Photosynthesis: Life from Light and Air

1
Photosynthesis Life from Light and Air
2
Plants are energy producers

• Like animals, plants need energy to live
• unlike animals, plants dont need to eat food to
  make that energy
• Plants make both FOOD ENERGY
• animals are consumers
• plants are producers

3
How do plants make energy food?

• Plants use the energy from the sun
• to make ATP energy
• to make sugars
• glucose, sucrose, cellulose, starch, more

sun
ATP
sugars
4
Building plants from sunlight air
sun

• Photosynthesis
• 2 separate processes
• ENERGY building reactions
• collect sun energy
• use it to make ATP
• SUGAR building reactions
• take the ATP energy
• collect CO2 from air H2O from ground
• use all to build sugars

ATP

sugars
carbon dioxide CO2
sugars C6H12O6
water H2O

5
Using light air to grow plants

• Photosynthesis
• using suns energy to make ATP
• using CO2 water to make sugar
• in chloroplasts
• allows plants to grow
• makes a waste product
• oxygen (O2)

6
What do plants need to grow?

• The factory for making energy sugars
• chloroplast
• Fuels
• sunlight
• carbon dioxide
• water
• The Helpers
• enzymes

Make ATP!Make sugar!I can do it allAnd no
oneeven notices!
sun
ATP
enzymes
7
Photosynthesis
sun
ENERGYbuilding reactions
ATP
ADP
SUGARbuilding reactions
used immediatelyto synthesize sugars
sugar
8
Chloroplasts are only in plants
animal cells
plant cells
9
Chloroplasts
absorbsunlight CO2
Leaf
sun
Leaves
Chloroplastsin cell
Chloroplast
Chloroplast
Chloroplasts contain Chlorophyll
makeENERGY SUGAR
10
So what does a plant need?

• Bring In
• light
• CO2
• H2O
• Let Out
• O2
• Move Around
• sugars

leaves
shoot
roots
11
Leaf Structure
12
Transpiration
O2
H2O
CO2

• CO2 in
• O2 out
• water out
• so it gets to leaves from roots

H2O
CO2
O2
13
Transpiration

• Water evaporates from the stomates in the leaves
• pulls water up from roots
• water molecules stick to each other
• more water is pulled up tree from ground

14
Function of Leaf Structures

• Cuticle
• waxy coating reduces water loss
• Epidermis
• skin protecting leaf tissues
• Palisades layer
• high concentration of chloroplasts
• collecting suns energy
• photosynthesis
• making ATP sugars
• Spongy layer
• air spaces
• gas exchange
• CO2 in for sugar production, remove waste O2

15
Do Now

• What is the equation for photosynthesis?
• Check answers to Tuesday nights homework
• 1. 4 2. 2 3. 4 4. 3 5. 2 6. 2 7. 4
• 8. Two raw materials necessary for photosynthesis
  are carbon dioxide and water. These two molecules
  are broken apart and rearranged to produce
  glucose and oxygen molecules

16
Stomates Guard Cells

• Function of stomates
• CO2 in
• O2 out
• H2O out
• gets to leaves for photosynthesis
• Function of guard cells
• open close stomates

guard cell
stomate
17
Guard cells Homeostasis

• Homeostasis
• keeping the internal environment of the plant
  balanced
• Stomates open
• let CO2 in
• needed to make sugars
• let H2O out
• needed for photosynthesis
• let O2 out
• get rid of waste product
• Stomates close
• if too much H2O evaporating

18
Xylem
carry water up from roots
19
Phloem food-conducting cells

• carry sugars around the plant wherever they are
  needed
• new leaves
• fruit seeds
• roots

20
How are they connected?
Respiration
Photosynthesis
21
Energy cycle
Photosynthesis
plants
CO2
O2
animals, plants
Cellular Respiration
ATP
The Great Circleof Life! Mufasa?
22
Another view
capturelight energy
Photosynthesis
synthesis
producers, autotrophs
CO2
O2
organicmoleculesfood
waste
waste
waste
consumers, heterotrophs
digestion
Cellular Respiration
ATP
releasechemical energy
