Title: Formal Program Specification


1
Formal Program Specification
Software Testing and Verification Lecture 16
  • Prepared by
  • Stephen M. Thebaut, Ph.D.
  • University of Florida

2
Overview
  • Review of Basics
  • Propositions, propositional logic, predicates,
    predicate calculus
  • Sets, Relations, and Functions
  • Specification via pre- and post-conditions
  • Specifications via functions

3
  • Propositions, Propositional Logic, Predicates,
    and the Predicate Calculus

4
Propositions and Propositional Logic
  • A proposition, P, is a statement of some alleged
    fact which must be either true or false, and not
    both.
  • Which of the following are propositions?
  • elephants are mammals
  • France is in Asia
  • go away
  • 5 gt 4
  • X gt 5

5
Propositions and Propositional Logic (contd)
  • Propositional Logic is a formal language that
    allows us to reason about propositions. The
    alphabet of this language is
  • P, Q, R, ?, V, ?, ?,
  • where P, Q, R, are propositions, and the
    other symbols, usually referred to as
    connectives, provide ways in which compound
    propositions can be built from simpler ones.

6
Truth Tables
  • Truth tables provide a concise way of giving the
    meaning of compound forms in a tabular form.
  • Example construct a truth table to show all
    possible interpretation for the following
    sentences
  • A V B, A ? B, and A ? B

7
Example
A B A V B A ? B A ? B
T T
T F
F T
F F
8
Equivalence
  • Two sentences are said to be equivalent if and
    only if their truth values are the same under
    every interpretation.
  • If A is equivalent to B, we write A ? B.
  • Exercise Use a truth table to show
  • (P ? Q) ? (Q V P)

9
Equivalence (contd)
  • Many users of logic slip into the habit of using
    ? and ? interchangeably.
  • However, A?B is written down in the full
    knowledge that it may denote either true or false
    in some interpretation, whereas A?B is an
    expression of fact (i.e., the writer thinks it is
    true).

How would you write A ? B as an expression of
fact?
10
Predicates
  • Predicates are expressions containing one or more
    free variables (place holders) that can be filled
    by suitable objects to create propositions.
  • For example, instantiating the value 2 for X in
    the predicate Xgt5 results in the (false)
    proposition 2gt5.

11
Predicates (contd)
  • In general, a predicate itself has no truth
    value it expresses a property or relation using
    variables.

12
Predicates (contd)
  • Two ways in which predicates can give rise to
    propositions
  • As illustrated above, their free variables may be
    instantiated with the names of specific objects,
    and
  • They may be quantified. Quantification introduces
    two additional symbols
  • ? and ?

13
Predicates (contd)
  • ? and ? are used to represent universal and
    existential quantification, respectively.
  • ?x duck(x) represents the proposition every
    object is a duck.
  • ?x duck(x) represents the proposition there is
    at least one duck.

14
Predicates (contd)
  • For a predicate with two free variables,
    quantifying over one of them yields another
    predicate with one free variable, as in
  • ?x Q(x,y) or ?x Q(x,y)

15
Predicates (contd)
  • Where appropriate, a domain of interest may be
    specified which identifies the objects for which
    the quantifier applies. For example,
  • ?i?1,2,,N Aigt0
  • represents the predicate the first N elements
    of array A are all greater than 0.

16
Predicate Calculus
  • The addition of a deductive apparatus gives us a
    formal system permitting proofs and derivations
    which we will refer to as the predicate calculus.
  • The system is based on providing rules of
    inference for introducing and removing each of
    the five connective symbols plus the two
    quantifiers.

17
Predicate Calculus (contd)
  • A rule of inference is expressed in the form
  • A1, A2, , An
  • C
  • and is interpreted to mean
  • (A1 ? A2 ? ? An) ? C

18
Predicate Calculus (contd)
  • Examples of deductive rules

A , B A
A A V B
A, A ? B B
A A
(contd)
19
Predicate Calculus (contd)
  • Examples of deductive rules (contd)

A ? B, B ? A A ? B
A ? B A ? B
?x P(x) P(n1) ? P(n2) ? ? P(nk)
20
  • Sets, Relations, and Functions

21
Sets and Relations
  • A set is any well-defined collection of objects,
    called members or elements.
  • The relation of membership between a member, m,
    and a set, S, is written
  • m ? S
  • If m is not a member of S, we write
  • m ? S

22
Sets and Relations (contd)
  • A relation, r, is a set whose members (if any)
    are all ordered pairs.
  • The set comprised of the first member of each
    pair is called the domain of r and is denoted
    D(r). Members of D(r) are called arguments of r.
  • The set comprised of the second member of each
    pair is called the range of r and is denoted
    R(r). Members of R(r) are called values of r.

23
Functions
  • A function, f, is a relation such that for each x
    ? D(f) there exists a unique element (x,y) ? f.
  • We often express this as yf(x), where y is the
    unique value corresponding to x in the function
    f.
  • It is the uniqueness of y that distinguishes a
    function from other relations.

24
Functions (contd)
  • It is often convenient to define a function by
    giving its domain and a rule for calculating the
    corresponding value for each argument in the
    domain.
  • For example
  • f (x,y)x ? 0,1, y x2 3x 2
  • This could also be written
  • f(x) x2 3x 2 where D(f)0,1

25
Conditional Rules
  • Conditional rules are a sequence of (predicate ?
    rule) pairs separated by vertical bars and
    enclosed in parentheses
  • (p1 ? r1 p2 ? r2 pk ? rk)

26
Conditional Rules (contd)
  • The meaning is evaluate predicates p1, p2,pk in
    order for the first predicate, pi, which
    evaluates to true, if any, use the rule ri if no
    predicate evaluates to true, the rule is
    undefined. (Note that ? ? ?.)
  • (p1 ? r1 p2 ? r2 pk ? rk)

27
Conditional Rules (contd)
  • For example
  • f ((x,y)(x divisible by 2 ? y x/2
  • x divisible by 3 ? y x/3
  • true ? y x))
  • Note that true ? r has the effect of if all
    else fails (i.e., if all the previous predicates
    evaluate to false), use r.

28
Recursive Functions
  • A recursive function is a function that is
    defined by using the function itself in the rule
    that defines it. For example
  • oddeven(x) (x ? 0,1 ? x
  • x gt 1 ?
    oddeven(x-2)
  • x lt 0 ?
    oddeven(x2))
  • Exercise define the factorial function
    recursively.

29
  • Specification via Pre- and Post-Conditions

30
Specification via Pre- and Post-Conditions
  • The (functional) requirements of a program may be
    specified by providing
  • an explicit predicate on its state before
    execution (a pre-condition), and
  • an explicit predicate on its state after
    execution (a post-condition).

31
Specification via Pre- and Post-Conditions
(contd)
  • Describing the state transition in two parts
    highlights the distinction between
  • the assumptions that an implementer is allowed to
    make, and
  • the obligation that must be met.

32
Specification via Pre- and Post-Conditions
(contd)
  • The language of pre- and post-conditions is that
    of the predicate calculus.
  • Predicates denote properties of program variables
    or relations between them.

33
Assumptions
  • Reference to a variable in a predicate implies
    that it exists and is defined.
  • Variables are assumed to be of type integer,
    unless the context of their use implies
    otherwise.
  • A1N denotes an array with lower index bound
    of 1 and upper index bound of N (an integer
    constant).

34
Example 1
  • Consider the pre- and post-conditions for a
    program that sets variable MAX to the maximum
    value of two integers, A and B.
  • pre-condition ?
  • post-condition ?

35
Example 2
  • Consider the pre- and post-conditions for a
    program that sets variable MIN to the minimum
    value in the unsorted, non-empty array A1N.
  • pre-condition ?
  • post-condition ?
  • What does unsorted mean here?

36
Example 2 (contd)
  • Possible interpretations of unsorted
  • ?(?i?1,2,,N-1 Ai?Ai1 V
  • ?i?1,2,,N-1 Ai?Ai1)
  • the sort operation has not been applied to A
  • What was the specifiers intent?

37
  • Specification via Functions

38
Specification via Functions
  • Programs may also be specified in terms of
    intended program functions.
  • These define explicit mappings from initial to
    final data states for individual variables and
    can be expanded into program control structures.
  • The correctness of an expansion can be determined
    by considering correctness conditions associated
    with the control structures relative to the
    intended function.

39
Specification via Functions (contd)
  • Data mappings may be specified via the use of a
    concurrent assignment function.
  • The domain of the function corresponds to the
    initial data states that would be trans-formed
    into final data states by a suitable program.
  • For example...

40
Specification via Functions (contd)
  • The conditional function
  • f (x ? 0 ? y ? 0 ? x, y xy, 0)
  • specifies a program, say F, for which
  • the final value of x is required to be the sum of
    the initial values of x and y, and
  • the final value of y is required to be 0...
  • if x and y are both initially ? 0. Otherwise,
    F may yield some other result (sufficient
    correct-ness) or not terminate (complete
    correctness) in keeping with f being undefined in
    this case.

41
Specification via Functions (contd)
  • Similarly, in a program with data space x, y, z,
    the sequence of assignment statements
  • x x1 y 2x
  • computes a function that can be specified by the
    concurrent assignment function
  • f (x,y,z x1,2(x1),z)
  • This function could also be specified using the
    short-hand notation
  • f (x,y x1,2(x1))
  • implying an assignment into that portion of the
    data space containing x and y, while that
    containing z is assumed to be unmodified.

42
Specification via Functions (contd)
  • In addition, when an intended function is
    followed by a list of variables surrounded by
    characters, the intent is to specify a programs
    effect on these variables only. Other variables
    are assumed to receive arbitrary, unspecified
    values.
  • For example, consider a program with variables x,
    y, and temp. The intended function description
  • f (x,y y,x) x,y
  • is equivalent to (x,y,temp y,x,?) where ?
    represents an arbitrary, unspecified value.

43
Comparing specification approaches
  • Pre- and post-conditions for a program with data
    space x, y, z, temp that is required to swap the
    values of x and y and leave z un-changed (but has
    no requirement concerning the disposition of
    temp)
  • pre-condition true
  • post-condition xy ? yx ? zz
  • Comparable intended function (f1)
  • f1 (x,y y,x) x,y,z
  • (z is unmodified and temp gets an unspecified
    value)

44
Comparing specification approaches (contd)
  • Pre- and post conditions given that the initial
    values of z and temp can be assumed to be greater
    that 0
  • pre-condition zgt0 ? tempgt0
  • post-condition xy ? yx ? zz
  • Comparable intended function (f2)
  • f2 (zgt0 ? tempgt0 ? x,y y,x) x,y,z
  • Comparable in the context of sufficient
    correctness. f2
  • is undefined when (zgt0 ? tempgt0) evaluates
    to false.

45
Formal Program Specification
Software Testing and Verification Lecture 16
  • Prepared by
  • Stephen M. Thebaut, Ph.D.
  • University of Florida
About PowerShow.com
