Photo: San Onofre Nuclear Generating Station

1
Photo San Onofre Nuclear Generating Station
Radio Channel Quality inIndustrial Sensor
Networks
Daniel Sexton, Jay WerbSICon 05February 9th 2005
2
(No Transcript)
3
Generic Mesh Network Features

• Bi-directional ? Acknowledgements and commands
• Multi-hop ? Extend solutions and resiliency
• Self-healing ? Reliable and flexible
• Standards ? IEEE 802.15.4
• Secure ? Symmetric link to link encryption

4
Anatomy of an installed system
Bridge nodes interface the sensor network to the
IP world
Mesh nodes form a reliable backbone for routing
sensor data
Sensors connect to end nodes to access the network
5
Value Proposition
? 25.61C
Motor Replaced
6
IEEE 802.15.4Standard

• Desirable features
• 250 kbps ? Flexibility, low duty cycle
• 2.4 GHz ? International
• Lightweight MAC ? low complexity
• Simple ASIC ? many sources ? low cost
• Network Security
• But will it work in a harsh factory environment?

7
Does the promise match the reality?

• Research focuses on radio reliability in
  factories
• Channel fading multipath
• Channel coherence
• Radio performance
• In simulation
• On the wire
• Statistical lost packets in factories
• Will channel diversity help?

8
Channel Fading

• Multipath effects
• Varies by position
• Varies by frequency
• Varies over time
• Overcome with diversity
• Path diversity
• Costs more routing nodes
• Frequency diversity
• Free with certain protocols

9
Fading Factors
Path Loss L(dB) 40 10NLogD L path loss at
2.4GHz D distance in meters NExponential Path
Loss Factor N2 for free space Observed values of
N 1.3ltNlt3.7 Factors Building Construction,
Channel Obstructions
This equation represents a single static channel
L(dB) 40 10Ne LogD Ne Value based on
installation type
Large ScaleL(dB) 40 10Ne LogD Ll LlRV
based on loss from Obstructions (Walls, Doors,
Ceilings) Ll usually a log normal distribution
from installations of same type
Small Scale L(dB) 40 10NeLogD Ls Ll Ls
RV based on measured Channel Characteristics Bot
h in time and space (Rayleigh, Rician, Nakagami,
etc).
The better we characterize Ne the less variance
in Ll
10
Frequency Diversity In situ experiment
11
Diversity Gains
NLOS Channel Rayleigh Faded
Methods to Obtain Diversity Gain (Small Scale)

• Frequency Diversity (Greater than Coherence
  Bandwidth)
• Good Margin for fading and interference
• Path Diversity (Greater than 1 wave length)
• Good Margin for fading, some for interference
• Time Diversity (Greater than Coherence Time)
• Good Margin for interference, some for fading

We use all Three Need to quantify Large Scale
Diversity Gain
12
Power Level

• How much power is enough?
• 1 mW (0 dBm) is typical power level for 802.15.4
• Not enough for target 100 meter range
• Especially when no line of sight available
• Interference from Bluetooth and WiFi
• Need similar power level to be heard
• Supporting tests and simulations to be published
• Regulatory limits
• 36 dBm in US 20 dBm in Europe (FH) 10 dBm some
  countries
• Transmitter energy consumption
• Transmitter percentage 35 at 15 dBm inflection
  point
• Tested at 15 dBm
• Seems about right more field experience needed

13
Covering the Bases
Static Multipath Time VariantMultipath StaticInterference(e.g. Microwave) Time VariantInterference(Other Networks)
Spatial Diversity(Mesh Routing) ? ? ? ?
Frequency Diversity (Channel Hopping) ? ? ? ?
Temporal Diversity(Retries) ? ? ? ?
Transmit Power(15 dBm) ? ? ? ?
Overall Risk Coverage ? ? ? ?

• Assumptions
• Spatial diversity supports a few paths
• Frequency diversity supports many channels
• Path diversity directs signal away from
  interferers
• Interference is channel limited

14
Early ResultsSummary

• Industrial protocols should support diversity
• Diversity gains gtgt10 dB
• Frequency diversity is free
• Some path diversity also provides redundancy
• Increase 2.4 GHz radio power to about 15 dBm
• Bluetooth/WiFi coexistence
• Hostile radio environment, line of sight often
  unavailable
• Range consistent with scale of industrial
  applications
• Likely range somewhat less than 100 meters
• Multihop architecture is necessary
• More testing needed in a wider variety of sites
