ERX Overview

1
ERX Overview

• Carrier Class Edge Switch Router

2
Unisphere Data Services Overview

• Redstone incorporated in September 1997
• Headquarters Westford, Massachusetts
• Joined Unisphere Solutions, a US-based,
  wholly-owned subsidiary of Siemens AG in April,
  1999
• The company is dedicated to addressing the
  challenges faced by service providers as they
  strive to keep pace with the rapid growth and
  demand for new services at the edge of the
  Internet

3
Unisphere Data Services Overview

• Redstone co-founders
• Jim Dolce Former Vice President General
  Manager, Remote Access Business Unit, Cascade
  Communications
• Kurt Melden Former co-founder and hardware
  development director, Cascade Communications
• Chris Lawler Former Vice President of
  Engineering, LAN Switching Division, 3Com Corp
• Products ERX700 and ERX1400 Edge Switch Routers
  and NMC-RX (EdgeControl) NMS

4
Market Segmentation

• Internet Edge
• Where service providers meet their customers
• For end-users Dedicated Internet and VPN access
• For service providers
• Service adaptation to IP
• Policy management
• IP VPN management
• Statistics Harvesting
• Accounting
• IP routing with QoS

Between now and 2002, 2 million businesses and
30 million consumers will get connected to the
Internet, Forrester, 8/1998, Network Strategies
5
First Generation Edge Solutions

• Current generation of Edge products limit
  Internet access!
• Limited density is exhausting POP space and power
• Performance designed for larger packet sizes
  cant keep up with todays traffic demands
• Lack of carrier features challenge ability to
  meet SLA commitments
• No QoS control limits new services

Cisco 7500
Ascend 9000
OC3/STM1
Internet Access Customers
Cisco 7500
FT1/E1 T1/E1
6
Next-Generation IP Edge Switch Router

• High Density (low power, small size) to conserve
  scarce point-of-presence (POP) rack space
• Hundreds of physical circuits/shelf
• Thousands of logical circuits/shelf
• High bandwidth capacity with 100 Wire Speed
  Performance
• Hardware redundancy and other Carrier reliability
  features provide high availability required to
  meet SLAs
• Supports wire speed QoS crucial to deployment of
  the business-grade Internet

7
Industry Leading Density
Available space in COs remains at a premium !
7 ft Telco Rack
ERX 1400
100 Wire Speed Efficiency Full Hardware
Redundancy Support for QoS
8
Wire Speed Performance
Packet Distribution on the Internet
Source MCI Traffic Study, IEEE Network 11/97
9
Wire Speed Performance

• Growth in demand for bandwidth and function (e.g.
  QoS) is outpacing the performance of pure
  software routers based solely on RISC processors
• Next Generation IP Edge Router designs require a
  precise blend of RISC and ASIC technology...
• Ultimate flexibility of a RISC processor
• Performance, density and cost benefits of a
  hardware solution
• Edge Routers have less stringent forwarding
  requirements but demand more features and
  flexibility

10
Fast, Flexible Architecture

• ASICs and FPGAs per line card deliver hardware
  assist for maximum performance
• Buffer and queue management
• QoS scheduling
• Address lookup
• Flow classification and rate measurement
• Statistics support
• RISCs per line card for flexibility
• L2/L3 packet header parsing and modifications
• QoS, classification, and statistics control
• Emerging standards support

11
Carrier Reliability

• NEBS Level 3 compliance
• Full redundancy and hot swap
• Distributed DC power and efficient power
  utilization (1KW for 924 T1s)
• Front-to-back airflow
• Midplane design means service uptime without
  cable moves
• Modular software architecture supports dynamic
  upgrades
• Storage of multiple images and configurations to
  ease service upgrades

Benefit Service Providers can safely deliver
network reliability guarantees as part of SLAs
12
ERX System Architecture
SRP I/O
I/O Adapter Modules
I/O Module DS3 T1 E1 E3 OC3c/STM1 OC12c/STM4 Giga
bit Ethernet Fast Ethernet
Midplane
Connection via passive Midplane
Line Modules
Line Modules CHT3 CT1/CE1 T3/E3 OC3c/STM1 OC12c/ST
M4 Gigabit Ethernet Fast Ethernet
5-10 Gbps Switch Route Processor (SRP) with
optional redundant SRP
13
Network Management
CNM Web App
Policy Server (e.g. RADIUS, DHCP)
EdgeControlTM
3rd Party and ISP Apps/OSS

dB
Applications
Command Line/Scripts
Bulk Stats
SNMP Traps
SNMP Sets/Gets
Access Methods
ERX1400
ERX700
Any IP Path
Elements
14
Network Element Management Overview

• Standards-based element management SNMP, MIB
  support, and CLI
• Cisco-interpreter CLI mode eliminates need for
  operator retraining and fully utilizes existing
  scripts
• CLI scripting language automates standard
  configuration tasks
• NMC-RX (EdgeControl), JAVA-based NMS with
  relational database eases network-wide policy
  control
• Statistics and accounting information gathered
  down to the packet flow level

15
NMC-RX (EdgeControl) Interface Examples
16
Monitoring and Diagnostics

• A full suite of tools to support ease of
  operation and speed problem resolution
• Comprehensive statistics for all interfaces
• Hard-wired hardware and firmware identification
  per line module, including revision level
• Detailed event logging and event filtering
• Diagnostic tests on power up or on command
• Diagnostic tests for line modules and protocol
  types
• Loopback tests at physical and logical levels
• Test pattern generation at physical and logical
  levels
• Dump capabilities for line modules and SRP

17
Applications
18
Next Gen POP Architecture
SubscriberAccessSolutions
Service Layer
Infrastructure Network Solutions
Edge
Core
SSS
DHCP
ERX-700/1400
PrivateLine
CRX-64000
ServiceReadyNetworking
Corporate Business
RADIUS
xDSL
ATM/POSSTM-1 /STM4
Small/Medium Business
ATM/POSSTM4/STM16
Cable
SOHO, Residential Access
DS1/DS3/OC3 E1/E3/STM1 Physical/Virtual
5-10 Gbps
20-80 Gbps
19
ERX Delivers the Network Edge
STM-4 ATM
Internet
Service Provider Edge Network
xDSL IP/PPP/ATM
ERX 700/1400
STM-1 POS
VPN
Telco Network
xDSL IP/Eth/PPP/ATM
E1 IP/Frame
Gig Ethernet Fast Ethernet
STM-1 ATM
ISP
STM-4 POS
E3 IP/PPP
CLEC
20
Edge Applications Private Line Aggregation
21
Edge Applications DSL Aggregation
Consumer Business Users (xDSL)
CLEC
ERX700/1400
IP/PPP/ATM
ISP
ATM/FR
OC3/STM1
E3 FR/ATM STM-1 ATM
OC12/STM4
IP/PPP/FR
POS/ATM
Gig Eth
DSLAM
IP/PPPoE/ATM
VPN
RADIUS
DHCP
IP/PPPoE/FR
Access Network Provider
Service Network Provider
Internet
BRAS support for PPP, PAP, CHAP, DHCP, and RADIUS
22
Outsourcing Internet Access
Use Virtual Routers, MPLS, ATM /FR VCs and/or
L2TP to outsource access
23
Wholesaling Value-Add with SSC
Content Provider
ISP A
SSC
IP Network
Corp VPN
ERX 1400
Billing
ASP
Wholesaler can connect subscriber to any VPN on
behalf of their partner, based on dynamic
subscriber selection
24
Tier-1 Provider Protocol Support

• Full support for IP and IP routing
• ICMP, IGMP, UDP, TCP, CIDR
• 32,000 IP interfaces
• Virtual routers with logically separate routing
  tables for VPN and wholesale applications
• Completely distributed routing for wire-speed
  efficiency all IP lookup and forwarding handled
  on line cards
• Highly scalable routing protocols BGP4, IS-IS,
  OSPF, and RIP

25
Routing Protocol Support
Highly scalable routing protocols optimized for
large networks

• BGP-4
• Confederations, route reflectors, route damping,
  peer groups, etc.
• IS-IS
• Level-1/Level-2 routing
• Multiple areas, Metric extension, Selective
  redistribution, mesh groups, MD5, etc.

• OSPF
• Inter/Intra areas, Type1/Type2 external routes
• RIPv2
• MPLS
• Access Lists, Route Maps, Route Redistribution

26
Ingress/Egress Protocol Support
All ports can support ingress or egress operations

• SDH/Sonet
• IP/ATM/SDH and IP/PPP/SDH
• Bellcore GR-253-CORE
• SONET or SDH
• PPP
• MTU
• LCP, IPCP, OSICP
• PAP, CHAP

• Frame Relay
• DTE/DCE
• LMI
• ATM
• LLC and VC mux
• AAL5
• ILMI
• UBR and nrt-VBR
• OAM F5

27
Service Offering IP VPNs
ERX 700/1400
Support for both VPN and wholesaling applications
28
ERX VPN Implementation
Grouping and applying VPN specific policies
Identification/ VPN membership
Transporting data to each VPN
Routing policy QoS policy Transport
selection Other services
ATM VCs MPLS tunnels L2TP tunnels IP Sec
tunnels IP in IP tunnels
Source interface Domain name IP header
info MPLS label?
Support for both VPN and wholesaling applications
29
QoS Delivery
The carrier edge aggregates and mediates QoS
between thousands of subscribers at the entrance
to the public network
CPE
Core
ERX 700/1400
Edge
Core
Mark/label packets for proper treatment by the
core
Classify packets and enforce associated QoS
policies
Allocate uplink bandwidth and system resources to
subscribers in relation to their service plan
30
Service Offering IP QoS

• Best-Effort
• Tiered Service
• Maximum bandwidth (CARS)
• Minimum bandwidth (CARS)
• Weighted Fair Queuing (WFQ)
• Gold, Silver, Bronze
• WFQ with uplink protection
• Gold, Silver, Bronze with minimum uplink
  guarantees

The ERX provides QoS tools to create innovative
service policies
31
IP QoS End to End
32
ERX Product Family
33
Pricing Availability
ERX 700

• Price leadership across full range of interfaces
• Base Configuration available now

ERX 1400
34
Backup Slides
35
Next Gen POP Architecture
SubscriberAccessSolutions
Service Layer
Edge
Core
Infrastructure Network Solutions
SSS
DHCP
ERX-700/1400
PrivateLine
ServiceReadyNetworking
Corporate Business
RADIUS
xDSL
ATM/POS
ATM/POS
Small/Medium Business
CRX-64000AS
Cable
SOHO, Residential Access
SMX-2100
PSTN
PSDN
Packet Telephony Solutions
36
Private Line Aggregation
Core Routing Switch
Edge Routing Switch
E1, E3
OC3/STM1 POS
SONET Ring
ERX-700/1400
CRX-64000
ADM/DACS bundles DS1s into M13 format
I
37
DSL Aggregation
Access Network Provider
Service Network Provider
DS3/E3 ATM
High Fan In Low Utilization (e.g. 2000 VCs)
PSTN
ATM End-to-End
Broadband access architecture uses industry
standard remote-access protocols such as PPP, IP,
PAP, CHAP, and RADIUS
38
Cable ISP Solution
Consumer Business Users (Cable Modem)
Cable Service Provider HFC Network
CLEC
Ethernet
ERX-700/1400
ISP/ RR/ _at_home
CMTS
ATM
OC3/STM1
CMTS
ATM
OC12/STM4
Ethernet
POS/ATM
IP/PPPoE or L2TP
Gig Eth / FE
DHCP RADIUS
VPN
SSS
SMX-2100
Key
Internet
PSTN
Fiber Fiber Node
Amplifier Splitter Tap
39
VPN Service Dedicated Routes
