Title: Circuit Analysis Techniques


1
LECTURE 2
2
Circuit Analysis Techniques
3
Circuit Analysis Techniques
  • Voltage Division Principle
  • Current Division Principle
  • Nodal Analysis with KCL
  • Mesh Analysis with KVL
  • Superposition
  • Thévenin Equivalence
  • Nortons Equivalence

4

5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Circuit Analysis using Series/Parallel Equivalents
  1. Begin by locating a combination of resistances
    that are in series or parallel. Often the place
    to start is farthest from the source.
  2. Redraw the circuit with the equivalent resistance
    for the combination found in step 1.
  3. Repeat steps 1 and 2 until the circuit is reduced
    as far as possible. Often (but not always) we
    end up with a single source and a single
    resistance.
  4. Solve for the currents and voltages in the final
    equivalent circuit.

9
(No Transcript)
10
Working Backward
11
(No Transcript)
12
Voltage Division
13
Application of the Voltage-Division Principle
14
(No Transcript)
15
Current Division
16
(No Transcript)
17
Application of the Current-Division Principle
18
  • Voltage division and
  • current division
  • Voltage division

19
  • Current division

20
Although they are veryimportant
concepts,series/parallel equivalents andthe
current/voltage divisionprinciples are not
sufficient to solve all circuits.
21
Node Voltage (Nodal) Analysis
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Writing KCL Equations in Terms of the Node
Voltages for Figure 2.16
node 1
node 2
node 3
26
node 1
node 2
node 3
27
No. of unknown v1, v2, v3 No. of linear
equation 3 Setting up nodal equation with KCL
at Node 1, Node 2, Node 3
28
No. of unknown v1, v2, v3 No. of linear
equation 3 Setting up nodal equation with KCL
at Node 1, Node 2, Node 3
29
Problem with node 3, it is rather hard to set the
nodal equation at node 3, but still solvable.
Why? As there is no way to determinethe current
through the voltage source, but v3Vs
v3
Problem with node 3, it is rather hard to set the
nodal equation at node 3 but still solvable.
Same as before.
30
May Not Be That Simple
31
Circuits with Voltage Sources
  • We obtain dependent equations if we use all of
    the nodes in a network to write KCL equations.
  • Any branch with a voltage source
  • define SUPERNODE, sum all current either in or
    out at the supernode with KCL
  • use KVL to set up dependent equation involving
    the voltage source.

32
At node 1
At the supernode
33
A
B
Summing all the current out from the supernode A
Why? As the current via the 10V source is equal
to the current via R4 plus the current via R3
34
B
Summing all the current into the supernode B
35
-v1 -10 v2 0
36
  • Any branch with a voltage source
  • define supernode, sum all current either in or
    out at the
  • supernode with KCL
  • use KVL to set up dependent equation involving
    the
  • voltage source.

37
(No Transcript)
38
(No Transcript)
39
Node-Voltage Analysis with a Dependent Source
  • First, we write KCL equations at each node,
    including the current of the controlled source
    just as if it were an ordinary current source.
  • Next, we find an expression for the controlling
    variable ix in terms of the node voltages.

40
(No Transcript)
41
(No Transcript)
42
Substitution yields
43
(No Transcript)
44
Node-Voltage Analysis
1. Select a reference node and assign variables
for the unknown node voltages. If the reference
node is chosen at one end of an independent
voltage source, one node voltage is known at the
start, and fewer need to be computed.
2. Write network equations. First, use KCL to
write current equations for nodes and supernodes.
Write as many current equations as you can
without using all of the nodes. Then if you do
not have enough equations because of voltage
sources connected between nodes, use KVL to write
additional equations.
3. If the circuit contains dependent sources,
find expressions for the controlling variables in
terms of the node voltages. Substitute into the
network equations, and obtain equations having
only the node voltages as unknowns.
4. Put the equations into standard form and solve
for the node voltages. 5. Use the values found
for the node voltages to calculate any other
currents or voltages of interest.
45
Step 1.Reference node
Step 1. v1
Step 2.
Step 1 v2
46
Step 1
Step 1
v2
v1
Step 2
v3
node 1
supernode
Step 1
ref
supernode
Step 3
47
Mesh Current Analysis
48
Definition of a loop
Definition of a mesh
49
Choosing the Mesh Currents
When several mesh currents flow through one
element, we consider the current in that element
to be the algebraic sum of the mesh currents.
50
(No Transcript)
51
Writing Equations to Solve for Mesh Currents
If a network contains only resistors and
independent voltage sources, we can write the
required equations by following each current
around its mesh and applying KVL.
52
For mesh 1, we have
For mesh 2, we obtain
For mesh 3, we have
53
(No Transcript)
54
Mesh Currents in Circuits Containing Current
Sources
A common mistake is to assume the voltages
across current sources are zero. Therefore, loop
equation cannot be set up at mesh one due to the
voltage across the current source is unknown
Anyway, the problem is still solvable.
55
As the current source common to two mesh,
combine meshes 1 and 2 into a supermesh. In other
words, we write a KVL equation around the
periphery of meshes 1 and 2 combined.
It is the supermesh.
Mesh 3
Three linear equations and three unknown
56
Creating a supermesh from meshes 1 and 3
-7 1 ( i1 - i2 ) 3 ( i3 - i2 ) 1 i3
0 1
Around mesh 2 1 ( i2 - i1 ) 2 i2 3
( i2 - i3 ) 0 2
Finally, we relate the currents in meshes 1 and
3 i1 - i3 7 3
Rearranging, i1 - 4 i2 4 i3
7 1 -i1 6 i2 - 3 i3 0 2 i1
- i3 7 3
Solving, i1 9 A, i2 2.5 A, and i3 2
A.
57
supermesh of mesh1 and mesh2
branch current
current source
58
Three equations and three unknown.
59
Mesh-Current Analysis
1. If necessary, redraw the network without
crossing conductors or elements. Then define the
mesh currents flowing around each of the open
areas defined by the network. For consistency, we
usually select a clockwise direction for each of
the mesh currents, but this is not a requirement.
2. Write network equations, stopping after the
number of equations is equal to the number of
mesh currents. First, use KVL to write voltage
equations for meshes that do not contain current
sources. Next, if any current sources are
present, write expressions for their currents in
terms of the mesh currents. Finally, if a current
source is common to two meshes, write a KVL
equation for the supermesh.
3. If the circuit contains dependent sources,
find expressions for the controlling variables in
terms of the mesh currents. Substitute into the
network equations, and obtain equations having
only the mesh currents as unknowns.
4. Put the equations into standard form. Solve
for the mesh currents by use of determinants or
other means. 5. Use the values found for the mesh
currents to calculate any other currents or
voltages of interest.
60
Superposition
  • Superposition Theorem the response of a circuit
    to more than one source can be determined by
    analyzing the circuits response to each source
    (alone) and then combining the results

Insert Figure 7.2
61
Superposition
Insert Figure 7.3
62
Superposition
  • Analyze Separately, then Combine Results

63
Use superposition to find the current ix.
Current source is zero open circuit as I 0
and solve iXv Voltage source is zero short
circuit as V 0 and solve iXv
64
Use superposition to find the current ix.
The controlled voltage source is included in all
cases as it is controlled by the current ix.
65
Voltage and Current Sources
Insert Figure 7.7
66
Voltage and Current Sources
Insert Figure 7.8
67
Voltage and Current Sources
Insert Figure 7.9
68
Source Transformation
Under what condition, the voltage and current of
the load is the same whenoperating at the two
practical sources?For voltage source
For current source
,
We have,
69
(No Transcript)
70
Voltage and Current Sources
  • Equivalent Voltage and Current Sources for
    every voltage source, there exists an equivalent
    current source, and vice versa

71
(No Transcript)
72
Thevenins Theorem
  • Thevenins Theorem any resistive circuit or
    network, no matter how complex, can be
    represented as a voltage source in series with a
    source resistance

73
Thevenins Theorem
  • Thevenin Voltage (VTH) the voltage present at
    the output terminals of the circuit when the load
    is removed

Insert Figure 7.18
74
Thevenins Theorem
  • Thevenin Resistance (RTH) the resistance
    measured across the output terminals with the
    load removed

75
Thévenin Equivalent Circuits
76
(No Transcript)
77
(No Transcript)
78
Thévenin Equivalent Circuits
79
Thévenin Equivalent Circuits
80
Finding the Thévenin Resistance Directly
When zeroing a voltage source, it becomes a short
circuit. When zeroing a current source, it
becomes an open circuit. We can find the
Thévenin resistance by zeroing the sources in the
original network and then computing the
resistance between the terminals.
81
(No Transcript)
82
(No Transcript)
83
Computation of Thévenin resistance
84
Equivalence of open-circuit and Thévenin voltage
85
A circuit and its Thévenin equivalent
86
Superposition
As the voltage source does not contribute any
output voltage, Only the current source has the
effect.
87
Determine the Thévenin and Norton Equivalents of
Network A in (a).
Source transformation
88
Find the Thévenin equivalent of the circuit shown
in (a).
v
As i -1, therefore, the controlled voltage
source is -1.5V.Use nodal analysis at node v,

Thus, Rth v/I 0.6/1 0.6 ohms
89
(No Transcript)
90
Applications of Thevenins Theorem
  • Load Voltage Ranges Thevenins theorem is most
    commonly used to predict the change in load
    voltage that will result from a change in load
    resistance

91
Applications of Thevenins Theorem
  • Maximum Power Transfer
  • Maximum power transfer from a circuit to a
    variable load occurs when the load resistance
    equals the source resistance
  • For a series-parallel circuit, maximum power
    occurs when RL RTH

92
Applications of Thevenins Theorem
  • Multiload Circuits

Insert Figure 7.30
93
Nortons Theorem
  • Nortons Theorem any resistive circuit or
    network, no matter how complex, can be
    represented as a current source in parallel with
    a source resistance

94
Nortons Theorem
  • Norton Current (IN) the current through the
    shorted load terminals

Insert Figure 7.35
95
Computation of Norton current
96
Nortons Theorem
  • Norton Resistance (RN) the resistance measured
    across the open load terminals (measured and
    calculated exactly like RTH)

97
Nortons Theorem
  • Norton-to-Thevenin and Thevenin-to-Norton
    Conversions

Insert Figure 7.39
98
Step-by-step Thévenin/Norton-Equivalent-Circuit
Analysis
1. Perform two of these a. Determine the
open-circuit voltage Vt voc. b. Determine
the short-circuit current In isc. c. Zero
the sources and find the Thévenin resistance Rt
looking back into the terminals.
99
2. Use the equation Vt Rt In to compute the
remaining value. 3. The Thévenin equivalent
consists of a voltage source Vt in series with Rt
. 4. The Norton equivalent consists of a current
source In in parallel with Rt .
100
(No Transcript)
101
Maximum Power Transfer
The load resistance that absorbs the maximum
power from a two-terminal circuit is equal to the
Thévenin resistance.
102
Graphical representation of maximum power transfer
Power transfer between source and load
103
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
