EE 319K Introduction to Embedded Systems

1
EE 319KIntroduction to Embedded Systems

• Lecture 14 Gaming Engines, Coding Style,
  Floating Point

2
Agenda

• Recap
• Software design
• 2-D arrays, structs
• Bitmaps, sprites
• Lab 10
• Agenda
• Gaming engine design
• Coding style
• Floating point

3
Numbers

• Integers (Z) universe is infinite but discrete
• No fractions
• No numbers between 5 and 6
• A countable (finite) number of items in a finite
  range
• Real numbers (R) universe is infinite
  continuous
• Fractions represented by decimal notation
• Rational numbers, e.g., 5/2 2.5
• Irrational numbers, e.g., p 22/7 3.14159265 .
  . .
• Infinity of numbers exist even in the smallest
  range

(Adapted from V. Aagrawal)
4
Number Representation

• Integers
• Fixed-width integer number
• Reals
• Fixed-point number ? I ?
• Store I, but ? is fixed
• Decimal fixed-point (?10m) I 10m
• Binary fixed-point (?2m) I 2m
• Floating-point number I BE
• Store both I and E (only B is fixed)

5
Wide Range of Real Numbers

• A large number
• 976,000,000,000,000 9.76 1014
• A small number
• 0.0000000000000976 9.76 10-14
• No fixed ? that can represent both
• Not representable in single fixed-point format

(Adapted from V. Aagrawal)
6
Floating Point Numbers

• Decimal scientific notation
• 0.513105, 5.13104 and 51.3103
• 5.13104 is in normalized scientific notation
• Binary floating point numbers
• Base B 2
• Binary point
• Multiplication by 2 moves the point to the left
• Normalized scientific notation, e.g., 1.02-1
• Known as floating point numbers

(Adapted from V. Agrawal)
7
Normalizing Numbers

• In scientific notation, we generally choose one
  digit to the left of the decimal point
• 13.25 1010 becomes 1.325 1011
• Normalizing means
• Shifting the decimal point until we have the
  right number of digits to its left
• Normally one
• Adding or subtracting from the exponent to
  reflect the shift

(Adapted from V. Agrawal)
8
Floating Point Numbers

• General format
• 1.bbbbb two2eeee
• or (-1)S (1F) 2E
• Where
• S sign, 0 for positive, 1 for negative
• F fraction (or mantissa) as a binary
  integer, 1F is called significand
• E exponent as a binary integer, positive or
  negative (twos complement)

(Adapted from V. Agrawal)
9
ANSI/IEEE Std 754-1985

• Single-precision float format

Bit 31 Mantissa sign, s0 for positive, s1 for
negative Bits 3023 8-bit biased binary exponent
0 e 255 Bits 220 24-bit mantissa, m,
expressed as a binary fraction, A binary 1 as
the most significant bit is implied. m
1.m1m2m3...m23
(Adapted from V. Agrawal)
10
IEEE 754 Floating Point Standard

• Biased exponent exponent range -127,127
  changed to 0, 255
• Biased exponent is an 8-bit positive binary
  integer
• True exponent obtained by subtracting 12710 or
  011111112
• 255 special case
• First bit of significand is always 1
• 1.bbbb . . . b 2E
• 1 before the binary point is implicitly assumed
• So we dont need to include it just assume its
  there!
• Significand field is 23 bit fraction after the
  binary point
• Significand range is 1, 2)
• Standard formats
• Single precision 8 (E) 23 (F) 1 (S) 32
  bits (float)
• Double precision 11 (E) 52 (F) 1 (S) 64
  bits (double)

(Adapted from V. Agrawal)
11
Numbers in 32-bit Formats

• Twos complement integers
• Floating point numbers
• The range is larger, but the number of numbers
  per unit interval is less than that for a
  comparable fixed point range

Expressible numbers
-231
231-1
0
Positive underflow
Negative underflow
Negative Overflow
Positive Overflow
Expressible negative numbers
Expressible positive numbers
0
-2-127
2-127
(2 2-23)2127
- (2 2-23)2127
(Adapted from V. Agrawal)
12
Binary to Decimal Conversion
Binary (-1)S (1.b1b2b3b4) 2E
Represents (-1)S (1 b12-1 b22-2 b32-3
b42-4) 2E
Example -1.1100 2-2 (binary) - (1 2-1
2-2) 2-2 - (1 0.5 0.25)/4 -
1.75/4 - 0.4375 (decimal)
(Adapted from V. Agrawal)
13
Decimal to Binary Conversion

• Converting from base 10 to the representation
• Single precision example
• Covert 10010
• Step 1 convert to binary - 0110 0100
• In a binary representation form of 1.xxx have
• 0110 0100 1.100100 x 26

14
Decimal to Binary Conversion (contd)

• 1.1001 x 26 is binary for 100
• Thus the exponent is a 6
• Biased exponent will be 6127133 1000 0101
• Sign will be a 0 for positive
• Stored fractional part f will be 1001
• Thus we have
• S E F
• 0 100 0 010 1 1 00 1000.
• 4 2 C 8 0 0 0 0 in
  hexadecimal
• 42C8 0000 is representation for 100

15
Positive Zero in IEEE 754
0 00000000 00000000000000000000000
Biased exponent
Fraction

• 1.0 2-127
• Smallest positive number in single-precision IEEE
  754 standard.
• Interpreted as positive zero.
• Exponent less than -127 is positive underflow
  can be regarded as zero.

(Adapted from V. Agrawal)
16
Negative Zero in IEEE 754
1 00000000 00000000000000000000000
Biased exponent
Fraction

• - 1.0 2-127
• Smallest negative number in single-precision IEEE
  754 standard.
• Interpreted as negative zero.
• True exponent less than -127 is negative
  underflow may be regarded as 0.

(Adapted from V. Agrawal)
17
Positive Infinity in IEEE 754
0 11111111 00000000000000000000000
Biased exponent
Fraction

• 1.0 2128
• Largest positive number in single-precision IEEE
  754 standard.
• Interpreted as 8
• If true exponent 128 and fraction ? 0, then the
  number is greater than 8.
• It is called not a number or NaN and may be
  interpreted as 8.

(Adapted from V. Agrawal)
18
Negative Infinity in IEEE 754
1 11111111 00000000000000000000000
Biased exponent
Fraction

• -1.0 2128
• Smallest negative number in single-precision IEEE
  754 standard.
• Interpreted as - 8
• If true exponent 128 and fraction ? 0, then the
  number is less than - 8
• It is called not a number or NaN and may be
  interpreted as - 8.

(Adapted from V. Agrawal)
19
IEEE Representation Values

• If E255 and F is nonzero, then VNaN ("Not a
  number")
• If E255 and F is zero and S is 1, then
  V-Infinity
• If E255 and F is zero and S is 0, then
  VInfinity
• If 0ltElt255 then V(-1)S 2 (E-127) (1.F)
  where "1.F" is intended to represent the binary
  number created by prefixing F with an implicit
  leading 1 and a binary point.
• If E0 and F is nonzero, then V(-1)S 2
  (-126) (0.F)
• These are "unnormalized" values.
• If E0 and F is zero and S is 1, then V-0
• If E0 and F is zero and S is 0, then V0

20
Addition and Subtraction

• 0. Zero check
• - Change the sign of subtrahend
• - If either operand is 0, the other is the result
• 1. Significand alignment right shift smaller
  significand until two exponents are identical.
• 2. Addition add significands and report
  exception if overflow occurs.
• 3. Normalization
• - Shift significand bits to normalize.
• - report overflow or underflow if exponent goes
  out of range.
• 4. Rounding

(Adapted from V. Agrawal)
21
Rounding

• Adjusting significands before addition will
  produce results that exceed 24 bit
• Round toward infinity
• select next largest normalized result
• Round toward minus infinity
• select next smallest normalized result
• Round toward zero
• truncate result
• Round to nearest
• select closest normalized result
• used by IEEE 754

22
Example

• Subtraction 0.510- 0.437510
• Step 0 Floating point numbers to be added
• 1.00022-1 and -1.11022-2
• Step 1 Significand of lesser exponent is
  shifted right until exponents match
• -1.11022-2 ? - 0.11122-1
• Step 2 Add significands, 1.0002 (- 0.1112)
• Result is 0.0012 2-1
• Step 3 Normalize, 1.0002 2-4
• No overflow/underflow since
• 127 exponent -126
• Step 4 Rounding, no change since the sum fits
  in 4 bits.
• 1.0002 2-4 (10)/16 0.062510

(Adapted from V. Agrawal)
23
FP Multiplication Basic Idea

1. Separate sign
2. Add exponents
3. Multiply significands
4. Normalize, round, check overflow
5. Replace sign

(Adapted from V. Agrawal)
24
FP Division Basic Idea

1. Separate sign.
2. Check for zeros and infinity.
3. Subtract exponents.
4. Divide significands.
5. Normalize/overflow/underflow.
6. Rounding.
7. Replace sign.

(Adapted from V. Agrawal)
