Solar Power

1
Solar Power
2
Before the bell rings get out your notes and
begin answering the following based on your row

• Row 1- (closest to the front!)- What are the
  three types of fossil fuels, and which do you
  believe is the best?
• Row 2- What is wind energy? How is it harnessed?
  What are the advantages and disadvantages?
• Row 3- What is hydroelectric energy? How is it
  harnessed? What are the advantages and
  disadvantages?
• Row 4- What is the difference between wave and
  tidal energy? How are they harnessed? What are
  the advantages and disadvantages?
• Row 5- What is biomass? What are the advantages
  and disadvantages?
• Row 6 (if there is one)- What is geothermal
  energy? How is it harnessed? What are the
  advantages and disadvantages?

3
Solar Heating Systems

• Passive system
• Uses an architectural design which enhances the
  absorption of solar energy without mechanical
  power
• Is used to reduce heating costs but must have a
  backup system.
• Uses roof overhangs to shade windows in the
  summer, and in winter allows sunlight to
  penetrate into a room.
• Uses building materials that absorb heat energy

4
(No Transcript)
5
Look at the overhanging roof
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
Solar Heating Systems

• Active system
• Requires mechanical energy through pumps and fans
  to move air or water carrying heat to areas where
  heat is stored.
• Energy is collected in a flat plate collector
• They have been used in to heat homes but also
  solar water heaters, solar pool heaters, and
  space heating systems.

10
Why do we need this boiler?
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Photovoltaic Cells

• A device made of silicon cells which changes
  sunlight directly to electricity through the
  release of electrons.
• Many uses (calculators, wristwatches, appliances,
  satellites, space shuttles, and some road signs.)
• Expanding globally and very important in Japan
• Have been used on the roof tops of buildings

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Solar Thermal Technology

• Uses mirror-lined dishes or panels that rotate
  with the sun and collect solar energy
• CSP- Concentrating solar power
• Converts the suns energy into heat which is then
  used to generate electricity.
• There are three types of CSP technologies
  trough, dish/engine, power tower

22
Parabolic Trough

• Power plants use a curved trough which reflects
  the direct solar radiation onto a receiver (also
  called absorber or collector) running along the
  trough, above the reflectors

23
Dish Design

• A dish system uses a large, reflective, parabolic
  dish (similar in shape to satellite television
  dish).
• It focuses all the sunlight that strikes the dish
  up onto to a single point above the dish, where a
  receiver captures the heat and transforms it into
  a useful form.

24
Power Tower

• Use an array of flat, moveable mirrors (called
  heliostats) to focus the sun's rays upon a
  collector tower (the receiver).
• This tower has a steam turbine to create
  electricity.

25
(No Transcript)
26
(No Transcript)
27
Solar lighting

• Parabolic collectors focus sunlight into a fiber
  optic system to illuminate buildings

28
Fiber Optic Lighting
29
Impacts of solar Energy

• No air pollution
• Inexhaustible supply
• Lack of consistent sunlight in most areas
• Requires large areas to produce a lot of energy
• Still too expensive to compete with fossil fuels
  in most cases
• Cannot be stored

30
