followed by
    Main.StdControl.start().
  • Therefore, a TinyOS application must have Main
    component in its configuration.
  • StdControl is a common interface used to
    initialize and start TinyOS components.

21
Std Control module
  • StdControl.nc
  • interface StdControl
  •   command result_t init()   command result_t
    start()   command result_t stop()

22
Std Control module
  • We see that StdControl defines three commands
  • init()-called when component is first
    initialized
  • start()-when it is executed for first time
  • stop()-when the device is powered off
  • The following 2 lines in Blink configuration
  • Main.StdControl -gt SingleTimer.StdControl
    Main.StdControl -gt BlinkM.StdControl
  • wire the StdControl interface in Main to the
    StdControl interface in both BlinkM and
    SingleTimer.

23
Std Control module
  • SingleTimer.StdControl.init() and
    BlinkM.StdControl.init() will be called by
    Main.StdControl.init() and in same way for the
    start() and stop() commands.
  • The BlinkM module uses the interface Leds, so
    Leds.init() is called explicitly in
    BlinkM.init().
  • -gt binds an interface on left to an
    implementation on right.
  • For e.g.
  •   BlinkM.Timer -gt SingleTimer.Timer
  • is used to wire the Timer interface used by
    BlinkM to the Timer interface provided by
    SingleTimer.

24
BlinkM module
  • BlinkM.nc
  • module BlinkM
  •   provides     interface StdControl
    uses     interface Timer     interface Leds

25
BlinkM module
  • The BlinkM module provides the interface
    StdControl also therefore BlinkM implements
    StdControl interface.
  • The BlinkM module also uses two interfaces Leds
    and Timer
  • The Leds interface defines several commands like
    redOn(),redOff(), and so forth, which turn the
    different LEDs ON and OFF.

26
BlinkM module continued..
  • BlinkM.nc Continued..
  • implementation   command result_t
    StdControl.init()     call Leds.init()
    return SUCCESS     command result_t
    StdControl.start()     return call
    Timer.start(TIMER_REPEAT, 1000)     command
    result_t StdControl.stop()     return call
    Timer.stop()     event result_t
    Timer.fired()       call Leds.redToggle()
    return SUCCESS

27
BlinkM module
  • BlinkM module implements the StdControl.init(),
    StdControl.start(), and StdControl.stop()
    commands, since it provides the StdControl
    interface.
  • The init() command in the implemented StdControl
    interface simply initializes the Leds
    subcomponent with the call to Leds.init().
  • The start() command invokes Timer.start() to
    create a repeat timer that expires every 1000 ms.
    stop() terminates the timer.
  • Each time Timer.fired() event is triggered, the
    Leds.redToggle() toggles the red LED.

28
Timer module
  • Timer.nc
  • interface Timer   command result_t start(char
    type, uint32_t interval)   command result_t
    stop()   event result_t fired()

29
Timer module
  • Timer interface defines the start() and stop()
    commands, and the fired() event.
  • The start() command is used to specify the type
    of the timer and the interval at which the timer
    will expire.
  • An event function i.e. in this case fired() will
    signal when specified interval of time is passed.
  • Such a interface is also known as a bidirectional
    interface as it provides commands that can be
    called by users of the interface and also signals
    events that call handlers in the user

30
References
  • http//docs.tinyos.net/index.php/TinyOS_Tutorials
  • http//csl.stanford.edu/pal/pubs/tinyos-programmi
    ng.pdf
  • http//www.tinyos.net/
  • http//en.wikipedia.org/wiki/TinyOS
  • http//www.princeton.edu/wolf/EECS579/imotes/tos_
    tutorial.pdf
  • http//www.pages.drexel.edu/kws23/tutorials/motes
    /motes.html
  • http//www.cmi.ac.in/sdatta/SE/doc/tutorial/lesso
    n1.html
