Image enhancement

1
Image enhancement

• Antti Tuomas Jalava
• Jaime Garrido Ceca

2
Overview

• Digital subtraction angiography. Dual-energy and
  energy-subtraction X-ray imaging. Temporal
  subtraction.
• Gray-scale transform.
• Convolution mask operators.
• High-frequency enhancement.
• Adaptive contrast enhancement.
• Objective assessment of Contrast Enhancement.

3
Digital Subtraction Angiography

• PROCESS
• Agent is injected to increase the density of the
  blood
• Number of X-ray images.
• An image taken before the injection of the agent
  is used as the mask or reference image.
• Subtracted from the live images to obtain
  enhanced images.
• Useful to detect sclerosis.
• The mathematical procedure involved may be
  expressed simply as
• Sensitive to motion

4
(No Transcript)
5
Dual-energy and Energy-subtraction X-ray Imaging

• X-ray images at multiple energy levels
• Distribution of specific materials in the object
  or body imaged
• Weighted combinations of multiple-energy images

• soft-tissue and hard tissue separately

6
(No Transcript)
7
Temporal Subtraction

• To detect normal or pathological changes occurred
  over a period of time.
• Detection of lung nodules
• Normal anatomic structures are suppressed and
  pathological are enhanced.

8
Gray Scale TransformOverview

• Gray-scale thresholding.
• Gray-scale windowing.
• Gamma correction.
• Histogram transformation.
• Histogram specification.
• Limitation of global operations.
• Local-area histogram equalization.
• Adaptive-neighborhood histogram equalization.

9
Gray-scale Transforms (I)

• Presence of different levels of density or
  intensity in the image.
• Histogram gray-scale transform.
• Improve the visibility of details.

10
Gray-scale Transforms (II)

• Gray-scale thresholding.
• Gray level object gt L new bi-level image.
• Problem Narrow range of gray levels.
• Solution Stretch the range of interest to the
  full range.
• Gray-scale windowing.
• Linear transformation
• Gamma correction.
• Non-linear transformations

11
Thresholding
12
Gamma Curve
13
Gamma Correction
14
Windowing
15
Histogram Transformation

• Principle maximal information is conveyed when
  PDF is uniform.
• Histogram transformation is used to enhance the
  image.
• Histogram-based methods
• Histogram equalization.
• Histogram specification.
• Local-area histogram equalization (LAHE).
• Adaptive-neighborhood histogram equalization.

16
Histogram Equalization

• Goal
• Discrete version
•


• Properties of this function
• Single value monotonically increasing.
• Maintain same range of values.

17
(No Transcript)
18
(No Transcript)
19
Histogram Specification

• Problem H. Equalization provides only one output
  image. Not satisfactory in many cases.
• Histogram Specification is a series of
  histogram-equalization steps to obtain
  prespecified histogram.
• Process
• Specify the desired histogram and derive
• Derive the histogram-equalizing transform
• Derive from
• Obtain
• Transform to image f.

20
Limitations of Global Operations

• Global operators (Gray-scale histogram
  transform) provides simple mechanisms to
  manipulate the image.
• Global approach to image enhancement ignores the
  nonstationary nature of images.
• Given wide range of details of interest in
  medical image, such as hard and soft tissues, it
  is desirable to design local and adaptive
  transform for effective image enhancement.

21
Local-area Histogram Equalization (LAHE)

• Problem Gray levels with low probability are
  merged upon quantization of the equalizing
  transform lost in the enhanced image.
• 2D sliding window.
• Resulting transform is applied only to the
  central pixel.
• Computationally expensive.
• LAHE variation
• Not every pixel. Only nonoverlapping rectangular
  block spanning the image.

22
Adaptive-neighborhood Histogram Equalization

• Limitation of LAHE no justification to the
  choice of the rectangular shape and the size of
  the window.
• Identification of shape and size neighborhoods
  for each pixel by region growing.
• Uniform region spans a limited range of gray
  levels by a specified threshold.
• Local area composed not only by foreground region
  growing but also by background one.
• Histogram of the local region equalizing
  transform to the seed pixel and all the pixels
  with the same value.

23
Adaptive-neighborhood Histogram Equalization
Original
Equalization, Background depth 5, growth
threshold 16
24
Convolution Mask Operators for Image Enhancement

• 2D convolution of images with 3 x 3 masks.
• Unsharp masking
• Subtraction Laplacian

25
Convolution Mask OperatorsUnsharp Masking

• Tackles blurring by an unknown phenomenon.
• Assumes that each pixel of original image
  contributes also to neighboring pixels.
• Results into a fog.
• Procedure
• The original degraded image is blurred.
• The blurred image is subtracted from the degraded
  image.
• Removes the fog.
• General form
• Where is local mean in degraded image
  .

Mean filter
Unsharp mask
26
Convolution Mask OperatorsSubtraction Laplacian

• Assumption that degraded image is a result of
  diffusion process that spreads intensity values
  over space as a function of time
• 3 x 3 convolution mask form
• of Laplacian (gradient)
• With weighting factor set to 1
• the subtraction Laplacian is

27
Convolution Mask OperatorsProblems

• Edge enhancement high-frequency emphasis (Over
  and under-shoot seen as halos around edges).
• While seeming sharper, some finer details might
  be lost.
• Can lead to negative pixel values.
• Linear mapping back to display range can cancel
  any enhancing.
• Fixed operators.
• No adaptivity to variability within image.

28
Unsharp mask, A 1, B 9, Normalized dynamic
range
Original
Unsharp mask, A 1, B 9, Dynamic range cut to
original
Subtracting Laplacian, A 1, B 5, Normalized
dynamic range
29
High-frequency Emphasis

• Bad idea Ideal highpass filter
• Introduces ringing artifacts.
• Butterworth highpass filter
• Use of smooth transition from stopband to pass
  band.
• Artifact reduction.
• Extracts only edges.
• Order n.
• Butterworth high-emphasis filter
• Adds constant to frequency space.
• Preserves image and sharpens edges.

30
Homomorphic Filtering (I)

• Already known Two images with different
  frequency composition that are added together can
  be separated with linear filtering.
• Two images multiplied with each other?
• Take logarithm first.
• (subscript l indicates that Fourier
  transform has
• been applied to Fourier transformed
  image)
• Then filter, inverse Fourier transform
• and reverse logarithm with exponent.

31
Homomorphic Filtering (II)

• Extension for convolved images (Chapter 10.3).
• generalized linear filtering.
• Operations are called homomorphic systems.
• With highpass filter used to achieve simultaneous
  dynamic range compression (brightness
  normalization) and contrast enhancement.

32
Original
Homomorphic filtering Butterworth High-frequency
emphasis filter, n 1, D 0.6, Ka 0.1, Kb
0.5
Butterworth High-frequency emphasis filter, n
1, D 0.6, Ka 0.1, Kb 0.5
Butterworth High-pass filter, n 1, D 0.6
33
Adaptive-neighborhood Enhancement in General

• Adaptive neighborhood (foreground)
• Interconnected segment of pixels with certain
  common property with a seed pixel. (Found with
  seed fill.)
• Properly defined segments should correspond to
  image features.
• Found regions are extended to overlap with
  adjacent regions (background).
• Borders of few pixels wide.
• Prevents edge artifacts like reversed intensity
  across border.
• Enhancing algorithm is performed within the
  combined foreground and background.
• Result is applied to each seed pixel and each
  pixel within foreground with same value of
  property than seed.
• Other pixels in foreground grow their own
  neighborhood.

34
Adaptive-neighborhood Contrast Enhancement

• Common property Similar gray value
• To be exact Growth tolerance .
• If , all pixels connected to seed
  pixel with gray value between 0.95 and 1.05 times
  the seed pixels gray value are included to
  foreground.
• All grown regions have contrast higher than
  independent of seed pixels gray value.
• Worst case scenario
•

• average foreground pixel gray value
• average background pixel gray value
• Webers ratio of 2 (for contrast of visible
  features)
• should be about 4 .
• Algorithm Increase contrast to by
  replacing seed pixels value with

(From equation 2.7)
(From equation 2.7)
35
Adaptive- neighborhood contrast
enhancement, growth tolerance 0.05, background
depth 5
Original
36
Objective Assessment of Contrast Enhancement

• Contrast histogram
• Distribution of contrast of all possible regions
  obtained by seed fill algorithm.
• Enhanced image should contain more counts of
  regions at higher contrast levels.
• In practice same as more spread contrast
  histogram.
• The second moment is used to characterize the
  spread

37
Image Enhancing- Ending Remarks

• Better contrast
• sharpness of detail and
• visibility of features
• are the targets for image enhancing.
• Results can vary with each approach and image.
• It can be beneficial to obtain several enhanced
  images with variety of approaches (as with most
  fields of image analysis).
• Image restoration is presented in chapter 10.
• Image restoration reversing the degradation when
  the exact mathematical model of degradation is
  known.

38
Seed Fill - Foreground
39
Seed Fill - Background
